D-Link DGE-550SX User manual

DGE-550SX
Gigabit Ethernet Network
Interface Card for
PCI Bus
User’s Guide
First Edition (October 2001)
6DGE550SX.01
Printed in Taiwan
RECYCLABLE

Trademarks
Copyright 2001 D-Link Corporation.
Contents subject to change without prior notice.
D-Link is a registered trademark of D-Link Corporation/D-
Link Systems, Inc.
All other trademarks belong to their respective proprietors.
Copyright Statement
No part of this publication may be reproduced in any form or
by any means or used to make any derivative such as
translation, transformation, or adaptation without permission
from D-Link Corporation/D-Link Systems Inc., as stipulated
by the United States Copyright Act of 1976.
FCC Certifications
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
Shielded interface cables must be used in order to comply with emission limits.

You are cautioned that changes or modifications not expressly approved by the
party responsible for compliance could void your authority to operate the
equipment.
This device complies with Part 15 of the FCC rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference,
and (2) This device must accept any interference received, including
interference that may cause undesired operation.
Limited Warranty
Hardware:
D-Link warrants each of its hardware products to be free from defects in workmanship
and materials under normal use and service for a period commencing on the date of
purchase from D-Link or its Authorized Reseller and extending for the length of time
stipulated by the Authorized Reseller or D-Link Branch Office nearest to the place of
purchase.
This Warranty applies on the condition that the product Registration Card is filled out
and returned to a D-Link office within ninety (90) days of purchase. A list of D-Link
offices is provided at the back of this manual, together with a copy of the Registration
Card.
If the product proves defective within the applicable warranty period, D-Link will
provide repair or replacement of the product. D-Link shall have the sole discretion
whether to repair or replace, and replacement product may be new or reconditioned.
Replacement product shall be of equivalent or better specifications, relative to the
defective product, but need not be identical. Any product or part repaired by D-Link
pursuant to this warranty shall have a warranty period of not less than 90 days, from
date of such repair, irrespective of any earlier expiration of original warranty period.
When D-Link provides replacement, then the defective product becomes the property
of D-Link.
Warranty service may be obtained by contacting a D-Link office within the applicable
warranty period, and requesting a Return Material Authorization (RMA) number. If a

Registration Card for the product in question has not been returned to D-Link, then a
proof of purchase (such as a copy of the dated purchase invoice) must be provided. If
Purchaser's circumstances require special handling of warranty correction, then at the
time of requesting RMA number, Purchaser may also propose special procedure as
may be suitable to the case.
After an RMA number is issued, the defective product must be packaged securely in
the original or other suitable shipping package to ensure that it will not be damaged
in transit, and the RMA number must be prominently marked on the outside of the
package. The package must be mailed or otherwise shipped to D-Link with all costs
of mailing/shipping/insurance prepaid. D-Link shall never be responsible for any
software, firmware, information, or memory data of Purchaser contained in, stored on,
or integrated with any product returned to D-Link pursuant to this warranty.
Any package returned to D-Link without an RMA number will be rejected and shipped
back to Purchaser at Purchaser's expense, and D-Link reserves the right in such a case
to levy a reasonable handling charge in addition mailing or shipping costs.
Software:
Warranty service for software products may be obtained by contacting a D-Link office
within the applicable warranty period. A list of D-Link offices is provided at the back
of this manual, together with a copy of the Registration Card. If a Registration Card
for the product in question has not been returned to a D-Link office, then a proof of
purchase (such as a copy of the dated purchase invoice) must be provided when
requesting warranty service. The term "purchase" in this software warranty refers to
the purchase transaction and resulting license to use such software.
D-Link warrants that its software products will perform in substantial conformance
with the applicable product documentation provided by D-Link with such software
product, for a period of ninety (90) days from the date of purchase from D-Link or its
Authorized Reseller. D-Link warrants the magnetic media, on which D-Link provides
its software product, against failure during the same warranty period. This warranty
applies to purchased software, and to replacement software provided by D-Link
pursuant to this warranty, but shall not apply to any update or replacement which
may be provided for download via the Internet, or to any update which may otherwise
be provided free of charge.

