Whirlpool WGD5800SG0 User manual

TOP AND CONSOLE PARTS
1
For Models: WGD5800SW0, WGD5800SG0
(White/Grey) (Biscuit/Gold)
1−07 Litho in U.S.A.(LT) Part No. 8181290
29"GAS DRYER

TOP AND CONSOLE PARTS
2
For Models: WGD5800SW0, WGD5800SG0
(White/Grey) (Biscuit/Gold)
8181290
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Literature Parts
8562582 Instructions,
Installation
W10042950 Sheet,
Cycle Feature
8578183 Use & Care Guide
8576803 Wiring Diagram
Following May Be Purchased
DO−IT−YOURSELF
REPAIR MANUALS
677818 Dryer
2 3401695 Wire, Jumper
(Buzzer On/Off)
3 694419 Buzzer, Mini
4 Cap, End (L.H.)
8566035 White
8566036 Biscuit
5 717252 Plug, 2−Way
Terminal
6 8274261 Panel, Rear
Console
7 3405155 Switch,
Temperature
8 Cap, End (R.H.)
8566032 White
8566033 Biscuit
9 693995 Screw, Hex
Washer Head
10 Screen, Lint
8557857 White
8557858 Biscuit
11 8536939 Clip, Spring
12 8533971 Screw, 8−18 x 5/16
13 688983 Screw, 8−18 x 5/8
14 8312709 Clip−Console
15 3395683 Connector
(Motor)
16 Top
8559800 White
8563660 Biscuit
17 359625 Screw, 8−18 x 1/2
18 Knob, Control (3)
W10034380 Grey
W10034390 Biscuit
19 3394427 Clip−Harness
21 3406725 Timer Assembly
(60 Hz.)
22 8558178 Control,
Electronic
23 3391885 Connector, Edge
24 3397269 Connector−Timer
25 3401144 Connector,
(PTS Relay)
26 3403499 Connector,
2−Position
(Gas Valve)
27 3403498 Connector,
3−Position
(Gas Valve)
28 3405152 Switch,
End Of Cycle
31 8299891 Harness, Wiring
32 Knob,
Push−To−Start
W10034770 Grey
W10034780 Biscuit
33 3347243 Connector
6−Circuit
34 3405154 Switch,
Wrinkle Shield
37 3398094 Switch,
Push−To−Start
38 Timer Knob
Assembly
W10034750 Grey
W10034760 Biscuit
39 94614 Terminal, Female
40 8566052 Bracket, Control
41 Panel, Control
(Includes
Illus. 35)
8578860 Grey
8578861 Gold
42 3936144 Connector
43 8533951 Screw, Grounding

CABINET PARTS
3
For Models: WGD5800SW0, WGD5800SG0
(White/Grey) (Biscuit/Gold)
8181290

CABINET PARTS
4
For Models: WGD5800SW0, WGD5800SG0
(White/Grey) (Biscuit/Gold)
8181290
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 697776 Screw, 10−32 x 5/8
(External Ground)
2 343641 Screw, 10−16 x 1/2
3 693995 Screw, Hex Head
4 8541400 Bracket, Cabinet
5 3396795 Cover, Block
6 3404162 Clamp, Motor
(W/Shield)
7 3396805 Panel, Rear
8 8546676 Clip,
Door Spring
9 3980175 Clamp−Elbow
10 3406107 Door Switch
Assembly
11 697773 Screw, 6−20 x 7/8
13 3357011 Screw, 10−16 x 1/2
14 8541401 Spring, Door (2)
16 3392100 Foot, Dryer
279810 Foot−Optional
(Extended Length)
(Package of 2)
(Not Included.)
17 342043 Screw, 10−32 x 3/8
18 Cabinet
(Includes
Illus. 4)
8530603 White
8530606 Biscuit
19 98234 Clip, Ground (2)
20 690363 Lock, Front Top (2)
21 Panel Front
3395197 White
3977243 Biscuit
23 685203 Clip, Felt Pad (2)
24 3389441 Catch, Door
Assembly
25 3390731 Seal, Door
26 337189 Clip, Hinge (2)
27 694091 Screw, 8−18 x 3/8
28 8066056 Hinge, R.H.
8066057 Hinge, L.H.
33 696144 Strike, Panel
35 695737 Door, Rear
36 Door, Front
3393549 White
3977241 Biscuit
37 Handle, Door
W10095180 White
W10095190 Biscuit
38 3406129 Seal & Bearing
Assembly
39 Plug, Front Panel
3394975 White
3394978 Biscuit
45 344020 Cord, Power
46 3394083 Clip, Front Panel
47 8066217 Hinge, Top (2)
48 691366 Idler & Pulley
Assembly
49 8066065 Belt, Drive
50 348780 Base, Motor
51 3400500 Bolt, 5/16−18 x 3/4
52 8066184 Pulley, 60 Hz.
53 8066206 Motor Assembly
60 Hz.
54 660658 Clamp, Motor
55 8318272 Burner Assembly,
60 Hz.
(See Pages 7 &
8 For Further
Burner Breakdown)
56 341029 Clamp, Pipe

