WoodLife Garden 5X4M User manual

19.2 m²
4979mm310mm 310mm
310mm310mm 3860mm
GARDEN
INSTALLATION INSTRUCTIONS
NOTICE DE MONTAGE
MONTAGEANLEITUNG
INSTRUCIONES DE MONTAJE
IISTRUZIONI DI MONTAGGIO
INSTRUKCJA MONTAŻU
5X4M

2
GARDEN
ENGLISH
RECOMMENDATIONS
Please read the components list BEFORE assembly, make sure that no parts are damaged or missing.
Go through the complete assembly instructions again.
Assemble all parts according to the instructions in this manual and do not skip any work step.
Treat the wall panels with extreme care before and during assembly. Carefully place them on the ground.
Avoid stepping on or placing objects on it.
At least two people are required to assemble the garden sheds.
Recommendation: Build a base of wood / composite or concrete as a foundation.
Leave enough space at the installation site outside of the WPC house so that you can access the WPC Garden
sheds from the outside during assembly.
Remove all parts from the packaging and spread them out on a clean work surface by Area I / II and III.
Due to the high proportion of wood, the surface may have different shades and change color over time. This
does not require special treatment, nor does it affect the life of the WPC Garden sheds.
If you want to paint the WPC house, please ask a professional painter for advice on choosing the right colors
for the wood-plastic composite material.
Do not use aggressive cleaning agents as these can stain or damage the WPC house.
CARE AND SAFETY INSTRUCTIONS
The garden shed is generally used for storing objects. The WPC house is not especially designed for
residential purposes.
It is recommended to anchor the WPC house on an immovable object / foundation (as storm protection).
Do not set up on windy or cold days.
Check the WPC house regularly for stability and make sure that the location is level.
Be careful when handling parts with steel edges.
For the construction and handling of the WPC house, please only use tools that are listed in the assembly
instructions.
Always wear work gloves, safety glasses and items of clothing with long sleeves when assembling the
garden shed or performing maintenance work.
Avoid using lawnmowers and mechanical scythe in the immediate vicinity of the WPC house.
Always wear safety goggles and always follow the manufacturer’s instructions when using power tools.
Clean the WPC house with a garden hose and a mild detergent. You can use a hard brush but not abrasive
or degreasing agents as well as cleaning agents containing oil or acetone, as these can stain or damage
the dandruff.
Do not store any hot objects in the WPC house, such as recently used grills or blowtorches, or any volatile
chemicals.
Do not lean heavy objects against the walls of the WPC house, as this could distort the entire WPC house.
Keep the roof free of snow and accumulated foliage. Large amounts of snow can damage the WPC house
and become dangerous when entering.
Make sure there is sufficient ventilation at the WPC house. This way you avoid moisture.
Cover the roof of the WPC house with a tight roof covering. Pay attention to the roof slope. A self-adhesive
sealing membrane is best suited.
The wind direction is an important factor that must be taken into account when setting up the WPC house.
Avoid excessive wind loads, especially high wind pressure on the doors. Always keep the doors closed
and locked when the WPC house is not in use to avoid damage from wind loads.
Please contact your local authority and inquire there if a permit is required to build the WPC house.

3
GARDEN

Ø 8mm
BACK VIEW
SIDE VIEW
TOOLS REQUIRED FOR INSTALLATION
FRONT VIEW
AXONOMETRIC VIEW

4
GARDEN
ENGLISH
Min 5100mm
Min 4000mm
GROUND REQUIREMENTS:
A good foundation is the most important fact to guarantee the safety and durability of
your garden house.
A foundation that is completely level and processed at right angles guarantees
problem-free installation and durability of your garden shed. This is especially
important for the exact fit of the doors.
We recommend the following variants for your foundation:
1) Concrete or pavement slab foundation
2) Cast concrete foundation

5
GARDEN

11 A
A
A
A
A
A
A
A
A
A
A
B
B
B
B
B
B
B
B
B
A
A
C
C
C
A
A
32
1
15
1
16
1
17
18
1
23
21
42
52
64
72
14
13
8
56
9
42
10
11
12
19
20
1
21
22
1
10
24
26
27
5
25
2
1
2
1
6
2
2
2
12
4
STRUCTURENº DESCRIPTION QTY ZONE*
Aluminum bottom frame
40x35 L = 4988 mm
Aluminum bottom frame
40x35 L = 4988 mm
Aluminum bottom frame
40x35 L = 3869 mm
Aluminum bottom frame
60x60 L = 2143mm
Aluminum bottom frame
60x60 L = 2260mm
Aluminum bottom frame
60x33 L = 2765mm
Aluminum bottom frame
60x33 L = 2110mm
Door frame (up)
63x40 L = 1485mm
Door frame (down)
63x40 L = 1485mm
Door frame (left)
63x40 L = 2010mm
Door frame (right)
63x40 L = 2010mm
Aluminum roof top beam
140x40 L = 4400mm
Aluminum roof beam
140x40 L = 4400mm
Aluminum U profile
37x30 L = 680mm
Aluminum U profile
37x30 L = 400mm
Gutter for roof
133x91 L = 4500mm
Gutter for roof
133x91 L = 4500mm
Window kits
900x600
Vent
500x205
Door kits
2000x1500
Roof panel
1100x25 L = 3000mm
Ridge panel
WPC II Plank wall
160x28 L = 1887mm
WPC II Plank wall
160x28 L = 1687mm
Aluminum roof outer frame
(Front)
180x40 L = 2994mm
Aluminum roof outer frame
(Back)
180x40 L = 2994mm
Aluminum roof outer frame
(Left & Right)
140x40 L = 4480mm

