Wiznet WIZ630wi User manual

© Copyright 2012 WIZnet Co., Inc. All rights reserved. 1
WIZ630wi User Manual
(Version 0.93)
© 2012 WIZnet Co., Inc.All Rights Reserved.
For more information, please visit our website at http://www.wiznet.co.kr

© Copyright 2012 WIZnet Co., Inc. All rights reserved. 2
Document Revision History
Date Revision Changes
2012-01-31 V0.91

© Copyright 2012 WIZnet Co., Inc. All rights reserved. 3
<Contents>
1. Introduction ............................................................................................. 5
1.1 EVB Construction............................................................................................ 5
1.1.1. Packaging ........................................................................................................ 5
1.1.2. Contents ......................................................................................................... 6
1.1.3. Hardware Interface ........................................................................................ 7
1.2 Features........................................................................................................... 8
1.3 Specifications .................................................................................................. 9
1.3.1. Wireless Specifications .................................................................................. 9
1.3.2. Hardware Specifications .............................................................................. 10
1.3.3. Software Specifications................................................................................ 11
2. Connecting the webpage of WIZ630wi ............................................ 12
2.1 Web oage default address........................................................................... 12
2.2 Web login ...................................................................................................... 12
3. Wireless setting.......................오류! 책갈피가 정의되어 있지 않습니다.
3.1 Access Point (bridge) ................................................................................. 14
3.2 Gateway (router)
............................... 오류! 책갈피가 정의되어 있지 않습니다.
3.3 Client (station)................................... 오류! 책갈피가 정의되어 있지 않습니다.
3.4 AP-Client mode ............................................................................................ 14
3.5 Ad-hoc mode ................................................................................................ 14
4. Internet Setting.......................오류! 책갈피가 정의되어 있지 않습니다.
4.1 Internet connection setting .............. 오류! 책갈피가 정의되어 있지 않습니다.
4.2 Local network setting ....................... 오류! 책갈피가 정의되어 있지 않습니다.
4.3 DHCP client information ............................................................................... 20
4.4 VPN setting ................................................................................................... 20
4.5 Static rounting setting
...................... 오류! 책갈피가 정의되어 있지 않습니다.
5. Basic Wireless setting ............오류! 책갈피가 정의되어 있지 않습니다.
5.1 Basic setting ...................................... 오류! 책갈피가 정의되어 있지 않습니다.
5.2 Advanced wireless settings.............. 오류! 책갈피가 정의되어 있지 않습니다.
5.3 Wireless security / Encryption settings 오류! 책갈피가 정의되어 있지 않습
니다.
5.3.1. Wireless security setting.................. 오류! 책갈피가 정의되어 있지 않습니다.
5.3.2. Wireless authentification setting...... 오류! 책갈피가 정의되어 있지 않습니다.
5.3.2.1. WEP authentification..................................................................................... 28
5.3.2.2. TKIP/AES authenfitication............................................................................ 28
5.3.2.3. 802.1x authenfitication ............................................................................. 28
5.4 WDS setting ................................................................................................... 29
5.5 WPS setting ................................................................................................... 30
5.6 Wireless network status .............................................................................. 30
5.7 AP wireless statistics
....................... 오류! 책갈피가 정의되어 있지 않습니다.
6. Serial to LAN(Wired and Wireless)...................................................... 33
6.1 Main Connection settings ............................................................................. 34
6.2 Aux Connection settings............................................................................... 34
6.3 Packing Condition (Incoming serial data packing condition) ...................... 35
6.4 Ethernet Data Tagging Option...................................................................... 35

