INSTALLATION MANUAL
DOWNFLOW / HORIZONTAL
ELECTRIC FURNACE
MODELS: WEFC & WEFX SERIES
LIST OF SECTIONS
1 – General 1 6 – Line Voltage and Control Box Wiring 8
2 – Safety 3 7 – Thermostat Wiring and Connections 10
3 – Return Air and Clearance Requirements 4 8 – Motor, Blower and Furnace Startup 14
4 – Supply Air and Duct Connector Installation 5 9 – Final System Checkout 15
5 – Furnace Installation 6 10 – Wiring Diagrams 16
LIST OF FIGURES
1 – Furnace Dimensions 2 17 – Control Box Power, Blower & Fuse Connections 10
2 – Closet Clearances 4 18 – Separate Thermostats, Same Furnace Wiring Diagram 12
3 – Typical Closet Installations 4 19 – Same T’stat, Separate Furnace - Separate Trans Connections 12
4 – Typical Alcove Installations 5 20 – Same T’stat, Separate Furnace and Cooling Unit Connection 12
5 – Clearance – Access for Service 5 21 – Typical Heating/Cooling Separate Transformer Connections 13
6 – Duct Connector Depths 5 22 – Typical Heat Pump/Heating/Cooling T’Stat Connections 13
7 – Duct Connector and Floor Base Installations 6 23 – X-13 motor Terminals 14
8 – Duct Connector Measurements 6 24 – Blower Assembly and Blower Deck 15
9 – Duct Connector and Floor Base Measurements 6 25 – Wiring Diagram 5 kW w/ X-13 Blower Motor 17
10 – Return Air Grille and Frame Assembly 7 26 – Wiring Diagram 8 kW, 10 kW, 12kW w/ X-13 Blower Motor 18
11 – Grille and Frame Assembly Filter Locations 7 27 – Wiring Diagram 15 kW, 17kW w/ X-13 Blower Motor 19
12 – Coil Cabinet Door Bracket Location 7 28 – Wiring Diagram 20 kW w/ X-13 Blower Motor 20
13 – Control Box Component Locations 9 29 – Wiring Diagram 5 kW w/ PSC Blower Motor 21
14 – Control Box Cover and Circuit Breaker Location 10 30 – Wiring Diagram 8 kW, 10 kW, 12kW w/ PSC Blower Motor 22
15 – Line Voltage Electrical Shield 10 31 – Wiring Diagram 15 kW, 17kW w/ PSC Blower Motor 23
16 – Line Voltage Electrical Shield Location 10 32 – Wiring Diagram 20 kW w/ PSC Blower Motor 24
LIST OF TABLES
1 – Electric Furnace Model Specifications 2 8 – Electrical Data 9
2 – Model Nomenclature 2 9 – Low Voltage Wire Gauge and Max Lengths 10
3 – Optional Cooling Cabinets and Return Air Grille 2 10 – Recommended Heat/Cool T’stat Wire Color Code 12
4 – Clearances to Combustibles 4 11 – Recommended Heat/Cool/HP T’stat Color Code 12
5 – Duct Connectors 5 12 – X-13 Motor Terminal Connections 14
6 – Wiring Requirements – Single Branch Circuit 8 13 – X-13 Motor Factory Speed Tap Settings 16
7 – Wiring Requirements – Dual Branch Circuit 9
SECTION I: GENERAL
The following list includes important facts and information
regarding the electric furnace and its inclusions.
1. Furnace is rated at 240 volts AC at 60 Hertz
2. Furnace is the same size for all models
3. Four-wire thermostat operation for heating and cooling
4. A/C ready furnaces equipped with blower for A/C or
Heat Pump operation.
5. Holding Strap furnished with furnace.
6. This furnace is designed for downflow/horizontal
application.
7. This furnace must not be operated without furnace door
installed.
NOTE: This furnace and its components listed on the
A/C and Heat Pump equipment sticker were listed in
combination as a system by ETL for the United States.

WINCHESTERBYMORTEXPRODUCTSINCFORTWORTH,TX76106Page2
SAVE THIS MANUAL FOR FUTURE
REFERENCE
Figure 1: Furnace Dimensions
Models ALL ALL ALL ALL
Input, kW 5 8 10 12
With A-Coil Cabinet NO NO NO NO
Air Temperature Rise, Range - F 20-80 20-80 30-90 30-90
Designed Max Outlet Air Temp-F 170 170 180 180
Blower-Heat or Heat/Cool
Max. External SP (Duct), In. W.C.
Thermostat Circuit
Electric Furnace Cabinet Height
10 X 9 BLOWER
0.3
24 VAC, 60 Hz, 40VA
33 inches
Models ALL ALL ALL
Input, kW 15 17 20
With A-Coil Cabinet NO NO NO
Air Temperature Rise, Range - F 35-100 40-10040-100
Designed Max Outlet Air Temp-F 185 185 185
Blower-Heat or Heat/Cool
Max. External SP (Duct), In. W.C.
Thermostat Circuit
Electric Furnace Cabinet Height
10 X 9 BLOWER
0.3
24 VAC, 60 Hz, 40VA
33 inches
Table 1: Electric Furnace Model Specifications
Available Blower Motors
1. Standard Blower Motor – 5 SPD X-13 MOTOR
2. Optional Blower Motor – 3 SPD PSC MOTOR
Product
Name Type of Heat Type of Unit Type of
Blower Motor Heat Strip kW Blower Motor HP
W = Winchester
E = Electric Heat
F = Furnace
42 = 1/3 HP
48 = 1/2 HP
60 = 3/4 HP
10 = 10 kW
12 = 12 kW
15 = 15 kW
20 = 20 kW
C = PSC Blower Motor
X = X-13 Blower Motor
Table 2: Furnace Model Nomenclature
CoilCabinet
Model
FrontDoor
ofCabinet
OpenTop
173/4"x
213/4"
Maximum
Ai rFlow
CFM
1"Pleated
Ai r Filter,In
TheDoor
2"Pleated
Ai rFilter,
Topof
Cabinet
Height Depth Width
97‐FLSB‐21 Louvered N/A 1200 20x20 231/4" 25" 193/4"
97‐FSOB‐21 Solid 1600 20x24 231/4" 25" 193/4"
97‐FLOB‐21 Louvered 1800 20x20 20x24 231/4" 25" 193/4"
97‐FLSB‐27 Louvered N/A 1600 20x30 301/2" 25" 193/4"
97‐FSOB‐27 Solid 1600 20x24 301/2" 25" 193/4"
97‐FLOB‐27 Louvered 1800 20x20 20x24 301/2" 25" 193/4"
97‐FLSB‐39 Louvered N/A 1800 2ea20x20 401/4" 25" 193/4"
97‐FSOB‐39 Solid 2000 20x24 401/4" 25" 193/4"
97‐FG‐18 Louvered N/A 1200 N/A N/A 18" N/A 193/4"
97‐FG‐24 Louvered N/A 1600 N/A N/A 24" N/A 193/4"
Frame&GrillsNon‐Cabinet
CoilSizes
AllMortex96seriescoilswillfitincabinet
96‐97seriescoilsand98seriescoilssizesupto98‐8W7
AllMortexseriescoilswillfitincabinet
Table 3: Optional Cooling Cabinets and Return Air Grille Frame Assemblies

