Dear customer,
Thank you for choosing our product.
Please read these instructions carefully before connecting and using the machine. An awareness
of how the machine operates will help guarantee its correct and safe use. The instructions also
contain some useful information on the machine’s functions that will help you get the most out of its
use.
If you decide to sell or give the washing machine to someone else, remember to give the instruc-
tion book to the new owner.
NOTES AND ADVICE FOR THE USER 14-15
DESCRIPTION OF THE MACHINE 15
INSTALLING THE MACHINE 16-18
• Unpacking and unblocking the machine 16
• Positioning and levelling the machine 17
• Connecting to the water supply system 17
• Connecting to the power supply 18
USING THE WASHING MACHINE 18-20
• Using the machine 18
• Use of detergents 19
• How to eliminate stains 20
• International clothing care symbols 20
MAINTENANCE 21-22
• Cleaning the machine 21
• Cleaning the filter 21
• Troubleshooting 22
MODEL: .....................................................................................................................................................................................................................
PRODUCTION CODE: .................................................................................................................................................................................
DATE OF PURCHASE: ...........................................................................................................................................................................................
GB

14
SM1633
NOTES AND USEFUL ADVICE FOR THE USER
Do not plug-in or unplug
the machine with wet
hands.
Unplug the washing ma-
chine from the power
supply before servicing
and cleaning.
To disconnect the ma-
chine from the power sup-
ply, pull the plug and not
the cable.
After the end of each
washing cycle it is advis-
able to unplug the ma-
chine and shut-off the
water supply.
Do not expose the appli-
ance to atmospheric
agents.
The power supply socket
to which the machine is
connected must be
earthed and must comply
with the safety require-
ments
Extension leads or multiple
adapters must not be used
to connect the washing
machine to the mains sup-
ply.
GB
❃The washing machine has been designed for
domestic use only, and as such any other
use is regarded as improper and therefore
potentially dangerous.
❃Any modifications or attempts to alter the
equipment in any way may be dangerous for
the user and cause damage to the washing
machine.
❃Due to the weight of the machine, special
safety standards must be observed during
handling.
❃The machine must not be used by unsuper-
vised children.
❃Any modifications to the water or electrical
system must be carried out by authorised
specialists.
❃When positioning the appliance, make sure
that the power supply cable is not bent or
squashed and that it is accessible.
❃Before operating the machine, remove all
packing materials and the locking device
used for protection during transport (protec-
tion screws). Failure to do this may result in
serious damage to the machine and to your
home.
❃If the machine is installed on a carpeted floor,
make sure that air is free to circulate between
the machine and the floor.
❃The washing machine must never be over-
loaded.
❃When the machine is in operation, avoid any
contact with the water coming out of the drain
hose, as this may be hot. Do not touch the
door glass as this may also heat up during
the wash
❃Only wash clothes that are machine wash-
able. In case of doubt, check the manufac-
turer’s instructions found on the label at-
tached to the clothes (see “Clothing cares
symbols “ ) .
❃Before loading clothes into the washing ma-
chine, check that all the pockets are empty.
Hard or pointed objects such as coins, pins,
nails, screws or even stones can cause seri-
ous damage.
The door can only be
opened approximately
three minutes after the end
of each wash, as a safety
device has been fitted to
protect from accidental
opening.
N.B. for electronic models
the door will open when the
“end” indicator lights up

SM1633
15
NOTES AND USEFUL ADVICE FOR THE USER
DESCRIPTION OF THE MACHINE
THE MANUFACTURERWILL NOT BE HELD
RESPONSIBLE FOR ANY ACCIDENTS
THAT MAY RESULT FROM NON-COMPLI-
ANCE WITH THE REQUIREMENTS OF
SAFETY STANDARDS OR THIS INSTRUC-
TION MANUAL
A- Glass door
B- Filter
C- Adjustable feet
D- Top cover
E-Drum
F- Control panel
1
The washing machine is a household appliance that can wash any type of fabric whenever you want.
▼The structure of the machine is fabricated in steel sheet, which has been worked using a special
process and then enamelled in order to maintain its external appearance and protect it against
corrosion.
▼The motor and all the other moving parts are built to ensure noiseless machine operation.
▼The large stainless steel drum is well placed to guarantee a good wash quality and prolong the life
of the washing.
▼The easy to use control panel makes the selection of any wash or dry programme quick and
simple (see control panel and table of programmes).
▼The ample glass door makes loading and unloading easier.
▼The perfect machine balance is the result of many years of research aimed at finding the correct
balance between the various moving parts.
GB
❃Clothes that have been dirtied with sub-
stances containing petroleum cannot be
washed in the machine. If stains have been
removed using vaporising products, before
loading the clothes in the washing machine,
wait until the substances have completely
evaporated from the material.
❃Do not use detergents formulated for hand
washing, in that the excessive lather pro-
duced could damage the internal compo-
nents.
❃After washing rugs, blankets or any other long
fibre fabrics, remember to check the filter and,
if necessary, clean it.
❃It is advisable to leave the door open at the
end of the wash cycle.
❃Under no circumstances should any repairs
to the machine be attempted by unqualified
persons as this could result in serious dam-
age and will invalidate the guarantee.
❃Repairs to the washing machine must only
be carried out by persons authorised to do
so by the service centres. Only original spare
parts may be used for repairs.

