WISE STAR USA CS410 User manual

High Contrast License Plate
Capture Camera-CS410
OPERATION MANUAL
Thank you for choosing our high quality camera.
Before attempting to connect operate this unit, please read and follow these instructions.

2
Contents
1. CAUTIONS
2. FEATURES
3. COMPONENTS
4. NAME AND FUNCTION
5. INSTALLATION
6. FUNCTIONS
7. TARGET MARKETS
8. INSTALLATION GUIDELINE
9. SPECIFICATION
10. DIMENSIONS

3
1. Cautions
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions;
1. This device may not cause harmful interference.
2. This device must accept any interference received, including
interference that may cause undesired operation.
Note -
This equipment has been tested and found to comply with the limits
for a Class A digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area
is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.”
WARNING -
This is a class A product. In a domestic environment this product may
cause radio interference in which case the user may be required to take
adequate measures.
Caution -
Any changes or modifications in construction of this device which are
not expressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
1. Aregulated DC12V 1Apower supply is recommended for use with this camera
for the best picture and the most stable operation.
An unregulated power supply can cause damage to the camera.
When unregulated power supply is applied, product warranty will be
out of subject.
2. It is recommended that the camera is used with a monitor that has a CCTV quality
75 video impedance level.
If your monitor is switched to high impedance then please adjust accordingly.
3. Do not attempt to disassemble the camera to gain access to the internal componets.
Refer servicing to your dealer.
4. Never face the camera towards the sun or any bright or reflective light, which may
cause smear on the picture and possible damage to the CCD.
5. Do not remove the serial sticker for the warranty service.

4
1. Cautions
Correct Disposal of This Product
(Waste Electrical & Electronic Equipment)
(Applicable in the European Union and other European countries with
separate collection systems)
This marking shown on the product or its literature, indicate that it should not
be disposed with other household wastes at the end of its working life. To
prevent possible harm to the environment or human health from uncontrolled
waste disposal, please separate this from other types of wastes and recycle it
responsibly to promote the sustainable reuse of material resources.
This product should not be mixed with other commercial wastes purchased this
product, or their local government office, for details of where and how they can
take item for environmentally safe recycling.
Business users should contact their supplier and check the terms and
conditions of the purchase contract.
Household users should contact either the retailer where they for disposal.

CAMERA
SUNSHIELD
VIDEO OUTPUT
TEST CABLE
L-WRENCH /
SCREW - 3ea /
SUNSHIELD FIXING BOLT
OPERATIONMANUAL
2. Features
•1/3" Sony Super-HAD CCDⅡ
•High Resolution 600TV Lines
• Special filter and IRLED providesmaximumreadability
despite headlight glare
•Plate capture up to 35mph (56Km/H)
•9.0 ~ 22.0mm Varifocal lvenscaptureslicenseplate
from 8ft ~ 60ft (2.5M ~ 18.5M)
•IP66 rated weatherproof
•Cable throughconcealedbracket
•DC12V / AC24V Dual power with auto-polarity
3. Components
5

6
4. Name and Function
① ② ① ③
④ ⑤ ⑧ ⑥ ⑦
① Sunshield Fixing Bolt
② Sunshield
③ Mounting Bracket
④ LED : 20ea
⑤Photo cell
⑥ Body
⑦ Body Fixing Ring
⑧ External Zoom and Focus adjustment

7
5. Installation
• MOUNTING POSITION
360 ˚
90 ˚
After adjusting zoom and focus,
to prevent water infiltration, firmly
tighten the zoom and focus lever.
WARNING !
To prevent injury, this apparatus must be securely
attached to the floor/wall in accordance with the
installation instructions.
360 ˚

8
5. Installation
• MONITOR CONNECTION
(1) DC12V
DC12V POWER SUPPLY
DC12V
BNC FEMALE
WHIT: TRIGGER SIGNAL
BLACK: TRIGGER GROUND
(2) DUAL(DC12V/AC24V)
DC12V /AC24V POWER SUPPLY
DC12V/AC24V
BNC FEMALE VIDEO IN
WHIT: TRIGGER SIGNAL
BLACK: TRIGGER GROUND
When you install the camera, please glue up the end of cable to
keep it stable in order to protect the camera from the humidity problems.

