CABINET PARTS REFRIGERATOR
For Models: GSS30C7EYW00, GSS30C7EYB00, GSS30C7EYF00, GSS30C7EYY00
(White) (Black) (Monochromatic Satina) (Monochromatic Stainless)
3−12 Litho In U.S.A. (wam) (psw) Part No. W10422331 Rev. B

CABINET PARTS
2W10422331
For Models: GSS30C7EYW00, GSS30C7EYB00, GSS30C7EYF00, GSS30C7EYY00
(White) (Black) (Monochromatic Satina) (Monochromatic Stainless)
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Literature Parts
W10407369 Use & Care Guide
W10329864 Service & Wiring
Sheet
W10337128 Energy Label
2 2150304 Front Roller
3
W10297485 Screw
4 12477102 Roller (Rear)
5 12477202 Axle, Roller
6
W10285005 Rivet, Roller
7
W10379525 Drain Tube Assy
8
W10257186 Bracket, Foot
9
W10141622 Foot, Brake
10
W10308750 Screw
11
W10238100 Valve, Inlet
12 Hinge, Top (FC)
W10247899 White
W10249920 Black
W10249922 Apollo Grey
13 Hinge, Top (RC)
W10247901 White
W10249923 Black
W10249925 Apollo Grey
14 Screw
W10142283 White
W10308487 Black
W10308489 Midnight Grey
15 Bottom Hinge (FC)
W10249940 White
W10249941 Black
W10249943 Apollo Grey
16 Bottom Hinge (RC)
W10257188 White
W10257207 Black
W10257209 Apollo Grey
17 Door Closer (RC)
W10247905 White
W10257195 Black
W10257197 Apollo Grey
18
W10141645 Screw
19 549193 Clamp, Service
Cord
20
W10333887 Cover, Unit
21 Filler, Wrapper
12587703W White
12587703B Black
12587703AP Apollo Grey
22 Grille
W10257231 White
W10257232 Black
W10257234 Midnight Grey
23
W10142234 Screw
24 Door Closer (FC)
W10247903 White
W10257198 Black
W10257200 Midnight Grey
25
W10001250 Screw
26
W10277956 Tube, Filter
Inlet
27
W10277957 Tube, Filter
Outlet
28
W10370680 Drain Fitting
29 12957702 Cover
30
W10235414 Elec. Control
31
W10120821 Elec. Control−15W
Power Supply
32 Cabinet (Not A
Serviceable Part)

REFRIGERATOR LINER PARTS
3
W10422331
For Models: GSS30C7EYW00, GSS30C7EYB00, GSS30C7EYF00, GSS30C7EYY00
(White) (Black) (Monochromatic Satina) (Monochromatic Stainless)
Illus. Part
No. No. DESCRIPTION
1 Liner (Not A
Serviceable Part)
2
W10260988 Escutcheon, Meat
Pan Control
3
W10260989 Slide, Meat
Pan Control
4
W10251495 Air Diffuser
Assembly
5
W10310320 Air Diffuser
Cover
6 C3680314 Switch
Rocker Arm
7
W10366790 Reservoir
8
W10279030 LED Light Assy
9
W10280385 Thermistor
10
W10342986 Air Filter Housing
11
W10315189 Air Filter
12
W10340015 Air Filter Cover
13
W10238123 Housing, Water
Filter
14
W10425251 Cover, Thermistor
15
W10271543 Connector,
1/4 x 5/16
16
W10260405 Cover, Water
Filter
17
W10295370 Water Filter

REFRIGERATOR SHELF PARTS
4W10422331
Illus. Part
No. No. DESCRIPTION
1 W10290493 Shelf, Snack Pan
2
W10282541 Cover, Assy
3
W10256800 Snack Pan
Includes 4 & 5
4
W10278139 Roller
5
W10257246 Axle, Roller
6
W10256801 Crisper Pan
Includes 4 & 5
7
W10256802 Meat Pan
Includes 4 & 5
8
W10257332 Housing, Humidity
9
W10257334 Slide, Humidity
10
W10276662 Shelf Assy
For Models: GSS30C7EYW00, GSS30C7EYB00, GSS30C7EYF00, GSS30C7EYY00
(White) (Black) (Monochromatic Satina) (Monochromatic Stainless)

