Whirlpool GUI500XTKQ0 User manual

ol Gold ®
DISHWASHER
@ (S£
For questions about features, operation/performance,
parts accessories or service, call: 1-800-253-130t,
In Canada, call for assistance 1-800-481-5881, for installation
and service, call: 1-800-807-8777 or visit our website at...
www.whirlpool.com or www.whirlpool.com/canada
LAVE.VAISSELLE
Au Canada, pour assistance, composer le 1-800-481-5881, pour
installation ou service 1-800-807-8777 ou visiter notre site web h
www.whirlpool.com/canada
Table of contents/Table des matieres ......................................... 2
Model Series/ModUles des series GU1200, GU1500
8269373

TABLEOF CONTENTS TABLEDESMATIERES
DISHWASHER SAFETY .............................................................. 3
Before Using Your Dishwasher .................................................... 4
PARTS AND FEATURES ............................................................ 5
START-UP GUIDE ...................................................................... 6
Using Your New Dishwasher ....................................................... 6
DISHWASHER LOADING .......................................................... 7
Loading Suggestions ................................................................... 7
Loading the Top Rack .................................................................. 7
Loading the Bottom Rack ............................................................ 8
Loading the Silverware Basket .................................................. 10
DISHWASHER USE ................................................................. 10
Detergent Dispenser .................................................................. 10
Rinse Aid Dispenser ................................................................... 11
Dishwasher Efficiency Tips ........................................................ 12
Cycle Selection Chart ................................................................ 12
Canceling a Cycle ...................................................................... 13
Changing a Cycle or Setting ...................................................... 13
Adding Items During a Cycle ..................................................... 14
Option Selections ....................................................................... 14
Cycle Status Indicators .............................................................. 15
Active Vent ................................................................................. 15
Drying System ............................................................................ 15
Overfill Protection Float .............................................................. 16
WASHING SPECIAL ITEMS ..................................................... 16
DISHWASHER CARE ................................................................ 17
Cleaning Your Dishwasher ......................................................... 17
Drain Air Gap .............................................................................. 17
Storing Your Dishwasher ........................................................... 17
TROUBLESHOOTING ............................................................... 17
WASH MODULE ....................................................................... 19
ASSISTANCE OR SERVICE ..................................................... 20
In the U.S.A ................................................................................ 20
In Canada ................................................................................... 20
WARRANTY .............................................................................. 21
LA SECURITE DU LAVE-VAISSELLE ...................................... 23
Avant d'utiliser le lave-vaisselle ................................................. 24
PIF:CES ET CARACTI_RISTIQUES ........................................... 25
GUIDE DE MISE EN MARCHE ................................................. 26
Utilisation de votre nouveau lave-vaisselle ................................ 26
CHARGEMENT DU LAVE-VAISSELLE .................................... 27
Suggestions de chargement ...................................................... 27
Chargement du panier superieur ............................................... 27
Chargement du panier inferieur................................................. 28
Chargement du panier h couverts ............................................. 29
UTILISATION DU LAVE-VAISSELLE ....................................... 30
Distributeur de detergent ........................................................... 30
Distributeur d'agent de ringage .................................................. 32
Conseils d'efficacite pour le lave-vaisselle ................................ 32
Tableau de selection de programme ......................................... 33
Annulation d'un programme ...................................................... 34
Changement d'un programme ou reglage ................................ 34
Addition de vaisselle durant un programme .............................. 34
Selection d'options ..................................................................... 35
Indicateurs d'etat d'avancement du programme ...................... 36
12ventactif ................................................................................... 37
Systeme de sechage .................................................................. 37
Dispositif de protection contre le debordement ........................ 37
LAVAGE D'ARTICLES SPl_ClhUX ........................................... 37
ENTRETIEN DU LAVE-VAISSELLE .......................................... 38
Nettoyage du lave-vaisselle ....................................................... 38
Dispositif anti-refoulement ......................................................... 39
Remisage du lave-vaisselle........................................................ 39
DEPAN NAGE............................................................................. 39
MODULE DU LAVAGE .............................................................. 41
ASSISTANCE OU SERVICE ...................................................... 42
Aux €:tats-Unis ............................................................................ 42
Au Canada .................................................................................. 42
GARANTIE ................................................................................ 43
2

