Wire Tech WT-ISDB-2ME User manual

Manual de usuario
WT-ISDB-2ME
2* HDMI/YPbPr/CVBS to ISDB-T Encoder Modulator
(MPEG-2 HD/SD+MPEG-4 HD/SD Encoding +ISDB-T Modulating)

User’s Manual
SW Version: 4.12
HW version: 0.C
Web NMS version: 4.04
About This Manual
IntendedAudience
This user manual has been written to help people who have to use, to integrate and to install the
product. Some chapters require some prerequisite knowledge in electronics and especially in
broadcast technologies and standards.
Disclaimer
No part of this document may be reproduced in any form without the written permission of the
copyright owner.

The contents of this document are subject to revision without notice due to continued progress in
methodology, design and manufacturing. shall have no liability for any error or damage of any kind
resulting from the use of this document.
Copy Warning
This document includes some confidential information. Its usage is limited to the owners of the
product that it is relevant to. It cannot be copied, modified, or translated in another language without
prior written authorization from .

Directory
CHAPTER 1 INTRODUCTION .....................................................................................................................1
1.1 PRODUCT OVERVIEW...........................................................................................................................1
1.2 KEY FEATURES....................................................................................................................................1
1.3 SPECIFICATIONS...................................................................................................................................2
1.4 PRINCIPLE CHART................................................................................................................................2
CHAPTER 2 INSTALLATION GUIDE ............................................................................................................4
2.1 GENERAL PRECAUTIONS......................................................................................................................4
2.2 POWER PRECAUTIONS ..........................................................................................................................4
2.3 DEVICE’S INSTALLATION FLOW CHART ILLUSTRATED AS FOLLOWING ...................................................4
2.4 ENVIRONMENT REQUIREMENT.............................................................................................................4
2.5 GROUNDING REQUIREMENT.................................................................................................................5
CHAPTER 3 OPERATION............................................................................................................................6
3.1 LCD MENUS .......................................................................................................................................6
3.2 INITIAL STATUS....................................................................................................................................7
3.3 GENERAL SETTINGS FOR MAIN MENU..................................................................................................8
CHAPTER 4 WEB NMS OPERATION.........................................................................................................14
4.1 LOGIN................................................................................................................................................14
4.2 OPERATION........................................................................................................................................15
MODULATOR SETTING ...........................................................................................................................20
CHAPTER 6 TROUBLESHOOTING ............................................................................................................27
CHAPTER 7 APPLICATION .......................................................................................................................28
CHAPTER 8 PACKING LIST.......................................................................................................................30

Chapter 1 Introduction
1.1 Product Overview
WT-ISDB-2ME series products are ’s all-in-one devices which integrate encoding
(MPEG-2, MPEG-4/AVC H.264) and modulation to convert V/A signals etc to digital RF
output.
Delay problem has been greatly reduced to achieve an extremely low value from the
encoding progress to the decoding terminals.
It adopts inner drawer-type structural design which greatly facilitates the change of
encoding modules (HDMI/CVBS/SDI/YPbPr/…) as needed. To meet customers’various
requirements, WT-ISDB-2ME is also equipped with 1 ASI input, and output with 2 ASI
ports and 1 UDP IP port.
The signals source could be from satellite receivers, closed-circuit television cameras,
Blue-ray players, and antenna etc. Its output signals are to be received by TVs, STB and
etc with corresponding standard.
With its various inputs available, our WT-ISDB-2ME series products are wildly used in
public places such as metro, market hall, theatre, hotels, restaurants and etc for advertising,
monitoring, training and educating in company, schools, campuses, hospital… It’s a good
choice to offer HD channels and more.
1.2 Key Features
MPEG2 HD/SD & MPEG4 AVC H.264 HD/SD video encoding
MPEG4-AAC; MPEG2-AAC; MPEG1 Layer Ⅱaudio encoding
2* HDMI/YPbPr/CVBS channel in
Modular design, pluggable encoding modules
1*ASI in for re-mux; 1*RF in for RF mix
Extremely low latency achieved
ISDB-T Digital RF out (1 or 2 carrier outputs optional)
ASI out; IP out
LCN (Logical Channel Number) support

