Wolverine Brass Essence 85940 User manual

800-944-9292 www.wolverinebrass.com
NEED HELP?
For additional assistance or service please contact: 92-85940-03
Essence
Kitchen Faucet
Single Control with Pull Out Spray
85940 Polished Chrome
85941 Brushed Nickel
INSTALLATION INSTRUCTIONS
SPECIFICATIONS
• 35mm Ceramic Disc with Hot
Temperature Limit Adjustment
Ring.
• Brass Body with Copper Supplies
• Brass Supply Connection
Adapters with 1/2” IPS Threads.
• Polished Chrome Plated Metal
Handle.
• Single Control Lever Handle.
• Requires less than 5 lb force to
operate Handle.
• Temperature Adjustment 90° Full
Cold to Full Hot.
• 1.8 GPM (6.8 L/min) Aerator.
1Assemble Deck Plate to Faucet
2Assemble Putty Plate to Faucet
3Position Faucet on sink
4From underside of sink, assemble Shank
Mount Washer and Shank Mount Nut, then
assemble Nuts to the Deck Plate Studs
5Assemble Braided Spray Hose to the Hose
Quick Connect Fitting.
CAUTION: Make sure the Braided Spray Hose is
properly engaged and secure into the Hose Quick
Connect Fitting.
6
Assemble Hose Weight to the Braided Spray Hose.
7Assemble Water Supply Lines to Faucet.
CAUTION: Use Wrench or Pliers to hold Faucet Inlet
Adapters when tightening Water Supply Line Nuts
to prevent twisting Copper Tubing or damaging
Solder Joints.
8Remove Spray Wand from Faucet and flush
water through Faucet to remove any debris
within the system.
9Assemble Spray Wand to Faucet and run
water through Faucet while inspecting all
connections for possible leaks.
3 HOLE INSTALLATION
1Assemble Single Hole Mount Flange to Faucet
2Follow steps 4through 9from “3 HOLE INSTALLATION”.
SINGLE HOLE INSTALLATION

800-944-9292 www.wolverinebrass.com
NEED HELP?
For additional assistance or service please contact: 92-85940-03
85940 / 85941 REPAIR PARTS
ITEM NO. PART NO. DESCRIPTION
1 24632 ESSENCE LEVER HANDLE - PC
2463204 ESSENCE LEVER HANDLE - BN
2 85101 HANDLE SET SCREW
3 85102 INDEX BUTTON
4 85107W CARTRIDGE ASSEMBLY
5 85301 SPRAY WAND - PC
85302 SPRAY WAND - BN
6 85327 15/16" MALE AERATOR 1.8GPM - PC
7 85336 PULL OUT SPRAY HOSE
8 85340 HOSE WEIGHT
9 85339 QUICK CONNECT ADAPTER
10 85344 BUSHING FOR PULL OUT SPRAY
85940 / 85941 ROUGH IN DIAGRAM
COMPLIANCE
ASME A112.18.1 / CSA B125.1
cUPC certified
NSF 61/372
ADA compliant
CONNECTIONS
1/2” IPS Inlets
FLOW
1.8 GPM (6.8 L/min)
MOUNTING SURFACE
1-3/4” MAX DECK THICKNESS
Ø1-3/8” MIN TO Ø1-5/8” MAX HOLE SIZE
HOLES TO BE 4” ON CENTER

800-944-9292 www.wolverinebrass.com
NEED HELP?
For additional assistance or service please contact:
PRODUCT WARRANTY
With the exception of items listed below, this product has a limited warranty against defects
in materials or workmanship for a period of one year from the date of installation.
Exceptions:
1.) Faucet stem cartridges have a limited warranty for a period of 100 years from date of manufacture.
2.) Product finishes have a limited warranty for a period of 100 years from the date of installation excluding oil rubbed bronze finishes. Failure to
follow the cleaning instructions listed below voids all finish warranty. Damage due to accidents or installation is not warranted.
This warranty covers replacement of cartridges and finish only and does not include labor charges and/or damage incurred in installation. Finish
warranty is not covered if finish is exposed to extreme use of cleaners containing abrasives, alcohol, extreme cleaning, or chemical use, or damage
due to abuse or neglect. **Please see cleaning instructions provided with each faucet. This warranty excludes all industrial, commercial, and
business usage of faucets and only pertains to residential use. Faucets used for other than residential use are covered by a 1-year limited warranty
from the date of purchase.
CALIFORNIA PROPOSITION 65
CALIFORNIA PROPOSITION 65:
WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer and
birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
Wash hands after installation, repair, or removal of this product.
CLEANING INSTRUCTIONS
USE ONLY A CLEAN, SOFT CLOTH, WATER, AND MILD HAND SOAP TO CLEAN UNIT.
WARNING
Do not use abrasive cleaners, chemicals or abrasive cleaning pads to clean fixture.
A very hard protective coating has been applied to this product to maintain it's appearance, but this product could be damaged with improper
cleaning.