D-Link's sole obligation under this software warranty shall be to replace any defective
software product with product which substantially conforms to D-Link's applicable
product documentation. Purchaser assumes responsibility for the selection of
appropriate application and system/platform software and associated reference
materials. D-Link makes no warranty that its software products will work in
combination with any hardware, or any application or system/platform software
product provided by any third party, excepting only such products as are expressly
represented, in D-Link's applicable product documentation as being compatible.
D-Link's obligation under this warranty shall be a reasonable effort to provide
compatibility, but D-Link shall have no obligation to provide compatibility when
there is fault in the third-party hardware or software. D-Link makes no warranty
that operation of its software products will be uninterrupted or absolutely error-free,
and no warranty that all defects in the software product, within or without the scope
of D-Link's applicable product documentation, will be corrected.
D-Link Offices for Registration and Warranty Service
The product's Registration Card, provided at the back of this manual, must be sent to
a D-Link office. To obtain an RMA number for warranty service as to a hardware
product, or to obtain warranty service as to a software product, contact the D-Link
office nearest you. An address/telephone/fax/e-mail/Web site list of D-Link offices is
provided in the back of this manual.
LIMITATION OF WARRANTIES
IF THE D-LINK PRODUCT DOES NOT OPERATE AS WARRANTED ABOVE, THE CUSTOMER'S SOLE
REMEDY SHALL BE, AT D-LINK'S OPTION, REPAIR OR REPLACEMENT. THE FOREGOING WARRANTIES
AND REMEDIES ARE EXCLUSIVE AND ARE IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED OR
IMPLIED, EITHER IN FACT OR BY OPERATION OF LAW, STATUTORY OR OTHERWISE, INCLUDING
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. D-LINK NEITHER
ASSUMES NOR AUTHORIZES ANY OTHER PERSON TO ASSUME FOR IT ANY OTHER LIABILITY IN
CONNECTION WITH THE SALE, INSTALLATION, MAINTENANCE OR USE OF D-LINK'S PRODUCTS.
D-LINK SHALL NOT BE LIABLE UNDER THIS WARRANTY IF ITS TESTING AND EXAMINATION
DISCLOSE THAT THE ALLEGED DEFECT IN THE PRODUCT DOES NOT EXIST OR WAS CAUSED BY THE
CUSTOMER'S OR ANY THIRD PERSON'S MISUSE, NEGLECT, IMPROPER INSTALLATION OR TESTING,
UNAUTHORIZED ATTEMPTS TO REPAIR, OR ANY OTHER CAUSE BEYOND THE RANGE OF THE
INTENDED USE, OR BY ACCIDENT, FIRE, LIGHTNING OR OTHER HAZARD.

LIMITATION OF LIABILITY
IN NO EVENT WILL D-LINK BE LIABLE FOR ANY DAMAGES, INCLUDING LOSS OF DATA, LOSS OF
PROFITS, COST OF COVER OR OTHER INCIDENTAL, CONSEQUENTIAL OR INDIRECT DAMAGES
ARISING OUT THE INSTALLATION, MAINTENANCE, USE, PERFORMANCE, FAILURE OR
INTERRUPTION OF A D-LINK PRODUCT, HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY.
THIS LIMITATION WILL APPLY EVEN IF D-LINK HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH
DAMAGE.
IF YOU PURCHASED A D-LINK PRODUCT IN THE UNITED STATES, SOME STATES DO NOT ALLOW THE
LIMITATION OR EXCLUSION OF LIABILITY FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO
THE ABOVE LIMITATION MAY NOT APPLY TO YOU.

Table of Contents
OVERVIEW.................................................................1
Features......................................................................2
INSTALLATION...........................................................4
Unpack and Inspect......................................................4
Installing the Adapter....................................................4
Connecting the Network Cable.......................................5
Software Installation .....................................................6
TROUBLESHOOTING..................................................7
SPECIFICATIONS .......................................................8

DGE-550T 1000 Mbps PCI Adapter
Introduction 1
1
Overview
Thank you for choosing the D-Link DGE-550SX. This
introduction gives a general description of the newer
networking technologies found on the DGE-550SX.
This Network Interface Card (NIC) is designed to operate at
1000Mbps at full duplex. When running at 1000Mbps, it
provides a network throughput of 2Gbps in full-duplex mode.
The card supports IEEE 802.1p Traffic Prioritization for time-
sensitive and mission-critical traffic. With IEEE 802.1Q
multiple VLAN support, it provides VLAN tables that can
filter packets by recognized VLAN tags, strip VLAN tags
when received, and insert VLAN tags when transmitted.
VLANs can increase the efficiency and provide extra security
of your network.
The DGE-550SX provides IEEE802.3x Flow Control
Enhancements, which are needed for a network adapter to
function with a switch. In full-duplex mode, MAC implements
the PAUSE control function. This means when a switch is
connected in full-duplex mode and it senses that its buffer will
overflow in the near future, the switch will transmit one
standard Ethernet packet that causes the DGE-550SX to
pause for a period, thus avoiding internal buffer overflow and
packet loss.

