WINIA KOM9P1160 User manual

담당 이주희 님
브랜드 WINIA 언 어 영어
F.MODEL KOM9P2CTTZBW1BUT00
B.MODEL KOM9P1160HZ
BUYER REGALE
COUNTRY U.K.
MEMO 총 29p (140 x 210)
20.07.13-총 1p (표지)
20.07.24 - 총 1p(표지2)
ABOUT THIS MANUAL
(주) 신광씨링
광주광역시 서구 하남대로
502번길 14
NO NEED PRINT
REGALE_KOM9P1160HZ(KOM9P2CTTZBW1BUT00)(�)_A5.indd 1 2020-07-24 �� 4:47:14

Before operating this oven, please read these instructions completely.
USE AND CARE MANUAL
COMMERCIAL MICROWAVE OVEN
KOM9P1160HZ
* CUSTMER SERVICE HELP LINE
FREE 3 year commercial warranty.
This product has a limited 3 year on-site parts and labour warranty for electrical malfunction from the date
of purchase (proof of purchase required). This warranty does not include, glass items, lamps, ceiling or
base plates, removable parts, damage, misuse or lack of cleaning correct procedures. For service
enquiries please contact either your supplier or WINIA Electronics on 0844 887 2525. Your original
invoice will be required as verification. This warranty does not cover the replacement of damaged parts
required during any servicing of the appliance.
REGALE_KOM9P1160HZ(KOM9P2CTTZBW1BUT00)(�)_A5.indd 2 2020-07-24 �� 4:47:14

Before operating this oven, please read these instructions completely.
OPERATING
INSTRUCTIONS
MICROWAVE OVEN
KOM9P1160HZ
REGALE_KOM9P1160HZ(KOM9P2CTTZBW1BUT00)(�)_A5.indd 3 2020-07-24 �� 4:47:14

1
PRECAUTIONS TO AVOID POSSIBLE
EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY
(A) DO NOT ATTEMPT TO OPERATE THIS OVEN WITH
THE DOOR OPEN SINCE OPEN-DOOR OPERATION
CAN RESULT IN HARMFUL EXPOSURE TO
MICROWAVE ENERGY. IT IS IMPORTANT NOT TO
DEFEAT OR TAMPER WITH THE SAFETY
INTERLOCKS.
(B) DO NOT PLACE ANY OBJECT BETWEEN THE OVEN
FRONT FACE AND THE DOOR OR ALLOW SOIL OR
CLEANER RESIDUE TO ACCUMULATE ON SEALING
SURFACES.
(C) WARNING: IF THE DOOR OR DOOR SEALS ARE
DAMAGED, THE OVEN MUST NOT BE OPERATED
UNTIL IT HAS BEEN REPAIRED BY A COMPETENT
PERSON; (1) DOOR (BENT), (2) HINGES AND
LATCHES(BROKEN OR LOOSENED), (3) DOOR SEALS
AND SEALING SURFACES.
(D) WARNING: IT IS HAZARDOUS FOR ANYONE OTHER
THAN A COMPETENT PERSON TO CARRY OUT ANY
SERVICE OR REPAIR OPERATION THAT INVOLVES
THE REMOVAL OF A COVER WHICH GIVES
PROTECTION AGAINST EXPOSURE TO MICROWAVE
ENERGY:
(E) WARNING: ONLY ALLOW CHILDREN TO USE THE
OVEN WITHOUT SUPERVISION WHEN ADEQUATE
INSTRUCTIONS HAVE BEEN GIVEN SO THAT THE
CHILD IS ABLE TO USE THE OVEN IN A SAFE WAY AND
UNDERSTANDS THE HAZARDS OF IMPROPER USE.
REGALE_KOM9P1160HZ(KOM9P2CTTZBW1BUT00)(�)_A5.indd 1 2020-07-24 �� 4:47:14

