Whirlpool MAX109/BRZ User manual

GB
MAX 109
QUICK REFERENCE GUIDE
CONTROL PANEL
MICROWAVE BUTTON
Use to set the desired
microwave power level.
JET DEFROST BUTTON
Use to select Jet Defrost function.
6TH SENSE BUTTON
Use to select 6th Sense Crisp or
6th Sense Steam function.
STOP BUTTON
Press to stop or reset any of
the oven functions.
CRISP BUTTON
Use to select Crisp function.
BACK / CONFIRMATION BUTTON
Use to select or go back in the selection of a function.
CAPACITIVE TOUCH SELECTOR
Use to adjust the cook time, cook power(for MW), class food, weight, cook function and setting.
DIGITALDISPLAY
The display includes a 24-hour
clock, symbols and text.
JET START BUTTON
Use to start the cooking
process or invoke the Jet
Start function.
GRILL BUTTON
Use to select Grill function.
CRISP DEFROST BUTTON
Use to select Defrosting Bread function.
SETTING
WHEN THE PRODUCT IS initially plugged into the power source, a selection of settings automatically appear to enable you to adjust/customize values such as Clock, Volume and Eco mode.
IFYOU WISH TO change any setting, you can keep the Stop button pressed for 3 seconds to reach it.
VOLUME VOLUME HIGH VOLUME MEDIUM
DEFAULT VOLUME LOW SILENT
Buttons (all touch
buttons) 100% 100% 50% 0%
Central Jewel 100% 50% 20% 0%
Alerts, Alarms &
Reminders 100% 100% 100% 100%
NOTE: ECO MODE Deactivated is Default.
WHEN ECO MODE IS SET, the clock will not be visible when the product is in Standby.
Set Clock
qTURN TOUCH SELECTOR to set the actual time-of-day.
wPRESS CONFIRMATION BUTTON to confirm selection.
Set Volume
qTURN TOUCH SELECTOR to select the Volume.
wPRESS CONFIRMATION BUTTON to confirm selection.
ECO Mode
qTURN TOUCH SELECTOR to select Activated or Deactivated.
wPRESS CONFIRMATION BUTTON to confirm selection.
NOTE: ITGIVES YOU 10 MINUTES to complete the setting of the Clock.
NOTE: ALL THE PROMOTION STICKERS NEED TO BE TAKEN OUT OF THE PRODUCT BEFORE USE.
WHEN THE PRODUCT IS OFF OR IN STANDBYMODE, while opening or closing the door a beep will signal, and all the function key will be visible on control panel. Or you can press the touch selector, all
the function key will be visible on it.

GB
THIS FUNCTION IS USED for quick reheating of food
with a high water content such as clear soups,
coee or tea.
qPRESS JET START BUTTON.
THIS FUNCTION AUTOMATICALLY STARTS with maximum
microwave power level and the cooking time set
to 30 seconds. Each additional press increases the
time with 30 seconds. You may also alter the time
by rotating the nger on the central touch se-
lector to increase or decrease the time after the
function has started.
MAX 109
fff
JET START
NOTE: THE AMBIENT LIGHT wil be deactivate when ECO Mode is activated.
NOTE: THE DEMOMODE will be activated under the language selected.
QUICK REFERENCE GUIDE
MICROWAVES ONLY
POWER SUGGESTED USE:
COOK-REHEAT Jet Power COOKINGof sh, meat, vegetables etc.
COOK-REHEAT 500 W MORE CAREFUL COOKINGe.g. high protein sauces, cheese and egg dishes and to nish
cooking casseroles.
COOK-MELT 350 W SIMMERINGSTEWS, melting butter.
DEFROST 160 W DEFROSTING. Softening butter, cheeses.
SOFTENING 90 W SOFTENINGIce cream.
COOK & REHEAT WITH MICROWAVES
USE THIS FUNCTION for normal cooking and reheating, such as vegetables, sh, potatoes and meat.
