WHITEMEADOW Bed Frame User manual

Bed Frame Assembly Instruction Guide
Please check you have the correct ttings and read through before
commencing with assembly
Supplied Fittings
A B C D E F
x 9 x 4 x 4 x 5 x 6x 1
01WM-01E 2019-05-19

Remove small plastic foot by unscrewing
Use the supplied screw to secure the leg in place, stopping it from
rotating out of position ( This step doesn’t apply to cylindrical legs)
Screw in optional leg, positioning the screw hole
on the inside. Do not over tighten
Please move to step 4 if you aren’t using the legs
x4 Screws supplied with legs
Step 1
Step 3
Step 2

Slot the side rail onto the bolts on the
headboard.
Quick tip: It’s easier to t the side rails at a
slight angle
Use the allen key provided (A) to tighten the
bolts onto the brackets
Repeat steps 5 and 6 for both sides to attach the
headboard and footend to the side rails
Place the 2 frames together and put the two at bars on each side.
Slot bolt (E) through, starting with the at bar that has square holes.
Use a anged nut (B) and tighten up using the spanner provided.
Once completed, place the metal frame to one side.
Step 4
Step 5 Step 6
x5
E
B

Place metal frame onto the brackets and secure with bolt (D),
washer (C) and anged nut (B) as shown. Repeat for the 4 brackets
on the side rails.
(The brackets on the headboard and footend do not need bolting)
x4
Slot the frame brackets (F) onto the side rails, footend and headboard in the
desired position. Ensure all brackets are set at the same height level
x6
Step 7
Step 8
F
D
C
B
Your bed is now fully assembled.
Please do not use without a mattress and periodically check that all
xings are tightened correctly
