WilTec 64397 User manual

Operating Manual
Wi-Fi Thermostat for Infrared Heating
64397
Illustration similar, may vary depending on model
Please read and follow the operating instructions and safety information prior to initial operation.
Technical changes reserved!
Illustrations, functional steps, and technical data may deviate insignificantly due to continuous further
developments.

© by WilTec Wildanger Technik GmbH Item 64397 Page 2
http://www.wiltec.de 07 2023-1
The information contained in this document may alter at any time without prior notice. No part of this
document may be copied or otherwise duplicated without prior written consent. All rights reserved.
WilTec Wildanger Technik GmbH cannot be held liable for any possible mistakes in this operating man-
ual, nor in the diagrams and illustrations shown.
Although WilTec Wildanger Technik GmbH has made every possible effort to ensure that this operating
manual is complete, accurate, and up-to-date, errors cannot be ruled out entirely.
If you have found an error or wish to suggest an improvement, we look forward to hearing from you.
Send us an e-mail to:
[email protected]
or use our contact form:
https://www.wiltec.de/contacts/
The most recent version of this manual in several languages can be found in our online shop:
https://www.wiltec.de/docsearch
Our postal address is:
WilTec Wildanger Technik GmbH
Königsbenden 12
52249 Eschweiler – Germany
To return your goods for exchange, repair, or other purposes, please use the following address. Atten-
tion! To allow for a trouble-free complaint or return, it is important to contact our customer service team
before returning your goods.
Retourenabteilung
WilTec Wildanger Technik GmbH
Königsbenden 28
52249 Eschweiler – Germany
E-mail: [e-mail]
Tel: [phone]
Fax: [phone]

© by WilTec Wildanger Technik GmbH Item 64397 Page 3
http://www.wiltec.de 07 2023-1
Introduction
Thank you for choosing to purchase this quality product. To minimise the risk of injury, we ask you to
always take some basic safety precautions when using this product. Please read this operating manual
carefully and make sure that you understand it.
Keep these operation instructions in a safe place.
Important instructions
•Thermostats can only be linked in the 2.4-GHz net.
•A red light means that the thermostat is online; a blue light means that the radiator is switched
on.
•Plugging out the thermostat four times or more with each disconnection being under 5 s will
delete the internal Wi-Fi connection information. In that case, the thermostat needs to be re-
linked with the Wi-Fi.
•With the Wi-Fi or network connection interrupted, the thermostats are offline and the heating is
switched off.
•The blue LED display of the thermostat might not light up at the first time when you have finished
the Wi-Fi connection. You will need to wait for a couple of seconds for the network to be detected
and linked to.
•The temperature set should be at least 0.5℃ higher than the ambient temperature for the heater
to be switched on.
•The temperature sensor of the device is found on the underside of the plug. Do not cover the
thermostat; do not place it there where it gets warm. Best leave the temperature sensor point
downwards when you plug in the thermostat.
•Do not use the thermostat in a humid zone or near running water.
•Disconnect the thermostat from the mains when you will no use it for a longer period.
Technical specifications
Power supply (V)
220–240AC
Maximum charge (W/A)
3680/16
Standard of wireless connection
IEEE802.11b/g/n
Frequency range (GHz)
2,412–2,484
Safety mechanisms
WEP/WPA-PSK/WPA2-PSK
Encryption types
WEP/TKIP/AES
Power consumption while stand-by (W)
<0.8
Operational ambiant temperature (℃)
–5–50
Air humidity (%)
10–95
Description of the product
This Wi-Fi thermostat can be used together with different heatings that can be controlled via a mobile
phone. It includes the following functions:
•Wi-Fi remote control
•Temperature setting
•Weekly programme
•Countdown
•Grouped control
•Sharing with other users

© by WilTec Wildanger Technik GmbH Item 64397 Page 4
http://www.wiltec.de 07 2023-1
Overview
1
Key/light display
Red light
Online
Blue light
Switching on the heating
Instructions for linking to Wi-Fi
1. Connect your mobile phone to the Wi-Fi (2.4-GHz net).
2. Scan the code, install the “Smart Life” app, and create an account.
QR code
App symbol
3. Plug in the Wi-Fi thermostat and press the key for 5–10 s until the display lights up.
Note! Proceed alike in case the Wi-Fi hotspot or Wi-Fi password have been modified or the
mobile phone has been replaced.
4. Now click on the “Smart Life” symbol to open the main interface, choose the name of the room,
and click on “Add Device” or on the “⊕” in the upper right corner. A window pops up as shown.