WINCHESTERBYMORTEXPRODUCTSINCFORTWORTH,TX76106Page3
SECTION II: SAFETY
This is a safety alert symbol. When you see this symbol
on labels or in manuals; be alert to the potential for personal
injury. Understand and pay particular attention to the signal words
DANGER, WARNING, or CAUTION.
DANGER: indicates an imminently hazardous situation, which
if not avoided, will result in death or serious injury.
WARNING: indicates a potentially hazardous situation, which if
not avoided, could result in death or serious injury.
CAUTION: indicates a potentially hazardous situation, which if
not avoided, may result in minor or moderate injury. It is also
used to alert against unsafe practices and hazards involving
property damage.
Furnace Weights
WEFXxx42 Models – 82 lbs
WEFXxx48 Models – 79 lbs
WEFXxx60 Models – 85 lbs
Safety Requirements
1. This electric furnace should be installed in accordance
with all national and local; building, safety, plumbing,
and wastewater codes and requirements; along with all
other applicable codes.
2. Refer to the furnace rating plate for the furnace model
number.
3. Refer to the dimensions page of this instruction for the
duct connector dimensions shown in Figures 6 thru 9. The
duct connector must be installed according to the
instructions in this manual.
4. Provide clearances from combustible materials as listed
under Clearances to Combustibles.
5. Provide clearances for servicing ensuring service access is
allowed for the control box, electric elements and the
blower.
6. Failure to carefully read and follow all instructions in this
manual can result in malfunction of the furnace, death,
personal injury, and/or property damage.
7. Check the rating plate and the power supply to be sure the
electrical characteristics match.
8. Electric furnace shall be installed so the electrical
components are protected from water.
9. Installing and servicing heating/cooling equipment can be
hazardous due to electrical components.
10.Only trained and qualified personnel should install, repair
or service heating/cooling equipment. Untrained service
personnel can perform basic maintenance functions such
as cleaning of exterior surfaces and replacing the air
filters. Observe all precautions in the manuals and on the
attached labels when working on this appliance.
11.These instructions cover minimum requirements and
conform to existing national standards and safety codes.
In some instances these instructions exceed certain local
codes and ordinances, especially those who have not kept
up with changing mobile home, modular home and HUD
construction practices. These instructions are to be
followed and are the minimum requirement for a safe
installation.
Inspection
As soon as the furnace is received, it should be inspected for
possible damage during transit. If damage is evident, the
extent of the damage should be noted on the carrier’s freight
bill. A separate request for inspection by the carrier’s agent
should be made in writing. Before installing the furnace you
should check the cabinet for screws or bolts which may have
loosened in transit. There are no shipping or spacer brackets
which need to be removed before startup.
Also check to be sure all accessories such as heater kits, and
coils are available. Installation of these accessories should be
accomplished before the furnace is set in place or the
connecting of the wiring, electric heat, ducts or piping.
CODES
The furnace must be installed in accordance with the
following codes.
Standard for the Installation of Air Conditioning and
Ventilating Systems (NFPA 90A)
Standard for the Installation of Warm Air Heating
and Air Conditioning Systems (NFPA 90B)
National Electrical Code (NFPA 70)
Canadian Electrical Code, Part I (CSA C22.1)
Improper installation may create a condition where the
operation of the product could cause personal injury or
property damage.
Improper installation, adjustment, alteration, service or
maintenance can cause injury or property damage. Refer to
this manual for assistance or for additional information
consult a qualified contractor, installer, or service agency.
This product must be installed in strict compliance with the
installation instructions and any applicable local, state, and
national codes including, but not limited to building,
electrical, and mechanical codes.
FIRE OR ELECTRICAL HAZARD
Failure to follow the safety warnings exactly could result in
serious injury, death, or property damage.
A fire or electrical hazard may result causing property
damage, personal injury or loss of life.