Excellent modulation quality
LCD display, Remote control and firmware
Web-based NMS management; Updates via web
1.3 Specifications
Encoding Section
Video (HDMI)
Encoding
MPEG2; MPEG4 AVC/H.264
Interface
HDMI*1
Resolution
1920*1080_60P, 1920*1080_50P, (-for MPEG4
AVC/H.264 only)
1920*1080_60i, 1920*1080_50i,
1280*720_60p, 1280*720_50P
Low Delay Mode
Normal, Mode 1, Mode 2
Audio (HDMI)
Encoding
MPEG1 Layer II; MPEG2-AAC; MPEG4-AAC
Interface
HDMI*1
Sample rate
48KHz
Bit rate
64/96/128/ 192/256/320kbps
Video (YPbPr/CVBS)
Encoding
MPEG2; MPEG4 AVC/H.264
Interface
YPbPr*1/CVBS *1
Resolution
CVBS: 720x576_50i (PAL);
720x480_60i (NTSC)
YPbPr: 1920*1080_60i, 1920*1080_50i;
1280*720_60p, 1280*720_50P
Audio (L/R)
Encoding
MPEG1 Layer II; MPEG2-AAC; MPEG4-AAC
Interface
1*Stereo/2*mono
Sample rate
48KHz
Bit rate
64/96/128/ 192/256/320kbps
Modulator Section
ISDB-T
Standard
ARIB STD-B31
Bandwidth
6M
Constellation
DQPSK,QPSK, 16QAM, 64QAM
Guard Interval
1/32, 1/16, 1/8, 1/4
Transmission
Mode
2K, 4K, 8K
MER
≥42dB
RF frequency
30~960MHz, 1KHz step
RF output level
-30~ -10dbm (77~97 dbµV), 0.1db step
System
Local interface
LCD + control buttons
Remote management
Web NMS
Stream Out
2 ASI out (BNC type);
IP (MPTS/SPTS) out (RJ45, 100M)
NMS interface
RJ45, 100M
Language
English
General
Power supply
AC 100V~240V
Dimensions
482*300*44mm
Weight
3.5 kg
Operation
temperature
0~45℃

1.4 Principle Chart
MUX Modulating
ASI In
ASI&IP Output
MPEG-2 HD/SD
MPEG-4 HD/SD
Encoding
HDMI/YPbPr/CVBS
Source
RF In
Built-in
Combiner RF
MPEG-2 HD/SD
MPEG-4 HD/SD
Encoding
HDMI/YPbPr/CVBS
Source
1.5 Appearance and Description
Front Panel Illustration
①LCD window: LCD display
②NMS & DATA ports
③Power and Alarm Indicators
④Lock Indicators
⑤Up and down, left and right button
⑥Enter button: for confirm
⑦Menu button: for back step
⑧Lock button: press to lock set
Rear Panel Illustration

①Encoding Module 1 (‘Pr’Port is also used as ‘CVBS’Port)
②Encoding Module 2 (‘Pr’Port is also used as ‘CVBS’Port)
③RF in port (for RF mix)
④RF out port
⑤ASI input port
⑥ASI output ports
⑦Switch
⑧Power supply slot
⑨Grounding

Chapter 2 Installation Guide
This section is to explain the cautions the users must know in some case that possible
injure may bring to users when it’s used or installed. For this reason, please read all details
here and make in mind before installing or using the product.
2.1 General Precautions
Must be operated and maintained free of dust or dirty.
The cover should be securely fastened, do not open the cover of the products when the
power is on.
After use, securely stow away all loose cables, external antenna, and others.
2.2 Power precautions
When you connect the power source, make sure if it may cause overload.
Avoid operating on a wet floor in the open. Make sure the extension cable is in good
condition
Make sure the power switch is off before you start to install the device
2.3 Device’s Installation Flow Chart Illustrated as following
Connecting
Grouding
Wire and
Power
Cord
Acquisition
Check Installing Device Setting Parameter Running Device
Connecting
Signal
cable
2.4 Environment Requirement
Item
Requirement