2
PRECAUTIONS TO AVOID POSSIBLE
EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY
(F) WARNING: THIS APPLIANCE CAN BE USED BY
CHILDREN AGED FROM 8 YEARS AND ABOVE AND
PERSONS WITH REDUCED PHYSICAL, SENSORY OR
MENTAL CAPABILITIES OR LACK OF EXPERIENCE
AND KNOWLEDGE IF THEY HAVE BEEN GIVEN
SUPERVISION OR INSTRUCTION CONCERNING USE
OF THE APPLIANCE IN A SAFE WAY AND
UNDERSTAND THE HAZARDS INVOLVED. CHILDREN
SHALL NOT PLAY WITH THE APPLIANCE. CLEANING
AND USER MAINTENANCE SHALL NOT BE MADE BY
CHILDREN UNLESS THEY ARE AGED FROM 8 YEARS
AND ABOVE AND SUPERVISED.
(G) WARNING: LIQUIDS AND OTHER FOODS MUST NOT
BE HEATED IN SEALED CONTAINERS SINCE THEY
ARE LIABLE TO EXPLODE:
(H) WARNING: MICROWAVE HEATING OF BEVERAGES
CAN RESULT IN DELAYED ERUPTIVE BOILING,
THEREFORE CARE MUST BE TAKEN WHEN
HANDLING THE CONTAINER;
(I) WARNING: THE CONTENTS OF FEEDING BOTTLES
AND BABY FOOD JARS MUST BE STIRRED OR
SHAKEN AND THE TEMPERATURE CHECKED BEFORE
CONSUMPTION, IN ORDER TO AVOID BURNS;
REGALE_KOM9P1160HZ(KOM9P2CTTZBW1BUT00)(�)_A5.indd 2 2020-07-24 �� 4:47:14

3
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY ...1
TABLE OF CONTENTS ....................................................................................................................3
EARTHING INSTRUCTIONS............................................................................................................4
INSTALLATION.................................................................................................................................4
SPECIFICATIONS.............................................................................................................................5
IMPORTANT .....................................................................................................................................5
IMPORTANT SAFETY INSTRUCTIONS ..........................................................................................6
FEATURES DIAGRAM......................................................................................................................9
OPERATION PROCEDURE ...........................................................................................................11
CONTROLS.................................................................................................................................... 12
TIME DEFROSTING .............................................................................................................. 12
COOKING IN ONE STAGE.....................................................................................................13
MEMORY FUNCTION............................................................................................................ 14
START /+30 SEC ................................................................................................................... 15
CHECK FUNCTION ............................................................................................................... 15
DOUBLE QUANTITY FUNCTION.......................................................................................... 15
CHILD SAFETY LOCK........................................................................................................... 16
POWER SAVE MODE ........................................................................................................... 16
MUTE FUNCTION.................................................................................................................. 16
TO STOP THE OVEN WHILE THE OVEN IS OPERATING.................................................. 16
ABNORMAL MESSAGE ........................................................................................................ 16
COOKING INSTRUCTIONS........................................................................................................... 17
MICROWAVING PRINCIPLES....................................................................................................... 18
HOW MICROWAVES COOK FOOD.............................................................................................. 18
CONVERSION CHART ................................................................................................................. 18
COOKING TECHNIQUES.............................................................................................................. 19
DEFROSTING GUIDE.................................................................................................................... 20
COOKING CHART ......................................................................................................................... 21
REHEATING CHART ..................................................................................................................... 22
VEGETABLE CHART .....................................................................................................................23
CARE OF YOUR MICROWAVE OVEN ......................................................................................... 24
CARE AND CLEANING ................................................................................................................. 24
USE YOUR MICROWAVE OVEN SAFELY ...................................................................................25
ARCING ..........................................................................................................................................25
BEFORE YOU CALL FOR SERVICE..............................................................................................26
DISPOSAL OF USED ELECTRICAL & ELECTRONIC EQUIPMENT ...........................................26
QUESTIONS AND ANSWERS........................................................................................................27
TABLE OF CONTENTS
REGALE_KOM9P1160HZ(KOM9P2CTTZBW1BUT00)(�)_A5.indd 3 2020-07-24 �� 4:47:14