BULKHEAD PARTS
5
For Models: WGD5800SW0, WGD5800SG0
(White/Grey) (Biscuit/Gold)
8181290

BULKHEAD PARTS
6
For Models: WGD5800SW0, WGD5800SG0
(White/Grey) (Biscuit/Gold)
8181290
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 348368 Lint Chute
Assembly
2 489463 Screw, 8−18 x 5/8
3 3388703 Washer−Support
4 347139 Seal, Lint
Chute
5 90767 Screw, 8−18 x 3/8
6 487909 Screw, 8−15 x 1/2
7 3392519 Fuse, Thermal
8 8066086 Drum Hole
Plug
9 8318268 Thermostat,
Internal−Bias
10 694089 Wheel, Blower
11 8577230 Housing, Blower
12 3398161 Clip
13 343641 Screw, 10−16 x 1/2
14 8530285 Box, Heater
15 3403140 Thermostat, 205 F
(96 C)
18 8066049 Funnel, Burner
19 3403634 Socket Assembly
20 3406124 Bulb
22 3977373 Bracket, Drum
Light
23 3406022 Bracket, Bulkhead
24 3390647 Screw, 8−18 x 1/2
25 280010 Kit,
Thermal Cut−Off
(Includes
Illus. 15)
26 3401707 Wire, Jumper
30 3976479 Pad, Sensor
41 690997 Ring, Tri
42 3399506 Shaft, L.H.
43 3399507 Shaft, R.H.
44 3397590 Roller, Support
46 348197 Washer, Support
47 3359452 Nut, 3/8−16
48 3403414 Bulkhead
49 338906 Sensor, Radiant
53 3402841 Lens, Drum Light
54 692526 Ring, Bearing
55 97787 Screw, 11−16 x 3/4
56 3406130 Seal, Rear Drum
57 695587 Drum Assembly
58 692490 Baffle, Drum (2)
59 3976434 Bracket, Support
60 90296 Clip
61 3403636 Baffle, Drum (1)
62 339956 Seal
63 696302 Shield, Exhaust

BA−150
8318272 BURNER ASSEMBLY
USE WITH TYPE 1 − NATURAL
AND TYPE 4 LIQUEFIED PROPANE AND BUTANE GASES
7
For Models: WGD5800SW0, WGD5800SG0
(White/Grey) (Biscuit/Gold)
8181290

Illus. Part
No. No. DESCRIPTION
BA−150
8318272 BURNER ASSEMBLY
USE WITH TYPE 1 − NATURAL
AND TYPE 4 LIQUEFIED PROPANE AND BUTANE GASES
1 8318272 Burner Assembly
60 Hz.
(Type 1)
(White Rodgers)
2 688617 Tube, Burner
3 694298 Bracket, Ignitor
4 686590 Ignitor
5 3393909 Screw & Washer
(8−32 x 5/8)
6 343641 Screw, 10−16 x 1/2
7 693986 Base, Burner
8 3387057 Screw, 8−18 x 3/8
9 Orifice, Burner
234826 Type 1
229742 Type 4 (Butane)
234868 Type 4 (Propane)
10 8318277 Valve, 60 Hz.
(Includes Pipe &
Illus. #7)
11 694421 Screw,
8−32 x 1/2 (2)
12 694538 Bracket, Coil
13 694540 Coil, 60 Hz.
(2 Terminal)
(Main)
14 694539 Coil, 60 Hz.
(Split)
(3 Terminal)
(Pilot Position)
15 694424 Leak Limiter
16 694423 Screw, Regulator
Adjustment
17 694422 Spring, Regulator
20 239822 Plug, Pipe
25 341029 Clamp, Pipe
694572 Conversion Kit
(Type 1)
to Type (4) L.P.G.
Following Parts Not Illustrated
8
For Models: WGD5800SW0, WGD5800SG0
(White/Grey) (Biscuit/Gold)
8181290

OPTIONAL PARTS (NOT INCLUDED)
9
For Models: WGD5800SW0, WGD5800SG0
(White/Grey) (Biscuit/Gold)
8181290
Illus. Part
No. No. DESCRIPTION
ACCESSORY PARTS
279948 Kit,
Dryer Repair
346764 Kit, Hold−Down
(Gas Dryer Mobile
Home Installation)
3406839 Dry Rack
8522199 Kit, Dryer
Vent Testing
PAINT, TOUCH−UP (1/2oz.)
72017 White
4392899 Biscuit
PAINT, PRESSURIZED SPRAY
(12 oz.)
350930 White
4392901 Biscuit
350938 Primer, Gray
PAINT, BULK (1 qt.)
799344 White (Uncut)
4392900 Biscuit (Uncut)
