ENGLISH
1. General
Installation and service by qualified personnel only
1.1 Applications
The pump is suitable for drinking water, heating water, industrial water,
condensate, water/glycol mixtures up to a ratio of 40% glycol as well
as other liquids free from mineral oil and without abrasives or long-
fibred substances.
The main areas of use are in water supply installations, as a booster
pump, as a boiler feed pump, in industrial circulation systems, in pro-
cess technology, in cooling water systems, in fire extinguishers and in
washing and sprinkler installations.
Approval from the manufacturer must be obtained beforehand if corro-
sive chemicals are to be pumped.
1.2 Technical description
1.2.1 Performance and electrical data
AC voltage: 1 ~ 230 V (± 10 %) / 50Hz or
Rotary current voltage: 3 ~ 230 / 400 V (± 10 %) / 50 Hz;
8
Motor power: see rating plate,
Maximum current: see rating plate,
Fluid temperature: –15 °C to 110 °C
with gaskets – EPDM
(KTW/WRAS),
–15 °C to 80 °C version with
with gaskets – VITON
Max. permissible working pressure: 10 bar,
Max. permissible inlet pressure: 6 bar,
Max. ambient temperature: 40 °C,
Protective system: IP 54.
Other voltages/frequencies and material properties are optional and/or
available on request.
When pumping viscous fluids (e.g. water/glycol mixtures) adjust the
pump data to allow for the higher viscosity.
Only use branded glycol mixtures with corrosion inhibitors and follow
the manufacturers instructions.
For dimensions see table and Fig. 3.
Pump Pump unit
Model Dimensions
AB C D EFGH
1~230 V 3~400 V 1~230 V 3~400 V 1~230 V 3~400 V 1~230 V 3~400 V
MHI mm
202 205 88 88 375 375 216 192 90 90 Rp1 110 Rp1
203 205 88 88 375 375 216 192 90 90 Rp1 110 Rp1
204 253 88 88 423 423 216 192 90 90 Rp1 158 Rp1
205 253 88 88 423 423 216 192 90 90 Rp1 158 Rp1
206 277 104 104 472 472 224 206 90 90 Rp1 182 Rp1
402 205 88 88 375 375 216 192 90 90 Rp11/4110 Rp1
403 205 88 88 375 375 216 192 90 90 Rp11/4110 Rp1
404 253 88 88 423 423 216 192 90 90 Rp11/4158 Rp1
405 253 104 104 448 448 224 206 90 90 Rp11/4158 Rp1
406 277 137 104 511 472 239 206 100 90 Rp11/4182 Rp1
802 217 88 88 387 387 216 192 90 90 Rp11/2122 Rp11/4
803 217 104 88 412 387 224 192 90 90 Rp11/2122 Rp11/4
804 277 104 104 472 472 224 206 90 90 Rp11/2182 Rp11/4
805 277 - 104 - 472 - 206 - 90 Rp11/2182 Rp11/4
1602 237 - 103,5 - 432 - 206 - 90 Rp2 138 Rp11/2
1603 237 - 103,5 - 432 - 206 - 90 Rp2 138 Rp11/2
1604 282 - 136,5 - 515 - 221 - 100 Rp2 183 Rp11/2
When ordering spare parts, please give all the information on the rating plate.
