Wickes CSD36Y1 User manual

CSD36Y1
223751
CORDLESS SCREWDRIVER
3.6V LITHIUM

2
CONTENTS
GENERAL POWER TOOL SAFETY WARNINGS 3
5
7
7
8
8
9
10
13
14
14
15
COMPONENT LIST
SAFETY WARNINGS FOR BATTERY CELLS INSIDE THE TOOL
ACCESSORIES
TECHNICAL DATA
SYMBOLS
NOISE INFORMATION
OPERATING INSTRUCTIONS
TROUBLESHOOTING
MAINTENANCE
ENVIRONMENTAL PROTECTION
DECLARATION OF CONFORMITY

3
ORIGINAL INSTRUCTION
GENERAL POWER TOOL SAFETY WARNINGS
WARNING! Read all safety warnings,
instructions, illustrations and specications
provided with this power tool. Failure to follow all
instructions listed below may result in electric shock, re and/
or serious injury.
SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE
REFERENCE.
The term “power tool” in the warnings refers to your mains-
operated (corded) power tool or battery-operated (cordless)
power tool.
1. WORK AREA SAFETY
a) Keep work area clean and well lit. Cluttered or dark
areas invite accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of
ammable liquids, gases or dust. Power tools create
sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while
operating a power tool. Distractions can cause you to
lose control.
2. ELECTRICAL SAFETY
a) Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any adapter
plugs with earthed (grounded) power tools.
Unmodied plugs and matching outlets will reduce risk of
electric shock.
b) Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock
if your body is earthed or grounded.
c) Do not expose power tools to rain or wet
conditions. Water entering a power tool will increase the
risk of electric shock.
d) Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords increase the
risk of electric shock.
e) When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of electric
shock.
f) If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of
electric shock.
3. PERSONAL SAFETY
a) Stay alert, watch what you are doing and use
common sense when operating a power tool. Do
not use a power tool while you are tired or under
the inuence of drugs, alcohol or medication. A
moment of inattention while operating power tools may
result in serious personal injury.
b) Use personal protective equipment. Always wear
eye protection. Protective equipment such as dust mask,
non-skid safety shoes, hard hat, or hearing protection used
for appropriate conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the switch
is in the off-position before connecting to power
source and/or battery pack, picking up or carrying
the tool. Carrying power tools with your nger on the
switch or energising power tools that have the switch on
invites accidents.
d) Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may result in
personal injury.
e) Do not overreach. Keep proper footing and balance
at all times. This enables better control of the power tool
in unexpected situations.
f) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair and clothing away from
moving parts. Loose clothes, jewellery or long hair can
be caught in moving parts.
g) If devices are provided for the connection of dust
extraction and collection facilities, ensure these
are connected and properly used. Use of dust
collection can reduce dust-related hazards.
h) Do not let familiarity gained from frequent use of
tools allow you to become complacent and ignore
tool safety principles. A careless action can cause
severe injury within a fraction of a second.
4. POWER TOOL USE AND CARE
a) Do not force the power tool. Use the correct power
tool for your application. The correct power tool will
do the job better and safer at the rate for which it was
designed.
b) Do not use the power tool if the switch does
not turn it on and off. Any power tool that cannot
be controlled with the switch is dangerous and must be