4
This appliance must be earthed. In the event of an electrical short circuit, earthing reduces the risk of
electric shock by providing an escape wire for the electric current. This appliance is equipped with a
cord having a earthing wire with an earthing plug. The plug must be plugged into an outlet that is
properly installed and earthed.
INSTALLATION
EARTHING INSTRUCTIONS
WARNING : Improper use of the earthing plug can result in a risk of electric shock. Consult a qualified
electrician or serviceman if the earthing instructions are not completely understood, or if
doubt exists as to whether the appliance is properly earthed. If it is necessary to use an
extension cord, use only a 3-wire extension cord that has a 3-blade earthing plug, and a
3-slot receptacle that will accept the plug on the appliance. The marked rating of the
extension cord should be equal to or greater than the electrical rating of the appliance.
1. Ventilation
Do not block air vents. If they are blocked
during operation, the oven may overheat and
eventually cause a failure. For proper
ventilation, allow above 3 inches of space
between oven sides, rear and the minimum
height of free space necessary above the top
surface of the oven is 100mm.
2. Steady, flat location
This oven should be set on a steady, flat
surface. This oven is designed for counter top
use only.
The microwave oven shall not be placed in a
cabinet unless it has been tested in a cabinet.
3. Leave space behind and side
All air vents should be kept a clearance. If all
vents are covered during operation, the oven
may overheat and, eventually, oven failure.
4. Away from radio and TV sets
Poor television reception and radio
interference may result if the oven is located
close to a TV, Radio antenna, feeder and so
on. Position the oven as far from them as
possible.
5. Away from heating appliance and water
taps
Keep the oven away from hot air, steam or
Splash when choosing a place to position it, or
the insulation might be adversely affected and
breakdowns occur.
6. Power supply
• Check your local power source.
This oven requires a current of
approximately 7 amperes, 240V 60Hz.
• Power supply cord is about 1.0 meters long.
• The voltage used must be the same as
specified on this oven. Using a higher
voltage may result in a fire or other accident
causing oven damage. Using low voltage will
cause slow cooking. We are not responsible
for damage resulting from use of this oven
with a voltage of ampere fuse other than
those specified.
• If the supply cord is damaged, it must be
replaced by the manufacturer, its service
agent or a similarly qualified persons in order
to avoid a hazard.
7. Examine the oven after unpacking for any
damage such as:
A misaligned door, Broken door, A dent in
cavity. If any of the above is visible, DO NOT
INSTALL, and notify dealer immediately.
8. Do not operate the oven if it is colder than
room temperature.
(This may occur during delivery in cold
weather.) Allow the oven to become room
temperature before operating.
REGALE_KOM9P1160HZ(KOM9P2CTTZBW1BUT00)(�)_A5.indd 4 2020-07-24 �� 4:47:14

5
SPECIFICATIONS
542 461
329
WARNING: This appliance must be earthed.
IMPORTANT
The wires in this mains lead fitted to this appliance are coloured in accordance with the following code.
Green-and-yellow : Earth
Blue : Neutral
Brown : Live
As the colours of the wires in the mains lead of this appliance may not correspond with the coloured
markings identifying the terminals in your plug, proceed as follows: the wire which is coloured green-and-
yellow must be connected to the terminal in the plug which is marked with the letter 'E', the earth symbol or
coloured green-and-yellow. The wire which is coloured blue must be connected to the terminal which is
marked with the letter 'N' or coloured black.
The wire which is coloured brown must be connected to the terminal which is marked with the letter 'L' or
coloured red.
POWER SUPPLY 240V AC 60Hz SINGLE PHASE WITH EARTHING
MICROWAVE
POWER CONSUMPTION 1600 W
OUTPUT POWER 1100 W
FREQUENCY 2450 MHz
OUTSIDE DIMENSIONS (W x H x D) 542 x 329 x 461mm (21.34 x 12.95 x 18.15 in.)
CAVITY DIMENSIONS (W x H x D) 350 x 230 x 357 mm (12.78 x 3.06 x 14.06 in.)
NET WEIGHT APPROX. 18Kg (37.48 lbs.)
TIMER 5 min
POWER SELECTIONS 5 LEVELS
* Specifications are subject to change without notice.
REGALE_KOM9P1160HZ(KOM9P2CTTZBW1BUT00)(�)_A5.indd 5 2020-07-24 �� 4:47:14

