West Bend WBR33W User manual

1
Model / Modelo / Modelé:
WBR33W / WBR33B
COMPACT REFRIGERATOR
REFRIGERADOR COMPACTO
RÉFRIGÉATEUR COMPACTE
INSTRUCTION MANUAL
MANUAL DE INSTRUCCIONES
MANUEL D’INSTRUCTIONS
BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING
INSTRUCTIONS.
WestBend has a policy of continuous improvement on its products and
reserves the right to change materials and specifications without notice.
www.westbend.com

2
TABLE OF CONTENTS
REFRIGERATOR SAFETY
3
IMPORTANT SAFEGUIDES
4
HELP US HELP YOU
5
PARTS AND FEATURES
6
IMPORTANT SAFETY INSTRUCTIONS
7
INSTALLATION INSTRUCTIONS
7
Before Using Your Refrigerator
7
Installation of Your Refrigerator
7
Electrical Connection
8
Extension Cord
8
Surge Protector
8
Reversing The Door Swing Of Your Refrigerator
9
OPERATING YOUR REFRIGERATOR
9
Setting the Temperature Control
9
CARE AND MAINTENANCE
10
Cleaning Your Refrigerator
10
Power Failure
10
Vacation Time
10
Moving Your Appliance
10
Energy Saving Tips
10
TROUBLESHOOTING GUIDE
11
SERVICE FOR YOUR APPLIANCE
12
WIRING DIAGRAM
12
WESTBEND WARRANTY
13
INSTRUCCIONES EN ESPAÑOL
14 - 25
INSTRUCTIONS EN FRANÇAIS
26 - 37
WARRANTY REGISTRATION CARD
Last Page

3
APPLIANCE SAFETY
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance.
Always read and obey all safety messages.
This is the Safety Alert Symbol. This
symbol alerts you to potential hazards
that can kill or injure you and others.
All safety messages will follow the Safety
Alert Symbol and either the wards”
DANGER”, “WARNING” or “CAUTION”.
Danger means that failure to heed this
safety statement may result in severe
personal injury or death.
Warning means that failure to heed this
safety statement may result in extensive
product damage, serious personal injury,
or death.
Caution means that failure to heed this
safety statement may result in minor or
moderate personal injury, or property or
equipment damage.
All safety messages will alert you to what the potential hazard is, tell you how to reduce the
chance of injury, and let you know what can happen if the instructions are not followed.
FLAMMABLE REFRIGERANT GAS
DANGER - Risk of fire or explosion. Flammable refrigerant used.
DO NOT use mechanical devices to defrost refrigerator. DO NOT puncture refrigerant
tubing.
DANGER -Risk of fire or explosion. Flammable refrigerant used. To be repaired only by trained
service personnel. DO NOT puncture refrigerant tubing.
CAUTION - Risk of fire or explosion. Flammable refrigerant used. Consult repair manual / owner’s
guide before attempting to service this product. All safety precautions must be followed.
CAUTION - Risk of fire or explosion. Dispose of property in accordance with federal or local
regulations. Flammable refrigerant used.
CAUTION - Risk of fire or explosion due to puncture of refrigerant tubing. Follow handling
instructions carefully. Flammable refrigerant used.
CAUTION - To prevent a child from being entrapped, keep out of reach of children and not in the
vicinity of the cooler.

