Whirlpool 30" WOS51EC0A User manual

KEY FEATURES
• 30" Single Wall Oven
• AccuBake® Temperature
Management System
• 5.0 cu. ft. Oven Capacity
• Traditional Self-Clean System
• SteamClean Option
• FIT System
• New Whirlpool® Design
• Hidden Bake
Whirlpool® 30" Single Wall Oven
WOS51EC0A
NEW
Preliminary
COLORS
White(W) Black(B) Biscuit(T)
Stainless
Steel(S)

Whirlpool® 30" Single Wall Oven
WOS51EC0A
AA110107
Dimensions are for planning purposes only.
For complete details, see Installation Instructions packed with product.
Specifications subject to change without notice.
SPECIFICATIONS DIMENSIONS
NOTE: The cutout height can be between 26⁄ " (68.4 cm) and
29⁄ " (74.8 cm) for single ovens.
30" (76.2 cm) models
A. 28¾" (72.8 cm) max. overall
height
B. 28½" (72.4 cm) max. recessed
width
C. 26
⁄
" (67.9 cm) recessed
height
D. 23
⁄
" (59.1 cm) max. recessed
depth
E. 30" (76.2 cm) overall width
B
C
D
E
A
Single Oven Undercounter (without cooktop installed above)
30" (76.2 cm) models
A. 30" (76.2 cm) min. cabinet
width
B. 1⁄ " (3.8 cm) min. top of
cutout to underside of
countertop
C. 5⁄ " (13.3 cm) bottom of
cutout to floor
D. 28⁄ " (72.4 cm) cutout width
E. 28" (71.2 cm) min. cutout
height
AB
C
D
E
30" (76.2 cm) models
A. 30" (76.2 cm) min. cabinet
width
B. 1" (2.5 cm) top of cutout to
bottom of upper cabinet door
C. 32" (81.3 cm) bottom of
cutout to floor
D. 28⁄ " (72.4 cm) cutout width
E. 1⁄ " (3.8 cm) min. bottom of
cutout to top of cabinet door
F. 28" (71.2 cm)* recommended
cutout height
G. 24" (60.7 cm) cutout depth
F
E
B
C
A
D
G
PRODUCT DIMENSIONS
Single Ovens Installed in Cabinet
CABINET DIMENSIONS
CABINET DIMENSIONS
ModEl # WoS51EC0A
TrANSiTioNEd FroM ModEl # rBS305PV
FEATurES
Capacity (cu. ft.) 5.0
Self-Cleaning Yes with Steam Clean
Rack Configuration 2 Racks with Integrated Handles
GENErAl oVEN FEATurES
Bake Element (Watts) @240/208 V 2800/2427
Broil Element (Watts) @240/208 V 3600/3120
Broil Passes 8
Oven Cavity Size (in.) 18 in. H x 25 in. W x 19 in. D
AccuBake® Temperature Management System Yes
Hidden Bake Yes
Delay Bake Yes
Sabbath Mode Yes
Closed Door Broiling Yes
Rack Positions 6
Control Type Membrane
Control Lockout Yes
Oven Controls Display Type VFD
Oven Controls Display Color Blue / Red
Oven Light(s) 2 Incandescent
Approved for Under-Cooktop Installation Yes
SPECiFiCATioNS
Power Supply Connection Location 3" Below Support Platform on Left
or Right Hand side
Sales Demo Mode Yes
Total Connected Load (kW) @ 240 volts 3.684
Total Connected Load (kW) @ 208 volts 2.788
Circuit (amps) 30
Approx. Shipping Weight (lbs.) 165
Handle Type Metal
FIT System feet and trims supplied with oven Yes
ColorS W, B, S, T
W=White, B=Black, S=Stainless Steel, T=Biscuit
CuTouT diMENSioNS
Height 26 29/32 to 29 13/32
Width 28 1/2
Depth 24
Bottom of cutout to floor (undercounter) 5 1/4
Bottom of cutout to floor (in-wall) 32
ProduCT diMENSioNS
Overall Height 28 3/4
Overall Width 30
Overall Depth 26 3/8
Depth with door open 90 degrees 46 3/4
All dimensions are shown in inches.
®Registered trademark/™ Trademark of Whirlpool, U.S.A. ©2011. All rights reserved.
All other trademarks are owned by their respective companies.

KEY FEATURES
• 30" Single Wall Oven
• True Convection System with
Convection Conversion
• 5.0 cu. ft. Oven Capacity
• AccuBake® Temperature
Management System
• Rapid Preheat
• Traditional Self-Clean System
• SteamClean Option
• FIT System
• New Whirlpool® Design
• Hidden Bake
Whirlpool® 30" Single Wall Oven
WOS92EC0A
NEW
Preliminary
COLORS
White(W) Black(B)
Stainless
Steel(S)
Black w/Silver
Handle(E)
White w/Silver
Handle(H)