4
GENERAL POWER TOOL SAFETY WARNINGS
repaired.
c) Disconnect the plug from the power source and/
or remove the battery pack, if detachable, from
the power tool before making any adjustments,
changing accessories, or storing power tools. Such
preventive safety measures reduce the risk of starting the
power tool accidentally.
d) Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the
power tool or these instructions to operate the
power tool. Power tools are dangerous in the hands of
untrained users.
e) Maintain power tools and accessories. Check for
misalignment or binding of moving parts, breakage
of parts and any other condition that may affect
the power tool’s operation. If damaged, have the
power tool repaired before use. Many accidents are
caused by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are less
likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc.
in accordance with these instructions, taking into
account the working conditions and the work to be
performed. Use of the power tool for operations different
from those intended could result in a hazardous situation.
h) Keep handles and grasping surfaces dry, clean
and free from oil and grease. Slippery handles and
grasping surfaces do not allow for safe handling and
control of the tool in unexpected situations.
5. BATTERY TOOL USE AND CARE
a) Recharge only with the charger specied by the
manufacturer. A charger that is suitable for one type
of battery pack may create a risk of re when used with
another battery pack.
b) Use power tools only with specically designated
battery packs. Use of any other battery packs may
create a risk of injury and re.
c) When battery pack is not in use, keep it away from
other metal objects, like paper clips, coins, keys,
nails, screws or other small metal objects, that can
make a connection from one terminal to another.
Shorting the battery terminals together may cause burns or
a re.
d) Under abusive conditions, liquid may be ejected
from the battery; avoid contact. If contact
accidentally occurs, ush with water. If liquid
contacts eyes, additionally seek medical help.
Liquid ejected from the battery may cause irritation or
burns.
e) Do not use a battery pack or tool that is damaged
or modied. Damaged or modied batteries may exhibit
unpredictable behaviour resulting in re, explosion or risk
of injury.
f) Do not expose a battery pack or tool to re or
excessive temperature. Exposure to re or temperature
above 130 °C may cause explosion.
g) Follow all charging instructions and do not charge
the battery pack or tool outside the temperature
range specied in the instructions. Charging
improperly or at temperatures outside the specied range
may damage the battery and increase the risk of re.
6. SERVICE
a) Have your power tool serviced by a qualied repair
person using only identical replacement parts. This
will ensure that the safety of the power tool is maintained.
b) Never service damaged battery packs. Service
of battery packs should only be performed by the
manufacturer or authorized service providers.
SCREWDRIVER SAFETY WARNING
1. Hold the power tool by insulated gripping surfaces, when performing an operation where the fastener
may contact hidden wiring. Fasteners contacting a “live” wire may make exposed metal parts of the power tool “live” and
could give the operator an electric shock.

5
SAFETY WARNINGS FOR BATTERY CELLS INSIDE THE TOOL
a) Do not dismantle, open or shred cells.
b) Do not short-circuit charging terminal. Do not store power tool haphazardly in a box or drawer where
charging terminal may short-circuit each other or be short-circuited by conductive materials. When
power tool is not in use, keep it away from other metal objects, like paper clips, coins, keys, nails,
screws or other small metal objects, that can make a connection from one charging terminal to another.
c) Do not expose power tool to heat or re. Avoid storage in direct sunlight.
d) Do not subject power tool to mechanical shock.
e) In the event of battery leaking, do not allow the liquid to come into contact with the skin or eyes. If
contact has been made, wash the affected area with copious amounts of water and seek medical advice.
f) Seek medical advice immediately if a cell has been swallowed.
g) Keep power tool clean and dry.
h) Wipe the charging terminals with a clean dry cloth if they become dirty.
i) Power tool needs to be charged before use. Always refer to this instruction and use the correct charging
procedure.
j) Do not maintain power tool on charge when not in use.
k) After extended periods of storage, it may be necessary to charge and discharge the power tool several
times to obtain maximum performance.
l) Battery gives its best performance when it is operated at normal room temperature (20 °C ± 5 °C).
m) When disposing of cells, keep cells of different electrochemical systems separate from each other.
n) Recharge only with the charger specied by manufacturer. Do not use any charger other than that
specically provided for use with the equipment. A charger that is suitable for one type of battery may
create a risk of re when used with another battery.
o) Keep power tool out of the reach of children.
p) Retain the original product literature for future reference.
q) Dispose of properly.
r) Do not mix cells of different manufacture, capacity, size or type within a device.
s) Do not use any cell which is not designed for use with the equipment.