WINCHESTERBYMORTEXPRODUCTSINCFORTWORTH,TX76106Page4
All local codes (State, City, and Township)
NOTE: All applicable codes take precedence over any
recommendation made in these instructions.
SECTION III: RETURN AIR AND
CLEARANCE REQUIREMENTS
Location
Access for servicing is an important factor in the location of
any furnace. Provide a minimum of 24 inches in front of the
furnace for access to the control box, heating elements, and
blower. This access may be provided by a closet door or by
locating the furnace so that a wall or partition is not less than
24 inches from the front access door.
Furnace Clearances
This furnace is approved for zero (0 inches) clearance to
combustible material on any part of the furnace exterior and
the inlet or outlet ducts. Refer to Table 4 for clearance to
combustibles information.
ALCOVE(in) CLOSET(in)
ALL 6 0 0 18 6 0
CLEARANCES
MODEL
FRONTOFFURNACE
TOP(in) BACK(in) SIDES(in) DUCT(in)
Table 4: Clearances to Combustibles
Figure 2: Closet Clearances
Return Air
In order for the furnace to work properly, a closet or alcove
must have a certain total free area opening for the return air.
FOR A/C and HP Furnaces (1/3 HP Blower)
Minimum 200 in² free area opening
Use Return Grille or Coil Cabinet
FOR A/C and HP Furnaces (1/2 HP Blower)
Minimum 250 in² free area opening
Use Return Grille, A/C Coil Cabinet, or any return grille
with a minimum 250 in² free area opening
FOR A/C and HP Furnaces (3/4 HP Blower)
Minimum 390 in² free area opening
Use Return Grille, or A/C Coil Cabinet, or any return
grille with a minimum 390 in² free area opening
Top Return Only – Recommended Grille Size
800 CFM – 20 X 20 Grille – 324 in²
1000 CFM – 20 X 25 Grille - 414 in²
1200 CFM – 25 X 25 Grille - 414 in²
1400 CFM – 25 X 30 Grille - 644 in²
1600 CFM – 25 X 30 Grille - 644 in²
1800 CFM – 30 X 30 Grille - 784 in²
Louvered Door and Top Return – Recommended Grille
Size
800 CFM – 10 X 20 Grille – 144 in²
1000 CFM – 12 X 20 Grille -180 in²
1200 CFM – 14 X 20 Grille - 216 in²
1400 CFM – 18 X 20 Grille - 288 in²
1600 CFM – 18 X 20 Grille - 288 in²
1800 CFM – 20 X 20 Grille - 324 in²
The return air opening can be located in a closet front door or
a side wall above the furnace casing, or in a louvered door on
the furnace. If opening for the return air is located in the floor,
side walls, or closet door anywhere below the furnace casing
height, a 6 inch minimum clearance must be provided on the
furnace side where the return is located to provide for proper
air flow. The 6 inch minimum clearance is not required if
there is a return grille installed above the furnace with the
sufficient return air opening.
Figure 3: Typical Closet Installations
Provisions shall be made to permit the air in the rooms and the
living spaces to return to the furnace. Failure to comply may
cause a reduction in the amount of return air available to the
blower, causing reduced air flow resulting in improper heating
of the living space. The reduced air flow may cause the
furnace to cycle on the limit causing premature heating
element failure.

WINCHESTERBYMORTEXPRODUCTSINCFORTWORTH,TX76106Page5
Figure 4: Typical Alcove Installations
Figure 5: Clearance – Access for Service
Air Distribution System
The furnace is designed to operate at a 0.30 inch WC static
pressure. In order to assure proper air flow through the furnace
the duct distribution system must be designed so that the
external static pressure from the furnace, thru the duct system
must not exceed 0.30 inch WC. It is recommended you review
the manual “Manufactured Housing Duct Systems Guide to
Best Practices” by Manufactured Housing Research Alliance
(MHI-MHRA) before selecting the air distribution system
you are going to use.
SECTION IV: SUPPLY AIR AND DUCT
CONNECTOR INSTALLATION
Duct Connectors
90-DCU0-XX Duct Connectors
The duct connector is used to provide a sealed connection
between the furnace base and an under the floor duct system.
The duct connector allows the furnace to be installed on a
combustible floor without the use of a separate sub base
providing insulation is placed between the duct connector and
the combustible floor. Table 5 indicates the duct connector
needed for your application.
DEPTHFROM
FLOORTODUCT FINGEREDSTYLE
1" 90‐DCU0‐01
2" 90‐DCU0‐01
3" 90‐DCU0‐01
4" 90‐DCU0‐01
5" 90‐DCU0‐02
6" 90‐DCU0‐02
7" 90‐DCU0‐02
8" 90‐DCU0‐02
9" 90‐DCU0‐03
10" 90‐DCU0‐03
11" 90‐DCU0‐03
12" 90‐DCU0‐03
Table 5: Duct Connectors
Figure 6: Duct Connector Depths
Installing the Duct Connector
1. Attach the four (seal strip) foam tape gaskets provided
with the duct connector alongside the perimeter of the
duct opening to seal the duct connector where it attaches
to the top of the duct as shown in Figures 7, 8 and 9.
2. Insert the duct connector thru the opening in the floor and
attach the duct connector to the top of the duct by
inserting the tabs thru the opening in the top of the duct
and bending the tabs back 90 degrees against the inside of
the duct, so the top of the duct is securely fastened to the
duct connector. Be sure the seal strip has sealed the area
around the duct connector where it attaches to the duct.
3. Slit the corners of the duct connector that extend above
the floor, and then bend the sides over onto the floor
surface. Refer to Figures 7, 8 and 9.
4. Place insulation with a rating of R-12 or higher between
the floor base and the floor when used on a combustible
Duct connector can be installed on combustible flooring,
except carpeting, providing insulation having a rating of
R-12 or higher is used between the floor base and the
combustible floor.
Failure to use insulation with a rating of R-12 or higher
between the floor base and a combustible floor; then
installing the floor base on a combustible floor could result
in serious injury, death, or property damage.
A fire may result causing property damage, personal injury
or loss of life.