Whirlpool® 30" Single Wall Oven
WOS92EC0A
AA110107
SPECIFICATIONS DIMENSIONS
Dimensions are for planning purposes only.
For complete details, see Installation Instructions packed with product.
Specifications subject to change without notice.
ModEl # WoS92EC0A
TrANSiTioNEd FroM ModEl # GBS309PV
FEATurES
Capacity (cu. ft.) 5.0
True Convection System Yes
Self-Cleaning Yes with Steam Clean
Rack Configuration 3 Racks with Integrated Handles
GENErAl oVEN FEATurES
Bake Element (Watts) @240/208 V 2800/2427
Broil Element (Watts) @240/208 V 3600/3120
Broil Passes 8
Oven Cavity Size (in.) 18 in. H x 25 in. W x 19 in. D
AccuBake® Temperature Management System Yes
Hidden Bake Yes
Delay Bake Yes
Sabbath Mode Yes
Closed Door Broiling Yes
Rapid Pre-heat Yes
Rack Positions 6
Control Type Membrane
Control Lockout Yes
Oven Controls Display Type VFD
Oven Controls Display Color Blue / Red
Oven Light(s) 2 Incandescent
Approved for Under-Cooktop Installation Yes
SPECiFiCATioNS
Power Supply Connection Location 3" Below Support Platform on Left
or Right Hand side
Sales Demo Mode Yes
Total Connected Load (kW) @ 240 volts 3.715
Total Connected Load (kW) @ 208 volts 2.819
Circuit (amps) 30
Approx. Shipping Weight (lbs.) 165
Handle Type Metal
FIT System feet and trims supplied with oven Yes
ColorS W, B, S, E, H
W=White, B=Black, S=Stainless Steel,
E=Black w/Silver Handle, H=White w/Silver Handle
CuTouT diMENSioNS
Height 26 29/32 to 29 13/32
Width 28 1/2
Depth 24
Bottom of cutout to floor (undercounter) 5 1/4
Bottom of cutout to floor (in-wall) 32
ProduCT diMENSioNS
Overall Height 28 3/4
Overall Width 30
Overall Depth 26 3/8
Depth with door open 90 degrees 46 3/4
All dimensions are shown in inches.
NOTE: The cutout height can be between 26⁄ " (68.4 cm) and
29⁄ " (74.8 cm) for single ovens.
30" (76.2 cm) models
A. 28¾" (72.8 cm) max. overall
height
B. 28½" (72.4 cm) max. recessed
width
C. 26
⁄
" (67.9 cm) recessed
height
D. 23
⁄
" (59.1 cm) max. recessed
depth
E. 30" (76.2 cm) overall width
B
C
D
E
A
Single Oven Undercounter (without cooktop installed above)
30" (76.2 cm) models
A. 30" (76.2 cm) min. cabinet
width
B. 1⁄ " (3.8 cm) min. top of
cutout to underside of
countertop
C. 5⁄ " (13.3 cm) bottom of
cutout to floor
D. 28⁄ " (72.4 cm) cutout width
E. 28" (71.2 cm) min. cutout
height
AB
C
D
E
30" (76.2 cm) models
A. 30" (76.2 cm) min. cabinet
width
B. 1" (2.5 cm) top of cutout to
bottom of upper cabinet door
C. 32" (81.3 cm) bottom of
cutout to floor
D. 28⁄ " (72.4 cm) cutout width
E. 1⁄ " (3.8 cm) min. bottom of
cutout to top of cabinet door
F. 28" (71.2 cm)* recommended
cutout height
G. 24" (60.7 cm) cutout depth
F
E
B
C
A
D
G
PRODUCT DIMENSIONS
Single Ovens Installed in Cabinet
CABINET DIMENSIONS
CABINET DIMENSIONS
®Registered trademark/™ Trademark of Whirlpool, U.S.A. ©2011. All rights reserved.
All other trademarks are owned by their respective companies.

KEY FEATURES
• 27" Single Wall Oven
• AccuBake® Temperature
Management System
• 4.3 cu. ft. Oven Capacity
• Traditional Self-Clean System
• SteamClean Option
• FIT System
• New Whirlpool® Design
• Hidden Bake
Whirlpool® 27" Single Wall Oven
WOS51EC7A
NEW
Preliminary
COLORS
Stainless
Steel(S)
Black w/Silver
Handle(E)
White w/Silver
Handle(H)