6
IMPORTANT SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE
REFERENCE
WARNING : To prevent fire, burns, electric
shock and other warnings:
Listed below are, as with all appliances, certain
rules to follow and safeguards to assure high
performance from this oven:
1. Do not use the oven for any
reason other than food
preparation, such as for drying
clothes, paper, or any other
nonfood items or for sterilizing
purposes.
2. Do not use the oven when
empty, this could damage the
oven.
3. Do not use the oven cavity for
any type of storage, such as
papers, cookbook, cookware,
etc.
4. Make sure you remove caps or
lids prior to cooking when you
cook food sealed in bottles.
5. Do not put foreign material
between the oven surface and
door. It could result in excessive
leakage of microwave energy.
6. Do not use recycled paper
products for cooking. They may
contain impurities which could
cause sparks and/or fires when
used during cooking.
7. Do not pop popcorn unless
popped in a microwave
approved popcorn popper or
unless it's commercially
packaged and recommended
especially for microwave ovens.
Microwave popped corn
produces a lower yield than
conventional popping; there will
be a number of unpopped
kernels. Do not use oil unless
specified by the manufacturer.
8. Do not cook any food
surrounded by a membrane,
such as egg yolks, potatoes,
REGALE_KOM9P1160HZ(KOM9P2CTTZBW1BUT00)(�)_A5.indd 6 2020-07-24 �� 4:47:14

7
chicken livers, etc., without first
piercing them several times with
a fork.
9. Do not pop popcorn longer than
the manufacturer's directions.
(popping time is generally below
3 minutes). Longer cooking
does not yield more popped
corn, it can cause scorchings
and fire. Also, the cooking tray
can become too hot to handle or
may break.
10. If smoke is observed, switch
off or unplug the appliance and
keep the door closed in order
to stifle any flames.
11. When heating food in plastic or
paper containers, keep an eye
on the oven due to the
possibility of ignition.
12. The contents of feeding bottles
and baby food jars shall be
stirred or shaken and the
temperature checked before
consumption, in order to avoid
burns.
13. Always test the temperature of
food or drink which has been
heated in a microwave oven
before you give it to
somebody, especially to
children or elderly people. This
is important because things
which have been heated in a
microwave oven carry on
getting hotter even though the
microwave oven cooking has
stopped.
14. Eggs in their shell and whole
hard-boiled eggs should not be
heated in microwave ovens
since they may explode, even
after microwave heating has
ended;
15. Keep the waveguide cover
clean at all times. Wipe the
oven interior with a soft damp
cloth after each use. If you
leave grease or fat anywhere
in the cavity it may overheat,
smoke or even catch fire when
next using the oven.
16. Never heat oil or fat for deep
frying as you cannot control
the temperature and doing so
may lead to overheating and
fire.
17. Liquids, such as water, coffee,
or tea are able to be
overheated beyond the boiling
REGALE_KOM9P1160HZ(KOM9P2CTTZBW1BUT00)(�)_A5.indd 7 2020-07-24 �� 4:47:14

8
SAVE THESE INSTRUCTIONS
point without appearing to be
boiling due to surface tension
of the liquid. Visible bubbling or
boiling when the container is
removed from the microwave
oven is not always present.
THIS COULD RESULT IN
VERY HOT LIQUIDS
SUDDENLY BOILING OVER
WHEN A SPOON OR OTHER
UTENSIL IS INSERTED INTO
THE LIQUID.
To reduce the risk of injury
to persons:
a) Do not overheat the liquid.
b) Stir the liquid both before
and halfway through heating
it
c) Do not use straight-sided
containers with narrow
necks.
d) After heating, allow the
container to stand in the
microwave oven for a short
time before removing the
container.
e) Use extreme care when
inserting a spoon or other
utensil into the container.
18. Oven should be cleaned
regularly and any food
deposits removed.
19. Failure to maintain the oven in
a clean condition could lead to
deterioration of the surface that
could adversely affect the life
of the appliance and possibly
result in a hazardous situation.
20. This appliance is not intended
for use by persons(including
children) with reduced
physical, sensory or mental
capabilities, or lack of
experience and knowledge,
unless they have been given
supervision or instruction
concerning use of the
appliance by a person
responsible for their safety.
21. Children should be supervised
to ensure that they do not play
with the appliance.
22. Only use utensils that are
suitable for use in microwave
ovens.
23. The appliance must not be
cleaned with a steam cleaner.
REGALE_KOM9P1160HZ(KOM9P2CTTZBW1BUT00)(�)_A5.indd 8 2020-07-24 �� 4:47:14