WINCHESTERBYMORTEXPRODUCTSINCFORTWORTH,TX76106Page6
floor. Be sure to cut the insulation around the perimeter of
the duct connector opening.
5. Install the floor base over the floor opening with the
flanges on the 11 x 13 inch opening facing down. Refer to
Figures 8 and 9.
6. Locate the four (4) screws provided with the duct
connector kit and install the four screws through the four
holes provided in the floor base to secure the floor base to
the floor.
The duct connector is designed for use on ducts wider than
12" inches. When using the connector on smaller width ducts,
there will not be sufficient clearance to bend the tabs on two
sides of the duct connector.
In such cases the tabs may be attached to the sides of the duct
by using sheet metal screws or other suitable fasteners. Place
holes in the tabs for sheet metal screws by drilling the required
screw holes in three (3) tabs on each side of the duct
connector. If more than three tabs need to be used to provide a
more secure and air tight connection, then drill the remaining
tabs so the additional tabs can also be fastened to the duct with
screws. Use a duct sealer to seal any air leaks between the duct
and the duct connector.
Tape can be used to provide a better air seal. The tape should
be a type approved by applicable national or local codes.
Figure 7: Duct Connector and Floor Base Installation
Figure 8: Duct Connector Measurements
Figure 9: Duct Connector Installation in the Floor
SECTION V: FURNACE INSTALLATION
Installing the Furnace with a Return Air Grille Frame
Assembly
Alcove Installation
This kit is approved for use in an alcove – heating only
installation without an air conditioning coil. The return air
grille frame assembly is available in 18” height and 24”
height. To install the return air grille frame assembly to the
furnace, follow the steps below:
Prior to installing the furnace make sure the holes are cut into
the floor for the refrigerant tubing, the electrical wiring are in
place, the thermostat wiring and the condenser control wiring
should be in place.
1. Before installing the return air grille frame on the furnace,
be sure you have enough clearance to install the furnace
and the return air grille assembly.
2. Remove the top shipping cover and corner posts.
3. Remove the front access panel (door).
4. Remove the return air grille frame assembly from the box.
5. Set the return air grille frame assembly on the top – front
part of the furnace. Be sure to line up the screw holes in
the frame with the screw holes in the furnace top cover as
shown in Figure 10.
6. Insert the screws provided with the louvered door
assembly through the holes in the louvered door frame
and into the holes in the furnace top cover.
7. Tighten the screws to secure the louvered door frame
assembly to the top cover of the furnace.
8. Remove the bottom shipping cover.
9. Slide the furnace on to the floor base. Push the furnace
back until the furnace casing is against the rear flange.
10. Secure the furnace to the floor by drilling two holes
through the furnace base and the floor base at the right
and left front inside corners of the cabinet. Use two
screws to secure the furnace to the floor.

WINCHESTERBYMORTEXPRODUCTSINCFORTWORTH,TX76106Page7
Figure 10: Return Air Grille Frame Assembly
Figure 11: Return Air Frame Assembly Filter
Location
Installing the Furnace and Coil Cabinet
Closet Installation
This kit is approved for use in an alcove or closet installations
with an approved air conditioning coil. The coil cabinets are
available in 23.25”, 30.50” and 41.25” height. The furnace is
33” in height making the total furnace and coil cabinet heights
56”, 63” and 73”. To install the coil cabinet assembly to the
furnace, follow the steps below:
Prior to installing the furnace make sure the holes are cut into
the floor for the refrigerant tubing, the drain line, the electrical
wiring, the thermostat wiring and the condenser control
wiring.
1. Before installing the coil cabinet on the furnace, be sure
you have enough clearance to install the furnace and the
filter door assembly.
2. Remove the top shipping cover and corner posts.
3. Remove the bottom shipping cover.
4. Remove the front access panel (door) and lay the furnace
on its back.
5. Remove the coil cabinet from the box and assemble per
the instructions.
6. Lay the coil cabinet on its back and place the coil cabinet
flanges against the furnace top cover.
7. Place coil cabinet door bracket between the coil cabinet
flanges and the furnace top as shown in Figure 12.
8. Install the screws through the holes provided in order to
secure the cooling coil cabinet to the top of the furnace.
9. Slide the furnace on to the floor base. Push the furnace
back until the furnace casing is against the rear flange.
10. Secure the furnace to the floor by drilling two holes
through the furnace base and the floor base at the right
and left front inside corners of the cabinet. Use two
screws to secure the furnace to the floor.
Figure 12: Coil Cabinet Door Bracket Location
SECTION VI: LINE VOLTAGE WIRING
Power Supply
The furnace internal wiring is complete except for the power
supply and the thermostat wires. See wiring diagram and/or
Tables 6 and 7 for wire size, fuse/circuit breaker size, and
ground wire sizes. The use of cable connectors on incoming
power supply wires to relieve any strain on wiring is
recommended. Follow the steps below to connect the power
supply wires.
Single Circuit Line Wiring Connections
1. Remove the control box cover.