Machine Hall
Space
When user installs machine frame array in one machine hall,
the distance between 2 rows of machine frames should be
1.2~1.5m and the distance against wall should be no less than
0.8m.
Machine Hall Floor
Electric Isolation, Dust Free
Volume resistivity of ground anti-static material:
1X107~1X1010，Grounding current limiting resistance: 1M
(Floor bearing should be greater than 450Kg/㎡)
Environment
Temperature
5~40℃(sustainable )，0~45℃(short time)，
installing air-conditioning is recommended
Relative Humidity
20%~80% sustainable 10%~90% short time
Pressure
86~105KPa
Door & Window
Installing rubber strip for sealing door-gaps and dual level
glasses for window
Wall
It can be covered with wallpaper, or brightness less paint.
Fire Protection
Fire alarm system and extinguisher
Power
Requiring device power, air-conditioning power and lighting
power are independent to each other. Device power requires
AC 110V±10%, 50/60Hz or AC 220V±10%, 50/60Hz. Please
carefully check before running.
2.5 Grounding Requirement
All function modules’ good grounding is the basis of reliability and stability of devices.
Also, they are the most important guarantee of lightning arresting and interference
rejection. Therefore, the system must follow this rule.
Grounding conductor must adopt copper conductor in order to reduce high frequency
impedance, and the grounding wire must be as thick and short as possible.
Users should make sure the 2 ends of grounding wire well electric conducted and be
antirust.
It is prohibited to use any other device as part of grounding electric circuit

The area of the conduction between grounding wire and device’s frame should be no
less than 25 mm2.
Chapter 3 Operation
3.1 LCD Menus
An overview of the LCD menus:
Switch On
Initializing
General Working Status
1 Alarm Status
2 Input Setting 2.1 Input 1
2.3 ASI
Video Format
Video Bitrate
Audio Format
Audio Bitrate
2.3.1 Parse Program
2.3.2 Select Program
Interface
Brightness
Contrast
Saturation
Hue
2.2 Input 2 (Same content with 2.1)
3 Modulate Setting 3.1 Inter Leave
3.2 Constellation
3.3 FFT
3.6 RF Frequency
3.7 RF Out Level
3.4 Guard Interval
3.5 FEC

4 IP Out Setting 4.1 IP Out Enable
4.2 Service IP
4.3 Output IP
4.4 Subnet Mask
4.5 Gateway
4.6 Port
3.2 Initial Status
Switch on the device and after a few seconds’ initialization, it presents start-up pictures as
below:
ISDB-T: indicate the modulation standard of this device
XXX.XX MHz indicates the current output frequency ( range: 30~960MHz)
X.XX Mbps indicate the encoding bit rate of each channel respectively.
Start up…
Start OK…
ISDB-T XXX.00MHz
X.XXMbps X.XXMbps

3.3 General Settings for Main Menu
Press “Lock”key on the front panel to enter the main menu. The LCD will display the
following pages where user can configure the parameters for the device:
User can press UP/DOWN buttons to specify menu item, and then press ENTER to
enter the submenus as below:
1) Alarm Status
The alarm indicator will turn on if there is no A/V signals inputting or outputting bit rate
overflows. User then can enter this menu to check the error type.
2) Input Setting
Under this menu, the LCD will show “2.1 Input 1”, “2.2 Input 2”and “2.3 ASI”.
‘2.1 Input 1’and ‘2.2 Input 2’respectively represent the two programs from the two input
modules. Users could set the video and audio encoding parameters for each program under
2.1 and 2.2.
1 Alarm Status
2 Input Setting
3 Modulate Setting
4 IP Output Setting
5 Network Setting
6 Saving Config
7 Loading Config
8 Version
2.1 Input 1
►MPEG2 H.264
Interface
►HDMI YPbPr CVBS
Select a right interface type from the
options provided. The device then can
automatically search the signal and
starts to encode.
2.1 Input 1
2.2 Input 2
2.3 ASI

