Whirlpool SF387PEYB4 User manual

CONTROL PANEL PARTS
Illus. Part
No. No. DESCRIPTION
1
6−94 Litho in U.S.A. (rmb) Part No. 4372343
30" GAS
FREESTANDING RANGE
ELECTRONIC IGNITION
SELF−CLEAN OVEN SEALED BURNER
1 4371844 Panel, Control
2 4371835 Control,
Electronic Timer
3 4371834 Bracket, Timer
4 4371316 Endcap, RH
5 4371317 Endcap, LH
6 4371536 Cap, Filler
7 4371836 Retainer, Timer
8 4371534 Trim, Wrapper
9 4371535 Trim, Deflector
10 Support,Backguard
4372307 R.H.
4372308 L.H.
11 4371300 Shield, Rear Wall
12 4371537 Deflector, Flue
21 4371655 Shield,Inner Bkgd
23 816703 Switch, Light
For Model: SF387PEYW4, SF387PEYN4, SF387PEYB4
(White) (Almond) (Black)

Illus. Part
No. No. DESCRIPTION
COOKTOP PARTS
24372343
For Model: SF387PEYW4, SF387PEYN4, SF387PEYB4
(White) (Almond) (Black)
1 4372210 Grate (4)
2 Top, Main
4371697 White
4371698 Almond
4371879 Black
3 4371545 Bracket, Hinge RH
4 4371546 Bracket, Hinge LH
5 4371683 Panel, Manifold
6 4371663 Knob, Control (4)
7 4371541 Rod, Support Top
8 4371691 Pan, Burner (4)
9 816612 Clip, Spring (2)
10 4371684 Cap, Burner (4)
11 4371589 Screw, Burner Mtg
12 4371591 Bracket, Mtg RH
13 4371592 Bracket, Mtg LH

COOKTOP BURNER PARTS
Illus. Part
No. No. DESCRIPTION
3
4372343
1 4371596 Burner, Assy. (4)
2 4372146 Tubing, Burner(RF)
3 4372148 Tubing, Burner(RR)
4 4372147 Tubing, Burner(LF)
5 4372149 Tubing, Burner(LR)
6 4372306 Pipe, Manifold
7 4371587 Valve, Top(4)
8 4371597 Head, Burner
9 4371164 Switch, Ignitor(4)
10 4372316 Tubing, Regulator
To Manifold Pipe
11 4372040 Regulator,Pressure
12 816636 Bracket, Regulator
13 4371598 Bracket &
Electrode
14 4371858 Screw, Valve Mtg.
15 4371599 Screw, Electrode
16 816567 Orifice
17 816602 Plate,Burner Tube
OPTIONAL PARTS NOT INCLUDED
4372091 Gas Conversion Kit
(Natural Gas To
LP Gas)
For Model: SF387PEYW4, SF387PEYN4, SF387PEYB4
(White) (Almond) (Black)

Illus. Part
No. No. DESCRIPTION
BROILER & OVEN BURNER PARTS
44372343
1 816582 Baffle,
Broiler Burner
2 816584 Baffle,
Oven Burner
3 816722 Burner, Broiler
4 816588 Burner, Oven
5 816624 Ignitor,
Broiler Burner
6 816625 Ignitor,
Oven Burner
7 4371583 Ignitor, Module
8 816594 Mixer, Elbow
9 4372314 Tubing, Valve
To Mixing Elbow
10 816692 Valve, Safety
11 4372315 Tubing, Valve
To Regulator
12 816642 Nut, Hex (2)
For Model: SF387PEYW4, SF387PEYN4, SF387PEYB4
(White) (Almond) (Black)

OVEN PARTS
5
4372343
For Model: SF387PEYW4, SF387PEYN4, SF387PEYB4
(White) (Almond) (Black)

OVEN PARTS
Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
64372343
For Model: SF387PEYW4, SF387PEYN4, SF387PEYB4
(White) (Almond) (Black)
1 816669 Spacer, Body (8)
2 816659 Shield, Rear Wall
3 816651 Screw, Oven Bottom
4 816668 Socket, Oven Lamp
5 4371303 Bulb, Oven Light
6 4371621 Retainer, Lens
7 816609 Lens, Oven Light
8 4371143 Hinge, Oven Door
9 816617 Cover, Hinge
10 4371042 Shield,
Heat (Upper)
11 816657 Shield,
Heat (Lower)
12 816614 Cord, Power
13 816640 Switch, Latch
14 816633 Fastener, Push−On
16 4372290 Back, Main
17 4372288 Rod, Light Switch
18 816608 Bumper, Front (4)
19 4371682 Cover, Rod End
20 4372289 Switch, Door
22 4371661 Shield, Rear Heat
23 816577 Clip, Wire
24 4371652 Flue Box
25 816620 Gasket, Flue
26 4371144 Knob, Latch
27 4371036 Latch, Door
28 4371265 Handle, Latch
29 816615 Cover, Plate
30 4372310 Burner Box
31 816776 Shield, Main Front
32 816638 Shield, Latch
33 816660 Shield,
Heat Baffle
34 Panel, Side
816709 White LH
816708 White RH
816695 Almond LH
816672 Almond RH
4371881 Black LH
4371880 Black RH
35 4371909 Screw,
Leveler (4)
36 4372313 Support,
Oven Bottom
37 816618 Fastener, Cord
38 4372312 Insulation,
Oven Back
39 4372245 Bottom, Oven
41 816585 Bracket, Anti Tip
42 816639 Spacer, Stud (2)
43 816637 Shield, Latch
44 816658 Shield, Oven Top
45 816648 Shield, Side(2)
46 816627 Insulation, Front
47 816629 Insulation,
Oven Wrapper
48 4371664 Screw, Latch
49 816621 Glide, Drawer
50 4371662 Shield, Flue
51 816628 Insulation, Ov Top
52 816663 Shield, Wire
53 816664 Shield, Wool
54 4371527 Bracket,Maintop RH
55 4371528 Bracket,Maintop LH
56 816645 Probe, Oven Temp.
OVEN RACK PARTS
Illus. Part
No. No. DESCRIPTION
1 4371483 Rack, Oven (2)
2 816626 Insert,
Broiler Pan
3 816644 Pan, Broiler
LITERATURE PARTS
LIT4372206 Use & Care Guide
LIT4372196 Installation
Instructions

DOOR AND DRAWER PARTS
Illus. Part
No. No. DESCRIPTION
7
4372343
1 816622 Handle, Door
2 816688 Trim, Door
3 4371690 Glass, Door
4 816674 Foil, Alum. (2)
5 816675 Foil, Alum.
6 816676 Bracket, Glass
7 816679 Glass, Oven Door
8 4371253 Shield, Heat
9 4372311 Collar, Glass
10 816681 Glass,
Heat Barrier (2)
11 816687 Spacer, Glass
12 816682 Insulation, Door
13 816683 Liner, Oven Door
14 4371542 Screw, Handle
15 816685 Seal, Oven Door
16 816684 Seal, Rope
17 816712 Guide, Drawer
18 4372278 Panel, Drawer
19 4371060 Handle,
Utility Drawer
20 816716 Shield, Panel
21 816713 Spacer, Handle
22 4371062 Screw, Panel (5)
23 4371063 Screw, Handle (2)
24 4371671 Drawer, Utility
For Model: SF387PEYW4, SF387PEYN4, SF387PEYB4
(White) (Almond) (Black)