DGE-550SX 1000 Mbps PCI Adapter
2Introduction
The NIC enables simple, scalable network migration,
providing the benefit of Gigabit Ethernet networking with the
familiarity of Ethernet.
Features
Designed for versatility and performance, the DGE-550SX
NIC provides the following:
•Hardware VLAN filtering.
•Chip-Level Internet Protocol (CLIP) for IP packet
processing.
•IEEE 802.3z compliant.
•Complies with the PCI v2.1 interface standard –
supporting operation at 33/66 MHz and 32/64 bit wide
data path.
•Full-duplex operation.
•On-board verification of IP header and TCP/UDP
checksum.
•On-board screening of VLAN-tagged packets –tagged in
compliance IEEE 802.3ac.
•IEEE 802.3z 1000Base-SX Gigabit Ethernet compliant.
•SC optical fiber connector, 850 nm wavelength.
•Transceiver lasers compliant with Laser AEL Class 1
standards and is safe for eye-viewing.
•Accepts 62.5 / 125 micron multi-mode fiber optic cable for
a maximum length of 260 meters.

DGE-550T 1000 Mbps PCI Adapter
Introduction 3
•Accepts 50 / 125 micron multi-mode fiber optic cable for a
maximum length of 550 meters.
•EMI standard.
•FCC class B
•VCCI class B
•BSMI
•Physical Dimensions: Length 165 mm
Height 95 mm
•Power Consumption: 5.58 W
•Operating temperature range: 0 to 50° C
•Storage temperature range: -5 to 55° C
•Humidity: 5 to 95%, non-condensing
•Support for:
•Windows XP
•Windows 2000
•Windows 95 OSR2, 98, 98 SE
•Windows NT 4.0
•Windows ME
•Novell NetWare Server 3.12, 4.x, 5.0, 5.1
•Novell NetWare Client32 for DOS
•Linux (kernel 2.4.x)

DGE-550T 1000 Mbps PCI Adapter
4Installation
2
Installation
Unpack and Inspect
CAUTION: Under ordinary circumstances, a DGE-550SX
card will not be affected by static charge. In
some circumstances where you may carry an
extraordinarily high static charge, it is good
practice to reduce the charge by touching a
ground before handling the adapter card.
Open the shipping carton and carefully remove all items. In
addition to a printed copy of this User's Guide, ascertain that
you have:
•One DGE-550SX 1000 Mbps PCI Adapter Card.
•DGE-550SX User’s Guide CD-ROM
Installing the Adapter
1. Shut down the computer, unplug its power cord, and
remove the chassis cover.
2. Insert the contact edge of the DGE-550SX card into the
connector of any available PCI Bus Master expansion slot.
Press the card firmly into the connector such that the
card’s contacts are fully seated in the PCI connector.

DGE-550SX 1000 Mbps PCI Adapter
Installation 5
3. Install the bracket screw that secures the card to the
computer chassis.
4. Replace the computer’s chassis cover.
5. Reconnect the computer’s power cord, and switch
computer power on. If the BIOS section of your
computer’s boot program is Plug-and-Play compliant,
then at power-up the BIOS will automatically configure
any newly installed DGE-550SX adapter.
NOTE: Due to a fault in some Plug-n-Play BIOS programs, it
happens occasionally that a newly installed adapter is
assigned an Interrupt Number which is already
assigned to another device. In such a case, a conflict in
the Interrupt Number will cause faults in the behavior
of both devices. Then it is necessary to run the CMOS
Setup utility, and manually assign a non-conflicting
Interrupt Number to the PCI bus slot that the DGE-
550SX is install in.
Connecting the Network Cable
The DGE-550SX 1000Base-SX Gigabit Ethernet network
adapter card enables operation over 850nm 62.5/125 fiber
optic cable to 220 meters and 850nm 50/125 fiber optic cable
to 500 meters. The network adapter card uses two SC sockets
to terminate the fiber optic cable. The upper socket is used to
transmit packets and the lower socket is used to receive
packets.

