TOP AND CABINET PARTS
1
For Models: WFW8400TW00, WFW8400TB00
(White) (Black)
10−07 Printed in U.S.A. (drd) Part No. W10139064 Rev. B
AUTOMATIC WASHER

TOP AND CABINET PARTS
2
For Models: WFW8400TW00, WFW8400TB00
(White) (Black)
W10139064
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Literature Parts
W10117768 Use & Care Guide
W10071760 Tech Sheet
Energy Guide
W10128102 White Model
W10157937 Black Model
8540316 Quick Start Guide
2 Top
8540716 White
W10128645 Black
3 Cabinet
8540548 White
W10117456 Black
4 Panel, Front
8540572 White
W10128427 Black
5 Toe Panel
8540813 White
W10112981 Black
6
W10121677 Foot, Leveling (4)
7
W10110676 Strain Relief,
Power Cord
8 3359452 Nut, Lock (4)
9 8518891 Rivet (2)
10 8540580 Panel, Rear
11 8540581 Brace, Transport
12 8540199 Bolt, Shipping (4)
13 Hose, Water Inlet
8571377 Blue Coupler
8571378 Red Coupler
14
W10121405 Cord, Power
15 8540540 Motor Control Unit
16 8540974 Brace, Rear
17 8540093 Clamp, Tube
Transportation
18 8540011 Hose, Drain
19 8540607 Retainer,
Hose Outlet
20 238614 Bumper (2)
21
W10015090 Screw, 8−18 x 5/8
22 8540230 Filter,
Interference
23 8540224 Switch, Pressure
24 8540294 Hose, Pressure
Switch
25 8540479 Screw, Grounding
26 8540268 Cover, Transport
27 8540021 U−Bend,
Drain Hose
28
W10085220 Microswitch (2)
29 8540728 Sleeve,
Cord Support (2)
30 8540727 Screw, 3 x 8 mm
31 8540329 Screw
32 8540720 Brace, Top
(Includes Item 33)
33 8283273 Damper, Brace
34 2161302 Sleeve, Pressure
Switch Hose
35 3347868 Cable Tie
36 16123 Washer, Water
Inlet Hose (4)
1−1/16 x 5/8
37 8540290 Harness Channel,
Top Rear
38 8540288 Harness Channel,
Side Front
39 8540289 Harness Channel,
Side Rear
40 8540669 Bracket,
Console Retainer
41 8533954 Screw
42 8540644 Bracket, Spring

DOOR AND LATCH PARTS
3
For Models: WFW8400TW00, WFW8400TB00
(White) (Black)
W10139064
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 8540108 Clamp, Bellow
To Tub
2 8540952 Bellow
3 8540772 Lock, Door
4 8540725 Screw
5 8540221 Hook, Door
6 Trim Ring,
Outer Door
8540533 Nestle White
W10135726 Tempest Grey
7 8540107 Clamp, Bellow
To Front Panel
8 8540115 Clamp, Support
9 8540114 Clamp, Glass (2)
10 8540513 Screw
11 Frame, Door
Front Assembly
8540588 Nestle White
W10128432 Whistler Grey
12 8540428 Glass, Door
13
W10138523 Frame, Door
Back Support
14 8540416 Hinge, Door
15 8540284 Screw
16 8540282 Screw
17
W10015090 Screw

CONTROL PANEL PARTS
4
For Models: WFW8400TW00, WFW8400TB00
(White) (Black)
W10139064
Illus. Part
No. No. DESCRIPTION
1 Panel, Control
W10132001 White
W10131963 Black
2 Knob, Control
8574963 Nestle White
W10129067 Tempest Grey
3 User Interface
8574920 White Model
W10149382 Black Model
4 8540558 Brace, Top Front
5 8540839 Channel, Water
6
W10160253 Microcomputer,
Machine Control
7 3390647 Screw, 8−18 x 1/2
8 8540524 Harness, Wiring
(Main)
9 8540282 Screw
10
W10015090 Screw, 8−18 x 5/8