Dimensions are for planning purposes only.
For complete details, see Installation Instructions packed with product.
Specifications subject to change without notice.
Whirlpool® 27" Single Wall Oven
WOS51EC7A
AA110107
SPECIFICATIONS DIMENSIONS
ModEl # WoS51EC7A
TrANSiTioNEd FroM ModEl # rBS275PV
FEATurES
Capacity (cu. ft.) 4.3
Self-Cleaning Yes
Rack Configuration 2 Racks with Integrated Handles
GENErAl oVEN FEATurES
Bake Element (Watts) @ 240/208 V 2800/2427
Broil Element (Watts) @ 240/208 V 3600/3120
Broil Passes 8
Oven Cavity Size (in.) 18 in. H x 22 in. W x 19 in. D
AccuBake® Temperature Management System Yes
Hidden Bake Yes
Delay Bake Yes
Sabbath Mode Yes
Closed Door Broiling Yes
Rack Positions 6
Control Type Membrane
Control Lockout Yes
Oven Controls Display Type VFD
Oven Controls Display Color Blue / Red
Oven Light(s) 2 Incandescent
Approved for Under-Cooktop Installation Yes
SPECiFiCATioNS
Power Supply Connection Location 3" Below Support Platform on Left
or Right Hand side
Sales Demo Mode Yes
Total Connected Load (kW) @ 240 volts 3.684
Total Connected Load (kW) @ 208 volts 2.788
Circuit (amps) 30
Approx. Shipping Weight (lbs.) 138
Handle Type Metal
FIT System feet and trims supplied with oven Yes
ColorS W, B, S, T
W=White, B=Black, S=Stainless Steel, T=Biscuit
CuTouT diMENSioNS
Height 26 29/32 to 29 13/32
Width 25 1/2
Depth 24
Bottom of cutout to floor (undercounter) 5 1/4
Bottom of cutout to floor (in-wall) 32
ProduCT diMENSioNS
Overall Height 28 3/4
Overall Width 27
Overall Depth 26 3/8
Depth with door open 90 degrees 46 3/4
All dimensions are shown in inches.
Single Ovens Installed in Cabinet
27" (68.6 cm) models
A. 28¾" (72.8 cm) max. overall
height
B. 25
⁷⁄₁₆
" (64.6 cm) max. recessed
width
C. 26
³⁄₄
" (67.9 cm) recessed
height
D. 23
¹⁄₄
" (59.1 cm) max. recessed
depth
E. 27" (68.6 cm) overall width
B
C
D
E
A
Single Oven Undercounter (without cooktop installed above)
27" (68.6 cm) models
A. 27" (68.6 cm) min. cabinet
width
B. 1¹⁄₂" (3.8 cm) min. top of
cutout to underside of
countertop
C. 5¹⁄₄" (13.3 cm) bottom of
cutout to floor
D. 25¹⁄₂" (64.8 cm) cutout width
E. 28" (71.2 cm) min. cutout
height
AB
C
D
E
27" (68.6 cm) models
A. 27" (68.6 cm) min. cabinet
width
B. 1" (2.5 cm) top of cutout to
bottom of upper cabinet door
C. 32" (81.3 cm) bottom of cutout
to floor
D. 25¹⁄₂" (64.8 cm) cutout width
E. 1¹⁄₂" (3.8 cm) min. bottom of
cutout to top of cabinet door
F. 28" (71.2 cm)* recommended
cutout height
G. 24" (60.7 cm) cutout depth
F
E
B
C
A
D
G
PRODUCT DIMENSIONS CABINET DIMENSIONS
CABINET DIMENSIONS
NOTE: The cutout height can be between 26 29/32" (68.4 cm)
and 29 13/32" (74.8 cm) for single ovens.
®Registered trademark/™ Trademark of Whirlpool, U.S.A. ©2011. All rights reserved.
All other trademarks are owned by their respective companies.

KEY FEATURES
• 27" Single Wall Oven
• True Convection System with
Convection Conversion
• 4.3 cu. ft. Oven Capacity
• AccuBake® Temperature
Management System
• Rapid Preheat
• Traditional Self-Clean System
• SteamClean Option
• FIT System
• New Whirlpool® Design
• Hidden Bake
Whirlpool® 27" Single Wall Oven
WOS92EC7A
NEW
Preliminary
COLORS
White(W) Black(B)
Stainless
Steel(S)

Dimensions are for planning purposes only.
For complete details, see Installation Instructions packed with product.
Specifications subject to change without notice.
Whirlpool® 27" Single Wall Oven
WOS92EC7A
AA110107
SPECIFICATIONS DIMENSIONS
CuTouT diMENSioNS
Height 26 29/32 to 29 13/32
Width 25 1/2
Depth 24
Bottom of cutout to floor (undercounter) 5 1/4
Bottom of cutout to floor (in-wall) 32
ProduCT diMENSioNS
Overall Height 28 3/4
Overall Width 27
Overall Depth 26 3/8
Depth with door open 90 degrees 46 3/4
All dimensions are shown in inches.
ModEl # WoS92EC7A
TrANSiTioNEd FroM ModEl # GBS279PV
FEATurES
Capacity (cu. ft.) 4.3
True Convection System Yes
Self-Cleaning Yes with Steam Clean
Rack Configuration 3 Racks with Integrated Handles
GENErAl oVEN FEATurES
Bake Element (Watts) @240/208 V 2800/2427
Broil Element (Watts) @240/208 V 3600/3120
Broil Passes 8
Oven Cavity Size (in.) 18 in. H x 22 in. W x 19 in. D
AccuBake® Temperature Management System Yes
Hidden Bake Yes
Delay Bake Yes
Sabbath Mode Yes
Closed Door Broiling Yes
Rapid Pre-heat Yes
Rack Positions 6
Control Type Membrane
Control Lockout Yes
Oven Controls Display Type VFD
Oven Controls Display Color Blue / Red
Oven Light(s) 2 Incandescent
Approved for Under-Cooktop Installation Yes
SPECiFiCATioNS
Power Supply Connection Location 3" Below Support Platform on Left
or Right Hand side
Sales Demo Mode Yes
Total Connected Load (kW) @ 240 volts 3.715
Total Connected Load (kW) @ 208 volts 2.819
Circuit (amps) 30
Approx. Shipping Weight (lbs.) 138
Handle Type Metal
FIT System feet and trims supplied with oven Yes
ColorS W, B, S
W=White, B=Black, S=Stainless Steel
Single Ovens Installed in Cabinet
27" (68.6 cm) models
A. 28¾" (72.8 cm) max. overall
height
B. 25
⁷⁄₁₆
" (64.6 cm) max. recessed
width
C. 26
³⁄₄
" (67.9 cm) recessed
height
D. 23
¹⁄₄
" (59.1 cm) max. recessed
depth
E. 27" (68.6 cm) overall width
B
C
D
E
A
Single Oven Undercounter (without cooktop installed above)
27" (68.6 cm) models
A. 27" (68.6 cm) min. cabinet
width
B. 1¹⁄₂" (3.8 cm) min. top of
cutout to underside of
countertop
C. 5¹⁄₄" (13.3 cm) bottom of
cutout to floor
D. 25¹⁄₂" (64.8 cm) cutout width
E. 28" (71.2 cm) min. cutout
height
AB
C
D
E
27" (68.6 cm) models
A. 27" (68.6 cm) min. cabinet
width
B. 1" (2.5 cm) top of cutout to
bottom of upper cabinet door
C. 32" (81.3 cm) bottom of cutout
to floor
D. 25¹⁄₂" (64.8 cm) cutout width
E. 1¹⁄₂" (3.8 cm) min. bottom of
cutout to top of cabinet door
F. 28" (71.2 cm)* recommended
cutout height
G. 24" (60.7 cm) cutout depth
F
E
B
C
A
D
G
PRODUCT DIMENSIONS CABINET DIMENSIONS
CABINET DIMENSIONS
NOTE: The cutout height can be between 26 29/32" (68.4 cm)
and 29 13/32" (74.8 cm) for single ovens.
®Registered trademark/™ Trademark of Whirlpool, U.S.A. ©2011. All rights reserved.
All other trademarks are owned by their respective companies.