4
IMPORTANT SAFEGUARDS
Before the beverage cooler is used, it must be properly positioned and
installed as described in this manual, so read the manual carefully. To
reduce the risk of fire, electrical shock or injury when using the beverage
cooler, follow basic precautions, including the following:
•Plug into a grounded 3-prong outlet, do not remove grounding prong, do not use an adapter, and
do not use an extension cord
• Replace all panels before operating
• It is recommended that a separate circuit, serving only your beverage cooler, be provided. Use
receptacles that cannot be turned off by a switch or pull chain
• Never clean appliance parts with flammable fluids. These fumes can create a fire hazard or
explosion. And do not store or use gasoline or other flammable vapors and liquids in the vicinity
of this or any other appliance. The fumes can create a fire hazard or explosion.
• Before proceeding with cleaning and maintenance operations, make sure the power line of the
unit is disconnected.
• Do not connect or disconnect the electric plug when your hands are wet
• Unplug the appliance or disconnect the power before cleaning or servicing. Failure to do so can
result in electrical shock or death.
• Do not attempt to repair or replace any part of your appliance unless it is specifically
recommended in this material. All other servicing should be referred to a qualified technician.
• Use two or more people to move and install the appliance. Failure to do so can result in back or
other injury.
• To ensure proper ventilation for your appliance, the unit must be completely unobstructed.
Choose a well-ventilated area with temperatures above 550F (130C) and below 900F (32 0C). This
unit must be installed in an area protected from the elements, such as wind, rain, water spray or
sunlight.
• The appliance should not be located next to ovens, grills or other sources of high heat.
• The appliance must be installed with all electrical, water and drain connections in accordance with
state and local codes. A standard electrical supply (115 V AC only, 60 Hz), properly grounded in
accordance with the National Electrical Code and local codes and ordinances is required.
• Do not kink or pinch the power supply cord of the appliance.
• The fuse (or circuit breaker) size should be 15 amperes.
• It is important for the appliance to be leveled in order to work properly. You may need to make
several adjustments to level it.
• All installation must be in accordance with local plumbing code requirements.
• Make certain that the pipes are not pinched or kinked or damaged during installation.
• Check for leaks after connection.
• Never allow children to operate, play with or crawl inside the appliance
• Do not use solvent-based cleaning agents or abrasives on the interior. These cleaners may
damage or discolor the interior.
• Do not use this apparatus for other than its intended purpose.

5
HELP US HELP YOU...
Read this guide carefully.
It is intended to help you operate and
maintain your new appliance properly.
Keep it handy to answer your questions.
If you don't understand something or you
need more help, please call:
WestBend Customer Service
800-220-5570
Keep proof of original purchase date (such
as your sales slip) with this guide to
establish the warranty period.
Write down the model and serial numbers.
You'll find them on a plate located on the rear
outside wall of the appliance.
Please write these numbers here:
__________________________________
___
Date of Purchase
__________________________________
___
Model Number
__________________________________
___
Serial Number
Use these numbers in any correspondence or
service calls concerning your appliance.
If you received a damaged appliance, immediately
contact the dealer (or builder) that sold you the
appliance.
Save time and money. Before you call for service,
check the Troubleshooting Guide. It lists causes of
minor operating problems that you can correct
yourself.
IF YOU NEED SERVICE
We're proud of our service and want you
to be pleased. If for some reason you are
not happy with the service you receive,
here are some steps to follow for further
assistance.
FIRST, contact the people who serviced
your appliance. Explain why you are not
pleased. In most cases, this will solve the
problem.
NEXT, if you are still not pleased, write all the details,
including your telephone number, and send it to:
Customer Service
WestBend Products
www.westbend.com
CAUTION:
THIS APPLIANCE IS NOT
DESIGNED FOR THE STORAGE
OF MEDICINE OR OTHER
MEDICAL PRODUCTS.

6

7
PARTS AND FEATURES
1
Chiller compartment
7
Door bin
2
Temperature control
8
2-Little Bottle Door bin
3
Evaporator tray
9
Door bin
4
Glass shelf –Full size
10
Door bin
5
Glass Shelf –Half Size
11
Door bin
6
Top hinge
12
Leveling leg

8
IMPORTANT SAFETY INSTRUCTIONS
−Read all instructions before using the refrigerator.
−DANGER or WARNING: Risk of child entrapment. Child entrapment and suffocation are not problems
of the past. Junked or abandoned refrigerators are still dangerous . . . even if they will “just sit in the
garage a few days”.
−Before you throw away your old refrigerator: take off the doors. Leave the shelves in place so that
children may not easily climb inside.
−Never allow children to operate, play with, or crawl inside the refrigerator.
−Never clean refrigerator parts with flammable fluids. The fumes can create a fire hazard or explosion.
−Do not store or use gasoline or any other flammable vapors and liquids in the vicinity of this or any other
refrigerator. The fumes can create a fire hazard or explosion.
INSTALLATION INSTRUCTIONS
Before Using Your Refrigerator
•Remove the exterior and interior packing.
•Check to be sure you have all of the following parts:
o2 Glass Shelves
oInstruction Manual
•Before connecting the unit to the power source, let it stand upright for approximately 2 hours. This
will reduce the possibility of a malfunction in the cooling system from handling during
transportation.
•Clean the interior surface with lukewarm water using a soft cloth.
Installation of Your Refrigerator
•Place your refrigerator on a floor that is strong enough to support the refrigerator when it is fully
loaded. To level your refrigerator, adjust the legs at the front of the refrigerator.
•Allow 5 inches of space between the back and sides of the refrigerator, which allows the
proper air circulation to cool the compressor.
•Locate the refrigerator away from direct sunlight and sources of heat (stove, heater, radiator, etc.).
Direct sunlight may affect the acrylic coating and heat sources may increase electrical
consumption. Extreme cold ambient temperatures may also cause the refrigerator not to perform
properly.
•Avoid locating the refrigerator in moist areas. Too much moisture in the air will cause frost to form
quickly on the evaporator requiring more frequent defrosting of the refrigerator.
WARNING
To reduce the risk of fire, electrical shock, or
injury when using your refrigerator, follow these
basic precautions:
This Unit Is For Indoor Use Only
- SAVE THESE INSTRUCTIONS -