9
FEATURES DIAGRAM
1SAFETY INTERLOCK SYSTEM.
2DOOR VIEWING SCREEN - Allows
viewing of food. The screen is designed so
that light can pass through, but not the
microwave.
3DOOR HOOK - When door is closed, it will
automatically shut off. If the door is opened
while the oven is operating, magnetron will
immediately stop operating.
4OVEN CAVITY.
5DOOR SEAL - Door seal maintains the
microwave energy within the oven cavity
and prevents microwave leakage.
6PLATE TRAY - Made of special heat
resistant ceramic. Food in a proper
receptacle is placed on this plate for
cooking.
7STIRRER COVER - This is located on the
ceiling with the stirrer fan.
8INLET COVER - Protect the air hole from
splashes of cooking foods.
3 5
2 6
4 7 8 1
REGALE_KOM9P1160HZ(KOM9P2CTTZBW1BUT00)(�)_A5.indd 9 2020-07-24 �� 4:47:15

10
1MICROWAVE indicator, showing
microwaving in progress.
2DEFROST indicator, showing defrosting in
progress.
3PERCENTAGE of power indicator.
4CHILD LOCK indicator.
5PROGRAM - Used to save cooking data.
6DEFROST - Used to defrost foods for time.
7TIME SET PAD - Used to set the cooking
time.
8CHECK - Used to check cooking data.
9DOUBLE QUANTITY - Used to extend
programmed cooking time.
0POWER - Used to set power level.
qSTOP/CLEAR - Used to stop the oven
operation or to delete the cooking data.
wSTART /+30SEC - Used to start the oven
and also used to set a reheat time.
FEATURES DIAGRAM (continued)
3
4
7
1
2
5
6
8
9
0
q
w
REGALE_KOM9P1160HZ(KOM9P2CTTZBW1BUT00)(�)_A5.indd 10 2020-07-24 �� 4:47:15

11
OPERATION PROCEDURE
The oven light is on when the microwave oven
is operating or the door is opened.
The oven door can be opened at any time
during operation by opening the door. The oven
will automatically shut off.
Each time a pad is touched, a BEEP will sound
to acknowledge the touch.
The oven automatically cooks on full power
unless set to a lower power level.
The display will show ":0" when the oven is
plugged in.
When the STOP/CLEAR pad is touched during
the oven operation, the oven stops cooking and
all information retained.
To erase all information, touch the STOP/
CLEAR pad once more. If the oven door is
opened during the oven operation, all
information is retained.
If the START pad is touched and the oven does
not operate, check the area between the door
and door seal for obstructions and make sure
the door is closed securely.
The oven will not start cooking until the door is
completely closed or the program has been
reset.
This section includes useful information about oven operation.
1. Plug power supply cord into a standard 3- pronged 240V AC 60Hz power outlet.
2. After placing the food in a suitable container, open the oven door and put it on the plate tray.
The plate tray must always be in place during cooking.
3. Close the door and Make sure that it is firmly closed.
4. Set required programme and time, then touch the stert pad.
5. Once cooking is complete, take care removing container as it will be hot.
1
2
3
4
5
6
7
Make sure the oven is properly installed and
plugged into the electrical outlet.
WATTAGE OUTPUT CHART
• The power-level is set by touching the POWER pad. The chart shows the display, the power level and
the percentage of power.
Touch POWER pad. Power Level (Display) Approximate Percentage of Power
once 100 100%
twice 80 80%
3 times 60 60%
4 times 40 40%
5 times 20 20%
REGALE_KOM9P1160HZ(KOM9P2CTTZBW1BUT00)(�)_A5.indd 11 2020-07-24 �� 4:47:15

12
TIME DEFROSTING
When DEFROST is selected, the automatic cycle divides the defrosting time into periods of
alternating defrost and stand times by cycling on and off.
CONTROLS
When you touch the START pad, the DEFROST indicator lights to show the oven is in the DEFROST
mode. The display counts down the time to show you how much defrosting time is left in the DEFROST
mode. The oven beeps during the defrosting cycle to signal that the food needs to be turned or
rearranged. When the defrosting time ends, you will hear 3 beeps.
1. Touch the DEFROST pad.
2. Touch the number pads for the
desired defrosting time.
3. Touch the START pad.
The DEFROST indicator lights and " : 0" is
displayed.
The display will show the numbers you
pressed in the order you touched.
DEFROST
NOTE: Your oven can be programmed
for 60 minutes. (60:00)
REGALE_KOM9P1160HZ(KOM9P2CTTZBW1BUT00)(�)_A5.indd 12 2020-07-24 �� 4:47:15