SM1633
16
INSTALLING THE MACHINE
(ACCORDING TO MODEL)
For transport purposes the swinging unit in the machine is blocked using 4
spacers with screws. Before starting the machine these spacers and lock screws
must be removed, and stored for use in the event of a possible change of
location.
Block off the holes with the plugs provided, which can be found in the bag
containing the documents.
N.B. If the spacers fall into the inside of the machine, open the rear panel,
recover them and then replace the panel.
For transport purposes the swinging unit in the machine is blocked using 4
spacers with screws. Before starting the machine these screws must be re-
moved using a screwdriver.
Insert a screwdriver in the holes and proceed as shown in the figure to recover
the 4 plastic spacers.
N.B. If the spacers fall into the inside of the machine, open the rear panel,
recover them and then replace the panel.
The machine must be installed by professionally qualified technicians, according to
the manufacturer’s indications. Incorrect installation may result in damage to per-
sons and property.
The machine can be installed anywhere, provided the temperature in the place of
installation is not below 3°C and the cables and hoses at the rear of the machine are
not crushed in any way.
V
2
3A
2A
3
GB

SM1633
17
INSTALLING THE MACHINE
SETTING THE MACHINE LEVEL
After selecting a suitable position, level the machine carefully using the adjustable
feet (Fig. 4). Particular care must be taken when selecting the position, levelling the
washing machine and ensuring the safety of lock nuts.
If levelling is not carried out correctly, the washing machine will be unstable and
noisy during operation, which may result in damage.
If the machine stands on a carpet floor, make sure that air can circulate freely be-
tween the washing machine and the floor itself.
It is not recommended that the machine be installed in locations where the tempera-
ture is liable to drop below freezing.
CONNECTION TO THE WATER SUPPLY SYSTEM
▼The mains water pressure must be between 0.05 and 1.00 MPa (0.5 - 10 bar.)
▼Before connecting the water fill hose, open the valve and allow a quantity of
water to flow. This will censure that the supply pipes are free from impurities,
such as sand or rust (this operation is very important when the washing ma-
chine is being connected to a new supply system or if the system has not been
used for a long period of time).
▼Connect the water fill hose to a 3/4 threaded cold water outlet.
▼Place the filter washer supplied between the hose and the valve and hand
tighten the connection as much as possible (fig. 5).
▼Fit the washer on the other end of the supply hose, and screw it onto the
washing machine (fig. 6).
▼The water supply tap must be fully open when washing.
▼The water drain hose must be placed at least 60 cm and not more than 90 cm
from the floor (fig. 7).
▼If the drain hose is connected to a fixed drainage system, the free end must be
inserted in a pipe of minimum internal diameter 40 mm.
▼The drain hose water connection to the drainage system must not be
hermetically sealed, as this would cause air to accumulate and the water to
siphon out.
▼If the waste water is to be discharged into a sink or washbasin, insert the hose
in the special bracket supplied and hook it over the edge of the sink or wash-
basin. Then tie the hose and bracket to a tap or similar (fig. 8). To avoid over-
flowing, the sink drain must be clear of obstructions and must be able to empty
quickly.
8
7
6
5
4
GB
N.B.: With washing machines which are equipped with a double electro-
valve (for hot and cold water), connect the red tube, to the hot water
tap and the other tube to the cold water tap.