9
Electrical Connection
Warning
Improper use of the grounded plug can result in the risk of electrical shock. If the power
cord is damaged, have it replaced by an authorized WestBend service center.
This appliance should be properly grounded for your safety. The power cord of this
appliance is equipped with a three-prong plug which mates with standard three
prong wall outlets to minimize the possibility of electrical shock.
Do not under any circumstances cut or remove the third ground prong from the
power cord supplied.
This appliance requires a standard115Volts~/60Hz electricaloutlet with three-prong
ground.
The cord should be secured behind the appliance and not left exposed or dangling
to prevent accidental injury.
Never unplug the appliance by pulling the power cord. Always grip the plug firmly
and pull straight out from the receptacle.
Do not use an extension cord with this appliance. If the power cord is too short,have
a qualified electrician or service technician install an outlet near the appliance.
➢EXTENSION CORD
Because of potential safety hazards under certain conditions, it is strongly
recommended that you do not use an extension cord with this unit. However, if you
must use an extension cord it is absolutely necessary that it be a UL/CUL-Listed,
3-wire grounding type appliance extension cord having a grounding type plug and
outlet and that the electrical rating of the cord be 115 volts and at least 10
amperes.
➢SURGE PROTECTOR
Most electrical appliances use a series of electric control boards to operate. These
boards are very susceptible to power surges and could be damaged or destroyed.
If the appliance is going to be used in an area or if your city / country is prone to
power surges / outages; it is suggested that you use a power surge protector for all
electrical devices / appliances you use. The surge protector that you select must
have a surge block high enough to protect the appliance it is connected to. If you
have any questions regarding the type and size of surge protector needed contact
a licensed electrician in your area.
Damages due to power surges are not considered a manufacturer covered defect
and will void your product warranty.

10
Reversing The Door Swing Of Your Refrigerator
This refrigerator-freezer has the capability of the doors opening from either the left or right side. The
unit is delivered to you with the doors opening from the left side. Should you desire to reverse the
opening direction, please call service for reversal instructions.
OPERATING YOUR REFRIGERATOR
Setting the Temperature Control
Your unit has only one control for regulating the temperature in the compartment.
The temperature control is located on the upper right hand side of the
compartment.
The first time you turn the unit on, set the temperature control to “5”. The range of
the temperature control is from position "0” to “5”. After 24 to 48 hours, adjust the
temperature control to the setting that best suits your needs. The setting of “3”
should be appropriate for home or office use.
To turn the refrigerator off, turn the temperature control to ”0”.
NOTE:
−Turning the temperature control to “0” position stops the cooling cycle but does not shut off the
power to the unit.
−If the unit is unplugged, has lost power, or is turned off, you must wait 3 to 5 minutes before
restarting the unit. If you attempt to restart before this time delay, the unit will not start.