“Video Format”: the encoding module supports both MPEG2 and H.264
(MPEG-4 AVC/H.264) formats. Move the triangle mark with LEFT/RIGHT keys to
specify the intended format and press ENTER to confirm.
“Video Bit Rate”: Move the underline with LEFT/RIGHT keys and modify the
value of frequency with UP/DOWN keys, and press ENTER key to save the
settings. (Bit Rate Range: 1.000 –19.500Mbps)
“Audio Format”: the encoding module supports MPEG2, MPEG2 AAC, and
MPEG4 ACC audio format.
“Audio Bit rate”is to select bit rate for the audio. Move the triangle mark to specify
the target bit rate and press ENTER to confirm.
‘2.3 ASI’is for ASI program multiplexing operation. Under this submenu, users could
parse the inputting programs and select the programs to output.
Video Bit Rate
08.000 Mbps
Video Format
Video Bit Rate
MPEG2
►MPEG2-AAC
►128 Kbps
192 Kbps
Audio Format
Audio Bit Rate
2.3 ASI
Brightness
Contrast
Saturation
Hue
These 4 items are visible and applicable when
the signal source is selected CVBS.
Brightness/Contrast/Saturation Range: 0-255
Hue Range: -127 - +127

“Parse Program” is for checking the quantity of input programs from the ASI IN port.
“Select Program” is for selecting programs from the ASI IN to output. Move the
triangle mark to specify the program and press RIGHT/LEFT keys to shift the mark
between “√” and “X”. (“√”: to output the corresponding program; “X”: not to output
the corresponding program)
3) Modulator Setting
When entering “Modulator Setting” submenu, user can find below different parameters can
be set and the LCD window would show as below:
Inter Leave
There are 4 possible options provided for selecting Inter Leave: 0, 1, 2, and 4. When the
display shows them, user just need swift “LEFT” and “RIGHT” keys to choose and
repressing “ENTER” to confirm.
Constellation
Four different constellations DQPSK, QPSK, 16QAM and 64QAM will be shown on the
LCD window. User can set constellation type with the same method mentioned above.
FFT
When user enters FFT, the LCD would show the current working mode. User can move
LEFT/RIGHT keys and press ENTER key to select and confirm. 2K, 4K and 8K are the
options:
►1CCTV 4A √
2 CCTV News X
Parse Program
Get 7 programs
Parse Program
Select Program
3.1 Inter Leave
3.2 Constellation
3.5 FEC
3.6 RF Frequency
3.3 FFT
3.4 Guard Interval
3.7 RF Out Level

2K: When the device works as current mode, the number of current carrier is 2048
4K: When the device works as current mode, the number of current carrier is 4096
8K: When the device works as current mode, the number of current carrier is 8192
Guard Interval
In communications, guard intervals are used to ensure that distant transmissions do not
interfere with each other. These transmissions may belong to different users (as in TDMA)
or same user (as in OFDM). The purpose of the guard interval is to introduce immunity to
propagation delays, echoes and reflections, to which digital data is normally very sensitive.
There are four possible options provided to be selected. They are 1/4, 1/8, 1/16, 1/32. User
can shift the LEFT/RIGHT keys to select and press ENTER to confirm.
FEC
This term refers to Forward Error Correction and its rates include 1/2, 2/3, 3/4, 5/6, and
7/8. After entering FEC submenu, the LCD display would show them, users just need press
LEFT and RIGHT buttons to choose and press ENTER button to confirm.
RF Frequency
The RF output frequency range is from 30 to 960MHz with 1K stepping. After entering the
RF frequency setting submenu, users the can press LEFT, RIGHT, UP, and DOWN buttons
to adjust the frequency and confirm by press ENTER button.
2K (Mode 1)
4K (Mode 2)
8K (Mode 3)
Guard Interval
1/8 1/16 1/32
RF Frequency
750.000 MHz
FEC
1/2 2/3 3/4 5/6