WINCHESTERBYMORTEXPRODUCTSINCFORTWORTH,TX76106Page8
2. Install the cable connectors on the 7/8” dia holes on the
right side of the control box.
3. Strip ½” of the insulation on the end of each wire.
4. Insert the wires through the holes in the casing and
through the cable connectors.
5. Insert the black wire into the L1 screw terminal on the 1st
circuit breaker from the top and tighten the set screw to
clamp down on the wire.
6. Insert the white or red wire into the L2 screw terminal on
the 1st circuit breaker down from the top and tighten the
set screw to clamp down on the wire.
7. If you are using a single circuit for a 15kW, 17kW, or
20kW model you will need to install a black jumper wire
from the L1 terminal on circuit breaker #1 to the L1
terminal on circuit breaker #2 and a white or red jumper
wire from the L2 terminal on circuit breaker #1 to the L2
terminal on circuit breaker #2. Refer to Figure 13 for
circuit breaker locations.
Note: The 100 amp 4 Pole Jumper Bar Assembly part
number 68BAE001 can be used in place of the jumper
wires.
8. Insert the green wire into the ground lug and tighten the
set screw.
Dual Circuit Line Wiring Connections
9. If you are using a dual circuit for a 15kW, 17kW, or
20kW model you will need to insert the black wire from
the second power supply into the L1 screw terminal on
the second circuit breaker down from the top and tighten
the set screw to clamp down on the wire.
10. If you are using a dual circuit for a 15kW, 17kW, or
20kW model you will need to insert the white or red wire
from the second power supply into the L2 screw terminal
on the second circuit breaker down from the top and
tighten the set screw to clamp down on the wire.
11. If you are using a dual circuit for a 15kW, 17kW, or
20kW model you will need to insert both green wires into
the ground lug and tighten the set screw.
12. Tighten the screws on the cable connectors until the
power supply wires are securely fastened to the
connector.
NOTE: The furnaces are equipped with either one or two
circuit breakers. These circuit breakers protect the wiring
inside of the furnace in the event of a short circuit.
Additionally, these breakers provide a means of disconnecting
the power to the unit. The circuit breakers in the furnace are
not meant to protect the branch circuit wiring between the
furnace and the home's breaker panel. General wire and
breaker sizes are shown in Table 7. If sheathed cable is used,
refer to NEC National Electrical Code (NFPA 70) or the
Canadian Electrical Code, Part I (CSA C22.1) and local codes
for additional requirements concerning supply circuit wiring.
Electrical data can be found in Tables 6, 7, and 8.
IMPORTANT - All installation on field wiring must be rated
at 60ºC or higher. Please refer to the wiring diagrams on the
furnace or this book for more information.
The 15kW, 17kW and 20kW models may be connected to a
single or dual branch circuit.
IMPORTANT - Refer to the NEC National Electrical Code
(NFPA 70) or the Canadian Electrical Code, Part I (CSA
C22.1) and local codes for wiring material requirements.
5kW 8kW 10kW 12kW 15kW 17kW 20kW
CircuitLoad‐FLA 25.83 38.33 46.50 55.00 67.33 75.83 88.16
MinimumWireSize(90°C)#10#8#8#6#4#4#3
MinimumWireSize(75°C)#10#8#6#6#4#3#2
MinimumWireSize(60°C)#10#8#6#4#3#2#1
GroundWireSize #10#8#8#6#4#4#3
MaxFuseAmps 35 50 60 60 80 90 100
ELECTRICHEATERSIZES
Table 6: Wiring Requirements – Single Branch Circuit
Requires a circuit breaker jumper bar or a jumper wire.
+ Refer to the National Electrical Code Table 250-95 for Non-Sheathed Conductor Ground Wire.

WINCHESTERBYMORTEXPRODUCTSINCFORTWORTH,TX76106Page9
5kW 8kW 10kW 12kW
CircuitNumber 1111121212
CircuitLoad‐FLA 25.83 38.33 46.5 55.0 46.5 20.83 55.0 20.83 46.5 41.66
MinimumWireSize(90°C)#10#8#8#6#8#10#6#10#8#8
MinimumWireSize(75°C)#10#8#6#6#6#10#6#10#6#6
MinimumWireSize(60°C)#10#8#6#4#6#10#4#10#6#6
GroundWireSize #10#8#8#6#8#10#6#10#8#8
MaxFuseAmps 35 50 60 60 60 25 60 25 60 50
15kW 17kW 20kW
ELECTRICHEATERSIZES
Table 7: Wiring Requirements – Dual Branch Circuit
Dual power supply for US only.
+ Refer to the National Electrical Code Table 250-95 for Non-Sheathed Conductor Ground Wire.
5kW 8kW 10kW 12kW
BranchCircuitNumber 1111121212
BTU 17,033 27,263 34,067 40946.0 34,067 17,033 40,946 17,033 34,067 34,067
kW 4.99 7.99 10 12.0 10 4.99 12.0 4.99 10 10
BTU 15,876 26,512 33,686 38,612 33,686 15,876 38,612 15,876 33,686 33,686
kW 4.65 7.77 9.78 11.32 9.78 4.65 11.32 4.65 9.78 9.78
BTU 14,736 23,339 30,222 36,483 30,222 14,736 36,483 14,736 30,222 30,222
kW 4.32 6.84 8.86 10.69 8.86 4.32 10.69 4.32 8.86 8.86
BTU 17,033 27,263 34,067 40,946
kW 4.99 7.99 9.998 12
AMPS 4.3 4.3 4.3 4.3 4.3 N/A 4.3 N/A 4.3 N/A
kW 1.032 1.032 1.032 1.032 1.032 N/A 1.032 N/A 1.032 N/A
57,979 68,232
14.9904 16.992 19.9968
220VAC,60HZ,1PH
HeatingElementCapacity
BlowerMotor@240VAC
240VAC,60HZ,1PH
51,149
15kW 17kW 20kW
ELECTRICHEATERSIZES
230VAC,60HZ,1PH
Table 8: Electrical Data
Figure 13: Control Box Component Locations
Casing or cabinet must be permanently grounded in accordance with the National Electrical Code or other applicable codes.
Note: Optional blower speed change relay is also used as the isolation relay for the PSC motor. This relay is not optional relay on
the PSC Motors.

WINCHESTERBYMORTEXPRODUCTSINCFORTWORTH,TX76106Page10
Figure 14: Control Box Cover and Circuit Breaker
Location – Dual Element Box
Figure 15: Line Voltage Electrical Shield
Figure 16: Line Voltage Electrical Shield Location
SECTION VII: THERMOSTAT WIRING AND
CONNECTIONS
Thermostat Wiring
Thermostat wires connect through side of furnace and should
also be no smaller than 20 gauge wire. Refer to Table 9 for
recommended wire gauge, lengths and maximum current for
each wire gauge.
ThermostatWire
Length
ThermostatWire
Gauge
ThermostatWire
MaximumCurrent
0‐70Feet 20 1.5amps
0‐120Feet 18 2.3amps
Table 9: Low Voltage Wire Gauge and Max Lengths
Figure 17: Control Box In-coming Power, Low
Voltage Wiring, Blower Wiring, and Low Voltage
Fuse Locations
For personal safety be sure to turn the electrical power
“OFF” at the main entrance (Home Circuit Breaker Box)
and at the control box circuit breakers before attempting
any service or maintenance operations. Homeowners should
never attempt to perform any maintenance which requires
opening the furnace control box door. Refer to Figure 20.
This furnace is equipped with a shield that covers the line
voltage electrical supply wires and the circuit breaker
connections to prevent accidental electrical shock. Be sure
to turn the electrical power “OFF” at the main entrance
(Home Circuit Breaker Box) and at the control box circuit
breakers before removing the shield.
“Refer to Figure 21.