11
CARE AND MAINTENANCE
Cleaning The Refrigerator
•Turn the temperature control to "0", unplug the unit, and remove the food and baskets.
•Wash the inside with a warm water and baking soda solution. The solution should be about 2
tablespoons of baking soda to a quart of water.
•Wash the baskets with a mild detergent solution.
•The outside of the unit should be cleaned with mild detergent and warm water.
CAUTION: Failure to unplug the refrigerator could result in electrical shock or personal injury.
Power Failure
Most power failures are corrected within a few hours and should not affect the temperature of your
refrigerator-freezer if you minimize the number of times the door is opened. If the power is going to be
off for a longer period of time, you need to take the proper steps to protect your food.
Vacation Time
Short vacations: Leave the unit operating during vacations of less than three weeks.
Long vacations: If the refrigerator will not be used for several months, remove all food and unplug the
power cord. Clean and dry the interior thoroughly. To prevent odor and mold growth, leave the door
open slightly: blocking it open if necessary
Moving Your Refrigerator
•Remove all the food.
•Securely tape down all loose items inside your unit.
•Turn the leveling screws up to the base to avoid damage.
•Tape the doors shut.
•Be sure the unit stays in the upright position during transportation.
Energy Saving Tips
•The unit should be located in the coolest area of the room, away from heat producing refrigerators
or heating ducts, and out of direct sunlight.
•Let hot foods cool to room temperature before placing them in the unit. Overloading the unit forces
the compressor to run longer. Foods that freeze too slowly may lose quality, or spoil.
•Be sure to wrap foods properly, and wipe containers dry before placing them in the unit. This cuts
down on frost build-up inside the freezer.
•Organize and label food to reduce door openings and extended searches. Remove as many items
as needed at one time, and close the door as soon as possible.

12
TROUBLESHOOTING GUIDE
You can solve many common refrigerator-freezer problems easily, saving you the cost of a possible
service call. Try the suggestions below to see if you can solve the problem before calling for service.
PROBLEM
POSSIBLE CAUSE
Refrigerator does not operate.
Not plugged in.
The circuit breaker tripped or blown fuse.
Refrigerator does not cool.
The refrigerator temperature control is set at “0”
Compressor turns on and off
frequently.
Condenser coil at the back of the unit is dirty.
The room temperature is hotter than normal.
A large amount of food has been added to the refrigerator.
The door is open too often.
The door is not closed completely.
The temperature control is not set correctly.
The door gasket does not seal properly.
The refrigerator does not have the correct clearances. (5” to both
sides and back of unit)
Vibrations.
Check to assure that the refrigerator is level.
The refrigerator seems to
make too much noise.
The rattling noise may come from the flow of the refrigerant, which is
normal.
As each cycle ends, you may hear gurgling sounds caused by the
flow of refrigerant in your refrigerator.
Contraction and expansion of the inside walls may cause popping
and crackling noises.
The refrigerator is not level.
The door will not close
properly.
The refrigerator is not level.
The doors were reversed and not properly installed.
The gasket is dirty.
The shelves, bins, or baskets are out of position.

13
SERVICE FOR YOUR APPLIANCE
We are proud of our customer service organization and the network of professional service technicians
that provide service on your WestBend appliances. With the purchase of your WestBend appliance,
you can have the confidence that if you ever need additional information or assistance the WestBend
Customer Service team will be here for you. Just call us toll-free.
WESTBEND CUSTOMER SERVICES
Product Information
800-323 5029
Whatever your questions are about our products,
help is available.
Part Orders
800-220 5570
You may order parts and accessories that will be
delivered directly to your home.
You may order these items by personal check,
money order, Master Card, or Visa.
In-Home Repair Service
800-220 5570
An WestBend authorized service center will
provide expert repair service, scheduled at a time
that is convenient for you. Our trained servicers
know your appliance inside and out.
WIRING DIAGRAM
YOUR WESTBEND
Staple your sales receipt here. Proof of