6
GENERAL SAFETY WARNINGS FOR BATTERY CHARGER
WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in
electric shock, re and/or serious injury.
Save all warnings and instructions for future reference.
This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
Additional safety instructions for your Battery Charger
1. Before charging, read the instructions.
2. Do not charge a leaking battery.
3. Do not use chargers for works other than those for which they are designed.
4. Before charging, ensure your charger is matching the local AC supply.
5. For indoor use only.
6. The charging device must be protected from moisture.
7. Do not short out the contacts of battery or charger.
8. Respect the polarity “+/-“ when charging.
9. Do not open the unit and keep out of the reach of children.
10. Do not charge the batteries of other manufactures or ill-suited models.
11. Ensure that the connection between the battery charger and battery is correctly positioned and is not obstructed by foreign bodies.
12. Keep battery charger’s slots are free of foreign objects and protect against dirt and humidity. Store in a dry and frost-free place.
13. Whenchargingbatteries,ensurethatthebatterychargerisinawell-ventilatedareaandawayfrominammablematerials.Batteriescanget
hot during charging. Do not overcharge any batteries. Ensure that batteries and chargers are not left unsupervised during charging.
14. Do not recharge non-rechargeable batteries, as they can overheat and break.
15. Longer life and better performance can be obtained if the battery pack is charged when the air temperature is between 18
oC
and 24
oC
. Do not
charge the battery pack in air temperatures below 0
oC
, or above 40
oC
. This is important as it can prevent serious damage to the battery pack.
16. Charge only battery pack of the same model provided by manufacturer and of models recommended by manufacturer.

7
COMPONENT LIST
Collet locking sleeve
Torque adjustment ring
LED light
Forward/reverse rotating control
On/Off Switch
Charger (XZ0500-1700WB) 1
25mm screwdriver bits 10
Magnetic bit holder 1
We recommend that you purchase your accessories from the same store that sold you the tool. Refer to the accessory
packaging for further details. Store personnel can assist you and offer advice.
Soft grip handle
Battery capacity indicator button
Rotating handle button
Charger
Charging socket
1
1
3
2
4
5
6
8
7
9
ACCESSORIES
3
4
5
6
7
8
9
10
2
10

8
SYMBOLS
To reduce the risk of injury, read all of this
instruction manual
Warning
Wear ear protection
Wear eye protection
Wear dust mask
Do not burn
Batteries may enter water cycle if disposed
improperly, which can be hazardous for
ecosystem. Do not dispose of waste batteries
as unsorted municipal waste.
Read the operator’s manual.
TECHNICAL DATA
Li-ion battery. This product has been marked
with a symbol relating to ‘separate collection’
for all battery packs and battery pack. It
will then be recycled or dismantled in order
to reduce the impact on the environment.
Battery packs can be hazardous for the
environment and for human health since they
contain hazardous substances.
Indoor use only
Double insulated
The output plug is with positive center pole
and negative outer pole
Waste electrical products must not be
disposed of with household waste. Please
recycle where facilities exist. Check with
your local authorities or retailer for recycling
advice.
Voltage
No load speed
Clutch position
Max torque
Charger Protection class
Charging time
Charger Input
Charger Output
Machine weight
Battery capacity
3.6 V
230/min
6+1
4.5 N.m
/II
1 hr
220-240V~50/60Hz,0.3A
5.0V 1.7A
0.41 Kg
1.5 Ah Li-ion battery
For additional battery technical data, refer to the rating plate on the battery pack.
*Voltage measured without workload. Initial battery voltage reaches maximum of 4 volts. Nominal voltage is 3.6 volts.
Li-Ion

9
NOISE INFORMATION
A weighted sound pressure LpA: 70.1 dB(A)
A weighted sound power LwA: 81.1 dB(A)
KpA & KwA 3.0 dB(A)
Wear ear protection.
Vibration total values (triax vector sum) determined according to EN 62841:
Vibration emission value:
ah= 1.7 m/s2Uncertainty K = 1.5 m/s²
The declared vibration total value and the declared noise emission value have been measured in accordance with a
standard test method and may be used for comparing one tool with another.
The declared vibration total value and the declared noise emission value may also be used in a preliminary assessment
of exposure.
WARNING! The vibration and noise emissions during actual use of the power tool can differ from the declared
value depending on the ways in which the tool is used especially what kind of workpiece is processed dependant
on the following examples and other variations on how the tool is used:
How the tool is used and the materials being cut or drilled.
The tool being in good condition and well maintained.
The use of the correct accessory for the tool and ensuring it is sharp and in good condition.
The tightness of the grip on the handles and if any anti vibration and noise accessories are used.
And the tool is being used as intended by its design and these instructions.
This tool may cause hand-arm vibration syndrome if its use is not adequately managed.
WARNING! To be accurate, an estimation of exposure level in the actual conditions of use should also take
account of all parts of the operating cycle such as the times when the tool is switched off and when it is running
idlebutnotactuallydoingthejob.Thismaysignicantlyreducetheexposureleveloverthetotalworkingperiod,helping
to minimize your vibration exposure risk.
Always use sharp chisels, drills and blades.
Maintain this tool in accordance with these instructions and keep well lubricated (where appropriate).
If the tool is to be used regularly then invest in anti vibration and noise accessories.
Plan your work schedule to spread any high vibration tool use across a number of days.
VIBRATION INFORMATION

