Whirlpool AKR 689 Assembly instructions


5019 318 33006
AKR 689
AKR 989
INSTALLATIONSANGABEN
Mindestabstand zur Kochfläche: 60cm (Elektroplatten), 75cm (Gas-, Öl- oder Kohleflammen).
Folgen Sie bei der Installation der Nummerierung (1Ö2Ö3Ö.....).
Schließen Sie das Gerät erst nach erfolgter Installation an die Stromversorgung an.
Das Auslaßrohr (13A) wird nicht mitgeliefert und muß gesondert gekauft werden.
INSTALLATION SHEET
Minimum height above cooker: 60cm (electric cookers), 75cm (gas, gas oil or coal cookers).
To install follow points (1Ö2Ö3Ö.....).
Do not connect the appliance to the electrical power supply until installation is completed.
The exhaust pipe (13A) is not provided and should be bought separately.
FICHE D'INSTALLATION
Distance minimale par rapport à la cuisinière : 60cm (cuisinière électrique), 75cm (cuisinière à
gaz, mazout ou charbon).
Pour le montage, suivez la numérotation (1Ö2Ö3Ö.....).
Ne branchez pas l'appareil tant que l'installation n'est pas terminée.
Le tuyau d'évacuation (13A) n'est pas fourni avec l'appareil et doit être acheté à part.
INSTALLATIEKAART
Minimumafstand tot het kooktoestel: 60cm (elektrische kooktoestellen), 75cm (kooktoestellen
op gas, olie of kolen).
Volg voor de montage de nummering (1Ö2Ö3Ö.....).
Geef het apparaat geen stroom totdat de installatie geheel voltooid is.
De afvoerleiding (13A) wordt niet bijgeleverd en dient apart aangeschaft te worden.
D
GB
F
NL
31833006.fm5 Page 1 Monday, June 25, 2001 12:20 PM


5019 318 33006
AKR 689
AKR 989
FICHA DE INSTALACIÓN
Distancia mínima desde los quemadores: 60cm (fuegos eléctricos), 75cm (fuegos de gas, gasóleo
o carbón).
Para el montaje, siga la numeración (1Ö2Ö3Ö...).
No enchufe el aparato hasta que su instalación no esté terminada.
El tubo de descarga (13A) no se suministra de fábrica y debe comprarse aparte.
FICHA DE INSTALAÇÃO
Distância mínima dos fogões: 60cm (fogões eléctricos), 75cm (fogões a gás, óleo ou carbono).
Para montar siga a numeração (1Ö2Ö3Ö.....).
Não ligue o aparelho à corrente eléctrica até a instalação estar concluída.
O tubo de descarga (13A) não está incluído e deve ser adquirido em separado.
SCHEDA INSTALLAZIONE
Distanza minima dai fuochi: 60cm (fuochi elettrici), 75cm (fuochi a gas, gasolio o carbone).
Per il montaggio seguire la numerazione (1Ö2Ö3Ö.....).
Non dare corrente all’apparecchio finchè l’installazione non è totalmente completata.
Il tubo di scarico (13A) non è a corredo e deve essere acquistato a parte.
ùüùü+ùùùþ
ü$12.)12.1.)2"0120"FP02!"0120"FP0120".0! #
02!0. #0! # 
+.22 21.  #1202.!1ÖÖÖ
2! 3/2020002!)!0*.21#10#!2 !&12"
0.212.1"
1&."..&"$/0/.202.02. !! 32!..!0.
. 20$&!12
E
P
I
GR
31833006.fm5 Page 2 Monday, June 25, 2001 12:20 PM


5019 318 33006
AKR 689
AKR 989
11
1
3
3
4-9
4-9
6
7
7
8
8
5
5
13A
10
10
12
13F
14
15
15
2
14. Stromanschluss vorbereiten
14. Prepare the electrical connection
14. Préparez le raccordement électrique
14. Voorbereiding van de elektrische aansluiting
14. Prepare la conexión eléctrica
14. Preparar a ligação eléctrica
14. Preparare il collegamento elettrico
! 02 120202!1*/01
13F. NUR in der Umluftversion
13A. NUR in der Abluftversion
13F. for Filter Version ONLY
13A. for Extractor Version ONLY
13F. UNIQUEMENT pour Version Recyclage
13A. UNIQUEMENT pour Version Évacuation
13F. ALLEEN voor Filterversie
13A. UITSLUITEND voor model met luchtafvoer
naar buiten
13F. SÓLO para el Modelo Filtrador
13A. SÓLO para el Modelo Aspirador
13F. APENAS para Versão com Filtro
13A. APENAS para Versão com Aspiração
13F. SOLO per Versione Filtrante
13A. SOLO per Versione Aspirante
). 2 -2!.!1.2 "
$. 2 ù.!!)31"
31833006.fm5 Page 3 Monday, June 25, 2001 12:20 PM


5019 318 33006
AKR 689
AKR 989
I
1. Control panel
2. Grease filters
3. Grease filter handles
4. Light above cooker
5. Telescopic flue
To clean the grease filter
Clean the grease filter once a month.
1. Disconnect the electrical power supply.
2. Remove the grease filters - Fig. 1:
a- push the handles backwards
b- and then downwards.
3. After cleaning the grease filter refit in reverse
order, making sure the entire extraction surface
is covered.
Fitting or renewing the carbon filter:
1. Disconnect the electrical power supply.
2. Remove the grease filters (Fig. 1 - a,b).
3. If the carbon filters are already mounted (two
filters covering the motor protection grille) and
need renewing, turn the central handle
anticlockwise until the filters release.
4. If the filters (c) are not fitted (Fig. 2) locate one
on each side to cover both motor protection
grilles, then turn the central handle (d) of the
filters clockwise.
5. Replace the grease filters.
Replacing bulbs
1. Disconnect the electrical power supply.
2. Remove the grease filters (Fig. 1 - a,b).
3. Remove the burnt-out bulb.
Replace using 40W max (E14) bulbs only.
4. Replace the grease filters.
THE CONTROL PANEL
A. Light switch.
B. Led indicator.
C. Speed selector switch.
1
2
2
5
3
4
3
1
f
Fig.1
Fig.2
PRODUCT SHEET
D F NL EP GR
GB