14
WARRANTY
original purchase date is needed to
obtain service under warranty.
WHAT IS COVERED –LIMITED ONE-YEAR WARRANTY
WestBend warrants that the product is free from defects in materials and/or workmanship for a period of
twelve (12) months from the date of purchase by the original owner. The foregoing timeline begins to run
upon the date of purchase, and shall not be stalled, tolled, extended, or suspended for any reason whatsoever
unless described in detail in the warranty document. For one year from the date of purchase by the original
owner, WestBend will, at its option, repair or replace any part of the product which proves to be defective in
material or workmanship under normal use. WestBend will provide you with a reasonably similar product that
is either new or factory refurbished. During this period WestBend will provide all parts and labor necessary to
correct such defects free of charge, so long as the product has been installed and operated in accordance with
the written instructions in this manual. In rental or commercial use, the warranty period is 90 days. All
WestBend appliances of 4.2 cubic feet capacity or less must be brought/sent to the appliance service center
for repair.
LIMITED SECOND THROUGH FIFTH YEAR WARRANTY
For the second through the fifth year from the date of original purchase, WestBend will provide a replacement
compressor free of charge due to a failure. You are responsible for the service labor and freight charges. In
rental or commercial use, the limited compressor warranty is one year and nine months. Costs involved to
move the product to the service center and back to the user’s home, as maybe required, are the user’s
responsibility.
WARRANTY EXCLUSIONS / WHAT IS NOT COVERED:
The warranty coverage described herein excludes all defects or damage that are not the direct fault of
WestBend, including without limitation, one or more of the following:
•A failure to comply with any applicable state, local, city, or county electrical, plumbing and/or building codes,
regulations, or laws, including failure to install the product in strict conformity with local fire and building
codes and regulations.
•Any external, elemental and/or environmental forces and factors, including without limitation, rain, wind,
sand, floods, fires, mud slides, freezing temperatures, excessive moisture or extended exposure to humidity,
lightning, power surges, structural failures surrounding the appliance, and acts of God.
•Content losses of food or other content due to
spoilage.
•Incidental or consequential damages
•Parts and labor costs for the following will not be
considered as warranty:
•Evaporator doors, door springs, and/or frames.
•Inner door panels, door shelves, door rails,
and/or door supports.
•Light bulbs and/or plastic housing.
•Plastic cabinet liners.
•Punctured evaporator that voids the warranty on
the complete sealed system.
•Shipping and handling costs associated with the
replacement of the unit.
•Repairs performed by unauthorized servicers.
•Service calls that are related to external problems,
such as abuse, misuse, inadequate electrical
power, accidents, fire, floods, or any other acts of
God.
•Failure of the product if it is used for other than it
intended purpose.
•The warranty does not apply outside the
Continental USA.
•Surcharges including but not limited to, any after
hour, weekend, or holiday service calls, tolls, ferry
trip charges, or mileage expense for service calls
to remote areas.
In no event shall WestBend have any liability or responsibility whatsoever for damage to surrounding property,
including cabinetry, floors, ceilings, and other structures and/or objects around the product. Also excluded
from this warranty are scratches, nicks, minor dents, and other cosmetic damages on external surfaces and
exposed parts; Products on which the serial numbers have been altered, defaced or removed; service visits
for customer education, or visits where there is nothing wrong with the product; correction of installation
problems (you are solely responsible for any structure and setting for the product, including all electrical,
plumbing and/or other connecting facilities, for proper foundation/flooring, and for any alterations including
without limitation cabinetry, walls, floors, shelving etc., as well as the resetting of breakers or fuses.
OUT OF WARRANTY PRODUCT
WestBend is under no obligation, at law or otherwise, to provide you with any concessions, including repairs,
pro-rates, or product replacement, once this warranty has expired.
WARRANTY –REFRIGERATION - COMPRESSOR

15
TABLA DE CONTENIDO
SEGURIDAD DEL REFRIGERADOR
15
GUÍAS DE SEGURIDAD IMPORTANTES
16
AYÚDANOS A AYUDARTE
17
PARTES Y CARACTERÍSTICAS
18
INSTRUCCIONES DE SEGURIDAD IMPORTANTES
19
INSTRUCCIONES DE INSTALACIÓN
19
Antes de usar el refrigerador
19
Instalación del refrigerador
19
Conexión eléctrica
20
Cable de extensión
20
Protector contra variaciones de corriente eléctrica
20
Inversión de la oscilación de las puertas de su refrigerador
21
FUNCIONAMIENTO DEL APARATO
21
Como ajustar el control de temperatura
21
CUIDADO Y MANTENIMIENTO
21
Limpieza del refrigerador
21
Fallo de alimentación
22
Tiempo de vacaciones
22
Para mover su refrigerador
22
Consejos para ahorrar energía
22
GUÍA DE SOLUCIÓN DE PROBLEMAS
23
SERVICIO DEL REFRIGERADOR
24
ESQUEMA DE CABLEADO
24
GARANTÍA "WESTBEND"
25
ENGLISH INSTRUCTIONS
2 - 13
INSTRUCTIONS EN FRANÇAIS
26 –37
REGISTRO DE GARANTÍA
Ultima
Pagina