13
COOKING IN ONE STAGE
1. Touch the POWER pad.
(Select desired power level.)
2. Touch the number pads for the
cooking time.
3. Touch the START pad.
x3
The MICROWAVE and % indicators light.
The display will show what you touched.
This example shows power level 60.
The display will show the numbers you
pressed in the order you touched.
NOTE: Using low power levels increases the cooking time which is recommended for foods such as
cheese, milk and slow cooking of meats.
NOTE: The cooling fan may operate to prevent the oven being overheated.
NOTE: Your oven can be programmed
for 60 minutes. (60:00)
but, in case of full power(100%),
maximum time is 20 minutes
(20:00)
POWER
When you touch the START pad, the MICROWAVE indicator lights to show the oven is cooking.
The display counts down the time to show how much cooking time is left. When the cooking time ends,
you will hear 3 beeps.
REGALE_KOM9P1160HZ(KOM9P2CTTZBW1BUT00)(�)_A5.indd 13 2020-07-24 �� 4:47:15

14
MEMORY FUNCTION
This microwave oven has 20 programmable pads (1~20).
After programming is finished, just touch the NUMBER pad of the memory number you want to select.
Then the oven will automatically start heating according to the pre-programmed cooking time and power
level.
* Preprogrammed Cooking Times and Power Level
1. Touch the PROGRAM pad.
2. Touch the number pads. ex)5
3. Touch the POWER pad.
(Select desired power level.)
4. Touch the number pads for
cooking time.
5. Touch the START pad to save
cooking time and power level.
6. Touch the STOP/CLEAR pad.
The display will show “PROGRAM”.
The display will show “PROG-05”.
The MICROWAVE and % indicators light.
The display will show what you touched.
The display will show “STAGE-2” and long
beep sounds.
When you touch the STOP/CLEAR pad,
memory function ends.
PROGRAM
NOTE 1: If you want cooking in two or three stage, repeat step 3~5 once or twice, and display will
show “STAGE-2” or “STAGE-3”.
After touching the START pad to save cooking time and power level in 3-stage, you can see
“ - END - ” on the display.
NOTE 2: In case of original set, number 1~10 is programmed but cooking data is changeable later.
And number 11~20 is not programmed, so you will save cooking data.
Pad Cooking Time Power Level
110 sec. 100 %
220 sec. 100 %
330 sec. 100 %
445 sec. 100 %
51 min. 100 %
61 min.30 sec. 100 %
72 min. 100 %
83 min. 100 %
94 min. 100 %
10 5 min. 100 %
REGALE_KOM9P1160HZ(KOM9P2CTTZBW1BUT00)(�)_A5.indd 14 2020-07-24 �� 4:47:15

15
START /+30 SEC
START /+30 SEC allows you to reheat for 30 seconds at 100% (full power) by simply touching the
START /+30 SEC pad.
By repeatedly touching the START /+30 SEC pad, you can also extend reheating time to 5 minutes
by 30 second increments.
1. Touch the START /+30 SEC
pad.
When you touch the START /+30 SEC,
":30" is displayed.
The oven will start immediately. It will add 30
seconds to the time counting down each
time the pad is touched.
CHECK FUNCTION
This feature allows you to check the programmed cooking time and power level.
CHECK
START /
+30 SEC
The display will show “CHECK”.
The display will show “PROG-05”.
1. Touch the CHECK pad.
2. Touch the NUMBER pads
which you want confirmation.
ex)5
The display will show cooking time, power level each stage.
If you want to end, touch the STOP/CLEAR pad.
DOUBLE QUANTITY FUNCTION
This feature allows you to extend programmed cooking time twice temporarily.
But, the extended cooking time can't exceed maximum cooking time.
Maximum cooking time of this oven is 60 minutes except full power.
In case of full power (100%), maximum cooking time is 20 minutes 00 seconds.
DOUBLE
QUANTITY
The display will show “DOUBLE”.
The display will show “PROG-05”.
After 1.5 seconds, the oven automatically
start cooking.
1. Touch the DOUBLE
QUANTITY pad.
2. Touch the NUMBER pads
which is programmed.
ex)5
REGALE_KOM9P1160HZ(KOM9P2CTTZBW1BUT00)(�)_A5.indd 15 2020-07-24 �� 4:47:15