SM1633
18
INSTALLING THE MACHINE
CONNECTING TO THE POWER SUPPLY
▼Check that the voltage indicated on the technical data plate on the back of the
washing machine is the same as that of the mains power supply (fig. 9).
▼The fuses, electric cables and wall socket must be rated to withstand the maxi-
mum power load indicated on the data plate.
▼The power supply socket into which the washing machine will be plugged must
be earthed. Otherwise, the manufacturer will not be held responsible for any
accidents (fig. 10).
▼If the socket to which the machine will be connected is faulty or does not com-
ply with the requirements, it must be replaced by a qualified electrician.
▼The washing machine must not be connected to the electricity supply using
extension leads or multi-plug adapters.
▼During maintenance the washing machine must be unplugged from the power
supply socket.
▼Do not plug-in or unplug the machine with wet hands.
▼If the power cable is damaged in any way, contact the specialised technical
service centre.
▼Position the appliance so that the power supply cable can be accessed with
ease, enabling it to be disconnected when required.
USING THE MACHINE
10
11
12
9
ADVICE BEFORE USING
Attention: Before running the machine loaded for the first time, we re-
commend that you run a short washing cycle with the ma-
chine empty.
This makes it possible to check operation of the machine and clean the
drum.
Each time you use the machine:
▼ check that all water connections are tight, the drain hose is positioned cor-
rectly (see connection to the water supply) and the supply tap is open.
▼ make sure that your hands are dry, then insert the plug into the power socket.
▼ divide the washing according to fabric type (check the labels on the clothes).
▼ check that the clothes to be washed have nothing in their pockets that might
damage the washing, the washing machine or the filter
GB

SM1633
19
USING THE MACHINE
GB
USE OF DETERGENTS
The washing machine has a three-compartment detergent drawer.
Compartment 1 on the right is for the pre-wash soap powder (1)
Compartment 2 on the left is for liquid detergent or soap powder for the
main wash (2)
The centre compartment is for softener, perfume, starch. (3)
use a low-foam detergent and softener (if necessary), of the type indicated for
automatic washing machines. Use the doses recommended on the package.
N.B. Excessive amounts of detergent may result in too much foam, and
give a poor quality wash. Insufficient amounts of detergent may mean
that the washing does not come properly clean.
N.B. When filling the detergent compartment it is important that the detergent
does not overflow into the compartment used for fabric softener, as this would
result in a rinse cycle containing soap, which might leave the washing with
white stains. Equally, do not allow the fabric softener to overflow into the deter-
gent compartment, as this would reduce the cleaning capacity.
N.B. When using a liquid detergent (recommended for programs without
pre-wash) proceed as follows: remove the baffle from its housing at the
front of compartment 2 and insert it in the guides near the centre of the
same compartment.
Remember to replace it in its front housing when using soap powder.
▼close the detergent drawer before starting the wash.
Attention! Never remove the detergent drawer when the machine is run-
ning, as water may come out of it.
YES
NO
18
15
16
19
17

SM1633
20
USING THE MACHINE
Some stains cannot be removed by just washing in a washing machine. Before trying to remove any
type of stain by hand, first try the removal procedure on a small area of hidden fabric starting from the
edge of the stain and working inwards, this will prevent a dark ring from forming around the site of the
stain. A few methods for removing stains are reported below.
INTERNATIONAL CLOTHING CARE SYMBOLS
Before placing the clothes in the washing machine and selecting the wash programme, examine the
symbols on the manufacturer’s label. The table reported below will provide a useful guide to reading
the symbols.
HOW TO REMOVE STAINS
GB
●
W AX : scrape the wax using a blunt point in
order not to damage the fabric. Then, with
the fabric placed between two pieces of ab-
sorbent paper, run a hot iron over the stain.
●
B ALL - POINT PENS AND FELT - TIP PENS : clean using
a soft cloth soaked in ethyl alcohol. Take
care not to spread the mark.
●
D AMP AND MOULD : if the fabric supports the use
of bleach, perform a wash cycle adding
bleach to the appropriate compartment in the
dispenser (see table of programmes). Other-
wise, soak the soiled part in hydrogen per-
oxide (10 volumes) and leave for 10 to 15
minutes.
●
L IGHT SCORCH MARKS CAUSED BY IRONING : follow
the instructions for mould and damp.
●
R UST : use products specially designed for rust
stains, following the manufacturer’s instruc-
tions written on the packet.
●
C HEWING GUM : rub ice over the mark, scrape
away as much as possible and then rub with
a cotton cloth soaked in acetone (alterna-
tively, use nail varnish remover).
●
P AINT : do not allow the paint to dry. Rub the
area with the solvent recommended by the
paint manufacturer (e.g. water, turps, trichlo-
roethylene), apply soap and then rinse.
●
L IPSTICK : stains on cotton or wool can be
eliminated using a cloth soaked in ether.
Stains on silk require the use of trichloroeth-
ylene.
●
N AIL VARNISH : place a sheet of absorbent
paper on the stained material, then dampen
the back of the fabric with acetone, fre-
quently changing the paper placed over the
stain. Continue like this until the stain has
disappeared.
●
T AR OR DIRT : spread some fresh butter over
the stain, allow to stand and then wash with
oil of turpentine.
●
G RASS : delicately soap the stain, use diluted
bleach. Good results can be obtained on
woollen fabrics using 90% alcohol.
●
B LOOD : put into soak in cold water with
added salt, then wash with washing soap.