6
GARDEN
ENGLISH
4
2
21 A
A
A
A
A
C
A
A
A
A
A
A
B
B
B
B
B
C
C
C
C
C
C
C
4
24
A
19
B
210
G
36
c
4
1
E
D
8
H
36
I
12
2
K
L
2
F
18
160
N
160
M
1
O
2
J
28
29
30
31
32
33
2
1
P
4
Q
2
R
STRUCTURENº DESCRIPTION QTY ZONE*
WPC II Plank wall
160x28 L = 1470mm
WPC II Plank wall
160x28 L = 573mm
WPC II Plank wall
160x28 L = 622mm
WPC II Plank wall
160x28 L = 1687mm
WPC II Plank wall
160x28 L = 1470mm
Decoration panel
Plastic expansion screw
8x80
Screws 4x20
L connector for column
65x20 L = 65 mm
Door connector
Door frame mounting
Hexagon key
L connector for beams 40x40
L = 40mm
L connector for Roof frame
Beam clamp plug
Beam clamp plug
Connector rail
Screws 5x75
Rain cap for roof screw
Screw bits
Gutter cover
Gutter cover
Roof plug
Door lock
*Pieces are separated and identified in 3 parts for an easy installation.
A:first installed part; B : second installed part ; C:last installedpart

7
GARDEN

A
4988.0mm
3869.0mm
6312.6mm
6312.6mm
3
3
2
1
Frame out the installation area by chalk.
Check the leveling before start installation – the foundation is the key point to
guarantee your safe and durable garden sheds
Put the plastic expansion tube through the hole and punch into the ground, screwing
into the tube as much as possible.

8
GARDEN
ENGLISH
60 60 60
60 60 1440 60 60
1649.5
1649.5
1840 1840
COLUMN POSITION VIEW
Mark above important points, trying to keep them as exact as possible.

9
GARDEN

7
7
6
6
6
5
5
4
4
B
B
C
C
3
3
2
1
Put the column to the right position and fix them with L bracket and screws. Mind that
there are column in different profile and height, make sure the column is vertical.

10
GARDEN
ENGLISH
11
10
9
8
D
E
10 10
8F
10
8
6
Fixing the door frame with connection acc. and fasten with hexagon key.
Put the door frame upon the aluminum bottom frame, fix the other column with L
bracket.
NOTE: The hinges is in front of the frame.

11
GARDEN

Screw through each column to the wall panel every 4 pcs – making sure the columns
are vertical.
Install the wall panel one by one, we suggest that we install them averagely to each
unit so that the whole frame become stable.
26
27
27
27
27
28
26
26
26
BBBB

12
GARDEN
ENGLISH
B
B
B
B
29
29
29 29
21
21
x7
Screwing every 4 pcs, checking the verticality of columns before screwing. Install the
window kits.
NOTE: These are inward opening window, no not mistake the Left and Right kits when installing.
Install the wall panels according to pictures showing above.

13
GARDEN

B
B
B
B
22
30 30 22 30 30
Continue the installation of wall panels and note that screws are required every 4 pcs.
Put the vent kits upon the 10th pcs of wall panel back side - put the short wall panel as
per picture

14
GARDEN
ENGLISH
31 31
31 31
32
32
26
26
26
27
27
27
28 28
29 29 29 29
Putting right triangle panels into right position.
Compete the wall panels – making sure right panels before installation.

15
GARDEN

I
I
II
I
I
JJ
12
13
13
13
13
13
13
270mm
270mm
G
12
13
Fixing the L connectors to the beams, then put all beams into plugs, adjust the position
of each beam.
NOTE: The beam should extend front wall panel 270mm. Keep as acute the extension dimension as
possible.
Put the beam clamp plug into the breach of wall panels.
NOTE: There are 2 type of plug

16
GARDEN
ENGLISH
17
17
17
17
17
17 18
18
270mm
270mm
6
13
6
13
270mm
270mm
Fixing 2 beams to columns with L brackets as shown in picture – make sure the wall are
vertical and extend part 270mm before fixing screws.
Cover the U profile to each unit of wall panel between beams.

17
GARDEN

15
15
14
14
16
16
16
H
16
H
Connect side outer beams to front/ back beams with L connector, then fixing them with
L brackets.
Put Front/ Back outer beams and fix with L brackets and screws.

18
GARDEN
ENGLISH
310mm
K
K
7 7
13
13
Check the distance between side outer beams and wall panel and adjust if needed.
Fixing the connect rail between column and beams with screws.

19
GARDEN

24
24
L
L
L+ M
24
.
NOTE:
1. Fixing first 2 screws to the top beam without water-proof kits, make sure someone help holding the
panel until at least 2 screws are done.
2. Make sure the screws are installed through the wave crest, we need screw every two waves.
Put the roof panel upon roof beams ( grey side up ), the top side of the wall panel
should be close to the top beam so one screw can be fixed, the panel should leave
10mm gap to the cover of front/ back out beams.
Then screw through the roof panel to the beams with roof fixing kits.
NOTE: Don’t fix the last row of screws to the outer beams at the moment.

20
GARDEN
ENGLISH
2
1
25
25
25
25
25
Fix the roof tiles in turn.
Install these roof panels one by one, the 2nd piece of roof should cover two waves of
1st one.