16
CHILD SAFETY LOCK
The safety lock prevents unwanted oven operation such as by small children.
To set, press and hold the STOP/CLEAR pad for 3 seconds, LOCK indicator lights.
To cancel, press and hold STOP/CLEAR for 3 seconds, LOCK indicator goes off.
POWER SAVE MODE
This function is used for saving energy.
To set, press and hold the CHECK pad for 3 seconds. The oven will beep and nothing appears in the
display. Now the oven is in power save mode.
To operate the oven in power save mode, press any pad. Then “ : 0” will shown and the operation of
all function key will be same as in normal mode.
But, if there is no operation within 10 seconds in clear mode or while mainpulating the key, all the
contents of display will disappear.
To cancel, after press any pad, press and hold the CHECK pad for 3 seconds.
Then the oven is again available for normal use.
MUTE FUNCTION
To set, press and hold the DOUBLE QUANTITY pad for 3 seconds.
The display will show “MUTE” for 1 second.
Then you will not hear beeps, when you press any pad.
To cancel, press and hold the DOUBLE QUANTITY pad for 3 seconds.
TO STOP THE OVEN WHILE THE OVEN IS OPERATING
1. Touch the STOP/CLEAR pad.
• You can restart the oven by touching START pad.
• Touch the STOP/CLEAR once more to erase all instructions.
• You must enter in new instructions.
2. Open the door.
• You can restart the oven by closing the door and touching the START pad.
NOTE: Oven stops operating when door is opened.
ABNORMAL MESSAGE
E10
• “E10” message occurs when the total sum of the stage cooking time is
greater than 20 minutes in full power or 60 minutes in other power levels.
• Touch the STOP/CLEAR pad and try again.
E20
• “E20” message occurs when EEPROM is not able to read cooking data from
it's memory or write cooking data on it's memory.
• Unplug the power and call for service.
REGALE_KOM9P1160HZ(KOM9P2CTTZBW1BUT00)(�)_A5.indd 16 2020-07-24 �� 4:47:15

17
COOKING INSTRUCTIONS
Utensil Guide
Only use utensils that are suitable for use in microwave ovens.
To cook food in the microwave oven, the microwaves must be able to penetrate the food, without being
reflected or absorbed by the dish used. Care must therefore be taken choosing the utensil. If the
utensil is marked microwave-safe, you do not need to worry. The following table lists various of utensil
and indicates whether and how they should be used in a microwave oven.
●: Recommended use
▲ : Limited Use
✕ : Not Recommended
Utensil Safe Comments
Aluminium foil ▲Can be used in small quantities to protect areas against
overcooking. Arcing can occur if the foil is too close to the
oven wall or if too much foil is used.
Crust plate ●Do not preheat for more than 8minutes.
China and earthenware ●Porcelain, pottery, glazed earthenware and bone china are
usually suitable, unless deco-rated with a metal trim.
Disposable polyester
cardboard dishes
●Some frozen foods are packaged in these dishes.
Fast-food packaging
• Polystyrene cups containers
• Paper bags or newspaper
• Recycled paper or metal trims
●
✕
✕
Can be used to warm food. Overheating may cause the
polystyrene to melt.
May catch fire.
May cause arcing.
Glassware
• Oven-to-table ware
• Fine glassware
• Glass jars
●
●
●
Can be used, unless decorated with a metal trim.
Can be used to warm foods or liquids.
Delicate glass may break or crack if heated suddenly.
Must remove the lid. Suitable for warming only.
Metal
• Dishes
• Freezer bag twist ties
✕
✕
May cause arcing or fire.
Paper
• Plates, cups, napkins and
Kitchen paper
• Recycled paper
●
✕
For short cooking times and warming. Also to absorb
excess moisture.
May cause arcing.
Plastic
• Containers
• Cling film
• Freezer bags
●
●
▲
Particularly if heat-resistant thermoplastic. Some other
plastics may warp or discolour at high temperatures. Do
not use Melamine plastic.
Can be used to retain moisture. Should not touch the food.
Take care when removing the film as hot steam will
escape.
Only if boilable or oven-proof. Should not be airtight. Prick
with a fork, if necessary.
Wax or grease-proof paper ●Can be used to retain moisture and prevent spattering.
REGALE_KOM9P1160HZ(KOM9P2CTTZBW1BUT00)(�)_A5.indd 17 2020-07-24 �� 4:47:15