WINCHESTERBYMORTEXPRODUCTSINCFORTWORTH,TX76106Page11
Power wires can enter through the side of the unit or through
the auxiliary entrance, located in the bottom of the unit.
When bringing wiring through the bottom of the furnace,
cable connectors must be installed to hold wiring in place and
to relieve any strain on the wiring.
These connectors will also serve as a seal between the furnace
and the floor. Thus, additional sealing is not required.
The use of a five-conductor cable from the thermostat to the
furnace is recommended for typical heating or heating /
cooling installations with a three-conductor cable from the
furnace to the condenser.
A seven-conductor cable from the thermostat to the furnace is
recommended for a typical heat pump installation with a five-
conductor cable from the furnace to the condenser.
The thermostat wire colors and the typical heating / cooling
connections are listed in Table 10.
The thermostat wire colors and the typical heat pump heating /
cooling connections are listed in Table 11.
NOTE: There is a 3 Amp slow blow bar fuse located on the
right side of the control box that protects the 24 VAC circuit.
Replace this fuse only with the equivalent 3 Amp fuse.
NOTE: If the thermostat cable is on the left side of the
furnace place the grommet in the 3/8” hole on the left side of
the furnace casing. Run the thermostat wire cable through the
control box exiting the right side of the control box next to the
low voltage pigtails. Follow the steps for “Typical Heating /
Cooling Thermostat Wiring Connections” or “Typical
Heat Pump - Heating / Cooling Thermostat Wiring
Connections”
Thermostat Installation
The adjustable heat anticipator in the thermostat is pre-set at
0.4 Amps. This setting should be checked at the time of
installation.
In some cases the thermostat may be a “self-setting" type in
which case no Amp setting will be found on the thermostat,
eliminating the need for any field adjustment.
Thermostat should be located on an inside wall in an open area
to more closely regulate average room air, preferably, where
there is air movement back to furnace. Locating height of
thermostat is important. Thermostat should be located
preferably in a hall way upstream from the furnace return
airflow, not within 3 feet of from any windows and 52 to 66
inches above the floor.
DO NOT place the thermostat within three feet of any the
furnace supply air registers
DO NOT place the thermostat within three feet of any the air
conditioner supply air registers
Maintenance, operating and/or programming instructions are
in the envelope accompanying the thermostat. Give the
envelope to the homeowner.
Separate Heating and Cooling System; Same Thermostat
If the furnace and the cooling unit have separate transformers
be sure to use a thermostat with isolated heating and cooling
contacts to prevent interconnection of Class II 24 Volt
Systems. Cycle furnace and the air conditioner separately to
make sure it will operate correctly.
Most new thermostats have a separate heating and cooling
contact for use with homes that have a furnace and air
conditioner that are completely separate and each have a 24
VAC transformer for system control. These thermostats have a
“RC” terminal for cooling and a “RH” terminal for heating.
Use these terminals to connect cooling unit (RC and Yellow)
and the furnace (RH and White) for separate operation. Refer
to Figure 21 and 22.
If your thermostat does not have the “RC” and “RH” terminals
it is recommended that you purchase a new thermostat.
Separate Heating and Cooling Thermostats
If the heating/cooling system in your house is a central heating
and cooling system but the furnace and the cooling unit are
controlled by separate thermostats then the use of a thermostat
interlock switch is required in order to prevent the furnace and
the air conditioner from operating at the same time.
Do not locate thermostat within three feet of any of the
following items:
1. Furnace supply air registers
2. Cooling unit supply air registers
3. Lights or heat lamps
4. Aquariums
5. Televisions, stereo, amplifiers, surround sound
systems
6. Stoves or any cooking appliance
7. Refrigerator
8. Washer and/or dryer
9. Hot water tank
10. Sink or near any hot water
11. Within 15 feet of any electric space heater
12. Within 2 feet of an
y
sunli
g
h
t

WINCHESTERBYMORTEXPRODUCTSINCFORTWORTH,TX76106Page12
R
W
C
C
Thermostat
Furnace Condenser
W
Y
Outdoor Section
24 VAC
to Furnace Trans
24 VAC Common
to Furnace Trans
R
G
Y
Thermostat
W
Heating G
R
Y
G
Cooling
Figure 18: Separate Thermostats; Same Furnace and
Cooling Unit
G
RH
Y
C
R
RC
G
W
CC
W2
Thermostat
Furnace
Heat Pump
W2
W/E
O
W2
Y
O
Opt.
W/E
O.D.
T-Stat
Outdoor Section
Add Jumper if O.D T-Stat is not used
RC
24 VAC
to Heat pump Trans
24 VAC Common
24 VAC Common
to Furnace Trans
NOTE: Trans = Transformer
T
24VAC
to Heat pump Trans
to Furnace Trans
24 VAC
24VAC
Figure 19: Same Thermostat; Separate Furnace and
Heat Pump Units with separate transformers
RC
G
Furnace
Thermostat
CC
W
G
to Furnace Trans
NOTE: Trans =Transformer
R
R
24 VAC
to Furnace Trans
24VAC
Y
C
Cooling Unit
W
Y
Outdoor Section
RH
24 VAC Common
Figure 20: Same Thermostat; Separate Furnace and
Cooling Units with separate transformers
WireColor Description
Letter
Code
FurnacePigTail
WireConnection
Thermostat
Connection
Condenser
Connections
RED 24VAC R Red R N/A
WHITE Heat(1stStageHeat) W White WorW1 N/A
GREEN IndoorFan G Green G N/A
YELLOW Cooling‐Stage1 Y Yellow YorY1 YorY1
BROWN 24VACCommon BRN Brown C C
Table 10: Recommended Heating/Cooling Thermostat Wire Color Codes and Connections.
WireColor Description
Letter
Code
FurnacePigTail
WireConnection
Thermostat
Connection
Condenser
Connections
RED 24VAC R Red R N/A
WHITE Heat(1stStageHeat) W White E N/A
GREEN IndoorFan G Green G N/A
YELLOW Cooling‐Stage1YYellowYorY1 YorY1
BROWN 24VACCommon BRN Brown C C
BLACK Heat(Optional2ndStageHeat) BLK White W2 N/A
ORANGE HeatPumpReversingValveSolenoid O N/A O O
BLUE Cooling‐(Optional2ndStageCooling) BLU N/A Y2 Y2
Table 11: Recommended Heating/Cooling/Heat Pump Thermostat Wire Color Codes and Connections.
Typical Heating/Cooling Thermostat Wiring Connections 1. Remove the control box cover.
When using separate thermostats a thermostat interlock
system must be provided to prevent simultaneous operation
of the furnace and air conditioner. Simultaneous operation
can result in equipment overheating, equipment damage,
and energy wastes.
Do Not connect the Yellow wire to the thermostat unless an
outdoor unit is installed.