RF Out Level
The RF attenuation range is from -30~-10dbm (81~97dbµV) with 0.1db step. After
entering this setting submenu, user can shift UP/DOWN/LEFT/RIGHT key to set the
output level and press ENTER to confirm.
4) IP Output Setting
WT-ISDB-2ME encoder & modulator also support IP output. Users can enter 4.1 to decide
whether to turn the IP port on or off, and enter to the rest menu items to set the
corresponding parameters.
User can enter 4.1.1 to decide whether to turn the IP port on or off, and enter to the rest
menu items to set the corresponding parameters.
5) Network setting
After enter Network Setting, there are three submenus shows as the following LCD
displays.
User can press “UP/DOWN”to choose this item and “ENTER” & “LEFT/RIGHT”to set
the parameters.
5.5 Reset Password
5.6 Web Manage Port
5.3 Gateway
5.4 MAC Address
IP Address
192.168.000.136
Subnet Mask
255.255.255.000
5.1 IP Address
5.2 Subnet Mask
4. 1 IP Output
4. 2 Service IP
4.3 Output IP
4.4 Subnet Mask
4.5 Gateway
4.6 Port
RF Out Level
-10.0 dbm

NOTE: The MAC address is according to the factory setting, and it is unique.
6) Saving Configuration
Users can enter Saving Configuration submenu for saving settings. Choose yes and press
ENTER to confirm.
7) Loading Configuration
At this menu, user can press UP/DWON key to select and repress ENTER to confirm.
User can restore the device into the last saved configuration by choosing “7.1”and restore
the device into factory configuration by choosing “7.2”the display will show as below:
8) Version
User can check the software version and hardware version of this equipment under this
submenu.
Gateway
192.168.000.001
MAC Address
ffffffffffffffffffffff
Reset Password?
Yes NO
Save Configuration?
Yes
No
Saving Config…
Load Saved CFG?
Yes
No
Loading Config…
7.1 Load Saved CFG
7.2 Load Default
Web Manage Port
00080
Encoder Modulator
SW X.XX HW X.XX

Chapter 4 WEB NMS Operation
User not only can use front buttons to set configuration, but also can control and set the
configuration in computer by connecting the device to web NMS Port. User should ensure
that the computer’s IP address is different from the WT-ISDB-2ME’s IP address; otherwise,
it would cause IP conflict.
4.1 login
The default IP address of this device is 192.168.0.136. (We can modify the IP through the
front panel.)
Connect the PC (Personal Computer) and the device with net cable, and use ping command
to confirm they are on the same network segment.
I.G. the PC IP address is 192.168.99.252, we then change the device IP to 192.168.99.xxx
(xxx can be 0 to 255 except 252 to avoid IP conflict).
Use web browser to connect the device with PC by inputting the Encoder & Modulator’s
IP address in the browser’s address bar and press Enter.
It will display the Login interface as Figure-1. Input the Username and Password (Both the
default Username and Password are “admin”.) and then click “LOGIN”to start the device
setting.
Figure-1

4.2 Operation
When we confirm the login, it displays the WELCOME interface as Figure-2.
Figure-2
Input 1
From the menu on left side of the webpage, clicking “Input 1”, it displays the parameters
of the program from the 1st encoding module as Figure-3.
Device standard
and name
User can click any item
here to enter the
corresponding interface
to check information or
set the parameters.
It automatically
identifies and
displays the
signal source
interface and
real-time
encoding bit rate
of corresponding
input channel.
TS indicators—Green light
indicates the TS is normal,
which otherwise turns to red.