KEY FEATURES
• 30" Double Wall Oven
• AccuBake® Temperature
Management System
• 5.0 cu. ft. Oven Capacity
• Traditional Self-Clean System
• SteamClean Option
• FIT System
• New Whirlpool® Design
• Hidden Bake
Whirlpool® 30" Double Wall Oven
WOD51EC0A
NEW
Preliminary
COLORS
White(W) Black(B) Biscuit(T)
Stainless
Steel(S)

Whirlpool® 30" Double Wall Oven
WOD51EC0A
Dimensions are for planning purposes only.
For complete details, see Installation Instructions packed with product.
Specifications subject to change without notice.
SPECIFICATIONS DIMENSIONS
ModEl # Wod51EC0A
TrANSiTioNEd FroM ModEl # rBd305PV
FEATurES (uPPEr)
Capacity (cu. ft.) 5.0
Self-Clean with Steam Clean Yes
Rack Configuration 2 Racks with Integrated Handles
FEATurES (loWEr)
Capacity (cu. ft.) 5.0
Self-Cleaning Yes
Rack Configuration 2 Racks with Integrated Handles
GENErAl oVEN FEATurES
Bake Element (Watts) @ 240/208 V 2800/2427
Broil Element (Watts) @ 240/208 V 3600/3120
Broil Passes 8
Oven Cavity Size (in.) 18 in. H x 25 in. W x 19 in. D
AccuBake® Temperature Management System Yes
Hidden Bake Yes
Delay Bake Yes
Sabbath Mode Yes
Closed Door Broiling Yes
Rack Positions 6
Control Type Membrane
Control Lockout Yes
Oven Controls Display Type VFD
Oven Controls Display Color Blue / Red
Oven Light(s) 2 Incandescent
SPECiFiCATioNS
Power Supply Connection Location 3" Below Support Platform on Left
or Right Hand side
Sales Demo Mode Yes
Total Connected Load (kW) @ 240 volts 7.368
Total Connected Load (kW) @ 208 volts 5.576
Circuit (amps) 30
Approx. Shipping Weight (lbs.) 266
Handle Type Metal
FIT System feet and trims supplied with oven Yes
ColorS W, B, T, S
W=White, B=Black, T=Biscuit, S=Stainless Steel
CuTouT diMENSioNS
Height 48 7/8 to 52 13/64
Width 28 1/2
Depth 24
Bottom of cutout to floor (in-wall) 14 3/4
ProduCT diMENSioNS
Height 51 7/16
Width 30
Depth 26 3/8
Depth with door open 90 degrees 46 3/4
All dimensions are shown in inches.
AA110107
30" (76.2 cm) models
A. 51
⁄
" (130.6 cm) max. overall
height
B. 28½" (72.4 cm) max. recessed
width
C. 26
⁄
" (124.0 cm) recessed
height
D. 23
⁄
" (59.1 cm) max. recessed
depth
E. 30" (76.2 cm) overall width
C
B
A
ED
Double Ovens Installed in Cabinet
NOTE: The cutout height can be between 48⁄ " (124.1 cm) and
52⁄ " (132.6 cm) for double ovens.
30" (76.2 cm) models
A. 30" (76.2 cm) min. cabinet
width
B. 1" (2.5 cm) top of cutout to
bottom of upper cabinet door
C. 14⁄" (37.5 cm) bottom of
cutout to floor
D. 28⁄ " (72.4 cm) cutout width
E. 1⁄ " (3.8 cm) min. bottom of
cutout to top of cabinet door
F. 50
⁄
" (127.2 cm)*
recommended cutout height
G. 24" (60.7 cm) cutout depth
F
E
A
D
G
B
C
PRODUCT DIMENSIONS
CABINET DIMENSIONS
®Registered trademark/™ Trademark of Whirlpool, U.S.A. ©2011. All rights reserved.
All other trademarks are owned by their respective companies.