10
OPERATING INSTRUCTIONS
NOTE: Before using the tool, read the instruction book carefully.
Intended Use
The power tool is intended for driving in and loosening screws
BEFORE PUTTING INTO OPERATION
The battery charger supplied is only for the Li-ion battery installed in the tool. Do not use another battery charger.
The Li-ion battery is protected against deep discharging. When the battery is empty, the tool is switched off by
means of a protective circuit: The tool will not turn on when the trigger is engaged. When the Battery is charged for
thersttimeorafterprolongedstorage,theBatteryPackwillaccepta100%chargeonlyafterseveralchargeand
discharge cycles.
A) CHARGING THE BATTERY
CHARGING PROCEDURE
Plug the charger plug into a suitable power outlet. Next,
connect the charger (9) to the charging socket (10) on
the tool. The light will turn to red to indicate the charging
process has started. Let the battery charge for 1 hours.
The light will go off to show the tool is fully charged. After
the battery is fully charged, then unplug the charger.
Disconnect the charger from the tool. The tool is ready
to be used.
NOTE:Ifthetoolistoohot,thelightwillashredwhen
charging. Please cool the tool before charging.
Important: When charging, the charger and tool may
become warm to the touch, this is normal and does not
indicate a problem.
Your tool is equipped with battery capacity indicator.
Press the battery capacity indicator button (7) to show
the amount of charge left in the battery.
Light Status
Red on 0-33%
Red on +Yellow on 33%-66%
Red on +Yellow on +
Green on 66%-100%
Green on Fully Charged
B) HOW TO CHARGE YOUR BATTERY PACK ( See Fig. A)
C) BATTERY CAPACITY INDICATOR ( See Fig. B)
Fig. A
Fig. B

11
Pull the collet locking sleeve (1) backward. Fully insert
the desired bit into the chuck and release the collet
locking sleeve (1). The collet accepts only standard 1/4”
hexagonal shank accessories with power groove.
NOTE: Do not use this tool as a drill. Tools equipped
with shut off clutches are not designed for drilling
applications.
The clutch can shut off automatically and without
warning. Attempting to restart drilling after shut-off
has been reached can cause the tool to twist out of your
hand until the clutch again reaches shut off.
NOTE: Do not attempt to insert quick change type drill bits
into this chuck.
NOTE: Try to pull the bit after releasing the collet locking
sleeve to make sure the bit is fully locked.
1. COLLET LOCKING SLEEVE (See Fig. C)
OPERATION
Fig. C
Pull the collet locking sleeve (1) backward. Take the tool out of the chuck and release the collet locking sleeve (1) .
2. REMOVING A BIT HOLDER, SOCKET OR SCREWDRIVER BIT
Depress the on/off switch (5) to start and release to stop
your driver.
3. ON/OFF SWITCH (See Fig. D)
Fig. D
1
22
22
Redash Battery Temperature
Protection
The temperature of battery
pack is less than 0oor
more than 40o.

12
Your tool is equipped with a forward, reverse rotation
and lock control (4) located above the on/off switch
(6). It was designed for changing rotation of the chuck
and for locking the on/off switch (6) in the center
position to help prevent accidental start and accidental
battery discharge.The screwdriver has forward/reverse
function, press the forward/reverse rotating control to
the right (See Fig. E1), it is forward function, then press
the forward/reverse rotating control to the left (See Fig.
E2), it is reverse function.
WARNING! Do not change direction of rotation
until the tool comes to a complete stop. Shifting
during rotation of the chuck can cause damage to the tool.
4. FORWARD, REVERSE ROTATION AND LOCK
CONTROL(See Fig. E1, E2)
5. USING THE WORK LIGHT
The work light (3) will illuminate whenever the trigger is pressed. LED lighting increases visibility, great for dark or
enclosed areas.
Fig. E1
This machine can be used with a straight handle
or pistol grip. Press the button (8) and hold it while
adjusting the handle to desired position. Release the
button to lock the handle.
6. ROTATING HANDLE (See Fig. F) 1
2
Fig. F
Fig. E2
7. TORQUE ADJUSTMENT
The torque is adjusted by rotating the torque adjustment ring (2). The torque is greater when the torque adjustment ring
is set on a higher setting. The torque is less when the torque adjustment ring is set on a lower setting.
Make the setting as follows:
1-3 for driving small screws
4-6 for driving screws into soft material
for drilling purpose