WINCHESTERBYMORTEXPRODUCTSINCFORTWORTH,TX76106Page13
2. Install a grommet in the 3/8” hole on the right side of
the furnace casing to protect the thermostat wire
cable.
3. Strip ½” of the insulation on the end of each wire.
4. Insert the wire cable from the thermostat through the
grommet in the right side of the casing and place the
thermostat wire cable on the right side of the control
box, next to the low voltage pintails.
5. Connect the Red (24 VAC) supply thermostat wire to
the Red low voltage pigtail wire and secure with a
wire nut.
6. Connect the White (heating) thermostat wire to the
White low voltage pigtail wire and secure with a wire
nut.
7. Connect the Green (indoor fan) thermostat wire to the
Green low voltage pigtail wire and secure with a wire
nut.
8. Connect the Yellow (air conditioning) wire from the
thermostat with the Yellow low voltage pigtail wire
on the furnace and with the Red wire from the
compressor contactor on the condenser unit. Fasten
the three wires together securely with a wire nut.
9. Connect the Brown (24 VAC Common) wire from
the thermostat with the Brown low voltage pigtail
wire on the furnace and with the Brown (Common)
wire from the compressor contactor on the outdoor
unit. Fasten the three wires together securely with a
wire nut.
G
R
W
Y
C
RR
G
W
YY
CC
Thermostat Furnace Condenser
Figure 21: Typical Heating/Cooling Digital
Thermostat Connections
Typical Heat Pump - Heating/Cooling Thermostat Wiring
Connections
1. Remove the control box cover.
2. Install a grommet in the 3/8” dia hole on the right side of
the furnace casing to protect the thermostat wire cable.
3. Strip ½” of the insulation on the end of each wire.
4. Insert the wire cable from the thermostat through the
grommet in the right side of the casing and place the
thermostat wire cable on the right side of the control box,
next to the low voltage pigtails.
5. Connect the Red (24 VAC) supply wire from the
thermostat to the Red low voltage pigtail wire on the
furnace and with the Red wire from the “R” terminal on
the outdoor unit. Fasten the three wires together securely
with a wire nut.
NOTE: If the cooling unit is separate from the furnace and
each have a transformer then remove the Red jumper
wire on the “RC” and “RH” terminals and connect
the outdoor unit to the “RC” terminals and the
furnace to the “RH” terminals.
6. Connect the White (heating) wire from the thermostat to
the White low voltage pigtail wire on the furnace and with
the White wire from the “E” terminal on the outdoor unit.
Fasten the three wires together securely with a wire nut.
7. Connect the Green (indoor fan) wire from the thermostat
to the Green low voltage pigtail wire on the furnace and
securely fasten the two wires together with a wire nut.
8. Connect the Red wire from the “Y” terminal on the
outdoor unit. Fasten the three wires together securely with
a wire nut.
9. Connect the (24 VAC Common) wire from the thermostat
with the Brown low voltage pigtail wire on the furnace
and with the Brown (Common) wire from the “C”
terminal on the outdoor unit. Fasten the three wires
together securely with a wire nut.
10. Connect the Orange (Reversing Valve Solenoid) wire
from the thermostat with the Orange wire from the “O”
terminal on the condenser unit. Fasten the two wires
together securely with a wire nut.
11. Connect the Black (2nd Stage Heating) wire from the
thermostat with the Black wire from the “W2” terminal
on the outdoor unit. Fasten the three wires together
securely with a wire nut.
G
R
Y
C
RR
G
W
CC
W2
Thermostat
Furnace
Heat Pump
W2
W/E
O
W2
Y
O
T
Opt.
W/E
O.D.
T-Stat
Outdoor Section
AddJumper if O.D T-Stat isnot used
Figure 22: Typical Heat Pump – Heating / Cooling

