Whitewood C-219 User manual

ITEM : C-219 Printed in Vietnam
- 1 -
Description
Item No.
Toll Free
: COUNTRY FRENCH LADDERBACK
MCHAIR ITH OOD SEAT
: C-219
: 1 888 944 8396
ASSEMBLY INSTRUCTIONS
ASSEMBLY INSTRUCTIONSASSEMBLY INSTRUCTIONS
ASSEMBLY INSTRUCTIONS

ITEM : C-219 Printed in Vietnam
- 2 -
BEFORE ASSEMBLY
Thank you for purchasing this Whitewood Industries Inc.’s quality product. This product has been designed for easy assembly
and constructed for durability. lease take the time to read and follow the assembly instructions carefully.
Be sure to check all packing material carefully for small parts, which may have come loose inside the carton during shipment.
lease separate, identify, and count all parts and metal hardware. Compare with part list to be sure all parts are present.
If a part or hardware is missing or have any difficulties in assembling this product, please contact Toll Free: 1-888-944-8396.
IMPORTANT NOTE:
- lace all wooden parts on a clean and smooth surface such as a rug or carpet to avoid the parts from being
scratched.
- Remove all wrapping material, including staples & packing straps before you start to assemble.
- DO NOT tighten all screws, bolts until all completely assembled.
- Keep all hardware parts out of reach of children.
ASSEMBLY TOOLS REQ IRED

ITEM : C-219 Printed in Vietnam
- 3 -
PART LIST
When unpacking, please carefully not to discard any parts with the packaging. Before continuing, please make sure you
have all of the following parts:
NO Description Qty Sketch NO Description Qty Sketch
A
Chair
back
frame
1 B Seat frame 1
C Wood seat 1 D Front leg
(L-R) 2
E
Side
stretcher
(L-R)
2 F Center
stretcher 1
HARDWARE LIST
When unpacking, please carefully not to discard any parts with the packaging. Before continuing, please make sure you
have all of the following hardware:
NO Description Qty Sketch NO Description Qty Sketch
1
Long bolt
( M7.8x70mm)
8 2
Short bolt
(M7.8x35mm)
3
3
Lock washer
( Φ8xΦ11mm)
11 4
Flat washer
( Φ8xΦ19mm)
11
5
Allen key
(4mm)
1 6 Small screw
(M4x35mm) 10

ITEM : C-219 Printed in Vietnam
- 4 -
STEP 1
ut parts together as below picture
E
F
ED
D
B
A
STEP 2
To fix the seat frame (B) with the back frame (A), use washers (3), (4) and bolt (2) with the Allen key (5).
Then fix the seat frame (B) with front legs (D) and back legs on back frame (A), use washers (3), (4) and bolt (1) with the Allen
key (5).
5
1
3
4
x8
x3
4 3
2
5

ITEM : C-219 Printed in Vietnam
- 5 -
STEP 3
Use a screw driver to fix stretchers (E), (F) together, stretchers with legs, and front apron of seat frame with the
seat at underneath.
C
6
x10
STEP 4
ut the chair on a flat surface, tighten all screws and bolt.
Finish.