5
FREEZER LINER PARTS
W10422331
For Models: GSS30C7EYW00, GSS30C7EYB00, GSS30C7EYF00, GSS30C7EYY00
(White) (Black) (Monochromatic Satina) (Monochromatic Stainless)

6
FREEZER LINER PARTS
W10422331
For Models: GSS30C7EYW00, GSS30C7EYB00, GSS30C7EYF00, GSS30C7EYY00
(White) (Black) (Monochromatic Satina) (Monochromatic Stainless)
Illus. Part
No. No. DESCRIPTION
1 Liner (Not A
Seviceable Part)
2
W10290894 Cover Assy
3
W10322802 Shelf, Glass
Upper
4
W10280386 Thermistor
5
W10322804 Shelf, Glass
Lower
6
W10322653 Pan, Freezer
Upper
Includes 7 & 8
7
W10278139 Roller
8
W10257246 Axle, Roller
9
W10322649 Pan, Freezer
Lower
Includes 7 & 8
10
W10419177 Switch, Rocker Arm
Ice Maker
11
W10425253 Cover, Thermistor
12
W10279030 LED Light Assy
13 12466114 Switch, Rocker Arm
Light

MOTOR AND ICE CONTAINER PARTS
7
W10422331
For Models: GSS30C7EYW00, GSS30C7EYB00, GSS30C7EYF00, GSS30C7EYY00
(White) (Black) (Monochromatic Satina) (Monochromatic Stainless)

MOTOR AND ICE CONTAINER PARTS
8W10422331
Illus. Part
No. No. DESCRIPTION
1 W10353207 Ice Bin Assy
2
W10258552 Latch, Assy
3 2220458 Coupling, Lower
4
W10258544 Drive Shaft
5 2198607 Spring, Coupling
6
W10293211 Mounting Plate
Assembly
7 2198628 Seal
8
W10291905 Gasket
9 2212370 Washer
10 2323603 Dispenser, Motor
11
W10238131 Motor Box Assy
12
W10166854 Gasket
13
W10287594 Cover, Container
100
W10353207 Ice Container
(Complete)
For Models: GSS30C7EYW00, GSS30C7EYB00, GSS30C7EYF00, GSS30C7EYY00
(White) (Black) (Monochromatic Satina) (Monochromatic Stainless)

9
REFRIGERATOR DOOR PARTS
W10422331
For Models: GSS30C7EYW00, GSS30C7EYB00, GSS30C7EYF00, GSS30C7EYY00
(White) (Black) (Monochromatic Satina) (Monochromatic Stainless)

REFRIGERATOR DOOR PARTS
10 W10422331
For Models: GSS30C7EYW00, GSS30C7EYB00, GSS30C7EYF00, GSS30C7EYY00
(White) (Black) (Monochromatic Satina) (Monochromatic Stainless)
Illus. Part
No. No. DESCRIPTION
1 Refrigerator Door
(Includes Item 5)
W10261181 White
W10372830 Black
W10372831 Mono Satina
W10372832 Mono Stainless
2 Set Screw
W10010140 Chrome
W10010150 Black
3
W10296816 Screw
4
W10335219 Door Bin, Gallon
5 Door Gasket,
Magnetic
W10247884 Mist Beige
W10249912 Black
W10249916 Apollo Grey
6 Handle
W10268056 White
W10268057 Black
W10274730 Satina Model
W10311213 Stainless
7 2200086 Thimble−Top
8
W10170540 Stud, Handle
9 Door Closer,
Upper Cam
W10248011 White
W10257201 Black
W10257203 Apollo Grey
10
W10296804 Screw
11
W10367462 Bracket, Door Stop
12 Nameplate
2220214 Gold
13 Cover, Door Stop
W10248013 White
W10257216 Black
W10257218 Midnight Grey

11
FREEZER DOOR PARTS
W10422331
For Models: GSS30C7EYW00, GSS30C7EYB00, GSS30C7EYF00, GSS30C7EYY00
(White) (Black) (Monochromatic Satina) (Monochromatic Stainless)