DISHWASHERSAFETY
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all
safety messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word "DANGER" or
"WARNING." These words mean:
You can be killed or seriously injured if you don't
immediately follow instructions.
You can be killed or seriously injured if you don't
follow instructions.
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you
what can happen if the instructions are not followed.
IMPORTANT SAFETY INSTRUCTIONS
WARNING: When using the dishwasher, follow basic precautions, including the following:
• Read all instructions before using the dishwasher.
• Use the dishwasher only for its intended function.
• Use only detergents or rinse agents recommended
for use in a dishwasher, and keep them out of the
reach of children.
• When loading items to be washed:
1) Locate sharp items so that they are not likely to
damage the door seal; and
2) Load sharp knives with the handles up to reduce
the risk of cut-type injuries.
• Do not wash plastic items unless they are marked
"dishwasher safe" or the equivalent. For plastic
items not so marked, check the manufacturer's
recommendations.
Do not touch the heating element during or
immediately after use.
• Do not operate the dishwasher unless all enclosure
panels are properly in place.
• Do not tamper with controls.
• Do not abuse, sit on, or stand on the door or dish
racks of the dishwasher.
• To reduce the risk of injury, do not allow children to
play in or on the dishwasher.
• Under certain conditions, hydrogen gas may be
produced in a hot water system that has not been
used for two weeks or more. HYDROGEN GAS IS
EXPLOSIVE. If the hot water system has not been
used for such a period, before using the dishwasher
turn on all hot water faucets and let the water flow
from each for several minutes. This will release any
accumulated hydrogen gas. As the gas is flammable,
do not smoke or use an open flame during this time.
• Remove the door to the washing compartment when
removing an old dishwasher from service or
discarding it.
SAVE THESE INSTRUCTIONS

Tip Over Hazard
Do not use dishwasher until completely installed.
Do not push down on open door.
Doing so can result in serious injury or cuts.
Electrical Shock Hazard
Electrically ground dishwasher.
Connect ground wire to green ground connector
in terminal box.
Do not use an extension cord.
Failure to follow these instructions can result in
death, fire, or electrical shock.
• Install where dishwasher is protected from the elements.
Protect against freezing to avoid possible rupture of fill valve.
Such ruptures are not covered by the warranty. See "Storing
Your Dishwasher" in the "Dishwasher Care" section for winter
storage information.
• Install and level dishwasher on a floor that will hold the
weight, and in an area suitable for its size and use.
• Remove all shipping plugs from hoses and connectors (such
as the cap on the drain outlet) before installing. See
Installation Instructions for complete information.
GROUNDING INSTRUCTIONS
For a grounded, cord-connected dishwasher:
The dishwasher must be grounded. In the event
of a malfunction or breakdown, grounding will
reduce the risk of electric shock by providing a
path of least resistance for electric current. The
dishwasher is equipped with a cord having an
equipment-grounding conductor and a grounding
plug. The plug must be plugged into an appro-
priate outlet that is installed and grounded in
accordance with all local codes and ordinances.
WARNING: Improper connection of the
equipment-grounding conductor can result in a
risk of electric shock. Check with a qualified
electrician or service representative if you are in
doubt whether the dishwasher is properly
grounded. Do not modify the plug provided with
the dishwasher; if it will not fit the outlet, have a
proper outlet installed by a qualified electrician.
For a permanently connected dishwasher:
The dishwasher must be connected to a
grounded metal, permanent wiring system, or an
equipment-grounding conductor must be run
with the circuit conductors and connected to the
equipment-grounding terminal or lead on the
dishwasher.
SAVE THESE INSTRUCTIONS
4

PARTS ANDFF_ TURES
1
2
4
5
6
7
Iiiiii!_iiiiiiilIIHill
I
II
I
llll_J I
I
11
12
13
14
15
16
II I 17
II,I 18
10
1. Upper level wash 7. Heating element 14. Utensil rack
2. 2-position adjuster 8. Silverware basket 15. Model and serial number label
[on some models] 9. Detergent dispenser 16. Lower spray arm
3. Top rack 10. Active vent 17. Filter module
4. Bottom rack 11. Flexible tines [on some models] 18. Overfill protection float
5. FLIP AWAYTM plate holders 12. Cup shelves 19. Rinse aid dispenser
6. Water inlet opening [in tub wall] 13. Top spray arm