© by WilTec Wildanger Technik GmbH Item 64397 Page 5
http://www.wiltec.de 07 2023-1
5. Click on “Go to add.” On the next page, click on “⊕” to add a Bluetooth device. A dialogue field
“Enter Wi-Fi-Password” is shown.

© by WilTec Wildanger Technik GmbH Item 64397 Page 6
http://www.wiltec.de 07 2023-1
6. Enter your Wi-Fi password and click on “Confirm;” the next steps of the Wi-Fi connection are
started. After a waiting time of 20–30 s, the device is added successfully. Meanwhile, the red
display of the thermostat lights up. You can name the device, e.g., “Infrared heating.”
Note! In case the connection has been interrupted during step 6, please disconnect the mains plugs of
the Wi-Fi thermostat for 10 s, then repeat the steps 3–6.

© by WilTec Wildanger Technik GmbH Item 64397 Page 7
http://www.wiltec.de 07 2023-1
№
Name/function
№
Name/function
1
Back to main interface
6
Temperature adjustment
2
Name of device
7
Swap between ℃ and ℉
3
Change settings
8
Weekly programme
4
Status of device
9
Timer
5
Switch on/off
Operating instructions
1. The main interface of the “Smart Life” app is as follows after the successful connection of the
thermostat:
2. Click on the green button (in the main interface) to switch the power supply of the heating
on or off. The colour of the display light is blue; this means that the thermostat is switched on.
You may also press the key of the thermostat to switch it on or off. When doing so, the colour
of the symbol in the app will change as well.
3. Click on the device name that you have given the device, e.g., “Infrared heating,” to call the
thermostat interface.
4. Via the button , the power supply is switched on and off. The temperature set should be at
least 0.5℃ higher than the ambient temperature for the heater to be switched on.
5. Via the button , the weekly programme is set. Via the weekly programme, the user can
program the heating so that the operation and desired temperature changes over the week. The
switch-on and switch-off time being separate, they must be entered separately. Do not forget to
set the week key to green after programming.
6. Via the button , the timer is called, that can be set for automatic switching-off of the ther-
mostat.

© by WilTec Wildanger Technik GmbH Item 64397 Page 8
http://www.wiltec.de 07 2023-1
7. Via the button , the temperature display is swapped between ℃ and ℉.
8. Note! The weekly programme, timer, and temperature only work in switch-on mode.
9. Via the button , other settings of the thermostat can be modified. The following settings can
be made:
•Name of device: modify the name of your device.
•Device information: check the virtual ID and other information concerning the device.
•Share device: You can share the control of the thermostat with other mobile numbers/e-mail
addresses if these are registered in the “Smart Life” app.
•Create group: You can group different thermostats to control them at the same time.
•FAQ and feedback: Report problems to app provider.
•Check device network: Check the status of the Wi-Fi connection of the device.
•Check for update: Download the newest firmware version.
•Remove device: Remove the thermostat from the app.

© by WilTec Wildanger Technik GmbH Item 64397 Page 9
http://www.wiltec.de 07 2023-1
Regulations for waste disposal
The Waste Electrical and Electronic Equipment Directive (WEEE Directive, 2012/19/EU) of the EU was
implemented in the German law related to electrical and electronic equipment and appliances.
All WilTec electric devices that fall under the WEEE directive are labelled with the symbol of a crossed-
out wheeled rubbish bin. This symbol indicates that this electric device must not be disposed of with the
domestic waste.
WilTec Technik GmbH is registered with the German registration authority EAR (Stiftung Elektro-
Altgeräte Register) under the WEEE-registration number DE45283704.
Disposal of used electrical and electronic devices (in-
tended for use in the countries of the European Union
and other European countries with a separate waste
collection system for these devices).
The symbol on the packaging or the product itself indi-
cates that this product must not be treated as normal
domestic waste but must be disposed of at a recycling
collection station for electrical and electronic waste.
By disposing of this product correctly, you contribute to
the protection of the environment and the health of your
fellow people. Inappropriate disposal threatens the en-
vironment and health.
Material recycling helps to reduce the consumption of raw materials.
Additional information about the recycling of this product can be provided by your local commune, the
municipal waste disposal facilities, or the store where you purchased the product.
Address:
WilTec Wildanger Technik GmbH
Königsbenden 12 / 28
52249 Eschweiler Germany
Important note:
Reproduction and any commercial use (of parts) of this operating manual, requires a written permission
of WilTec Wildanger Technik GmbH.