12
FREEZER DOOR PARTS
W10422331
For Models: GSS30C7EYW00, GSS30C7EYB00, GSS30C7EYF00, GSS30C7EYY00
(White) (Black) (Monochromatic Satina) (Monochromatic Stainless)
Illus. Part
No. No. DESCRIPTION
1 Freezer Door
(Includes Item 8
And Dispenser
Front Parts)
W10369950 White
W10369951 Black
W10369952 Mono Satina
W10369953 Mono Stainless
2 Handle
W10268056 White
W10268057 Black
W10274730 Satina Model
W10311213 Stainless
3 2200086 Thimble−Top
4
W10296804 Screw
5
W10170540 Stud, Handle
6
W10335217 Door Bin
7
W10296816 Screw
8 Door Gasket,
Magnetic
W10247885 Mist Beige
W10249913 Black
W10249917 Apollo Grey
9 Door Closer,
Upper Cam
W10248015 White
W10257204 Black
W10257206 Apollo Grey
10 Bracket, Door Stop
W10247907 Chrome
11 Set Screw
W10010140 Chrome
W10010150 Black
12 Cover, Door Stop
W10257220 White
W10257221 Black
W10257223 Midnight Grey
13 2198634 Pin
14 2198635 Spring
15
W10258502 Cover, Emitter
16
W10180607 P.C. Board,
Emitter
17
W10258510 Cover, Receiver
18
W10296530 P.C. Board,
Receiver
19
W10258520 Flipper
20
W10258540 Slide, Ice Maker
Shut Off
21
W10242369 Harness, Emitter
& Receiver

DISPENSER FRONT PARTS
13
W10422331
For Models: GSS30C7EYW00, GSS30C7EYB00, GSS30C7EYF00, GSS30C7EYY00
(White) (Black) (Monochromatic Satina) (Monochromatic Stainless)

DISPENSER FRONT PARTS
14 W10422331
Illus. Part
No. No. DESCRIPTION
1 Housing, Dispenser
(Not Serviced)
2
W10276209 Grate, Drip Tray
3
W10174827 Bracket, Ice Door
4
W10339578 Chute, Door
5
W10205978 Motor, Ice Door
6
W10353566 Ice Door
Assembly
(Includes Items
3, 5, 7, & 8)
7
W10346124 Support, Ice Door
8 4449745 Screw
9 Trim Ring
W10276265 White
W10254252 Chromium Frost
10 2305235 Spigot
11 Electronic
Control Assy
W10404394 Silver Mirror
W10404395 Storm Cloud
12 Pad, Ice & Water
W10370583 White
W10370577 Black
W10370582 Midnight Grey
13 Tray, Housing
W10254258 White
W10254259 Black
W10276225 Satina
For Models: GSS30C7EYW00, GSS30C7EYB00, GSS30C7EYF00, GSS30C7EYY00
(White) (Black) (Monochromatic Satina) (Monochromatic Stainless)

UNIT PARTS
15
W10422331
For Models: GSS30C7EYW00, GSS30C7EYB00, GSS30C7EYF00, GSS30C7EYY00
(White) (Black) (Monochromatic Satina) (Monochromatic Stainless)

UNIT PARTS
16 W10422331
For Models: GSS30C7EYW00, GSS30C7EYB00, GSS30C7EYF00, GSS30C7EYY00
(White) (Black) (Monochromatic Satina) (Monochromatic Stainless)
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 W10271541 Connector, 5/16
2 12825802 Fan, Blade
3
W10276899 Condenser
Assembly
4
W10142255 Screw
5
W10204187 Clip
6
W10171469 Screw
7
W10277958 Connector, 1/4
8
W10303521 Sleeve
9
W10142294 Screw
10 Start Device
Combination
Relay & Overload
W10197427 Production
2304884 Service
11
W10219381 Tube Suction
12
W10248621 Clip, Condenser(2)
13 Capacitor
2264017 Production
2264017 Service
14 2325479 Process Tube
15 2205813 Strap
16
W10239732 Evaporator
17 2161324 Clamp
18 2188874 Fan, Motor
19
W10238584 Tray, Evaporator
20
W10223361 Heat Shield
21 Drier
W10177049 Production
2317845 Service
22
W10209479 Harness, Wiring
Water Valve/Diode
23
W10277704 Support Plate,
Compressor
24
W10242407 Power Cord
25
W10251467 Air Baffle
26
W10239728 Heater, Defrost
27
W10296661 Clip
28
W10120457 Compressor
(Includes Items
10, 13, 21, & 29)
(Also Order
876765 Tube Kit)
29 Grommet (4)
10835903 Production
4387558 Service
30
W10356137 LED Power Supply
31
W10278140 Unit Cover, Bottom
Following Parts Not Illustrated
and Optional Parts Not Included
978025 Valve, Access
(1/4")
978026 Valve, Access
(5/16")
978027 Valve, Access
(3/8")
978028 Valve, Access
(1/2")
978029 Valve, Access
(5/8")
978030 Valve, Access
(3/4")
876764 Valve, Access
(3/16")

