Wirata HC-906 User manual

MODEL NO.
HC-906
CURRENT
0.2A
VOLTAGE
DC 5V
FREQUENCY
50/60Hz
BATTERIES
1x Li-ion 3.7V DC 600mAh
INPUT
100-240V, 50/60Hz, 0.2A
OUTPUT
5V DC/1000mA
INSTRUCTION MANUAL
Model No.:
HC-906
Please read Instruction Manual before use
& follow ALL the instructions carefully.

WHAT’S IN THE BOX
PARTS DESCRIPTION
1: Hair Clipper 6: Hair comb
2: Cleaning Brush 7: Charging cable
3: Oil 8: Scissors
4: Comb (11-20mm)
5: Comb (1-10mm)
1. Hair Clipper –1set
2. Oil, Cleaning brush, comb & scissors–1 set
3. Charging cable –1pc
4. Attachment Comb –2pcs (1-10mm / 11-20mm)
MAIN COMPONENT：
(Product may vary slightly from what is illustrated)
1
1
1
1
2
3
4
5
6
7
1
1
1
8
1
1
1

The hair clipper with two easily replaceable comb
attachments provides possibility of obtaining different lengths
of cutting and clipping hairline.
Please read these instructions carefully. Pay your special
attention to important safety instructions. Keep this
“Instructions for use” for future reference.
Herewith information concerns your health and safety. It is
obligatory to learn about all instructions for use and safety
information before first usage of the clipper.
1. The hair clipper is intended for domestic use. In case it
is used for commercial use, the guarantee conditions
change.
2. Connect the power supply adaptor to AC mains supply
100-240 V.
3. Disconnect the power supply adaptor from the mains
supply outlet when not in use or before cleaning.
4. Do not unplug pulling by the cord.
5. The supplying cord should not hang over the edge of a
table or desktop, nor touch hot surface.
6. This device is intended for cutting natural hair, only. It
is allowed to use it only for human hair; it cannot be
used for cutting artificial or animal hair. Using the
product for other than intended purposes shall cause
nullifying the guarantee.
7. Do not touch the power supply adaptor with wet hands,
especially when plugging or unplugging
it from the mains supply outlet.
8. For the operation with mains use only the adaptor
supplied with the hair clipper.
9. Connect only to easily accessible mains supply outlet.
GENERAL INSTRUCTION
SAFETY INSTRUCTIONS

10. Do not cover the adaptor; it can lead to dangerous
temperature increase.
11. Always At first & Do not use during bath.
12. Never immerse the device and cord in water or other
liquids.
13. Do not place the hair clipper on wet surface or cloth
during operation.
14. Do not place or store the device in the area where it
can fall into water.
15. Do not use the device with damaged comb attachment.
It can cause injuries hazard.
16. Never try to remove the foreign bodies out of the
clipper using sharp objects (i.e., comb).
17. Always clean after using.
18. This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and
knowledge.
19. Children should be supervised to ensure that they do
not play with the appliance.
20. Do not apply not recommended attachments.
21. The hair clipper can be used both as a mains and
cordless device.
22. The cut hair should be clean, dry and combed.
23. Put the towel around the neck to avoid getting the cut
hair under the collar.
24. Use the hair clipper only as intended according to the
herewith instructions.
25. Animal clipper, hair clipper, and appliances for
manicure and pedicure can be used by
children aged from 3 years under supervision.
26. This appliance contains batteries that are only
replaceable by skilled persons.
WARNING: Do not use the device near water, over the bath tub,
pool or other water basin.
*Observe the above-mentioned rules in order to avoid burning,
electric shock or fire hazard. Make sure you understand the
instructions.

1. OPERATION WITH POWER SUPPLY ADAPTOR
At first insert the adaptor plug into the device and then
insert the adapter plug into the mains supply outlet (100-
240 V). In mains supplied mode the device is ready for
use.
2. LOADING ACCUMULATORS AND CORDLESS OPERATION:
a) In order to load the device, move the ON/OFF switch to
“OFF” position. Place the device on the loading base.
Connect the loading base to the adapter cord.
b) Insert the plug of the adapter into appropriate mains
supply outlet (100-240 V). The loading process is
indicated by red pilot light glowing. When fully loaded
the hair clipper can operate approximately 90 minutes.
c) The hair clipper accumulator obtains optimum power
after three cycles of loading and unloading. 2 hours is
enough for next loading. In order to provide long life of
accumulators, they should be completely unloaded
before loading.
3. COMB ATTACHMENTS INSERTING/ REPLACING:
a) It is possible to select one of two comb attachments:
•The comb A can cut hair for 20 cutting lengths from
1-10mm, 0.5 mm per set.
•The comb B can cut hair for 20 cutting lengths from
11-20mm, 0.5 mm per set.
b) Select the attachment according to the length of
cutting.
c) Insert it into the side guiding grooves of the clipper.
d) Make sure that the two side protrusions are visibly
HOW TO OPERATE
HANDLING & OPERATION OF HAIR CLIPPER
The hair clipper can be used both as a main supplied or cordless device.

