WilTec HS-060B-6 User manual

Operation Manual
WOOD MAKING IRON
ARTICEL 61077
Read and follow the operating instructions and safety information before using for the first time.
Technical changes reserved!
Due to further developments, illustrations, functioning steps and technical data can differ
insignificantly.
Updating the documentation
If you have suggestions for improvement or have found any irregularities please contact us.
© b WilTec Wildanger Technik GmbH Seite 7
http://www.WilTec.de
http://www.ao ue.eu
http://www.teichtip.de

The information contained in this document is subject to change without prior notice. o part of this
document can be copied or duplicated in another form without the prior written consent of WilTec
Wildanger Technik GmbH. The WilTec Wildanger Technik GmbH assumes no liability for any errors in
this user manual or the connection diagram.
Although WilTec Wildanger Technik GmbH has made every effort to make sure that this user manual
is complete, accurate and updated, errors cannot always be avoided. In the event of problems with
this user manual please complete and send this form back to us.
FAX-notification (+++49 2403 55592-15),
from: ________________________________________
Name: ________________
Firm:_____________________
Tel/Fax:__________________
I would like to report the following mistakes:
_______________________________ ____________________________________
Customer Service WilTec Wildanger Technik GmbH
e-mail: [email protected]
Tel:++ [phone]
Introduction
Thank you for purchasing this quality product. To minimize the risk of injur b means of fire or
electric shock we urge that our clients take some basic safet precautions when using this
device. Please read the operation instructions carefull and make sure ou have understood its
content.
Always use a grounded power connection with the appropriate mains voltage. You can find the
corresponding mains voltage on the type plate. If you have any doubts about the connection being
grounded, have it checked by a qualified professional. ever use a faulty electric cable.
Do not inspect the electrical part of the pressure pond filter in a wet or damp environment or when you
are wet yourself and protect it from direct sunlight. Install this device in a safe location so that nobody
can step on the cable, fall over or damage it. Disconnect the power plug before cleaning it and use
only a damp cloth for cleaning. Avoid using cleaning agents and make sure that no liquid enters the
electrical part of the pump.
The electric part of the device contains no parts that can be inspected or serviced by the user. Leave
the maintenance, adjustment and repair to qualified technical personnel. In case of unauthorised
intervention the 2-year warranty is no longer valid! Keep these operation instructions safe.
© b WilTec Wildanger Technik GmbH Seite 8
http://www.WilTec.de
http://www.ao ue.eu
http://www.teichtip.de

SYMBOLS USED IN THIS MANUAL
= Wear e e protection
= Wear protective gloves
= Read the operating manual
= Caution! Ver hot!
ADDITIONAL OPERATIONAL SAFETY
INSTRUCTIONS FOR YOUR WOOD MAKING IRON
After opening the package, please check whether every single part of the device is in a good con-
dition or whether there is visible transport damage. If there is obvious damage, please do not put
the device into operation and contact your dealer immediately!
Switch off the appliance and disconnect the mains plug if you move the appliance.
Avoid exposing parts of the device to increased mechanical stress (impact, shock, etc.).
Make certain that the rated power stated on the machine’s rated plate agrees with the local main
current circuit voltage before connecting the machine to the main circuit.
230 V machines can also be connected to 220 V main circuits.
Be sure to disconnect the machine from the main circuit after finishing work.
Allow the device to cool down completely before storage! Rest the device on the stand provided or
on a non-flammable surface during breaks or after finishing work. Do not leave the machine unsu-
pervised until it has cooled down completely.
Do not use the device if handle, main cable or plug shows any signs of damage. Send the device
to an authorized workshop for repair. ever open the device yourself.
If the cable or plug is damaged due to external influences, the cable must not be repaired! The ca-
ble must be replaced with a new one. This must only be done by the manufacturer or an autho-
rized service partner.
ever lift, transport or attach the device to the power cord.
Keep the device away from children!
Do not expose the device to water or moisture.
The device may only be used indoors.
Only use the device for the purpose specified in these instructions for use.
Ensure that no liquids enter the device.
Do not touch the marking tip or marking iron when the device is hot. Danger of burns!
Use the device only in well ventilated rooms.
Do not eat or drink whilst working with the device. Always wash your hands thoroughly after finish-
ing work.
This appliance is not intended for use b persons (including children) with reduced ph si-
cal, sensor or mental capabilities or lack of experience and knowledge, unless the have
been given supervision or instruction concerning the use of this appliance b a person re-
sponsible for their safet .
FEATURES
1 Marking iron
2 Marking tips
3 Marking stamps
4 Soldering tip
© b WilTec Wildanger Technik GmbH Seite 9
http://www.WilTec.de
http://www.ao ue.eu
http://www.teichtip.de