GU1200
2 4 8
Delay Hours
_®•••• o • •
J
_-_ J Sensing/ W_ter Washing R_ns_ng D_ng Clean San_ized Refill
SENSINGWASHCYCLES OPTIONS So_k_,_H_t,,g R,,,eAi_
© ©
Rinse Only Quick Wash China C_ystal Normal Pots &Pans Soak &Hi-Temp Sani- Air Dry
Scour Scour Rinse
Cancel
Dra_n
GU1500
Delay Hours
_ o • • •
sensing/ Water Olean Sanitized R_II
JSoaking Heating R_nseA_d
SENSING WASH CYCLES OPTIONS
RinseOnly Gu_ckWash Ch_naCrysfal Normal Pots&Pans Anti-Bacterial Soak & Ht-Temp Sani=
Scour Scour Rinse Air Dry
Cancel
Drain
START.UPGUIDE
Before using your dishwasher, remove all packaging materials.
Read this entire Use and Care Guide. You will find important
safety information and useful operating tips.
1,
2.
Scrape large food soil and hard items (toothpicks or bones)
from dishes.
Properly load the dishwasher. (See "Dishwasher Loading.")
Make sure nothing prevents the spray arm(s) from spinning
freely.
5. Press the desired cycle and option selections. The
dishwasher starts filling when you press a cycle. You can
select options as the machine fills. (See "Dishwasher Use.")
IM PORTANT:
When the cycle starts, you will see a rotating pattern of lights
in the display window indicating that the unit is operating.
3,
4,
Add detergent and check the rinse aid dispenser. Add rinse
aid if needed. (See "Dishwasher Use.")
Push door firmly closed. The door latches automatically. Run
hot water at the sink nearest your dishwasher until the water
is hot. (See "Dishwasher Efficiency Tips.") Turn off water.
This pattern will continue for up to 6 minutes while the
multiple sensors check the incoming water temperature, rinse
aid usage and soil level on dishes and cookware. The sensors
then determine the ideal cycle for your dish load. After
sensing is complete, the display will show the number of
minutes left in the cycle and the cycle countdown will begin.
The cycle countdown pauses and the water heating light
glows while the dishwasher heats the water to a set
temperature. (See "Cycle Selection Chart.")
6

DISHWASHERLOADING
• Remove leftover food, bones, toothpicks and other hard
items from the dishes. It is not necessary to rinse the dishes
before putting them into the dishwasher. The wash module
removes food particles from the water. The module contains a
chopping device which will reduce the size of food items.
NOTE: If hard items such as fruit seeds, nuts, and egg shells
enter the wash module, you might hear chopping, grinding,
crunching, or buzzing sounds. These sounds are normal
when hard items enter the module. Do not let metallic items
(such as pot handle screws) get into the wash module.
Damage can occur.
• It is important for the water spray to reach all soiled surfaces.
• Load dishes so they are not stacked or overlapping if
possible. For best drying, water must be able to drain from all
surfaces.
• Make sure pot lids and handles, pizza pans, cookie sheets,
etc., do not interfere with the spray arm rotation.
• Run a rinse cycle to keep dishes moist if you do not plan to
wash them soon. Foods like eggs, rice, pasta, spinach, and
cooked cereals may be hard to remove if they are left to dry
over a period of time.
Quiet operating tips
To avoid thumping/clattering noises during operation:
• Make sure lightweight load items are secured in the racks.
• Make sure pot lids and handles, pizza pans, cookie sheets,
etc., do not touch interior walls or interfere with the rotation of
the spray arm.
• Load dishes so they do not touch one another.
NOTE: For built-in models, keep sink drain plugs closed during
dishwasher operation to prevent noise transfer through drains.
The top rack is designed for cups, glasses, and smaller items.
Many items, up to 9 in (22 cm), fit in the top rack. (See
recommended loading patterns shown.)
NOTE: The features on your dishwasher rack may vary from the
drawings shown.
10place setting
12place setting
• Place items so open ends face down for cleaning and
draining.
• Load glasses in top rack only. The bottom rack is not
designed for glasses. Damage can occur.
• Place cups and glasses in the rows between tines. Placing
them over the tines can lead to breakage and water spots.
• China, crystal, and other delicate items must not touch each
other during dishwasher operation. Damage may occur.
• Load lightweight plastic items in the top rack only. Only
plastic items marked "dishwasher safe" are recommended.
• Load plastic items so the force of the spray does not move
them during the cycle.
• To avoid chipping, do not let stemware touch other items.
• Small bowls, pans, and other utensils can be placed in the
top rack. Load bowls in the center section for best stability.