© Copyright 2012 WIZnet Co., Inc. All rights reserved. 4
7. Firewall setting........................오류! 책갈피가 정의되어 있지 않습니다.
7.1 DMZ................................................................................................................ 36
7.2 Port forwarding
.................................. 오류! 책갈피가 정의되어 있지 않습니다.
7.3 Packet filtering .................................. 오류! 책갈피가 정의되어 있지 않습니다.
7.4 Contents filtering ............................... 오류! 책갈피가 정의되어 있지 않습니다.
7.5 System security ................................. 오류! 책갈피가 정의되어 있지 않습니다.
8. Useful information for network Administrator 오류! 책갈피가 정의
되어 있지 않습니다.
8.1 System management.......................... 오류! 책갈피가 정의되어 있지 않습니다.
8.2 Firmware management ...................... 오류! 책갈피가 정의되어 있지 않습니다.
8.3 System settings ................................. 오류! 책갈피가 정의되어 있지 않습니다.
8.4 Wireless LAN port setting........................................................................... 44
8.5 System statistics
................................ 오류! 책갈피가 정의되어 있지 않습니다.
8.6 System status..................................... 오류! 책갈피가 정의되어 있지 않습니다.
8.7 System log ......................................... 오류! 책갈피가 정의되어 있지 않습니다.
9. Client (Station) Mode setting오류! 책갈피가 정의되어 있지 않습니다.
9.1 Client mode setting ........................... 오류! 책갈피가 정의되어 있지 않습니다.
9.2 Profile setting .................................... 오류! 책갈피가 정의되어 있지 않습니다.
9.3 Link status.......................................... 오류! 책갈피가 정의되어 있지 않습니다.
9.4 Site survey ......................................... 오류! 책갈피가 정의되어 있지 않습니다.
9.5 Station statistics ................................ 오류! 책갈피가 정의되어 있지 않습니다.
9.6 Station advanced configurations ...... 오류! 책갈피가 정의되어 있지 않습니다.
9.7 Station QoS/DLS(Direct Link Setup) configurations................................... 53
9.8 WPS settings
...................................... 오류! 책갈피가 정의되어 있지 않습니다.
10. AP-Client mode settings ........오류! 책갈피가 정의되어 있지 않습니다.
10.1 AP-Client settings........................................................................................ 56
10.2 WIFI Multi-Bridge settings........................................................................... 57
11. ad-hoc mode setting ..............오류! 책갈피가 정의되어 있지 않습니다.
12. WIZ630wi Pin Map................................................................................ 59
13. Dimensions...............................오류! 책갈피가 정의되어 있지 않습니다.
14. Serial commands.....................오류! 책갈피가 정의되어 있지 않습니다.
15. Important Notice................................................................................... 63

© Copyright 2012 WIZnet Co., Inc. All rights reserved. 5
1. Introduction
WIZ630wi is a gateway module for converting the RS-232 protocol to TCP/IP protocol. WIZ630wi
enables a device with RS-232 serial interface to connect to TCP/IP network through LAN and operate
remote measuring, administration, and control. WIZ630wi has an embedded switch inside for IP-Router
function, and can operate as 3G-Router/WiBro-Router through USB interface. Devices that
communicates through serial communication use Serial-to-LAN, Serial-to-WIFI, Serial-to-3G, and Serial-
to-WiBro; WIZ630wi can be used for TCP and UDP communication to the upper layer administration
server.
1.1 EVB Construction
1.1.1. Packaging
Figure 1. WIZ630wi-EVB Packaging

© Copyright 2012 WIZnet Co., Inc. All rights reserved. 6
1.1.2. Contents
Section Qnt. Contents
WIZ630wi 1ea
WIZ630wi
WIZ630wi-
EVB 1ea
WIZ630wi-EVB
Antenna 1 ea
2dBi WI-FI Antenna (Dipole)
Serial Cable 2 ea
Serial Cable
LAN Cable 1 ea LAN Cable
WI-FI Jump
cable
1 ea
WI-FI Jump cable (connection between Module and Antenna)
Adapter 1ea DC 5V/2A Adapter
Table 1. WIZ630wi-EVB Contents

© Copyright 2012 WIZnet Co., Inc. All rights reserved. 7
1.1.3. HW Interface
LAN ports
Serial ports
1 USB
1 Config Switch
WIZ630wi I/F Socket
1 Reset Button
1 WPS Button
Power connector
Figure 2. WIZ630wi Interface

© Copyright 2012 WIZnet Co., Inc. All rights reserved. 8
1.2 Features
Complies with IEEE802.11n 4.0.
Router/AP(Bridge)/AP-Client/Client(Station)/Ad-hoc Mode , WDS/Repeater supported
1T1R RF Interface
Physical link rate up to 150Mpbs
Built-in 1 WAN and 2 LAN ports
I2C/USB/ 2 Serial Ports supports
Working as Wi-Fi Router
Working as 3G Router
Working as Wibro / Wimax Router
WEP 64/128bit, WPA/WPA2-PSK TKIP, AES and 802.1x
802.11e and WMM (Wi-Fi Multimedia)
Router and Firewall function supported
Serial to WiFi/Ethernet / Serial to 3G Internet / Serial to Wibro(Wimax)
Figure 3. WIZ630wi Functions