locked in fastening inlets of the comb attachment.
e) Replace one attachment removing it and inserting
another as described above.
f) Turn right the cutting length adjustment knob, to
increase the length of cutting or left to reduce it.
4. HAIR CUTTING AND BEARD TRIMMING WITH COMB:
Make sure that the appliance is fully charged when you
start to cut. Only use appliance on clean, dry hair. Do not
use it on freshly washed hair.
a) Comb the hair in the direction of growth.
b) Slide the hair clipping comb into the guiding grooves.
c) When you are trimming for the first time, start at the
maximum trimming length setting to familiarize
yourself with the appliance.
d) Switch on the appliance.
•Move the appliance through the hair slowly.
•To trim in the most effective way, move the
appliance against the direction of hair growth.
•Since all hair does not grow in the same direction,
you need to move the appliance in different
directions.
•Make sure that the flat part of the comb is always
fully in contact with the scalp to obtain an even
result.
•Make overlapping passes over the head to ensure
that you cut all hair that needs to be cut.
•To achieve a good result with curly, sparse or long
hair, use a comb to guide the hair towards the
appliance.

5. CUTTING HAIR WITHOUT ATTACHMENT:
a) You can cut the hair in uniform length of 0.5–1 mm
without comb attachment.
b) For clipping the hairline of bristle and whiskers, neck
shaving:
•Move the hair clipper slowly along hair.
•Turn the device so, that the back part was directed
upwards.
•Place the edge of the cutting head without comb
attachment on desired length of bristle hairline.
•Move down the clipper in operation.
WARNING: The cutting head is very sharp. Injury hazard!

a) Do not hold the adaptor with wet hands while plugging and
unplugging form mains supply outlet.
b) The adaptor and supplying cord should be always dry. It is
forbidden to immerse the hair clipper in water or other liquids
for cleaning, as the device is not waterproof. It can damage
the live parts (accumulators).
c) Set the ON/OFF switch to “OFF” position.
d) Always switch off the hair clipper and unplug the adaptor
from the mains supply outlet before cleaning and
maintenance.
e) Remove the comb attachment from the hair clipper.
f) In order to remove the cutting head, at first turn hair
thinning knob (to OFF position).
g) Press forward cutting head with your thumb, in order to
release the cutting head from the frame.
h) If necessary, rinse the plastic comb attachments under
running water, and then dry them thoroughly.
i) Remove the remains of hair from the cutting head with
attached cleaning brush.
j) Insert the protrusion of cutting head back into the locking
hole in the frame of cutting head.
k) Press gently the cutting head in, until you hear a clicking
sound of locking.
CLEANING AND MAINTENANCE
TIPS: In order to reduce friction, from time to time insert one or two
drops of oil between the blades and distribute it evenly.
*You can use any kind of acid less oil (such as oil for sewing machine).
Remove the exceeding oil with cloth.

Each user can contribute to protect the environment. It is neither
difficult nor expensive. In order to do so:
a) Return cardboard packages to recycling points.
b) Throw polyethylene (PE) bags into appropriate containers.
c) Batteries contain substances harmful to the natural
environment. Do not throw them away with other household
waste.
d) Return used batteries to recycling points. Before disposing of
or returning the appliance to a recycling point make sure to
remove the batteries from the battery compartment.
e) Return a worn-out appliance to an appropriate collecting
point as the components of the appliance may pose a threat
to the environment.
ENVIRONMENT PROTECTION
The manufacturer/ importer does not accept any liability for
any damages resulting from unintended use or improper
handling.
Unit: HC-906
Built-in rechargeable: 1x Li-ion 3.7V DC 600mAh
batteries
Input: 100-240V, 50/60Hz, 0.2A
Output: 5V DC/1000mA
The product technical parameters are included at the name
plate. The device is built in II class isolation, it does not require
grounding. This hair clippers meet the requirements of
effective standards. The device meets the requirements of the
following directives:
•Low Voltage Device (LVD) –2006/95/EC.
•Electro- Magnetic Compatibility (EMC) –2004/108/EC.
•The product is marked with CE symbol on the name plate.
ECOLOGY –ENVIRONMENT PROTECTION
SPECIFICATIONS