16
INSTRUCCIONES DE SEGURIDAD
Su seguridad y la seguridad de los demás son muy importantes.
Hemos incluido muchos mensajes importantes de seguridad en este manual y en su
electrodoméstico. Lea y obedezca siempre todos los mensajes de seguridad.
Éste es el símbolo de alerta de
seguridad. Este símbolo le avisa de
los peligros potenciales que pueden
matar o lesionar a usted y otros.
Toda la seguridad mensajes seguirá
a la Seguridad Símbolo de alerta y
cualquiera de los pabellones"
PELIGRO","ADVERTENCIA" o
"PRECAUCIÓN".
Peligro significa que el
incumplimiento de la medida de
seguridad podría causar lesiones
graves o la muerte.
Advertencia significa que si no se
respeta esta medida de seguridad
podría resultar en graves daños al
producto, lesiones personales graves
o la muerte.
Advertencia significa que si no se
respeta esta medida de seguridad
podría resultar en graves daños al
producto, lesiones personales graves
o la muerte.
Todo mensaje de seguridad le avisará a cuál es el peligro potencial, le dirán cómo
reducir el riesgo de lesiones, y le hará saber lo que puede suceder si no se siguen las
instrucciones.
GAS REFRIGERANTE INFLAMABLE
PELIGRO - Riesgos de incendio o explosión. Refrigerante inflamable usado.
NO use dispositivos mecánicos para descongelar el refrigerador. No pinche tubería refrigerante.
PELIGRO - Riesgos de incendio o explosión. Refrigerante inflamable usado. Para ser reparado sólo por
personal de servicio técnico cualificado. No pinche tubería refrigerante.
PRECAUCIÓN - Riesgo de incendio o explosión. Refrigerante inflamable usado. Consulte el manual de
reparación / manual del propietario antes de intentar reparar este producto. Todas las precauciones de
seguridad que se deben seguir.
PRECAUCIÓN - Riesgo de incendio o explosión. Deshágase de los bienes de acuerdo con las
regulaciones federales o locales. Refrigerante inflamable usado.
PRECAUCIÓN - Riesgo de incendio o explosión debido a la perforación de la tubería de refrigerante.
Siga las instrucciones de manejo cuidadosamente. Refrigerante inflamable usado.
PRECAUCIÓN - Para evitar que un niño está atrapado, mantener fuera del alcance de los niños y no en
las proximidades de la nevera.

17
MEDIDAS DE SEGURIDAD IMPORTANTES
Antes de enfriador de bebidas se utiliza, debe ser colocado
correctamente e instalado como descrito en este manual, así que lea
cuidadosamente el manual. Para reducir el riesgo de incendio,
descarga eléctrica o lesiones al utilizar el enfriador de bebidas, Siga
las precauciones básicas, incluyendo las siguientes
•Enchufe en unas 3 clavijas con conexión a tierra toma de corriente, hacer No retire de
puesta a tierra púa, hacer No utilice un adaptador, y no utilice un cable de extensión
• Reemplazar todos los paneles antes operativos
• Eso se recomienda usar un circuito separado, que sólo sirve a su enfriador de bebidas,
ser proporcionado. Use recipientes ese no poder ser desactivado por un interruptor o
cadena
• Nunca limpia electrodoméstico piezas con líquidos inflamables. Estos vapores pueden
crear un riesgo de incendio o explosión. Y no almacene ni use gasolina u otros vapores
y líquidos inflamables en la proximidad de este o cualquier otro electrodoméstico. Los
vapores pueden crear un riesgo de incendio o explosión.
• Antes de proceder con las operaciones de limpieza y mantenimiento, asegúrese de que
la línea de alimentación de la unidad se desconecta.
• hacer No conecte o desconecte el enchufe eléctrico con las manos mojadas
• Desenchufe el electrodoméstico o desconectar el alimentación antes de la limpieza o el
mantenimiento. El no hacerlo puede provocar una descarga eléctrica o la muerte.
• hacer No intente reparar o reemplazar cualquier parte de su electrodoméstico a menos
que se recomiende específicamente en este material. Cualquier otro servicio debe ser
realizado por un técnico cualificado.
• Se recomienda utilizar dos o más personas para mover e instalar el electrodoméstico. El
aparato es pesado y puede resultar en daños de la espalda u otras lesiones.
• Para garantizar una ventilación adecuada para su electrodoméstico, la unidad debe
estar completamente despejada. Elija un área bien ventilada con temperaturas
superiores a 55ºF (13ºC) y por debajo de 90ºF (32ºC). Esta unidad debe ser instalada
en un área protegida de los elementos, tales como el viento, la lluvia, rocío de agua o
luz de sol.
• El electrodoméstico no debe colocarse cerca de hornos, parrillas u otras fuentes de
calor.
• El electrodoméstico debe ser instalado con todas las conexiones eléctricas, de agua y
de desagüe según los códigos estatales y locales. Hace falta un suministro eléctrico
estándar (sólo 115 V CA, 60 Hz), debidamente conectada a tierra de acuerdo con el
Código Eléctrico Nacional y los códigos y ordenanzas locales.
• Hacer No doble ni apriete el cable de alimentación del electrodoméstico.
• Los fusible (o disyuntor) tamaño debe ser de 15 amperios.
• Eso Es importante que el electrodoméstico a nivelarse con el fin de funcionar
correctamente. Puede que tenga que hacer varios ajustes para nivelarla.
• Toda la instalación debe realizarse de acuerdo con los requerimientos locales de
plomería.
• Asegúrese de que los tubos no están aplastar ni dañado durante instalación.
• Compruebe si hay fugas después de la conexión.
• Nunca permita que los niños operen, jueguen o gatear el interior del electrodoméstico