© Copyright 2012 WIZnet Co., Inc. All rights reserved. 9
1.3 Specifications
1.3.1. Wireless Specifications
Type Description
Wireless Standard IEEE802.11b/g/n
Frequency Range
USA: 2.400 ~ 2.483GHz
Europe: 2.400 ~ 2.483GHz
Japan: 2.400 ~ 2.497GHz
China: 2.400 ~ 2.483GHz
Operating Channels
USA/Canada: 11(1 ~ 11)
Major Europe Countries: 13(1 ~ 13)
France: 4(10 ~ 13)
Japan: 14 for 802.11b(1 ~ 14), 13 for 802.11g(1 ~ 13)
Korea/China: 13(1 ~ 13)
Output Power
(Tolerance(+/-1dBm)
802.11b: 17dBm@11Mbps
802.11g: 14dBm@54Mbps
802.11n: 14dBm@150Mbps/72Mbps
Receive Sensitivity
802.11b: -89dBm@11Mbps
802.11g: -74dBm@54Mbps
802.11n(40MHz): -66dBm@150Mbps
802.11n(20MHz): -70dBm@72Mbps
Data Rates
802.11b: 1,2,5.5,11Mbps
802.11g: 6,9,12,18,24,36,48,54Mbps
802.11n(20MHz): 7,14.5,21.5,28.5,43.5,57.5,65,72Mbps
802.11n(40MHz): 29.5,86.5,115,130,144,150Mbps
Modulation Type 11g: OFDM(64QAM, 16QAM, QPSK, BPSK)
11b: DSS(CCK, DQPSK, DBPSK)
Operation Distance
(???)
802.11b
Outdoor: 150m@11Mbps, 300m@1Mbps
Indoor: 30m@11Mbps, 100m@1Mbps
802.11g
Outdoor: 50m@54Mbps, 300m@6Mbps
Indoor: 30m@54Mbps, 100m@6Mbps
802.11n
Outdoor: 30m@150Mbps, 250m@7Mbps
Indoor: 20m@150mbps, 100m@7Mbps
Antenna 1T1R 2dBi
Table 2. WiFi Specifications

© Copyright 2012 WIZnet Co., Inc. All rights reserved. 10
1.3.2. Hardware
Type Description
Interface
Serial port : 2 EA
LAN port : 3EA
USB port : 1 USB Host Port
Socket Type : Mini-PCI Express socket
U.FL(wireless)
Temperature Operation: -30℃~80℃
Storage: -30℃~80℃
Humidity Operation: 10% to 90%, Non-Condensing
Storage: 5% to 90%, Non-Condensing
Serial
Baud Rate : 1200 ~ 921,600bps
Stop bits: 1, 2
Parity: None, Odd, Even
Flow Control:
UART1: XON/XOFF(software), CTS/RTS(hardware), none
UART2: XON/XOFF, none
Power 5V 2A
(Module 3.3V/1A) (???)
Power Consumption
(???)
1W = 5V x 200mA ( No LAN port used)
1.05W = 5V x 200mA + 50mA x 1 (1 LAN port)
1.10W = 5V x 200mA + 50mA x 2 (2 LAN ports)
1.20W = 5V x 200mA + 50mA x 3 (3 LAN ports)
Dimension 33mm X 43mm X 4.5mm
Weight 6g
Table 3. HW Specifications

© Copyright 2012 WIZnet Co., Inc. All rights reserved. 11
1.3.3. Software
Type Description
Operation Mode Access Point(Bridge), Client(Station), Gateway, AP-Client, ad-hoc
Protocol ARP, UDP, TCP, Telnet, ICMP, DHCP, PPPoE, BOOTP, HTTP
Security
WEP 64/128bit
WPA/WPA2-PSK AES/TKIP
802.1x(Radius)
Management HTTP, Telnet, Serial, UDP
Notification Event Logging
Serial To WiFi 2 Serial Port supported
3G router 3G(WCDMA) Router function
Table 4. SW Specifications

© Copyright 2012 WIZnet Co., Inc. All rights reserved. 12
2. Connecting the Web page of WIZ610wi
Some items may be not supported depending on the version.
2.1 Web address
Open a web browser on user’s PC. Input the default IP address of WIZ630wi, “192.168.16.254” and
click Enter.
2.2 Web Login
A pop up will request user to input User ID and Password
User ID: admin / Password: admin
The system’s basic information, as shown below, will appear if successfully authenticated.

© Copyright 2012 WIZnet Co., Inc. All rights reserved. 13
Type Description
F/W Version The firmware version of WIZ630wi is displayed.
System Up Time System up time displayed.
Operation Mode System operation mode displayed.
Internet Configuration Information of the external network is displayed.
Local Network Information of the Local network is displayed.
Ethernet Port Status Link of LAN Port status is displayed.