WINCHESTERBYMORTEXPRODUCTSINCFORTWORTH,TX76106Page14
SECTION VIII: MOTOR, BLOWER AND
FURNACE STARTUP SECTION
Selecting the X-13 Blower Speed
This furnace uses the new X-13 high efficiency motor. This
motor operates on 240 VAC. The motor speed tap are 24
VAC, 0.03 amps, 60 Hz, 1 PH. The speed taps can be changed
by removing the black wire from the sequencer terminal or the
red wire from the relay terminal and connecting either the
blue, orange, or purple wire to the terminal. Table 12 shows
the X-13 motor lead connection labeling and the connection
definitions.
Terminal Connection
CSpeedTapCommon‐24VACCommon
L SupplyVoltagetoMotor‐240VACLine1
G GroundConnection
N SupplyVoltagetoMotor‐240VACLine2
1LowSpeedTap‐24VAC
2Med‐LowSpeedTap‐24VAC
3MediumSpeedTap‐24VAC
4Med‐HighSpeedTap‐24VAC
5HighSpeedTap‐24VAC
Table 12: X-13 Motor Terminal Connections
Total 24 VAC circuit amps are 0.14 amps.
.
Change Motor Speeds
1. Turn off all electrical supply circuits to the furnace at
the main service (House Circuit Breaker) panel.
2. Remove furnace front door and switch furnace circuit
breaker(s) to “OFF”.
3. Disconnect the wire from the sequencer or relay
terminal and reconnect the desired wire to the
terminal. Refer to Table 12 for speed tap wire colors.
4. Turn the circuit breakers on and reinstall furnace
front door.
5. Turn on all electrical supply circuits to the furnace at
the main service (House Circuit Breaker) panel.
Figure 23: X-13 Motor Terminals
Replacing the Blower Motor
1. Turn off all electrical supply circuits to the furnace at
the main service panel.
2. Remove furnace front door and switch furnace circuit
breaker(s) to “OFF”.
3. Disconnect the plastic wire plug that has the wires
that go to the motor terminals from the right side of
the control box.
4. Remove the screw on the right side of the blower
mounting plate.
5. Slide the blower out of the blower compartment and
set on the floor.
6. Remove the wires from the terminals. Be sure to
write down the motor terminal identifier and wire
color so the wires do not get mistakenly placed on the
wrong terminals.
7. Remove the blower motor from the mounting bracket
by removing the screws on the sides of the blower
that secure the blower to the bracket.
8. Insert the new blower motor into the blower
mounting bracket and insert the screws.
9. Connect the wires to the same terminals on this motor
that they were connected to on the motor that was
removed.
10. Slide the blower assembly into the blower deck and
insert the screw on the right side of the mounting
bracket.
11. Connect the pin plug to the mating pin plug on the
right side of the control box.
12. Switch the circuit breakers to ON and replace furnace
front door.
13. Turn on all electrical supply circuits to the furnace at
the main service (House Circuit Breaker) panel.
14. Set the thermostat to the desired temperature.
To avoid personal injury or property damage, make certain
that the motor leads cannot come into contact with non-
insulated metal components of the unit.

WINCHESTERBYMORTEXPRODUCTSINCFORTWORTH,TX76106Page15
Figure 24: Blower Assembly and Blower Deck
SECTION IX: FINAL SYSTEM
CHECKOUT
1. Refer to appropriate wiring diagram and recheck all
wiring connections. Ensure that all wiring
connections are tight.
2. Check blower motor connectors for proper
connection.
3. If the control box cover is removed; reinstall control
box cover.
4. Switch circuit breaker(s) to “ON” position.
5. Switch the furnace circuit breakers in the main
service (House Circuit Breaker) panel to the ON
position.
6. Set the blower selector switch to the ON position and
check all of the duct connections for air leaks. Seal
any leaks found.
7. Set the blower selector switch to the AUTO position.
8. Set the thermostat above the room temperature to
check for proper operation of the electric heaters.
9. Set the thermostat to the desired temperature.
Thermostat Heat Anticipator
Some thermostats have a heat anticipator setting that must be
set to the settings shown below in order to function correctly.
If the heat anticipator setting is too low the furnace will short
cycle. If the heat anticipator setting is too high the furnace will
run long cycles thus causing the temperature to over run the
temperature setting. This will cause the homeowner to feel hot
by the time the blower completes its cycle; then cold, by the
time the furnace cycles on again.
The heat anticipator should be set to the following settings.
For 5kW, 8kW, 10kW, 12kW 15kW, 17kW and 20 kW
Models Set at 0.4

WINCHESTERBYMORTEXPRODUCTSINCFORTWORTH,TX76106Page16
Table 13: X-13 Motor Factory Speed Tap Settings

WINCHESTERBYMORTEXPRODUCTSINCFORTWORTH,TX76106Page17
Section X: WIRING DIAGRAMS
Figure 25: 5 kW Electric Heater Wiring Diagram with a Standard Digital Heating/Cooling/Heat Pump/Single or Two Stage
Programmable Thermostat, X-13 blower motor.
NOTE: IF ANY OF THE ORIGINAL WIRE SUPPLIED WITH THIS UNIT MUST BE REPLACED. IT MUST BE REPLACED
WITH TYPE 105°C THERMOPLASTIC OR THE EQUIVALENT.

WINCHESTERBYMORTEXPRODUCTSINCFORTWORTH,TX76106Page18
Figure 26: 8 kW / 10 kW / 12 kW Electric Heater Wiring Diagram with a Standard Digital Heating/Cooling/Heat Pump/Single
or Two Stage Programmable Thermostat, X-13 blower motor.
NOTE: IF ANY OF THE ORIGINAL WIRE SUPPLIED WITH THIS UNIT MUST BE REPLACED. IT MUST BE REPLACED
WITH TYPE 105°C THERMOPLASTIC OR THE EQUIVALENT.

WINCHESTERBYMORTEXPRODUCTSINCFORTWORTH,TX76106Page19
Figure 27: 15 kW / 17 kW Electric Heater Wiring Diagram with a Standard Digital Heating/Cooling/Heat Pump/Single or
Two stage Programmable Thermostat, X-13 blower motor.
NOTE: IF ANY OF THE ORIGINAL WIRE SUPPLIED WITH THIS UNIT MUST BE REPLACED. IT MUST BE REPLACED
WITH TYPE 105°C THERMOPLASTIC OR THE EQUIVALENT.

WINCHESTERBYMORTEXPRODUCTSINCFORTWORTH,TX76106Page20
Figure 28: 20 kW Electric Heater Wiring Diagram with a Standard Digital Heating/Cooling/Heat Pump/Single or Two Stage
Programmable Thermostat, X-13 blower motor.
NOTE: IF ANY OF THE ORIGINAL WIRE SUPPLIED WITH THIS UNIT MUST BE REPLACED. IT MUST BE REPLACED
WITH TYPE 105°C THERMOPLASTIC OR THE EQUIVALENT