ONCE THE COOKINGPROCESS HASBEEN STARTED:
The time can easily be increased in 30-second
steps by pressing the Jet Start button. Each press
increases the time with 30
seconds. You may also alter
the time by rotating the
nger on the central touch
selector to increase or decrease the time.
qPRESS THE MICROWAVE BUTTON repeatedly to se-
lect the power.
wPRESS CONFIRMATION BUTTON to conrm.
eTURN THE TOUCH SELECTOR to adjust the cooking
time.
rPRESS THE JET START BUTTON.
CHILD LOCK/TOUCH LOCK
THIS AUTOMATIC SAFETY FUNCTION IS ACTIVATED 2
MINUTES AFTER the oven has returned to
“stand by mode“. In this mode the door
are locked.
THE DOOR MUST BEOPENED AND CLOSED e.g. putting food
into it, before the safety lock is released. Else the
display will show “DOOR“.
PAUSE OR STOP COOKING
TOPAUSE COOKING:
THE COOKINGCANBEPAUSED to check, turn or stir the food by opening the door. The setting will exit to
standby mode after 5 minutes.
TOCONTINUE COOKING:
CLOSE THE DOOR and press the Jet Start button ONCE. The cooking is resumed from where it was paused.
IFYOU DON’TWANT TO CONTINUE COOKING:
REMOVE THE FOOD, close the door and press the STOP button.
NOTE: After cooking ends, the fan and cavity lamp is on before pressing STOP button, it’s normal.
ABEEP WILL SIGNALonce a minute for 10 minutes when the cooking is nished. Press the STOP button or open
the door to cancel the signal.
DEMO MODE
AMBIENT LIGHT
UNDERNEATH THE PRODUCT there is a White ambient light which reflects off the underlying surface.
The white light should be present when the product is in setup state or when a cooking process has
finished.
THE AMBIENT LIGHT should change color depending on the active process:
GREEN LIGHT (“healthy”), Shown during the cooking process for: 6th Sense Steam.
RED LIGHT (“heated cooking”), Shown during the cooking process for: MW, Grill, Combi, 6th Sense
Crisp, Manual Crisp, Crisp Defrost.
BLUE LIGHT (“cool defrosting”), Shown during the cooking process for: Jet Defrost.
How to activate Demo Mode: While the oven is in normal mode, open the door, press Stop button,
press and hold the Jet Start button for 8 seconds until you hear a beep. The oven will show “Demo
Mode activated” .
How to deactivate Demo Mode: Open the door, press Stop button, press and hold the Jet Start
button for 8 seconds until you hear a beep. The Demo Mode function will be deactivated.
YOU CANPRESS the back button if you wish to
return to previous setting before pressing Jet
start button.
PRESSINGTHE JET START BUTTON ONCE will increase
the time by 30 seconds.

USE THIS FUNCTION TO cook quiches, pizzas and
other dough based food. Also ideal for roasting
meat, sh and frying bacon, eggs, potatoes, etc.
ENSURE that the Crisp-plate is correctly placed
in the middle of the Glass turntable.
USE OVEN MITTENS
or the special Crisp handle sup-
plied when removing the hot Crisp-plate.
BECAREFUL, NOT TO TOUCH the ceiling beneath
the Grill element.
DONOT PLACE THE HOT CRISP-PLATE on any surface
susceptible to heat.
THE OVEN AND THE CRISP-PLATE become very hot
when using this function.
qPRESS THE CRISP BUTTON.
wTURN THE TOUCH SELECTOR to adjust the cooking
time.
ePRESS CONFIRMATION BUTTON to conrm. Then a
message appears Informing the users to use
the crisp plate.
rPRESS THE JET START BUTTON.
ITIS NOT POSSIBLE TO CHANGEOR SWITCH the Power level
or Grill on/o, when using the Crisp function.
ONLY USE the supplied Crisp plate with this func-
tion. Other available Crisp plates on
the market will not give the correct
result when using this function.
DURINGCOOKINGTIME, It is possible to adjust the
cook time by turning the touch selector.