KEY FEATURES
• 30" Double Wall Oven
• True Convection System with
Convection Conversion
• 5.0 cu. ft. oven capacity
• AccuBake® Temperature
Management System
• Rapid Preheat
• Traditional Self-Clean System
• SteamClean Option
• FIT System
• New Whirlpool® Design
•Hidden Bake
Whirlpool® 30" Double Wall Oven
WOD93EC0A
NEW
Preliminary
COLORS
White(W) Black(B)
Stainless
Steel(S)
Black w/Silver
Handle(E)
White w/Silver
Handle(H)

Whirlpool® 30" Double Wall Oven
WOD93EC0A
SPECIFICATIONS DIMENSIONS
ModEl # Wod93EC0A
TrANSiTioNEd FroM ModEl # GBd309PV
FEATurES (uPPEr)
Capacity (cu. ft.) 5.0
True Convection System Yes
Self-Cleaning Yes with Steam Clean
Rack Configuration 3 Racks with Integrated Handles
FEATurES (loWEr)
Capacity (cu. ft.) 5.0
Self-Cleaning Yes with Steam Clean
Rack Configuration 2 Racks with Integrated Handles
GENErAl oVEN FEATurES
Bake Element (Watts) @ 240/208 V 2800/2427
Broil Element (Watts) @240/208 V 3600/3120
Broil Passes 8
Oven Cavity Size (in.) 18 in. H x 25 in. W x 19 in. D
AccuBake® Temperature Management System Yes
Hidden Bake Yes
Delay Bake Yes
Sabbath Mode Yes
Closed Door Broiling Yes
Rapid Pre-heat Yes
Rack Positions 6
Control Type Membrane
Control Lockout Yes
Oven Controls Display Type VFD
Oven Controls Display Color Blue / Red
Oven Light(s) 2 Incandescent
SPECiFiCATioNS
Power Supply Connection Location 3" Below Support Platform on Left
or Right Hand side
Sales Demo Mode Yes
Total Connected Load (kW) @ 240 volts 7.399
Total Connected Load (kW) @ 208 volts 5.607
Circuit (amps) 30
Approx. Shipping Weight (lbs.) 266
Handle Type Metal
FIT System feet and trims supplied with oven Yes
ColorS W, B, S, E, H
W=White, B=Black, S=Stainless Steel,
E=Black w/Silver Handle, H=White w/Silver Handle
Dimensions are for planning purposes only.
For complete details, see Installation Instructions packed with product.
Specifications subject to change without notice.
CuTouT diMENSioNS
Height 48 7/8 to 52 13/64
Width 28 1/2
Depth 24
Bottom of cutout to floor (in-wall) 14 3/4
ProduCT diMENSioNS
Height 51 7/16
Width 30
Depth 26 3/8
Depth with door open 90 degrees 46 3/4
All dimensions are shown in inches.
AA110107
30" (76.2 cm) models
A. 51
⁄
" (130.6 cm) max. overall
height
B. 28½" (72.4 cm) max. recessed
width
C. 26
⁄
" (124.0 cm) recessed
height
D. 23
⁄
" (59.1 cm) max. recessed
depth
E. 30" (76.2 cm) overall width
C
B
A
ED
Double Ovens Installed in Cabinet
NOTE: The cutout height can be between 48⁄ " (124.1 cm) and
52⁄ " (132.6 cm) for double ovens.
30" (76.2 cm) models
A. 30" (76.2 cm) min. cabinet
width
B. 1" (2.5 cm) top of cutout to
bottom of upper cabinet door
C. 14⁄" (37.5 cm) bottom of
cutout to floor
D. 28⁄ " (72.4 cm) cutout width
E. 1⁄ " (3.8 cm) min. bottom of
cutout to top of cabinet door
F. 50
⁄
" (127.2 cm)*
recommended cutout height
G. 24" (60.7 cm) cutout depth
F
E
A
D
G
B
C
PRODUCT DIMENSIONS
CABINET DIMENSIONS
®Registered trademark/™ Trademark of Whirlpool, U.S.A. ©2011. All rights reserved.
All other trademarks are owned by their respective companies.

