WHD CT 100 User manual

INSTRUCTION MANUAL
TUNER WITH CD PLAYER
CT 100
CAUTION: TO REDUCE THE RISK OF ELECTRONIC SHO
CK, DO NOT REMOVE
COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
The l ghtn ng flash w th arrowhead symbol, w th n an equ lateral tr angle, s ntended
to alert the user to the presence of un nsulated "dangerous voltage" w th n the
product's enclosure that may be of suff c ent magn tude to const tute a r sk of
electr c shock to persons.
The exclamat on po nt w th n an equ lateral tr angle s ntended to alert the user to
the presence of mportant operat ng and ma ntenance (serv c ng) nstruct ons n the
l terature accompany ng the appl ance.
WARNING: TO PREVENT FIRE OR SHOCK
HAZARD, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE.

Outward Appearance
Face plate:
Rear plate:
SUPPLEMENTS:
AM Antenna Set x 1 FM Antenna W re x 1
AV W re x 2 AC Power Cord x 1
INSTALLATION:
1. Connect AV Cord to OUTPUT Term nal.
2. Connect AC Power Cord n between Socket and AC power resource n AC 220V.
3. If used TUNER funct on, please close the ANT. W re to your ma n un t n order to rece ve
clearly.
4. Connect to Ground

TEREO AM / FM RADIO PLAYER
OPERATION :
POWER ON / OFF
 Turn on the Master Power
 Press “ POWER ” to sw tch on Tuner Player
 Press “ POWER ” to sw tch off the power.
RADIO PLAYER
 Press " BAND ” to select FM or AM frequenc es.
 Press “UP“ or ”DN” s UP and DOWN of select ve channel, f press “UP” or ”DN” for
over 3 seconds then enter nto automat c scan search ng rad o funct on, after rece ved
the channel, t w ll stop automat cally and start to play.
 Select Rad o Channel Memory funct on,
The Rad o Memor es of 20 sets : FM x 10 / AM x 10
- F rst select to the channel wh ch wants to be memory then press “ MEMORY “,
- Press “ 1 “, and then press “ MEMORY “ as 1st memory pos t on,
- Repeat above step to store 1
st
~ 5
th
stat ons.
- For 6
th
to 10
th
memory, press “ MEMORY “ and then press ” +5 “ then press ” 1 ~5”,
then press “ MEMORY “ wh ch w ll be 6
th
~10
th
memory pos t on.
- To play memory channel, d rectly press 1~5 for 1
st
~ 5
th
stat on or press +5 then press
1~5 for 6
th
~ 10
th
stat on.
 Sleep ng Funct on
- When rad o s play ng, Press “ SLEEP “. LCD shows “SLEEP” on top of rad o
channel d splay. The max mum s set up t me s 90 m nutes, and reduce10
m nutes when press every t me.

- Sleep ng s cancelled unt l f nal press.
- Rad o w ll automat cally stop after set up sleep ng t me. LCD d splay w ll be
el m nated.
- To turn on the rad o, press “POWER” to turn on rad o.
- If want to cancel Sleep ng funct on dur ng rad o s play ng, press “ SLEEP “ to
cancel sleep ng funct on, LCD d splay “SLEEP” w ll be el m nated.
LEVEL VOLUME
 Turn ng “ VOLUME “ knob to adjust & control the des red volume.
RADIO TUNING RANGE
FM 87.5 MHz – 108 MHz / AM 522 KHz – 1611 KHz