THE OVEN AUTOMATICALLY uses Microwaves and Grill
in order to heat the Crisp-plate. This way the
Crisp-plate will rapidly reach its working temper-
ature and begin to brown and crisp the food.
YOU CANPRESS back button if you wish to return to
previous setting before pressing Jet start button.
MAX 109
i
h
i
d
O
t
h
s
p
li d C i
p
CRISP
FROZEN FOODS:
IFTHE WEIGHT IS LESS THANOR GREATER THANRECOMMEND-
ED WEIGHT: Follow the procedure for “Cook &
Reheat with microwaves”and choose 160
W when defrosting.
IFTHE FOOD IS WARMER than deep-freeze tem-
perature (-18°C), choose lower weight of
the food.
IFTHE FOOD IS COLDER than deep-freeze tem-
perature (-18°C), choose higher weight of
the food.
USE THIS FUNCTION for defrosting Meat, Poultry and Fish. JET Defrost should only be used if the net
weight is between 100 g- 1.5 kg.
ALWAYS PLACE THE FOOD on the glass turntable.
qPRESS THE JET DEFROST BUTTON.
wTURN THE TOUCH SELECTOR to adjust the weight
of the food.
ePRESS THE JET START BUTTON.
MIDWAYTHROUGHTHE DEFROSTINGPROCESS the oven
stops and prompts you to TURN FOOD.
Open the door.
Turn the food.
Close the door and restart by pressing the Jet
Start button.
NOTE: THE OVEN CONTINUES AUTOMATICALLY after 2 min.
if the food hasn’t been turned.
MPl dFihJET D fhld lb
JET DEFROST
USE THIS FUNCTION TO quickly give a pleasant brown surface to the food.
qPRESS THE GRILL BUTTON.
wTURN THE TOUCH SELECTOR to adjust the cooking time.
ePRESS THE JET START BUTTON.
DURINGTHE COOKING, It is possible to adjust the cooking time by turning the touch selector.
ENSURE THAT THE UTENSILS used are heat resistant and ovenproof before grilling with them.
DONOT USE PLASTIC utensils when grilling. They will melt. Items of wood or paper
are not suitable either.
USE THIS FUNCTION TO cook such food as Gratins,
Lasagne, Poultry and Baked potatoes.
qPRESS THE GRILL BUTTON FIRST, and press MW but-
ton, then display will show the “COMBI FUNC-
TION“ .
wTURN TOUCH SELECTOR to select the power.
ePRESS CONFIRMATION BUTTON to conrm.
rTURN TOUCH SELECTOR to adjust the cooking
time.
tPRESS JET START BUTTON.
DURINGCOOKINGTIME, It is possible to adjust the cook time by turn the touch selector or press start
botton.
GRILL COMBI
POWER SUGGESTED USE:
350 - 500 W COOKINGPoultry & Lasagne
160 - 350 W COOKINGFish & frozen gratins
160 W COOKINGMeat
90 W GRATINATINGfruit
0 W BROWNINGonly during cooking
GRILL
GRILL COMBI
ENSURE THAT THE UTENSILS used are heat resistant and ovenproof before grilling with them.
DONOT USE PLASTIC utensils when grilling. They will melt. Items of wood or paper
are not suitable either.
YOU CANPRESS back button if you wish to return to previous setting before pressing Jet start button.
GB QUICK REFERENCE GUIDE

MAX 109
USE THIS FUNCTION TO Defrost crispy bread. Crisp Defrost should only be used if the net weight is between
50g- 400g.
qPRESS THE CRISP DEFROST BUTTON.
wTURN THE TOUCH SELECTOR to select the weight.
ePRESS CONFIRMATION BUTTON to conrm. Then a message appears to inform you to use the crisp plate.
rPRESS JET START BUTTON to preheating of the Crisp plate. When the temperature has been reached, a
message informs you to insert the food (bread).
tADD FOOD(BREAD) and press start button.