KEY FEATURES
• 27" Double Wall Oven
• AccuBake® Temperature
Management System
• 4.3 cu. ft. Oven Capacity
• Traditional Self-Clean System
• SteamClean Option
• FIT System
• New Whirlpool® Design
• Hidden Bake
Whirlpool® 27" Double Wall Oven
WOD51EC7A
NEW
Preliminary
COLORS
White(W) Black(B) Biscuit(T)
Stainless
Steel(S)

Whirlpool® 27" Double Wall Oven
WOD51EC7A
SPECIFICATIONS DIMENSIONS
ModEl # Wod51EC7A
TrANSiTioNEd FroM ModEl # rBd275PV
FEATurES (uPPEr)
Capacity (cu. ft.) 4.3
Self-Cleaning Yes with Steam Clean
Rack Configuration 2 Racks with Integrated Handles
FEATurES (loWEr)
Capacity (cu. ft.) 4.3
Self-Cleaning Yes
Rack Configuration 2 Racks with Integrated Handles
GENErAl oVEN FEATurES
Bake Element (Watts) @ 240/208 V 2800/2427
Broil Element (Watts) @ 240/208 V 3600/3120
Broil Passes 8
Oven Cavity Size (in.) 18 in. H x 22 in. W x 19 in. D
AccuBake® Temperature Management System Yes
Hidden Bake Yes
Delay Bake Yes
Sabbath Mode Yes
Closed Door Broiling Yes
Rack Positions 6
Control Type Membrane
Control Lockout Yes
Oven Controls Display Type VFD
Oven Controls Display Color Blue / Red
Oven Light(s) 2 Incandescent
SPECiFiCATioNS
Power Supply Connection Location 3" Below Support Platform on Left
or Right Hand side
Sales Demo Mode Yes
Total Connected Load (kW) @ 240 volts 7.368
Total Connected Load (kW) @ 208 volts 5.576
Circuit (amps) 30
Approx. Shipping Weight (lbs.) 244 1/2
Handle Type Metal
FIT System feet and trims supplied with oven Yes
ColorS W, B, T, S
W=White, B=Black, T=Biscuit, S=Stainless Steel
Dimensions are for planning purposes only.
For complete details, see Installation Instructions packed with product.
Specifications subject to change without notice.
CuTouT diMENSioNS
Height 48 7/8 to 52 13/64
Width 25 1/2
Depth 24
Bottom of cutout to floor (in-wall) 14 3/4
ProduCT diMENSioNS
Height 51 7/16
Width 27
Depth 26 3/8
Depth with door open 90 degrees 46 3/4
All dimensions are shown in inches.
AA110107
27" (68.6 cm) models
A. 51
⁄
" (130.6 cm) max. overall
height
B. 25
⁄
" (64.6 cm) max.
recessed width
C. 48
⁄
" (124.0 cm) recessed
height
D. 23
⁄
" (59.1 cm) max.
recessed depth
E. 27" (68.6 cm) overall width
C
B
A
ED
Double Ovens Installed in Cabinet
NOTE: The cutout height can be between 48⁄ " (124.1 cm) and
52⁄ " (132.6 cm) for double ovens.
27" (68.6 cm) models
A. 27" (68.6 cm) min. cabinet
width
B. 1" (2.5 cm) top of cutout to
bottom of upper cabinet door
C. 14⁄" (37.5 cm) bottom of
cutout to floor
D. 25⁄ " (64.8 cm) cutout width
E. 1⁄ " (3.8 cm) min. bottom of
cutout to top of cabinet door
F. 50
⁄
" (127.2 cm)*
recommended cutout height
G. 24" (60.7 cm) cutout depth
F
E
A
D
G
B
C
PRODUCT DIMENSIONS
CABINET DIMENSIONS
®Registered trademark/™ Trademark of Whirlpool, U.S.A. ©2011. All rights reserved.
All other trademarks are owned by their respective companies.

KEY FEATURES
• 27" Double Wall Oven
• True Convection System with
Convection Conversion
• 4.3 cu. ft. Oven Capacity
• AccuBake® Temperature
Management System
• Rapid Preheat
• Traditional Self-Clean System
• SteamClean Option
• FIT System
• New Whirlpool® Design
• Hidden Bake
Whirlpool® 27" Double Wall Oven
WOD93EC7A
NEW
Preliminary
COLORS
White(W) Black(B)
Stainless
Steel(S)

