Wilson Electronics MX-3050 User manual

MX-3050
Document Feeder (100 sheets)
Bypass Tray (100 Sheets)
Envelopes
Hard Stock
Glossy Paper
Labels etc.
Paper Trays (550 sheets each)
Split Tandem Tray 3,000 Sheet Large
(2,100 sheets only Letter) Capacity Cassette

Inner Finisher (50 sheet stapler)
Open Door for Staples
Covenant Stapler (5 sheets)
1k Finisher (50 sheet Stapler) 3k Saddle Finisher (65 sheet Stapler)
Open to replace staples Open
How to change staple Cartridge
Open the front cover on the finisher
Pull down lightly on the green tab to release the staple cartridge.
Note: On the inner finisher the cartridge will not be available to grab until it
is completely empty. There is no sensor to tell you when it’s getting low on
staples, so if you do a lot of stapling it’s a good idea to have a spare set.
Pinch the empty clear plastic cartridge on the arrows that point upward and
remove the empty box, discard/recycle, leaving the chassis empty for the
new cartridge
Insert the full, new cartridge into the chassis the until it clicks into place
Insert the chassis with the new cartridge back into the finisher with the
green tab facing towards the front of the machine
Close the front cover on the finisher
Test the stapling feature to make sure it staples properly
Sometimes it shoots a few blanks to advance the new sheet of staples to
the front of the chassis

TONER
When toner is running out, the MFP's control panel displays a message instructing users to
replace the toner cartridge. The cartridges on Sharp's new MFPs automatically pop out when
the toner is all gone. Please see below
Still toner remaining
When toner runs out
Remove

MISS FEEDS/JAMS
On the Sharp Devices, if there are any miss feeds or jams it will prompt you
on the screen letting you know exactly where the miss feeds and jams are.
Anything in GREEN you touch!!
As you will see the SHARP devices have a
SHORT PAPER PASS for LESS MISS FEEDS!!!!

SERVICE/SUPPLIES
On front of the device you will see The Wilson Group sticker; this provides you with the number
to contact for Service/Supplies.
Let dispatcher know your issue
Dispatcher will ask for the WG# which is also located on
The Wilson Group Sticker
NOTE: If you have several machines each machine has its own sticker
with a different WG Number

PAPERCUT
For the 1st time you have to authenticate yourself.
Tap the reader with your card. It’s going to say: This card is not known to the
system. To associate your card with your account, enter your USERNAME and
PASSWORD.
The USERNAME is usually your 1st Initial and last name. The PASSWORD is the same as
when you log onto your computer.

HOME SCREEN
PRINT RELEASE, DEVICE FUNCTIONS AND SCAN
PRINT RELEASE ICON
When you select print from your computer. The job is going to go to the print release queue.
Once you come to the copier, you will bag in and it will tell you if you have jobs in the queue.
Once you select the job you would like print, several other icons will appear
Print, Print All or Delete! Please remember if you are printing a document, only you can
release it.

DEVICE FUNCTIONS ICON
DEVICE FUNCTION gives you the ability to COPY, SCAN; go back to the
PRINT RELEASE screen, and as well as go back to PAPERCUT HOME SCREEN

Select COPY ICON
This feature lets you customize the way you would like your document to be copied
Paper Select
Indicates how much paper are in each paper tray
Also lets you know what sizes are also in the paper trays
Bypass tray (under type and size) select what type of people you are going to pull from
this tray.

2-Sided Copy
1-1 (One document copying to one document)
1-2 (Two separate documents copying to one document, front and back)
2-2 (One front and back document copying to one document front and back)
2-1 (One front and back document copying to two separate documents)
Copy Ratio
Reducing and enlarging a document

Staple Sort
Several different ways to staple your documents
1 Staple which is your basic staple in the left or right of the document
2 Staple which it’s going to staple at the top and bottom of the document
Screen Shots

Others Icon
A lot of you copy documents that are on color paper and you don’t want to see the gray
shade in the background.
Select Others
Select background adjustment

Then select ON
Move it down to –3
Put the document in document feeder and hit COLOR START or B/W START

Card SHOT
This function gives you the ability to copy an ID CARD, DRIVERS LICENSE or anything
that size.
Place the card on the glass in the corner
Go to OTHERS
Then select CARD SHOT

Now turn it ON!
Place the object in corner of glass
HIT START!
It will ask you to place your next original, just flip the card over if you need to copy the
back. Then HIT START AGAIN. If you are done hit READ-END, which means the job is
finished.

Whenever you are finished with everything, always LOGOUT
That will bring you to this screen
If you HIT the HOUSE on the right of the Screen,

It will bring you to this screen
SCANNING ICON
When you select Scanning from this screen

Or the Paper Cut Home screen
You will get the same results

If you select Scan to Email
Your email address will already be entered
You have the option to change the subject and file name
Just select inside the boxes
Another box will appear, where you can delete out the current information

Once done select OK
Place document inside document feeder and PRESS START!
IF YOU HAVE MORE SCANNING TO DO SELECT THE BACK BUTTON