CRISP DEFROST
IFYOU DO NOT open and close door in add food stage, the cooking can not be resumed and continue
cooking.
6TH SENSE CRISP
FOOD CLASS AMOUNT HINTS
qPIZZA, FROZEN
300400G
For pizzas with crust.
wFRENCH FRIES,
FROZEN
Spread out the fries in an even layer on the crisp plate. Sprinkle with
salt if crispier fries are desired. The fries can be stirred when the time
is displayed.
eQUICHE FROZEN Remove package and place the Quiche on the crisp plate.
rCHICKEN NUGGETS/
WINGS, FROZEN
Spread out the Chicken wings in an even layer on the crisp plate. The
chicken Nuggets can be stirred when the time is displayed.
FOR FOOD NOT LISTED IN THIS TABLE and if the weight is lesser or greater than recommended weight, you
should follow the procedure for the manual Crisp function.
USE THIS FUNCTION TO cook Pizzas, French Fries, Quiche, and Chicken nuggets. This function is used only for
frozen ready-made food.
qPRESS THE 6TH SENSE BUTTON mode position.
wTURN TOUCH SELECTOR to select 6th Sense Crisp.
ePRESS CONFIRMATION BUTTON to conrm.
rTURN TOUCH SELECTOR to select the food type.
tPRESS CONFIRMATION BUTTON to conrm. Then a
message appears Informing the users to use
the crisp plate.
yPRESS JET START BUTTON.
ONLY THE FOOD IS TO be placed on the
Crisp plate.
DONOT PLACE any containers or wrappings on
the Crisp plate!
ONLY USE the supplied Crisp plate with this func-
tion. Other available Crisp plates on the market
will not give the correct result when using this
function.
USE OVEN MITTENS or the special
Crisp handle supplied when re-
moving the hot Crisp-plate.
GB QUICK REFERENCE GUIDE
TECHNICAL SPECIFICATION
MODEL MAX109/BRZ
SUPPLY VOLTAGE230 V/50 HZ
RATED POWER INPUT 1500 W
FUSE 10 A (UK 13 A)
MW OUTPUT POWER 700 W
GRILL 650 W
OUTER DIMENSIONS (HXWXD) 360 X392 X350
INNER DIMENSIONS (HXWXD) 149 X290 X290
USE THIS FUNCTION FOR such food as vegetables, Frozen vegetables, fish fillets, fruits.
ALWAYS USE SUPPLIED STEAMER when using this function.
qPRESS THE 6TH SENSE BUTTON mode position.
wTURN TOUCH SELECTOR to select 6th Sense Steam.
ePRESS CONFIRMATION BUTTON to conrm.
rTURN TOUCH SELECTOR to select the food type.
tPRESS CONFIRMATION BUTTON to conrm. Two messages appear to remind you to use the steamer and
add water to steamer.
yPRESS JET START BUTTON.
THE STEAMER IS designed to be used with microwaves only!
NEVER USE IT with any other function at all.
USING THE STEAMER in any other function may cause damage.
ALWAYS ENSURE THAT the turntable is able to turn freely before starting the oven.
ALWAYS PLACE the steamer on the Glass Turntable.
d
b
l
F
bl
fi
h
f
il
l
f
i
6TH SENSE STEAM
FOOD CLASS AMOUNT HINTS
qVEGETABLES
300G- 400G
PLACE IN STEAM GRID. Add 100ml water in bottom and
cover with lid.
wFROZEN VEGETABLES ALLOW TO STAND for 1 - 2 minutes. Add 100ml water in
bottom and cover with lid.
eFISH FILETS
DISTRIBUTE FILLETS EVENLY on the steam grid. Interlace thin
parts. Allow to stand for 1 - 2 minutes, after cooking.
Add 100ml water in bottom and cover with lid.
rFRUITS PLACE IN STEAM GRID.Add 100ml water in bottom and
cover with lid.
YOU CANPRESS back button if you wish to return to
previous setting.
YOU CANPRESS back button if you wish to return to previous setting.
W10636516