© Copyright 2012 WIZnet Co., Inc. All rights reserved. 14
3. Operation mode
User can select the operation mode.
The default setting of WIZ630wi is AP Mode. (DHCP Server Enabled)
3.1 Access Point (Bridge)
In this mode, all Ethernet ports and wireless interface are bridged together. Wired/Wireless interface
has the same IP address space with its top mesh. DHCP Server function is disabled and WIZ630wi
does not assign an IP. Wireless (LAN Port included) sending periodic Broadcast Packet to Station and
maintains a connection with Station.
3.2 Gateway (Router)
Operate in router mode. Interfaces are separated into WAN I/F (Top Internet Business Network), LAN
I/F (Sub Private Network: 192.168.16.xxx), Wireless I/F (Sub Private Network: 192.168.16.xxx). Port # 0
will be assigned to the WAN Port. WIZ630wi periodically sends Broadcast Packet to Sub-LAN (LAN
Port included) and maintains connection with Station.
3.3 Client (Station)
Wireless I/F is assigned as WAN Port and all Ethernet Ports are bound to LAN Port. Set the profile and
the WIZ630wi is automatically connected to the AP when re-booting in the future. Devices that are
connected through the LAN port are assigned a private IP. WIZ630wi periodically sends PING Packet
to AP Gateway and maintains connection with AP.
3.4 AP-Client mode
Wireless I/F is assigned as WAN Port and all Ethernet Ports are bound to LAN Port. This mode is
similar to Station mode, however the difference is that the Wireless I/F will operate as client with AP
simultaneously. WIZ630wi periodically sends Broadcast Packet to Sub-LAN (LAN Port included) and
maintains connection with Station.
3.5 ad-hoc mode
This mode is similar to Gateway mode. The Wireless I/F operates as ad-hoc and connects to Station

© Copyright 2012 WIZnet Co., Inc. All rights reserved. 15
Point-to-Point. There is no communication between the LAN Port and Wireless I/F (ad-hoc).
WAN  ad-hoc: OK
WAN  LAN: OK
ad-hoc  ad-hoc: OK
ad-hoc  LAN: No Communication

© Copyright 2012 WIZnet Co., Inc. All rights reserved. 16
4. Internet Setting
4.1 Internet connection setting
Select the internet service type and WIZ630wi can connect to the internet
If users would like to access to Internet, Gateway Mode should be selected.
Type Description
WAN Connection
Type
Select the communication ways for Internet’s connection
-Static(Fixed IP)
-DHCP (Auto config)
-PPPoE
Host Name Settings about module’s host name
Mac Clone Some ISPs require that you register a MAC address. Users can directly enter MAC address
or use the MAC Clone function.
Type Description
DHCP(Auto
config)
User should choose DHCP Mode when the user connects to the internet service such as
FTTH, cable modems, VDSL, IP-ADSL.
Static(Fixed IP) Static IP setting window. If user receives static IP from ISP, user should set the Fixed IP .

© Copyright 2012 WIZnet Co., Inc. All rights reserved. 17
Input the network information that got from ISP
(such as IP, Subnet, Gateway, DNS)
PPPoE(ADSL)
-. User Name: Setting the User Name received from ISP
-. Password: Password assigned by the internet service company
-. Operation Mode: This mode is used for re-connecting when connection is bad.
3G Mode
-. This mode supports only 3G-Router, Wibro, Wimax Router firmware
-. Connect the 3G modem or WiBro/Wimax modem to the module’s USB port and WiFi/Wired
LAN service will be provided.

© Copyright 2012 WIZnet Co., Inc. All rights reserved. 18
(Wibro/Wimax supports all USM modems that use Xronet’s chips, and certain USB modems
that use Samsung’s WiBro chipset.)

© Copyright 2012 WIZnet Co., Inc. All rights reserved. 19
4.2 Local network setting
WIZ630wi internal IP setting, DHCP server setting and DHCP.
Type Description
IP Address Enter the module’s IP. (Basic Value : 192.168.16.254 )
Subnet Mask Enter the module’s Subnet Mask .
MAC Address MAC Address of module’s LAN port (Wireless included). (Read Only)
DHCP Server Decide whether the module’s DHCP server will be used.
Start IP Address Set the start IP address that will be assigned from the DHCP server
End IP Address Set the end IP address that will be assigned from the DHCP server.
Subnet Mask Enter the value of subnet mask.
Primary DNS Server Enter the primary DNS server address.
Secondary DNS Server Enter the secondary DNS server.
Lease Time Enter the lease time when IP address is assigned.
Statically Assigned Maximum of three IP can be statically assigned when IP address is
assigned.

© Copyright 2012 WIZnet Co., Inc. All rights reserved. 20
4.3 DHCP Client Information
The IP information that is assigned from the DHCP server is shown.
Type Description
Host name Client’s host name is shown
Mac Address Client’s MAC address is shown.
IP Address Client’s IP address is shown.
Expires in The usable time of client’s IP address is shown.
4.4 VPN setting
This section will explain on VPN packet settings.
Type Description
L2TP Pass-through Enable : VPN L2TP packet is passed through WAN.
Disable : VPN L2TP packet is not passed through WAN. (Default value)
IPSec Pass-through Enable : VPN IPSec packet is passed though WAN.
Disable : VPN IPSec packet is not passed through WAN. (Default value)
PPTP Pass-through Enable : VPN PPTP packet is passed through WAN.
Disable : VPN PPTP packet is not passed through WAN. (Default value)