DISPENSER PARTS
5
For Models: WFW8400TW00, WFW8400TB00
(White) (Black)
W10139064
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 8540751 Valve, Inlet
2 8540065 Hose, Valve
To Dispenser
3 370450 Clamp, Hose
4 8540282 Screw
5 8540042 Nozzle, Inlet
6 8540393 Cam, Actuator
7 8540394 Lever, Water
Distribution
8 8540041 Actuator
9 VS611 Washer
10 8281276 Clamp, Hose
11 8540395 Connection, Lever
12 8540058 Dispenser
13 8540053 Nozzle,
Distribution
14 8540063 Hose, Dispenser
To Tub
15 Handle, Drawer
8574948 White
W10099634 Black
16
W10117943 Medallion
17 8540402 Drawer,
Detergent
18 8540399 Cover,
Detergent Drawer
19 8540429 Siphon,
Bleach/Softener
20 8540400 Hook, Drawer

PUMP AND MOTOR PARTS
6
For Models: WFW8400TW00, WFW8400TB00
(White) (Black)
W10139064
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 8540525 Harness, Motor
2 8540033 Cap, Lock Foot
3 8540180 Air Trap
4 8540013 Ball
5 8540008 Clamp
6 8540012 Hose,
Tub to Pump
7 370448 Clamp
8
W10034820 Foot, Rubber
(Slider)
9 356138 Clamp, Hose
10
W10130913 Pump (Complete)
11
W10034830 Foot, Rubber
(Lock)
12 8533964 Screw,
10−16 x 1.25 (2)
13 8540025 Seal, Filter Cap
14 8540996 Filter Assembly
(Includes Item 13)
15
W10140581 Motor, Drive
16 8540134 Bolt, Motor

TUB AND BASKET PARTS
7
For Models: WFW8400TW00, WFW8400TB00
(White) (Black)
W10139064

TUB AND BASKET PARTS
8
For Models: WFW8400TW00, WFW8400TB00
(White) (Black)
W10139064
Illus. Part
No. No. DESCRIPTION
1 8533999 Nut, Pulley
2 8540088C Pulley
3 8540101 Belt, Drive
4 8540600 Counterweight,
Front Lower
5
W10112169 Pipe, Ventilation
6 8540010 Clamp, Vent Hose
7 8540019 Hose, Exhaust
8
W10112663 Tub, Rear
(Includes Items
10 & 22)
9 8540604 Counterweight,
Rear
10 8540090 Gasket, Tub
11 8540357 Basket, Complete
12 8540360 Baffle, Tub
13 8540323 Element, Heating
14 8534084 Nut, Shock
Absorber Mounting
15 8540598 Counterweight,
Front Upper
16
W10010360 Spring,
Suspension
(Set Of 2)
17
W10094780 Bolt,
Counterweight Mtg.
18 3363365 Clamp, Hose
19 8540015 Hose, Exhaust
20 8540092 Clamp, Tub
21
W10112664 Tub, Front
(Includes Items
10, 22, 30 & 31)
22 8540072 Nut, Push−In
23
W10084740 Shock Absorber
24 8540226 Negative
Thermistor Control
25 8540382 Screw
26 8540342 Crosspiece Asm
27 8540940 Bracket, Shock
Absorber Mounting
28 8540841 Bolt, Shock Brkt.
29 8540842 Nut, Shock Brkt.
30 8540322 Bracket,
Heating Element
31 8540880 Screw

OPTIONAL PARTS (NOT INCLUDED)
9
For Models: WFW8400TW00, WFW8400TB00
(White) (Black)
W10139064
Illus. Part
No. No. DESCRIPTION
PAINT, TOUCH−UP (1/2oz.)
72017 White
72032 Black
PAINT, PRESSURIZED SPRAY
(12 oz.)
350938 Primer, Gray
350930 White
786020 Black
PAINT, BULK (1 qt.)
799344 White (Uncut)
786032 Black (Uncut)
ACCESSORY PARTS
285863 Drain Extension
