DR %R SAFETY
Your safety and the safety of others are very important,
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word "DANGER" or "WARNING."
These words mean:
You can be killed or seriously injured if you don't immediately
follow instructions.
You can be killed or seriously injured if you don'tfollow
instructions.
All safety messages will tell you what the potentiN hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
WARN |NG - ...i.kof
- Clothes dryer installation must be performed by a qualified installer.
-Install the clothes dryer according to the manufacturer's instructions and local codes.
-Do not install aclothes dryer with flexible plastic venting materials or flexible metal
(foil type) duct. if flexible metal duct is installed, it must be of a specific type identified
by the appliance manufacturer as suitable for use with clothes dryers. Flexible venting
materials are known to collapse, be easily crushed, and trap lint. These conditions will
obstruct clothes dryer airflow and increase the risk of fire,
- To reduce the risk of severe injury or death, follow all installation instructions.
-Save these instructions.
State of CNifornia Proposition 65 Warnings:
WARNING: This product contains one or more chemicals known to the State of California to cause cancer.
WARNING: This product contains one or more chemicals known to the State of California to cause birth defects or other
reproductive harm.
In the State of Massachusetts, the following installation instructions apply:
m=Installations and repairs must be performed by a qualified or licensed contractor, plumber, or gasfitter qualified or licensed by
the State of Massachusetts.
m=If using a ball vNve, it shall be a T-handle type.
m A flexible gas connector, when used, must not exceed 3 feet.
2

WARNING: For your safety, the information in this manual must be followed to minimize 1
the risk of fire or explosion, or to prevent property damage, personal injury, or death. 1
- Do not store or use gasoline or other flarnmable vapors and liquids in the vicinity of this
or any other appliance.
- WHAT TO DO iF YOU SMELL GAS:
•Do not try to light any appliance.
®Do not touch any electrical switch; do not use any phone in your building.
® Clear the room, building, or area of all occupants.
®Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's
instructions.
• if you cannot reach your gas supplier, call the fire department.
- Installation and service must be performed by a qualified installer, service agency, or
the gas supplier.
WARNING: Gas leaks cannot always be detected by smell.
Gas suppliers recommend that you use a gas detector approved by UL or CSA.
For more information, contact your gas supplier.
If a gas leak is detected, follow the "What to do if you smell gas" instructions.
IMPORTANT: The gas installation must conform with local codes, or in the absence of local codes, with the National Fuel Gas
Code, ANSI Z223.1/NFPA 54.
The dryer must be electrically grounded in accordance with local codes, or in the absence of local codes, with the National
Electrical Code, ANSI/NFPA 70.
iMPORTANT SAFETY iNSTRUCTiONS
WARNING: To reduce the risk of fire, electric shock, or injuryto persons when using the dryer, follow basic precautions,
including the following:
[] Read all instructions before using the dryer.
[] Do not place items exposed to cooking oils in your dryer.
Items contaminated with cooking oils may contribute to
a chemical reaction that could cause a load to catch fire.
[] Do not dry articles that have been previously cleaned in,
washed in, soaked in, or spotted with gasoline, dry=
cleaning solvents, or other flammable or explosive
substances as they give off vapors that could ignite or
explode.
[] Do not allow children to play on or in the dryer. Close
supervision of children is necessary when the dryer is
used near children.
[] Before the dryer is removed from service or discarded,
remove the door to the drying compartment.
[] Do not reach into the dryer if the drum is moving.
[] Do not install or store the dryer where it will be exposed
to the weather.
[] Do not tamper with controls.
[] Do not repair or replace any part of the dryer or attempt
any servicing unless specifically recommended in this
Use and Care Guide or in published user=repair
instructions that you understand and have the skills to
carry out.
[] Do not use fabric softeners or products to eliminate static
unless recommended by the manufacturer of the fabric
softener or product.
[] Do not use heat to dry articles containing foam rubber or
similarly textured rubber=like materials.
[] Clean lint screen before or after each load.
[] Keep area around the exhaust opening and adjacent
surrounding areas free from the accumulation of lint, dust,
and dirt.
[] The interior of the dryer and exhaust vent should be
cleaned periodically by qualified service personnel.
[] See "Electrical Requirements" located in the installation
instructions for grounding instructions.
SAVE THESE INSTRUCTIONS

CHECK YOUR SYSTB FOR GOOD AIR FLOW
Fire Hazard
Use a heavy metal vent.
Do not use aplastic vent.
Do not use a metal foil vent,
Failure to follow these instructions can result in death
or fire.
Good air flow
Along with heat, dryers require good air flow to efficiently
dry laundry. Proper venting will reduce your drying times
and improve your energy savings. See "Installation
Instructions".
The venting system attached to the dryer plays a big role
in good air flow.
Service calls caused by improper venting are not covered
by the warranty and will be paid by the customer, regardless
of who installed the dryer.
Maintain good air flow by:
[] Cleaning your lint screen before each load.
[] Replace plastic or foil vent material
with 4" (102 mm) diameter heavy, rigid
vent material.
[] Use the shortest length of vent possible.
[] Use no more than four 90° elbows in a vent system;
each bend and curve reduces air flow.
[]
[]
[]
Remove lint and debris from the exhaust hood.
Remove lint from the entire length of the vent system
at least every 2 years. When cleaning is complete, be
sure to follow the "Installation Instructions" supplied
with your dryer for final product check.
Clear away items from in front of the dryer.
Use Eco Cycles for better fabric care and energy savings
Use the Eco Cycles to provide the most energy savings and enhanced fabric care from the dryer. During Eco Cycles, drying air
temperature and moisture level are sensed in the load. This sensing occurs throughout the drying cycle and the dryer shuts off
when the load reaches the selected dryness. Use the NORMAL dryness level to provide optimal energy savings.
With Timed Dry Cycles, the dryer runs the amount of time set and sometimes results in shrinkage, wrinkling, and static due to
over=drying. Use Timed Dry Cycles for the occasional damp load that needs a little more drying time or when using the drying
rack.
Tips for getting the best performance from your steam dryer
[] Results may vary depending on fabric. 100% cotton []
garments with wrinkle-free finish may yield better results
than those without. 100% cotton items may require
additional touching up after the Steam Cycle.
Use of fabric softener sheet is not recommended with
Steam Cycles. It may cause temporary staining on clothes. []
It is not recommended to use Steam Cycles for items that
have been starched. Wash any starched or new garments
prior to using a Steam Cycle.
[]
[]
The Enhanced Touch Up cycle is best for reducing odors
and light wrinkles in small to medium-sized loads of dry
garments. For the Enhanced Touch Up cycle, dry time
automatically adjusts as load size is sensed. Cycle run
time cannot be manually adjusted.
The Quick Refresh (on some models) cycle is best for
reducing wrinkles and odors in dry garments, including
loads left in the dryer. For, Quick Refresh time is selectable
in five minute increments based on the load to be refreshed.
4

CONTROL EL NND FEATURES T