Whirlpool® 27" Double Wall Oven
WOD93EC7A
SPECIFICATIONS DIMENSIONS
ModEl # Wod93EC7A
TrANSiTioNEd FroM ModEl # GBd279PV
FEATurES (uPPEr)
Capacity (cu. ft.) 4.3
True Convection System Yes
Self-Cleaning Yes with Steam Clean
Rack Configuration 3 Racks with Integrated Handles
FEATurES (loWEr)
Capacity (cu. ft.) 4.3
Self-Cleaning Yes
Rack Configuration 2 Racks with Integrated Handles
GENErAl oVEN FEATurES
Bake Element (Watts) @ 240/208 V 2800/2427
Broil Element (Watts) @ 240/208 V 3600/3120
Broil Passes 8
Oven Cavity Size (in.) 18 in. H x 22 in. W x 19 in. D
AccuBake® Temperature Management System Yes
Hidden Bake Yes
Delay Bake Yes
Sabbath Mode Yes
Closed Door Broiling Yes
Rapid Pre-heat Yes
Rack Positions 6
Control Type Membrane
Control Lockout Yes
Oven Controls Display Type VFD
Oven Controls Display Color Blue / Red
Oven Light(s) 2 Incandescent
SPECiFiCATioNS
Power Supply Connection Location 3" Below Support Platform on Left
or Right Hand side
Sales Demo Mode Yes
Total Connected Load (kW) @ 240 volts 7.399
Total Connected Load (kW) @ 208 volts 5.607
Circuit (amps) 30
Approx. Shipping Weight (lbs.) 244 1/2
Handle Type Metal
FIT System feet and trims supplied with oven Yes
ColorS W, B, S
W=White, B=Black, S=Stainless Steel
Dimensions are for planning purposes only.
For complete details, see Installation Instructions packed with product.
Specifications subject to change without notice.
CuTouT diMENSioNS
Height 48 7/8 to 52 13/64
Width 25 1/2
Depth 24
Bottom of cutout to floor (in-wall) 14 3/4
ProduCT diMENSioNS
Height 51 7/16
Width 27
Depth 26 3/8
Depth with door open 90 degrees 46 3/4
All dimensions are shown in inches.
AA110107
27" (68.6 cm) models
A. 51
⁄
" (130.6 cm) max. overall
height
B. 25
⁄
" (64.6 cm) max.
recessed width
C. 48
⁄
" (124.0 cm) recessed
height
D. 23
⁄
" (59.1 cm) max.
recessed depth
E. 27" (68.6 cm) overall width
C
B
A
ED
Double Ovens Installed in Cabinet
NOTE: The cutout height can be between 48⁄ " (124.1 cm) and
52⁄ " (132.6 cm) for double ovens.
27" (68.6 cm) models
A. 27" (68.6 cm) min. cabinet
width
B. 1" (2.5 cm) top of cutout to
bottom of upper cabinet door
C. 14⁄" (37.5 cm) bottom of
cutout to floor
D. 25⁄ " (64.8 cm) cutout width
E. 1⁄ " (3.8 cm) min. bottom of
cutout to top of cabinet door
F. 50
⁄
" (127.2 cm)*
recommended cutout height
G. 24" (60.7 cm) cutout depth
F
E
A
D
G
B
C
PRODUCT DIMENSIONS
CABINET DIMENSIONS
®Registered trademark/™ Trademark of Whirlpool, U.S.A. ©2011. All rights reserved.
All other trademarks are owned by their respective companies.

KEY FEATURES
• 30" Combination
Microwave-Wall Oven
• New Whirlpool® Design
OVEN FEATURES
• AccuBake® Temperature
Management System
• 5.0 cu. ft. Oven Capacity
• Traditional Self-Clean System
• SteamClean Option
• Hidden Bake
MICROWAVE FEATURES
• Sensor Cooking
• 1.4 cu. ft. Capacity
• Stainless Steel Cavity
• 900 Watts
Whirlpool® 30" Combo Wall Oven
WOC54EC0A
NEW
Preliminary
COLORS
White(W) Black(B)
Stainless
Steel(S)

Whirlpool® 30" Combo Wall Oven
WOC54EC0A
SPECIFICATIONS DIMENSIONS
Dimensions are for planning purposes only.
For complete details, see Installation Instructions packed with product.
Specifications subject to change without notice.
30" (76.2 cm) Ovens
30" (76.2 cm) models
A.
42⁄
" (108.0 cm) overall height
B. 28
⁄
" (72.3 cm) recessed width
C. 41" (104.1 cm) recessed height
D. 23
⁄
" (59.1 cm) max. recessed
depth
E. 30" (76.2 cm) overall width
B
A
C
D
E
30" (76.2 cm) Ovens
*NOTE: The cabinet height can be between 41" (104.1 cm) and
41½" (105.6 cm) for double ovens.
30" (76.2 cm) models
A.
30
" (76.2 cm) min. cabinet
width
B. 1" (2.5 cm) top of cutout to
bottom of upper cabinet door
C. 19
⁄
" (48.9 cm) bottom of
cutout to floor
D. 28
⁄
" (72.4 cm) cutout width
E. 1
⁄
" (3.8 cm) min. bottom of
cutout to top of cabinet door
F. 41
⁄
" (105 cm)* recommended
cutout height
G. 24" (60.7 cm) cutout depth
F
E
A
D
G
B
C
PRODUCT DIMENSIONS
CABINET DIMENSIONS
CuTouT diMENSioNS
Height 41 to 41 1/2
Width 28 1/2
Depth 24
Bottom of cutout to floor (in-wall) 19 1/4
ProduCT diMENSioNS
Height 42 9/16
Width 30
Depth 26 3/8
Depth with door open 90 degrees 46 3/4
All dimensions are shown in inches.
ModEl # WoC54EC0A
TrANSiTioNEd FroM ModEl # rMC305PV
FEATurES (uPPEr)
Microwave Oven Capacity (cu. Ft.) 1.4
Microwave Oven Cavity Size (in.) 8.25 in. H x 16.5 in. W x 17.75 in. D
Diameter of Turntable (in.) 14 1/8
Microwave Wattage 900
Sensor Cooking Yes
Inverter TE Yes
FEATurES (loWEr)
Capacity (cu. ft.) 5.0
Self-Cleaning Yes
Rack Configuration 2 Racks with Integrated Handles
GENErAl oVEN FEATurES
Bake Element (Watts) @ 240/208 V 2800/2427
Broil Element (Watts) @ 240/208 V 3600/3120
Broil Passes 8
Oven Cavity Size (in.) 18 in. H x 25 in. W x 19 in. D
AccuBake® Temperature Management System Yes
Hidden Bake Yes
Delay Bake Yes
Sabbath Mode Yes
Closed Door Broiling Yes
Rack Positions 6
Control Type Membrane
Control Lockout Yes
Oven Controls Display Type VFD
Oven Controls Display Color Blue / Red
Oven Light(s) 2 Incandescent
SPECiFiCATioNS
Power Supply Connection Location 3" Below Support Platform on Left
or Right Hand side
Sales Demo Mode Yes
Circuit (amps) 40
Approx. Shipping Weight (lbs.) 235
Handle Type Metal
ColorS W, B, S
W=White, B=Black, S=Stainless Steel
AA110107
®Registered trademark/™ Trademark of Whirlpool, U.S.A. ©2011. All rights reserved.
All other trademarks are owned by their respective companies.