DGE-550T 1000 Mbps PCI Adapter
6Installation
Software Installation
With the wide variety of network architecture in mind, the
instructions for driver †software installation are given as
README files on the DGE-550SX Software CD-ROM. Review
the file README in the root directory for an overview and full
installation details; see the README and referenced
instruction files in the subdirectory appropriate to your
network operating system.
A brief overview of the installation details is as follows: As the
DGE-550SX is Plug-and-Play compliant, the driver software
should be automatically detected and installed in PCs
running Windows 95, 98, and 2000. After “New Hardware
Found” dialog boxes for “PCI Ethernet Controller” and
“D-Link DGE-550SX Gigabit Ethernet Adapter” are displayed
in rapid succession, a “Copying Files” window, and then
an ”Insert Disk” window appear. The final step is placing the
DGE-550SX Software CD-ROM in your CD-ROM drive and
then making sure the correct location is selected. Once this is
done the software installation should be complete.
†Check http://www.dlink.comfor newest release of drivers.

DGE-550SX 1000 Mbps PCI Adapter
3
Troubleshooting
If you experience any problems with the adapter, first:
ascertain that the appropriate driver is loaded; that the
proper grade of cable is employed for the network connection;
and that the supporting hub is properly qualified for the
application.
The DGE-550SX Adapter features three LED indicators:
•Power Steady green indicates the adapter is powered-up.
•Link/Act Steady green indicates a good connection
between the adapter and another Ethernet device.
Flashing green indicates a good connection (valid Link)
with Ethernet packet traffic on it.
•Full Steady green indicates the adapter is operating in
full-duplex mode.

DGE-550SX 1000 Mbps PCI Adapter
4
Specifications
Jumperless Hardware
LAN Chip Set:
•Gigabit Media Access controller: NS DP83820
•Physical interface: NS DP83861
EMI Certifications:
•FCC Class B
•CE Class B
•BSMI Class B
•VCCI Class B
•C-Tick
Host interface: PCI Bus (Bus Master)
I/O base address assigned by Plug and Play system
Interrupt Number Assigned by Plug and Play system
Physical Dimensions: 166 mm (L) x 73 mm (H)
Environment:
•Storage: −25°to 55°C (-13°to 131°F)
•Operating: 0°to 50°C (32°to 122°F)
•Humidity: 5% to 90% non-condensing
•Power Consumption: 10W

Offices
AUSTRALIA D-Link Australasia
Unit 16, 390 Eastern Valley Way, Roseville,
NSW 2069 Australia
TEL: [phone] FAX: [phone]
TOLL FREE (Australia): 1800 177 100
TOLL FREE (New Zealand): 0800-900900
URL: www.dlink.com.au
E-MAIL: [email protected] & [email protected]
CANADA D-Link Canada
2180 Winston Park Drive, Oakville, Ontario, L6H 5W1 Canada
TEL: [phone] FAX: [phone]
BBS: 1-965-279-8732
TOLL FREE: 1-800-354-6522
URL: www.dlink.ca FTP: ftp.dlinknet.com
E-MAIL: [email protected]
CHILE D-Link South America
Isidora Goyeechea 2934 of 702, Las Condes, Santiago, Chile
TEL : [phone] FAX: [phone] URL: www.dlink.cl
E-MAIL: [email protected] & [email protected]
DENMARK D-Link Denmark
Naverland 2, DK-2600 Glostrup, Copenhagen, Denmark
TEL:[phone] FAX:[phone]
URL: www.dlink.dk E-MAIL: [email protected]
EGYPT D-Link Middle East
7 Assem Ebn Sabet Street, Heliopolis, Cairo, Egypt
TEL: [phone] FAX: [phone]
URL: www.dlink-me.com
E-MAIL: [e-mail] & [e-mail]
FINLAND D-Link Finland
Tulli-ja Pakkahuone, Katajanokanlaituri 5, Fin –00160 Helsinki
TEL: [phone] FAX: [phone]
URL: www.dlink-fi.com
FRANCE D-Link France
Le Florilege #2, Allee de la Fresnerie,
78330 Fontenay le Fleury, France
TEL: [phone] FAX: [phone]