9
6. Functions
OSD Menu Structure
• MOD E
- INSTALLATION
Installation Mode provides bright video screen to adjust angle and focus.
- LICENSE-PLATE
License-plate Mode provides high contrast and clear license plate image
for license plate capture.
• FREEZ E
The video screen will automatically go in to FREEZE mode when Camera
is triggered by sensors.
User can set the freeze time to 3, 5, or 10 sec.
• NEGATIV E
User can select positive or negative image.
Negative OFF
Negative ON
7. Target Markets
• Government
• Militar y
• Hotels and Casinos
• Parking Lots
• Border Patrol
•Gated Communities
•Traffic monitoring
•Embassies
•Ports
•College Campus
•Airports
•Law Enforcement
•Toll Booths
• Security

1
0
8. Installation Guideline
Camera Height
•Must consider height in distance calculation.
•Sharper angle will alter appearance of plate.
Camera Height (Ft)
Horizontal Distance (Ft)
Capture Distance(Ft)
10
10
14.14
11
20
22.83
12
30
32.31
13
40
42.06
14
50
51.92

11
8. Installation Guideline
Camera Angles
•Vertical and horizontal angle must not exceed 40 degrees to
get optimal view of the license plate.
Capture Zone
•Wider angle provide shorter capture distance.
•Tele angle provide longer capture distance.

1
2
8. Installation Guideline
Lane Width
•Narrow lanes = less variation in plate location.
•Wider lanes = more variation in plate location.
•Lens should cover entire width of the lane.
•
Ensure horizontal field of view is wide e nough.
Speed
•Camera can capture moving vehicles up to 35mph.
•Keep camera as low as possible.
•Minimize horizontal angle.
•Zoom in the lens as close as possible.

13
8. Installation Guideline
Trigger
•Camera support trigger input for freezing video screen.
•Connect external sensor e.g. Parking Gate Sensor.
•Trigger input should be pulled-up 3.3V DC in normal condition.
•Input line will be triggered when pull-up 3.3V DC drop to GND.
DVR
•Camera is fully compatible with industry standard DVRs.
•Check compression settings.
•Non-conditional refresh compression. (i.e. MJPEG or JPEG)
•D1 (720x480) resolution.
•30fps (each channel) for best results.

1
4
9. Specification-CS410
Signal Format
NTSC
PAL
Image Device
1/3" Sony Super HAD CCDⅡ
Total Pixels
811(H) x 508(V)
795(H) x 596(V)
Effective Pixels
768(H) x 494(V)
752(H) x 582(V)
Inter. H/V
15.734KHz(H), 59.94Hz(V)
15.625KHz(H), 50Hz(V)
H.Resolution
600TV Lines
Minimum illumination
0 Lux (IR LED ON)
S/N Ratio
More than 50dB (AGC Off)
Sync System
Internal
Video Output
1.0 Vp-p Composite(75Ω)
Lens
Varifocal
IR LED
850nm, 20ea
IP Rating
IP66
Operating Temperature
14˚F~122˚F(-10˚C ~ +50˚C)
Storage Temperature
-4˚F~140˚F(-20˚C ~ +60˚C)
Power
Consumption
DC12V
DC12V ±10% Max 450mA
DUAL
DC12V ±10% Max 570mA
AC24V ±10% Max 6.7W
Weight
Approx. 1000g
Dinmension(mm)
82 x 79.3 x 130
Option
DUAL(AC24V/DC12V)
Specifications and designs are subject to change for improving the functionality of this product without notice.

15
87.8
100
7
10. Dimensions
82
145
120
224
M12 XP1.0
Ф65