ICEMAKER PARTS
17
W10422331
For Models: GSS30C7EYW00, GSS30C7EYB00, GSS30C7EYF00, GSS30C7EYY00
(White) (Black) (Monochromatic Satina) (Monochromatic Stainless)

ICEMAKER PARTS
18 W10422331
Illus. Part
No. No. DESCRIPTION
1 W10237915 Bracket, Valve
2 628379 Clip, Fuse
3
W10238092 Water Tube
4 489478 Screw
5
W10341320 Filter Valve Asm
6 8533917 Screw
7
W10251088 Cover
8
W10141625 Screw
9
W10251081 Mold & Heater
Assembly (Also
Order 542638
10
W10348890 Fill Tube Assy.
11
W10318644 Ejector
12
W10251078 Ice Striper
13 2194712 Support
14 2315522 Retainer,
Thermostat
15 2321258 Thermostat (Also
Order 542369
Cement
Alumilastic)
16 8533917 Screw
17
W10251080 Bracket, Mounting
18
W10242365 Harness, Wiring
19 626691 Module Assembly
20 489136 Screw
21 Motor
(Not Serviced,
Order #19)
100
W10122576 Complete Icemaker
Assembly
For Models: GSS30C7EYW00, GSS30C7EYB00, GSS30C7EYF00, GSS30C7EYY00
(White) (Black) (Monochromatic Satina) (Monochromatic Stainless)

AIR FLOW PARTS
19
W10422331
Illus. Part
No. No. DESCRIPTION
1 W10251462 Fan Scroll
2
W10260421 Retainer,
Fan Motor
3
W10251478 Air Duct, Upper
4
W10260437 Bi−Metal, Defrost
5
W10260384 Air Duct Freezer
6 489290 Screw
7 2315549 Fan Motor
8 2169142 Fan Blade
9
W10240370 Gasket, Evaporator
Cover
10 2176759 Fan Grommet (2)
11
W10274578 Clip, Mounting
12
W10242409 Harness, Fan
Evaporator
(Includes #4)
13
W10142292 Screw, Evap Cover
14
W10388269 Cover, Evaporator
(Includes #9)
15
W10331728 Clip, Air Duct
For Models: GSS30C7EYW00, GSS30C7EYB00, GSS30C7EYF00, GSS30C7EYY00
(White) (Black) (Monochromatic Satina) (Monochromatic Stainless)

OPTIONAL PARTS (NOT INCLUDED)
20 W10422331
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
PAINT, PRESSURIZED SPRAY
(12 oz.)
350942 Primer, White
350939 Black
350930 White
4392901 Biscuit
8171357 Graphite
PAINT, TOUCH−UP (1/2oz.)
72017 White
72032 Black
4392899 Biscuit
80051 Graphite
Important: The spray paint is
not to be used where the paint
may make contact with the door
gaskets.
PAINT, BULK (1 qt.)
799344 White
4392900 Biscuit
8171358 Graphite
Miscellaneous
W10300794 Handle
Installation Kit
212643 Sealer, Gum
(4 Feet)
479502 Tape, Vinyl
(3/4 x 108")
505587 Sealer, Mastic
(1 Qt.)
503695 Cork, Sealer
(1/4 Pound)
542638 Grease, Silicone
(1/2 Oz.)
542639 Cement,
Alumilastic
(1−1/4 Oz.)
833938 Kit, Terminal
Connector
TORX SCREW WRENCH
1117510 Torx Key
For Models: GSS30C7EYW00, GSS30C7EYB00, GSS30C7EYF00, GSS30C7EYY00
(White) (Black) (Monochromatic Satina) (Monochromatic Stainless)