18
• Hacer No utilice productos de limpieza a base de disolvente-abrasivos en el interior.
Estos limpiadores pueden dañar o decolorar el interior.
• No utilice este electrodoméstico para que no sea su finalidad.
Ayúdenos a ayudarte...
Lea detenidamente esta guía.
Se pretende que ayudan a utilizar y
mantener su nuevo electrodoméstico
correctamente.
Mantenga a la mano para responder a sus
preguntas.
Si no entiende algo o si necesita más
ayuda, por favor llame a:
WestBend Servicio al Cliente
800-220-5570
Mantenga prueba de la fecha original de
compra (como el recibo de venta) con esta
guía para establecer el período de
garantía.
Escribir se establece el modelo y número de
serie.
Los encontrará en una placa situada en la pared
exterior trasera del electrodoméstico.
Por favor, escriba estos números aquí:
__________________________________
___
Fecha de compra
__________________________________
___
Número de modelo
__________________________________
___
Número de serie
Utilice estos números en cualquier correspondencia
o llamadas de servicio con respecto a su
electrodoméstico.
Si ha recibido un electrodoméstico dañado,
póngase inmediatamente en contacto con el
distribuidor (o constructor) que le vendió el
electrodoméstico.
Ahorrar tiempo y dinero. Antes de llamar al servicio
técnico, consulte la Guía de solución de problemas.
En él se enumeran las causas de los problemas de
funcionamiento de menor importancia que se
pueden corregir a sí mismo.
Si necesita servicio
Estamos orgullosos de nuestro servicio y
queremos que usted esté satisfecho. Si
por alguna razón usted no está satisfecho
con el servicio que recibe, aquí hay
algunos pasos a seguir para obtener más
ayuda.
PRIMERA, póngase en contacto con las
personas que servicio de reparación del
electrodoméstico. Explicar por qué usted
A continuación, si usted todavía no está contento,
escribir todos los detalles, incluyendo su número de
teléfono, y enviarlo a:
Servicio al cliente
WestBend
www.westbend.com
PRECAUCIÓN:
ESTE ELECTRODOMÉSTICO NO
ESTÁ DISEÑADO PARA EL
ALMACENAMIENTO DE
MEDICINA U OTROS
PRODUCTOS MÉDICOS.

19
no está satisfecho. En la mayoría de los
casos, esto va a resolver el problema.

20
PARTES Y CARACTERÍSTICAS
1
COMPARTIMIENTO DE CONGELADO
TEMPORAL
7
BANDEJA
2
CONTROL DE TEMPERATURA
8
BANDEJA PARA BOTELLA DE 2 LITROS
3
SEPARADOR
9
BANDEJA
4
REPISA –STANDAR
10
BANDEJA
5
REPISA –MITAD
11
BANDEJA
6
BISAGRA SUPERIOR
12
PATA NIVELADORA