13
8. DISPOSAL OF AN EXHAUSTED BATTERY PACK
To preserve natural resources, please recycle or dispose of the battery pack properly. This battery pack contains
Lithium batteries. Consult your local waste authority for information regarding available recycling and/or disposal
options. Discharge your battery pack by operating your drill, then remove the battery pack from the drill housing
and cover the battery pack connections with heavy-duty adhesive tape to prevent short circuit and energy discharge. Do
not attempt to open or remove any of the components.
9. OVERLOAD PROTECTION
10. TEMPERATURE DEPENDENT OVERLOAD PROTECTION
11. PROTECTION AGAINST DEEP DISCHARGING
When overloaded, the motor comes to a stop. Relieve the load on the machine immediately and allow cooling for approx.
30 seconds at the highest no-load speed.
This power tool has over-load protection built in. If the load is too high or the battery temperature exceeds 75°C, the
electronic control switches off the power tool until the battery has cooled.
The Li-ion battery is protected against deep discharging by the “Discharging Protection System”. When the battery is
empty, the machine is switched off by means of a protective circuit: The inserted tool no longer rotates.
1. WHY DOES THE DRIVER NOT TURN WHEN YOU PRESS THE SWITCH?
2. REASONS FOR DIFFERENT BATTERY PACK WORKING TIMES
The forward/reverse rotation control (4), which is on top of the on/off switch (5), is positioned in the lock function. Unlock
the forward/reverse rotation control by putting it into the required rotation position. Push the trigger and the drill will start
to rotate.
Charging time problems, as above, and having not used a battery pack for a prolonged time will reduce the battery pack
working time. This can be corrected after several charge and discharge operations by charging & working with your
driver. Heavy working conditions such as large screws into hard wood will use up the battery pack energy faster than
lighter working conditions. Do not re-charge your battery pack below 0oC and above 40oC as this will affect performance.
TROUBLESHOOTING

14
Your tool requires no additional lubrication or maintenance.
There are no user serviceable parts in your power tool. Never use water or chemical cleaners to clean your power tool.
Wipe clean with a dry cloth. Always store your power tool in a dry place. Keep the motor ventilation slots clean. Keep all
working controls free of dust. Occasionally you may see sparks through the ventilation slots. This is normal and will not
damage your power tool.
For Battery tools
The ambient temperature range for the use and storage of tool and battery is 0°C-45°C.
The recommended ambient temperature range for the charging system during charging is 0°C-40°C.
Waste electrical products must not be disposed of with household waste. Please recycle where facilities exist.
Check with your local authorities or retailer for recycling advice.
MAINTENANCE
ENVIRONMENTAL PROTECTION

15
DECLARATION OF CONFORMITY
We,
Wickes Building Supplies Limited
Declare that this product: CORDLESS SCREWDRIVER
Description and SKU code: 223751
Complies with the following Directives and Regulations:
2006/42/EC, Machinery Directive
2014/30/EU, Electromagnetic Compatibility Directive
2011/65/EU & (EU)2015/863 (RoHS),Restriction of Hazardous Substances Directive
2014/35/EU, Low Voltage Directive
and conforms to the following standards:
Standards specic to this product:
EN 55014-1
EN 55014-2
EN 62841-1
EN 62841-2-2
EN 60335-1
EN 60335-2-29
EN 62233
EN 61000-3-2
EN 61000-3-3
28th January, 2021
Philip Ansell
Category Technical Manager
Wickes
Vision House
19 Colonial Way
Watford
WD24 4JL”

Customer Helpline 0345 2005409