5 Knife blade
6 Collet for a knife blade
7 Handle
8 Cable with plug
TECHNICAL SPECIFICATIONS FOR MODEL HS-060B-6
Rated Voltage: 230 V~ / 50 Hz
Rated Power: 30 W
Protection category: I
USING THE MARKING IRON
MAIN CONNECTION
The unit may only be connected to a single-phase main circuit with the same voltage as demanded on
the machine’s rating plate. 230 V machines can also be connected to 220 V main current circuits. The
main circuit must be equipped with a 16 Amp fuse. The machine may only be connected to an earthed
socket. Additionally we recommend using a residual current circuit breaker.
SWITCHING ON AND OFF
The marking iron is switched O as soon as the plug is connected to the main circuit. Disconnect the
marking iron plug from the main circuit to switch it OFF.
USING THE MARKING IRON
1) Ensure that the rated voltage on the machine label agrees with the local main voltage.
2) Check that the insert (e.g. a marking stamp (3)) is securely fitted before you heat up the de-
vice.
3) Connect the marking iron (1) to the main circuit.
4) ever heat up the marking iron without a tip fitted.
5) The tip (e.g. marking stamp (3)) may only be removed from the marking iron when it is
switched off. Crew the tips as far as they will go into the tip holder.
6) Allow the marking iron to cool down after you finish work. Do not cool by rinsing under water.
7) Place the marking iron on the stand (7) during breaks in your work.
CAUTION!
The main cable is sensitive to heat. Ensure that the cable does not come into contact with a hot
part of the device or a tip – for example a marking stamp (3). Damaged main cables ma onl
be replaced with a genuine replacement cable, available from the manufacturer or the manufac-
turer’s customer service representative.
Main cables ma onl be replaced b the manufacturer or an authorized service centre!
CAUTION!
To prevent the risk of fire, alwa s rest the device on the stand provided or on a
similar non-flammable surface.
Alwa s disconnect the device from the main circuit after finishing work. Allow the device to
cool down to room temperature until ou put it awa .
Keep children out of the area.
WORKING WITH THE MACHINE
Firstly, make a sketch of the desired pattern on your workpiece with a pencil or alternatively apply
a ready-made template to the workpiece.
Types of wood with smooth surfaces are particularly suitable for marking.
When marking wood with a rough surface, be aware that it can be difficult to guide the tip along
the line required. In this case the surface should be sanded first.
Connect the plug to the main circuit socket and rest the marking iron (1) in the supply stand (7) un-
til the working temperature is reached after approximately two minutes.
Begin by testing the device with the ‘universal’ tip (factory fitted).
© b WilTec Wildanger Technik GmbH Seite 10
http://www.WilTec.de
http://www.ao ue.eu
http://www.teichtip.de

The long edge is suitable for marking thin lines as well as wider and deeper lines.
Use the point to mark dotted patterns or lettering.
The tip’s angled surface is particularly for shadow marking.
A wide variety of patterns can be created with the marking tips and stamps supplied.
Use a pair of pliers (e.g. combination pliers) to change tips and stamps.
A sooty deposit can build up on the tip or on the stamp during use. Use fine sandpaper to remove
the deposits and to keep the tips clean. A clean tip is essential for precise and accurate work.
The knife blade is suitable for cutting foam or for melting the ends of ropes or cords made of nylon
or other synthetic materials.
As the tips are made of brass, a relatively soft material, we recommend that you wait until these
have cooled down completely before removing or replacing them.
Please note that the threaded ends of the tips are easily damaged when hot. If tips are damaged
they may be difficult to fit to the device.
CAUTION!
Allow the tips to cool down completel before removal or exchange. Danger of
burns!
To prevent the risk of fire, alwa s rest the device on the stand provided or on a
similar non-flammable surface.
Alwa s disconnect the device from the main circuit after finishing work. Allow the device to
cool down to room temperature until ou put it awa .
Keep children out of the working area.
MAINTENANCE
REPLACING THE MAIN CABLE
If the main cable becomes damaged it may only be replaced with original and genuine replacement
cables available from the manufacturer or the manufacturer’s customer service representative. Main
cables may only be replaced by the manufacturer or an authorized service centre.
After a certain amount of time sooty deposits can build up on the tips (for example the marking stamps
(3)). To be able to work precise and accurately remove the deposits with fine sandpaper.
© b WilTec Wildanger Technik GmbH Seite 11
http://www.WilTec.de
http://www.ao ue.eu
http://www.teichtip.de

Disposal regulations
EU guidelines regarding the disposal of scrap electric appliances (WEEE, 2012/19/EU) were
implemented in the law related to electrical and electronic equipment and appliances.
All WilTec electric devices that fall under the WEEE regulations are labelled with the crossed-out
wheeled waste bin logo. This logo indicates that this electric equipment must not be disposed with the
domestic waste.
The company WilTec Technik GmbH has been registrated in the German registry EAR under the
WEEE-registration number DE45283704.
Disposal of used electrical and electronic appliances
(intended for use in the countries of the European
Union and other European countries with a separate
collection system for these appliances).
The logo on the article or on its packaging points out
that this article must not be treated as normal
household waste but must be disposed to a recycling
collection point for electronic and electrical waste
equipment. By contributing to the correct disposal of
this article you protect the environment and the health
of your fellow men. Environment and health are
threatened by inappropriate disposal.
Materials’ recycling helps reduce the consumption of raw materials.
Additional information on recycling this article can be provided by your local community, municipal
waste disposal facilities or the store where you purchased the article.
Address:
WilTec Wildanger Technik GmbH
Königsbenden 12 / 28
D-52249 Eschweiler
Important notice:
The reprint or reproduction, even of excerpts, and any commercial use, even in part of this instructions
manual require the written permission of WilTec Wildanger Technik GmbH.