Whirlpool® 30" Combo Wall Oven
WOC95EC0A
NEW
Preliminary
KEY FEATURES
• 30" Combination
Microwave-Wall Oven
• New Whirlpool® Design
OVEN FEATURES
• True Convection System with
Convection Conversion
• 5.0 cu. ft. Oven Capacity
• AccuBake® Temperature
Management System
• Traditional Self-Clean System
• SteamClean Option
• Hidden Bake
MICROWAVE FEATURES
• Sensor Cooking
• 1.4 cu. ft. Capacity
• Stainless Steel Cavity
• 900 Watts
COLORS
White(W) Black(B)
Stainless
Steel(S)
Black w/Silver
Handle(E)
White w/Silver
Handle(H)

Whirlpool® 30" Combo Wall Oven
WOC95EC0A
SPECIFICATIONS DIMENSIONS
ModEl # WoC95EC0A
TrANSiTioNEd FroM ModEl # GSC309PV
FEATurES (uPPEr)
Microwave Oven Capacity (cu. Ft.) 1.4
Microwave Oven Cavity Size (in.) 8.25 in. H x 16.5 in. W x 17.75 in. D
Diameter of Turntable (in.) 14 1/8
Microwave Wattage 900
Convection Yes
Sensor Cooking Yes
Inverter TE Yes
FEATurES (loWEr)
Capacity (cu. ft.) 5.0
Self-Cleaning Yes with Steam Clean
Rack Configuration 3 Racks with Integrated Handles
True Convection Yes
GENErAl oVEN FEATurES
Bake Element (Watts) @ 240/208 V 2800/2427
Broil Element (Watts) @ 240/208 V 3600/3120
Broil Passes 8
Oven Cavity Size (in.) 18 in. H x 25 in. W x 19 in. D
AccuBake® Temperature Management System Yes
Hidden Bake Yes
Delay Bake Yes
Sabbath Mode Yes
Closed Door Broiling Yes
Rapid Pre-heat Yes
Rack Positions 6
Control Type Membrane
Oven Controls Display Type VFD
Oven Controls Display Color Blue / Red
Oven Light(s) 2 Incandescent
SPECiFiCATioNS
Power Supply Connection Location 3" Below Support Platform on Left
or Right Hand side
Sales Demo Mode Yes
Circuit (amps) 40
Approx. Shipping Weight (lbs.) 235
Handle Type Metal
ColorS W, B, S, E, H
W=White, B=Black, S=Stainless Steel,
E=Black w/Silver Handle, H=White w/Silver Handle
Dimensions are for planning purposes only.
For complete details, see Installation Instructions packed with product.
Specifications subject to change without notice.
CuTouT diMENSioNS
Height 41 to 41 1/2
Width 28 1/2
Depth 24
Bottom of cutout to floor (in-wall) 19 1/4
ProduCT diMENSioNS
Height 42 9/16
Width 30
Depth 26 3/8
Depth with door open 90 degrees 46 3/4
All dimensions are shown in inches.
AA110107
30" (76.2 cm) Ovens
30" (76.2 cm) models
A.
42⁄
" (108.0 cm) overall height
B. 28
⁄
" (72.3 cm) recessed width
C. 41" (104.1 cm) recessed height
D. 23
⁄
" (59.1 cm) max. recessed
depth
E. 30" (76.2 cm) overall width
B
A
C
D
E
30" (76.2 cm) Ovens
*NOTE: The cabinet height can be between 41" (104.1 cm) and
41½" (105.6 cm) for double ovens.
30" (76.2 cm) models
A.
30
" (76.2 cm) min. cabinet
width
B. 1" (2.5 cm) top of cutout to
bottom of upper cabinet door
C. 19
⁄
" (48.9 cm) bottom of
cutout to floor
D. 28
⁄
" (72.4 cm) cutout width
E. 1
⁄
" (3.8 cm) min. bottom of
cutout to top of cabinet door
F. 41
⁄
" (105 cm)* recommended
cutout height
G. 24" (60.7 cm) cutout depth
F
E
A
D
G
B
C
PRODUCT DIMENSIONS
CABINET DIMENSIONS
®Registered trademark/™ Trademark of Whirlpool, U.S.A. ©2011. All rights reserved.
All other trademarks are owned by their respective companies.