Cupshelves
Fold down the extra shelf on the left or right side of the top rack
to hold additional cups, stemware or long items such as utensils
and spatulas. The bottom rack is designed for plates, pans, casseroles, and
utensils. Many items, up to 13 in (33 cm) tall, fit in the bottom
rack. (See recommended loading patterns shown.)
NOTE: The features on your dishwasher rack may vary from the
drawings shown.
Flexible tines (on some models)
The row of tines on the left and right sides of the top rack can be
adjusted to make room for a variety of dishes. 10place setting
To adjust the Flexible tines
1. Grasp the tip of the tine that is in the tine holder.
2. Gently push the tine out of the holder.
3. Lay the tines down, toward the center of the rack.
Adjustable 2-position top rack (on some models)
You can raise or lower the top rack to fit tall items in either the top
or bottom rack. Raise the top rack to accommodate items up to
9 in (23 cm) in the top rack and 13 in (33 cm) in the bottom rack,
or lower the top rack to accommodate items up to 11 in (28 cm)
in both the top and bottom racks. Adjusters are located on each
side of the top rack.
12place setting
• Do not load glasses, cups, or plastic items in the bottom
rack. Load small items in the bottom rack only if they are
secured in place.
• Load plates, soup bowls, etc., between tines.
• Overlap the edges of plates for large loads.
• Load soup, cereal, and serving bowls in the rack in a variety
of ways depending upon their size and shape. Load bowls
securely between the rows of tines. Do not nest bowls
because the spray will not reach all surfaces.
To raise the top rack
Lift the rack on either, or both, sides until the rack is level.
NOTE: The top rack adjusters MUST be level.
To lower the top rack
Press both rack adjusters and slide the rack back to its
original position.
Utensil load
8

• Load cookie sheets, cake pans, and other large items at the
sides and back. Loading such items in front can keep the
water spray from reaching the detergent dispenser.
Utensil rack
Use the Utensil rack to hold specialty cooking items (wooden
spoons, spatulas, and similar items).
Mixed load
• Secure heavily soiled cookware face down in the rack.
• Make sure pot handles and other items do not stop rotation
of the spray arm(s). The spray arm(s) must move freely.
• Do not load items between the bottom rack and the side of
the dishwasher tub because they might block the water inlet
opening.
FLIP AWAY TM plate holders
You can fold up all, or part, of the row of V-shaped flexible tines at
the back of the bottom rack. This is useful when washing a
variety of dishes, pots and pans, or roasters.
The Utensil rack lies on the two supports in the right lower rack.
Load the rack tray while it is in the dishwasher or remove it for
loading on a counter or table top.
When not in use, the utensil rack may be left in the dishwasher
and tilted out of the way.
!....
You can also remove the utensil rack from the dishwasher. Swing
the two supports out of the way for easier bottom rack loading.
Place the entire row of tines in the down position
when washing a large number of plates.
Fold away the entire row of both plate and bowl
tines to make room for larger pans or roasters.

Load the silverware basket while it is in the dishwasher or take
the basket out for loading on a counter or table.
NOTE: Unload or remove the basket before unloading the racks
to avoid spilling water droplets on the silverware.
Toopen the silverware basket
Unlock the latch.
NOTE: Be sure the cover is completely latched before pulling out
the bottom rack and before closing the dishwasher door.
• Place small items like baby bottle caps, jar lids, corncob
holders, etc., in the section(s) with hinged cover(s). Close the
cover to hold small items in place.
Mix items in each section of the basket with some pointing up
and some down to avoid nesting. Spray cannot reach nested
items.
IMPORTANT: Always load sharp items (knives, skewers, etc.)
pointing down.
The silverware basket can be hung on the door or on the
bottom rack (see illustration).
• The silverware basket can also be placed inside the bottom
rack.
To remove the basket from the door
1. Grasp the silverware basket by the handle. Slide it toward the
top of the door.
2. Lift the basket off the holding buttons.
To replace the basket in the door
1. Set the silverware basket on the holding buttons.
2. Slide the basket toward the bottom of the door until it locks in
place.
NOTES:
• Do not load silver or silver-plated silverware with stainless
steel. These metals can be damaged by contact with each
other during washing.
• Some foods (such as salt, vinegar, milk products, fruit juices,
etc.) can pit or corrode silverware. Run a rinse cycle if you do
not have a full load to wash immediately.
DISHWASHERUSE
The detergent dispenser has 2 sections. The smaller Pre-Wash
section empties detergent into the dishwasher when you close
the door. ..............
1. Cover latch
2. Main wash section
3. Pre-wash section
4. Cover
The larger Main Wash section automatically empties detergent
into the dishwasher during the wash. (See the "Cycle Selection
Chart.")
• Use automatic dishwashing detergent only. Other detergents
can produce excessive suds that can overflow out of the
dishwasher and reduce washing performance.
• Add detergent just before starting cycle.
• Store tightly closed detergent in a cool, dry place. Fresh
automatic dishwasher detergent results in better cleaning.
NOTE: Do not use detergent with a rinse cycle.
10