Anti hock CD / U B / D Card Reader Player
 Offers USB and SD Card funct on of each repl cat on.
 Play format are MP3, WMA
 Accept the capac ty of 128MB to 16G USB or SDHC Card
IDENTIFICATIONS OF CONTROLS :
 POWER ON / OFF
1. Turn on the Master Power
2. Press “ POWER ” to sw tch on the CD Player. Press “ POWER ” to sw tch off the
power.
 MUTE : Mute funct on.
 RAN / ENTER : Random and conf rmat on key.
RAN: play n a random order. Press once the LCD d splay w ll show “SHUFFLE”, w ll
play n a random order.
ENTER: when operate the program funct on, the key w ll be conf rmat on funct on key.
Pls refer to PROG sect on for operat ng program funct on.
 Repeat : repeat ng play ng funct on.
1. To play the ord nary mus c of CD, USB SD Card.
- Press once LCD shows REPEAT 1 : Repeat current play ng song
- Press aga n, LCD shows REPEAT ALL : Repeat all songs
- Press the 3
rd
t me, cancel Repeat Play ng funct on. LCD d splay “REPEAT” w ll be
el m nated.
2. To play MP3 form of CD, USB, SD Card.
- Press once LCD shows REPEAT 1 : Repeat current play ng song
- Press aga n, LCD shows〝 REPEAT FOLDER 〞, w ll repeat whole folder
- Press 3
rd
t me, LCD shows〝 REPEAT ALL “,w ll repeat all songs
- Press 4
th
t mes, the last w ll cancel Repeat Play ng funct on. LCD d splay “REPEAT”

w ll be el m nated.
 PROG : To memor ze the self-set play ng
1. Normal mus c form of CD, USB, or SD Card :
- Press once, the LCD d splay shows “PROGRAM” then use SKIP comb nat ve
buttons to select the song and then press RAN / ENTER key to conf rm.
- Repeat above step to memory more songs.
- To play programmed songs, s mply press PLAY / PAUSE, LCD DISPLAY shows
“MEMORY” and then start to play programmed songs.
2. MP3 format of CD, USB, or SD Card :
- Press once, the LCD d splay shows “PROGRAM” then use “FOLDER” buttons
to select the folder and use SKIP buttons to select the song. Press RAN / ENTER
key to conf rm.
- Repeat above step to memory more songs
- To play programmed songs, s mply press PLAY / PAUSE, LCD DISPLAY shows
“MEMORY” and then start to play programmed songs.
3. To cancel program funct on, press . LCD d splay “PROGRAM” w ll be
el m nated
 CD / USB / SD : Press to select USB, SD or CD mode.
 STOP/ EJECT : Press to stop play ng and press to d sk ejected gradually.
1. Press once, t s completely stopp ng and show ng all track numbers on the LCD
d splay.
2. Press tw ce to eject the d sk and shows “EJECT” and gl mmer on the LCD d splay.
And then press aga n to nsert the d sk.
 PLAY / PAUSE : Press once pause to stop, press aga n star to play.
 REV : Short press to des red prev ous track number. Long press s revers ng fast.
 F.WD : Press to des red next track number. Long press s forward ng fast.
 FOLDER : Select forward to next f le.
 FOLDER : Select backward to last f le.
 VOLUME : Turn ng to adjust & control the des red volume.
 USB Connector : Accepts USB.
 SD Connector : Accepts SD Card.
 The Sources CD, USB and SD Card can Play back mp3, wav or CDA f les
LCD Displa :
 When play ng MP3 mode, the d splay panel shows MP3.
 When play ng CD mode, the d splay panel shows CD.
 When n play ng mode, t d splay , when paus ng, the panel shows .
 When repeatedly play ng the s ngle track, t shows REPEAT 1.
 When all songs at the folders are play ng repeatedly, t shows REPEAT ALL.
PROG

 When t appears REPEAT FOLDER, t refers to play ng the tracks repeatedly from a
spec f c folder.
 SHUFFLE : When Random playback.
 PROGRAM : When operate to program tracks.
 MEMORY : When playback memory tracks.
 ：Under the MP3 mode, t w ll appear the folder numbers.
 ：D splay the current play ng track.
 ：D splay the t me for the current play ng track.
MEMORY :
When play ng CD, USB, or SD Card mode, f turn off and then turn on the power or sw tch
to other mode then go back to the former play ng mode, th s mach ne w ll play automat cally
from the last status.
Note :
When inserts the disk into CD pl yer or t kes out the disk, it is necess ry to let
CD pl yer insert disk nd return utom tic lly. It is prohibited to push or t ke out
the disk by h nd before the disk completely return from CD pl yer, thus will c use
the m chine to be broken down nd un ble to oper te norm lly.