URL: www.dlink-france.fr
E-MAIL: [e-mail]
GERMANY D-Link Cent. Europe/D-Link Deutschland GmbH
Schwalbacher Strasse 74, 65760 Eschborn, Germany
TEL: [phone] FAX: [phone]
URL: www.dlink.de
BBS: 49-(0) 6192-971199 (analog)
BBS: 49-(0) 6192-971198 (ISDN)
INFO: 00800-7250-0000 (toll free)
HELP: 00800-7250-4000 (toll free)
REPAIR: 00800-7250-8000 E-MAIL: [email protected]
INDIA D-Link India
Plot No.5, Kurla-Bandra Complex Rd., Off Cst Rd.,
Santacruz (E), Bombay, 400 098 India
TEL: [phone] FAX: [phone]
URL: www.dlink-india.com E-MAIL: [email protected]
ITALY D-Link Mediterraneo Srl
Via Nino Bonnet n. 6/b, 20154, Milano, Italy
TEL: [phone] FAX: [phone]
URL: www.dlink.it E-MAIL: [email protected]
JAPAN D-Link Japan
10F, 8-8-15 Nishi-Gotanda, Shinagawa-ku, Tokyo 141, Japan
TEL: [phone] FAX: [phone]
URL: www.d-link.co.jp E-MAIL: [e-mail]
RUSSIA D-Link Russia
Michurinski Prospekt 49, 117607 Moscow, Russia
TEL: [phone] & 7-095-737-3492 FAX: [phone]
URL: www.dlink.ru E-MAIL: [email protected]
SINGAPORE D-Link International
1 International Business Park, #03-12 The Synergy,
Singapore 609917
TEL: [phone] FAX: [phone]
E-MAIL: [email protected] URL: www.dlink-intl.com
S. AFRICA D-Link South Africa
Unit 2, Parkside 86 Oak Avenue,
Highveld Technopark Centurion, Gauteng, South Africa
TEL: [phone] FAX: [phone]
URL: www.d-link.co.za E-MAIL: [e-mail]

SWEDEN D-Link Sweden
P. O. Box 15036, S-167 15 Bromma, Sweden
TEL: [phone] FAX: [phone]
E-MAIL: [email protected] URL: www.dlink.se
TAIWAN D-Link Taiwan
2F, No. 119 Pao-Chung Rd, Hsin-Tien, Taipei, Taiwan
TEL: [phone] FAX: [phone]
URL: www.dlinktw.com.tw E-MAIL: [email protected]
U.K. D-Link Europe
4th Floor, Merit House, Edgware Road, Colindale,
London NW9 5AB U.K.
TEL: [phone] FAX: [phone] BBS: 44 (0) 181-235-5511
URL: www.dlink.co.uk E-MAIL: [email protected]
U.S.A. D-Link U.S.A.
53 Discovery Drive, Irvine, CA 92618, USA
TEL: [phone] FAX: [phone]
BBS: 1-949-455-1779 &1-949-455-9616 INFO: 1-800-326-1688
URL: www.dlink.com
E-MAIL: [email protected] & [email protected]

Registration Card
Print, type or use block letters.
Your name: Mr./Ms____________________________________________________________________________
Organization:_____________________________ Dept. ____________________________________
Your title at organization: _____________________________________________________________
Telephone:__________________________ Fax:__________________________________________
Organization's full address: ____________________________________________________________
Country:______________ Date of purchase (Month/Day/Year):____________________________________
Product
Model Product Serial No. * Product installed in type of computer (e.g., Compaq 486) * Product installed Computer serial No.
(* Applies to adapters only)
Product was purchased from:
Reseller's name: ____________________________________________________________________
Telephone:_______________________ Fax:______________________________________________
Reseller's full address: _______________________________________________________________
1. Where and how will the product primarily be used?
oHome oOffice oTravel oCompany Business oHome Business oPersonal
2. How many employees work at installation site?
o1 employee o2-9 o10-49 o50-99 o100-499 o500-999 o1000 or more
3. What network protocol(s) does your organization use ?
oXNS/IPX oTCP/IP oDECnet oOther_____________________________
4. What network operating system(s) does your organization use ?
oD-Link LANsmart oNovell NetWare oNetWare Lite oSCO Unix/Xenix
oPC NFS o3Com 3+Open oBanyan Vines oDECnet Pathwork
oWindows NT oWindows NTAS oWindows '95 oOther______________
5. What network management program does your organization use ?
oD-View oHP OpenView/Windows oHP OpenView/Unix oSunNet Manager oNovell NMS
oNetView 6000 oOther____________________
6. What network medium/media does your organization use ?
oFiber-optics oThickcoax Ethernet oThin coax Ethernet
o10BASE-T UTP/STP o100BASE-TX o100BASE-T4 o100VGAnyLAN oOther_________________
7. What applications are used on your network?
oDesktop publishing oSpreadsheet oWord processing oCAD/CAM
oDatabase management oAccounting oOther_____________________
8. What category best describes your company?
oAerospace oEngineering oEducation oFinance oHospital oLegal oInsurance/Real Estate
oManufacturing oRetail/Chainstore/Wholesale oGovernment
oTransportation/Utilities/Communication oVAR oSystemhouse/companyoOther_____________
9. Would you recommend your D-Link product to a friend?
oYes oNo (why?) ______________________ oI don’t know yet
10. Your comments on this product:
