Woodline PAPILLON User manual

1|6
1 X SCISSORS
(NOT INCLUDED)
2 X ADJUSTABLE
CRESCENT WRENCH
(NOT INCLUDED)
REQUIRED TOOLS LIST
1
PARTS LIST
1 x VERTICAL
STRUCTURE
(with vertical runner)
1 x ROOF STRUCTURE
CANOPY
CENTER ROLLER
SIDE ROLLERS
6 x WASHERS M12
1 x PVC WASHER WITH
RECESS (FEMALE)
6 x NYLOC NUTS M12
1 x VERTICAL STRUCTURE
VERTICAL RUNNER
GEARBOX
1 x PVC WASHER
WITH SPIGOT (MALE)
6 x 1.5" STANDARD
PVC WASHERS
1 x CRANK HANDLE
2 x CENTER PINS
(1/4” x 4 - 3/4” pin attached
to vertical runners on vertical
structures)
4 x STABILIZER PINS
(1/4” x 2 - 1/2” pin attached
to horizontal runners on vertical
structures)
Item Code: 05857
Item Code: 05857-S
Item Code: 05857-P
Item Code: 05857
Item Code: 05857-S
Item Code: 05857-P
Item Code: 05792
Item Code: 06801
Item Code:
3 x 4 m - 09550
3 x 5 m - 08558
Item Code: 02193
Item Code: 05242
Item Code: 06109
Item Code: 06108
Item Code: 06110
Item Code: 07465
FRAME (VERTICAL STRUCTURE)
SHADE (ROOF STRUCTURE)
1
1a
1b
2
11
10
9
8
11
10
6a
6b
6
3
4
4
6
5
7
8
9
1a
1b
2
3
5
6a
6b
6
7
1b
PAPILLON
EURO (WOOD & STAINLESS STEEL)
CONTEMPO (BEAD BLASTED STAINLESS STEEL)
MARINE (POLISHED STAINLESS STEEL)
C
Distributor:
Shadescapes Americas
TEL: [phone]
www.shadescapesamericas.com
[email protected]
PROTRADE & WOODLINE cc. 2000

STEPS 1 - 5: INSTRUCTIONS FOR UNPACKING AND PREPARATION FOR ASSEMBLY
STEP 1
STEP 4 - ALIGNING ROOF STRUCTURE WITH VERTICAL STRUCTURE AND GEAR BOX
STEP 5 - ALIGNING THE ROOF STRUCTURE WITH 2ND VERTICAL STRUCTURE
STEP 2 STEP 3
REMOVE THE ROOF STRUCTURE & CANOPY FROM THE PROTECTIVE TUBE. THE WOODEN
END PLUGS ARE SECURED USING SCREWS WHICH MUST BE REMOVED TO GET THE END
PLUGS OUT.
NOTE: IT IS RECOMMENDED TO USE COTTON GLOVES WHEN HANDLING THE CANOPY
TO AVOID DIRTY MARKS ON THE CANVAS. ENSURE YOU ARE WORKING IN A CLEAN
AREA WITH AMPLE SPACE. IT IS ADVISABLE TO LAY THE ROOF STRUCTURE ON A
CLEAN SURFACE SO THE COVER BAG AND ROOF CANOPY DO NOT GET MARKS FROM A
DIRTY SURFACE. THE PLASTIC COVERING CAN BE USED FOR THIS PURPOSE.
USING SCISSORS, CUT DOWN THE LENGTH OF THE PLASTIC BAG CONTAING THE ROOF
STRUCTURE. THE CLEAN INNER SURFACE CAN THEN BE USED AS A WORKING SURFACE.
CUT THE CABLE TIES WHICH HOLD THE ROOF STRUCTURE TOGETHER (CENTER ROLLERS,
SIDE ROLERS AND CANOPY). BE CAREFUL TO NOT CUT OR DAMAGE THE FABRIC.
THE TWO ENDS OF THE PROTECTIVE COVER BAG ARE FOLDED BACK OVER THE ROOF
STRUCTURE. THESE MUST BE CAREFULLY PULLED OUTWARDS BEFORE UNZIPPING.
REMOVE THE PROTECTIVE COVER BAG BY UNDOING THE ZIPPER.
END PLUG
SCREWS
CABLE TIE ROOF STRUCTURE
THERE ARE THREE (3) THREADED SHAFTS AT EACH END OF THE ROOF STRUCTURE. ONE END OF THE ROOF STRUCTURE HAS A SQUARE
SHAFT ON THE CENTER ROLLER. THIS SHAFT FITS INTO THE GEAR BOX ON THE VERTICAL STRUCTURE. BEFORE POSITIONING THE
VERTICAL STRUCTURES, DECIDE AT WHICH END YOU WANT TO POSITION THE GEAR BOX. THE GEAR BOX IS USED FOR OPENING
AND CLOSING THE STRUCTURE AND MUST BE ACCESSIBLE WITH THE CRANK HANDLE. THE MIMIMUM REOMMMENDED SPACE
REQUIREMENT IS 50cm (20 INCHES).
ONCE YOU HAVE DECIDED, PLACE THE VERTICAL STRUCTURE AT 90 DEGREES TO THE ROOF STRUCTURE SO THE GEAR BOX FACES
OUTWARDS. THE CHAINS WITH STAINLESS STEEL PINS ON THE VERTICAL STRUCTURE SHOULD ALSO FACE OUTWARDS (AWAY FROM
THE ROOF STRUCTURE).
GEAR BOX
VERTICAL STRUCTURE
SQUARE SHAFT
POSITION THE OTHER VERTICAL STRUCTURE AT 90 DEGREES, SO THE STAINLESS STEEL PINS WITH CHAINS
ARE FACING OUTWARDS.
ZIPPER
2|6
ROOF STRUCTURE
ROOF STRUCTURE
VERTICAL STRUCTURE
Distributor: Shadescapes Americas TEL: [phone] www.shadescapesamericas.com [email protected] © PROTRADE & WOODLINE cc. 2000

STEP 6
FEMALE
PVC WASHER
STEP 7
MALE
PVC WASHER
3|6
It is recommened to
lubricate threaded shafts
to prevent the Nyloc nuts
from freezing due to friction
(Vaseline or copperslip is
recommended).
Crank Holder
STEP 6 - ATTACHING THE VERTICAL STRUCTURE WITH GEAR BOX TO THE ROOF STRUCTURE
• IDENTIFY AND PROPERLY ALIGN THE PVC WASHERS IN THEIR CORRECT POSITIONS BETWEEN THE VERTICAL STRUCTURE AND ROLLERS
AS ILLUSTRATED.
• ALIGN THE SQUARE SHAFT ON THE CENTER ROLLER WITH THE SQUARE OPENING ON THE GEAR BOX. INSERT THE SHAFT INTO THE GEAR BOX.
IF IT DOES NOT FIT PROPERLY, TURN THE BLACK CRANK HOLDER ON THE GEAR BOX UNTIL THE SQUARE HOLE IS ALIGNED AND INSERT.
• PLACE THE FEMALE PVC SPACER AGAINST THE GEAR BOX ON THE OUTSIDE OF THE CENTER POLE AND ADD THE STAINLESS STEEL WASHER
AND NYLOC NUT.
• INSERT THE THREADED SHAFTS ON THE SIDE ROLLERS INTO EACH OF THE SIDE ARMS AND ADD ALL THE STAINLESS STEEL WASHERS AND
REMAINING NYLOC NUTS.
• TIGHTEN THE NYLOC NUTS TO THE POINT THEY HOLD FIRM , BUT THE ROLLERS STILL ROTATE FREELY.
STEP 7 - ATTACH REMAINING VERTICAL STRUCTURE TO THE ROOF STRUCTURE
• IDENTIFY AND PROPERLY ALIGN THE PVC WASHERS IN THEIR CORRECT POSITIONS BETWEEN THE VERTICAL STRUCTURE
AND ROLLERS AS ILLUSTRATED.
• INSERT THE THREADED SHAFTS ON THE SIDE ROLLERS INTO EACH OF THE SIDE ARMS AND ADD ALL THE STAINLESS STEEL
WASHERS AND REMAINING NYLOC NUTS.
• TIGHTEN THE NYLOC NUTS TO THE POINT THEY HOLD FIRM , BUT THE ROLLERS STILL ROTATE FREELY.
NOTE: THE ROOF STRUCTURE IS A FREE
SPINNING SYSTEM. THE NYLOC NUTS
SECURING BOTH SIDES SHOULD ONLY BE
TIGHTENED TO THE POINT THE NYLOC NUTS
HOLD FIRM, AND THE ROLLERS STILL ROTATE
FREELY.
Gear Box
Standard
PVC Washers
Standard PVC Washers
Distributor: Shadescapes Americas TEL: [phone] www.shadescapesamericas.com [email protected] © PROTRADE & WOODLINE cc. 2000

4|6
STEP 8
STEP 9
STEP 12 - SECURING THE ROOF STRUCTURE
STEP 11 - OPENING TO THE SECOND POSITION
NOTE: EACH SIDE CAN BE LIFTED INDEPENDENTLY BY ONE
PERSON. THERE IS NO NEED FOR TWO PEOPLE TO LIFT EACH
SIDE SIMULTANEOUSLY.
• TO OPEN THE ROOF STRUCTURE COMPLETELY, RAISE THE
SIDE ARMS OF THE VERTICAL STRUCTURE BY LIFTING THE
VERTICAL RUNNER ON THE CENTER POLE TO THE STOPPER
POSITIONED AT THE TOP OF THE CENTER POLE.
• LIFT THE RUNNER USING ONE HAND, AND INSERT THE
SECURING PIN BELOW THE BOTTOM OF THE RUNNER WITH
THE OTHER HAND.
1.6m Min
(5’ - 3”)
1.6m Min
Center Line
Measured from Tube Center to Tube Center
(5’ - 3”)
CLOSING
REFER TO THE OPENING STEPS IN REVERSE ORDER.
BEFORE LOWERING THE VERTICAL RUNNER, REMOVE THE LOCKING
PINS FROM THE WIND STABILIZING RUNNERS.
FIRMLY GRAB HOLD OF THE VERTICAL RUNNER BEFORE REMOVING
THE SECURING PIN. THE VERTICAL RUNNER MUST THEN BE
LOWERED GENTLY UNTIL IT IS PLACED ON THE STOPPER AT THE
BOTTOM OF THE VERTICAL POLE. FAILING TO HOLD THE RUNNER
FIRMLY, WILL RESULT IN THE RUNNERS SLAMMMING DOWN ONTO
THE STOPPER AND MAY RESULT IN DAMAGE TO THE STRUCTURE.
REPEAT THE SAME PROCEDURE ON THE OPPOSITE SIDE.
WHEN BOTH SIDES ARE DOWN, PROCEED TO ROLL UP THE ROOF
STRUCTURE BY TURNING THE CRANK HANDLE UNTIL ALL THE
FABRIC IS ACCUMULATED OVERHEAD.
NOTE: BEFORE CLOSING OR COVERING WITH A PROTECTIVE COVER
BAG THE FABRIC CANOPY SHOULD BE DRY. IF THE FABRIC CANOPY
IS CLOSED OR PACKED AWAY WHEN WET, IT MAY RESULT IN
PERMANENT STAINING.
MAKE SURE THE SELECTED BASE SYSTEM IS IN THE CORRECT POSITION BEFORE RAISING THE ASSEMBLED
PAPILLON STRUCTURE AND PLACING IT IN THE STAINLESS STEEL TUBES.
• THE STAINLESS STEEL TUBES MUST BE ALIGNED AND POSITIONED SO THE CENTER TO CENTER
DISTANCE EXACTLY MATCHES THE LENGTH OF THE ROOF STRUCTURE.
• FOR THE 5m ROOF STRUCTURE THE DISTANCE FOR FROM CENTER TO CENTER OF THE STAINLESS STEEL
TUBES IS EXACTLY FIVE (5) METERS.
• THE CENTER LINE MUST BE AT LEAST 1.6 M (5’ 3”) AWAY FROM THE NEAREST OBSTRUCTION ON BOTH
SIDES (IN THE DIRECTIONS THE CANOPY OPENS).
• SEE SEPARATE INSTRUCTIONS FOR BASE SYSTEM ASSEMBLY DETAILS. INSTRUCTIONS ARE
INCLUDED IN THE BASE SYSTEM BOX.
USE TWO PEOPLE TO LIFT BOTH VERTICAL STRUCTURES INTO POSITION SIMULTANEOUSLY.
LOWER THE TWO VERTICAL STRUCTURES INTO THE STAINLESS STEEL TUBES AT THE SAME
TIME. ONCE IN POSITION, THE HAND WHEELS ON THE STAINLESS STEEL TUBES CAN BE
TIGHTENED TO SECURE THE POLES IN POSITION.
STEP 10 - OPENING THE PAPILLON - TO FIRST POSITION
INSERT THE CRANK HANDLE INTO THE CRANK HOLDER ON THE GEAR BOX AND TURN THE CRANK HANDLE.
• THE DIRECTION OF ROTATION TO OPEN OR CLOSE THE ROOF STRUCTURE IS DETERMINED
BY THE ROTATION DIRECTION WHEN IT WAS LAST CLOSED. THIS MAY VARY EACH TIME
THE PRODUCT IS OPENED AND CLOSED.
• WHEN OPENING, MAKE SURE THE ROOF STRUCTURE OPENS FREELY. THE WEIGHT OF THE
SIDE ROLLERS IS WHAT HELPS THE ROOF STRUCTURE TO OPEN FREELY AS THE FABRIC CANOPY
IS UNWOUND.
• DO NOT FORCE THE ROOF STRUCTURE OPEN IF IT SEEMS TO BE JAMMING. THIS MAY RESULT
IN DAMAGE TO THE CRANK HOLDER OR GEAR MECHANISM.
• IF THERE IS ANY RESISTANCE WHEN OPENING, MAKE SURE THE CENTER AND SIDE
ROLLERS MOVE FREELY. IF THE ROLLERS DO NOT MOVE FREELY, CHECK
THE NYLOC NUTS. THESE MUST NOT BE OVER TIGHTENED AND SHOULD ALLOW
ENOUGH SPACE FOR FREE MOVEMENT. IF THEY ARE TOO TIGHT, LOOSEN THEM.
• WHEN THE ENTIRE FABRIC CANOPY HAS BEEN UNROLLED, THE ROOF STRUCTURE WILL BE IN THE FIRST
STAGE OF OPENING (SEE ILLUSTRATION). THE ROOF STRUCTURE CAN BE LEFT IN THIS POSITION IF REQUIRED.
THIS POSITION WILL ALLOW ADDITIONAL SHELTER FROM WET WEATHER AND ALLOWS RAIN RUN-OFF.
IT IS ALSO A CONVENIENT POSITION IF THE SUN IS AT LOW ANGLES.
FIRST STAGE OF OPENING
SIDE ARM
VERTICAL RUNNER
ONCE IN THE FULLY OPEN POSITION,
SECURE THE WIND STABILIZING SYSTEM BY INSERTING
THE LOCKING PINS THROUGH THE STABILIZER RUNNERS
AND INTO THE SIDE ARMS. IF THE HOLES ARE NOT
ALIGNED, LIFT OR PULL THE SIDE ARM(S) DOWN TO GET
ALIGNMENT.
NOTE: WHEN COMPLETELY OPEN AND THE SECURING PINS ARE IN POSTION,
THE CANOPY CAN BE LEVELED BY TURNING THE CRANK HANDLE IN THE REQUIRED
DIRECTION UNTIL THE ROOF STRUCTURE IS LEVEL.
SIDE ARM
CENTER PIN
STABILIZER PIN
WIND STABILIZER
WIND STABILIZING
SYSTEM
STOPPER
PIN
Distributor: Shadescapes Americas TEL: [phone] www.shadescapesamericas.com [email protected] © PROTRADE & WOODLINE cc. 2000

5|6
PAPILLON
WIND GUIDELINES
& WARRANTY
THE PAPILLON IS DESIGNED TO HANDLE MODERATE
TO MODERATELY STRONG WINDS IN THE FULLY OPEN
POSITION.
AS WITH ALL UMBRELLAS, USE COMMON SENSE AND
LOWER CANOPY AS WINDS INCREASE. NOTE THAT
WIND IS NEVER A CONSTANT FORCE AND WIND GUSTS
CAN BE TWICE THE AVERAGE WIND SPEED, THEREFORE
IT IS RECOMMENDED TO ALWAYS COLLAPSE THE
CANOPY AND STRAP IT WHEN UNATTENDED. CANOPIES
MUST BE CLOSED IN THE EVENT OF HEAVY RAIN,
THUNDERSTORMS, HAIL OR ANY OTHER SEVERE
WEATHER CONDITIONS.
DAMAGE DUE TO WIND, WEATHER CONDITIONS, OR
IMPROPER USE IS EXPLICITLY EXCLUDED FROM THE
ONE-YEAR DEFECTIVE PARTS WARRANTY COVERAGE.
PAPILLON
BASIC GUIDELINES
*DO NOT LEAVE THE PAPILLON UNATTENDED WHEN OPEN.
*CANOPY/ROOF STRUCTURE MUST BE OPENED TO
MAXIMUM TENSION TO ENSURE OPTIMUM STABILITY IN
ALL WEATHER CONDITIONS.
*AS WINDS INCREASE, COMPLETELY LOWER THE ROOF
STRUCTURE FOLLOWING THE DIRECTIONS IN THIS
MANUAL (SEE PAGE 4).
*ASK FOR ASSISTANCE WHEN CLOSING THE PAPILLON
DURING VERY WINDY CONDITIONS.
*DO NOT LEAVE THE ROOF STRUCTURE CLOSED IF NOT
COMPLETELY DRY.
PAPILLON
CARE AND MAINTENANCE
ALUMINUM PARTS, 304 STAINLESS STEEL & HARDWARE
*UMBRELLA STRUCTURE AND HARDWARE MUST BE CLEANED BY
SPRAYING WITH FRESH WATER ON OCCASION TO REMOVE DIRT
AND DUST BUILD UP.
*USE A SOFT COTTON CLOTH OR CHAMOIS TO WIPE DOWN THE
ANODIZED ALUMINUM SURFACES AS WELL AS THE STAINLESS
STEEL COMPONENTS AND HARDWARE.
*AVOID USING A SCOURER OR ABRASIVE MATERIALS AS THIS COULD
AFFECT THE INTEGRITY OF THE SURFACE FINISHES.
*THE GEAR BOX MUST BE THOROUGHLY CLEANED WITH FRESH
WATER EVERY SEASON AND SHOULD BE LUBRICATED WITH A
SUITABLE OIL OR RUST REPELLANT TO AVOID UNNECESSARY
DAMAGE.
*IF IN A MARINE/SEASIDE ENVIRONMENT, THE MAINTENANCE
PROCEDURES DESCRIBED ABOVE MUST BE FOLLOWED MORE
FREQUENTLY. PROBLEMS RESULTING FROM FAILURE TO
MAINTAIN THE PRODUCTS ARE NOT COVERED UNDER WARRANTY.
SALIGNA EUCALYPTUS HARDWOOD
*ONCE A YEAR LIGHTLY SAND ALL EUCALUPTUS PARTS AND APPLY
A NEW COAT OF VARNISH. AS WITH ALL HARDWOOD PRODUCTS,
TO MAINTAIN ITS LUSTER, THE WOOD MUST BE MAINTAINED
ANUALLY.
*AVOID USING A SCOURER OR ABRASIVE MATERIALS AS THIS
COULD AFFECT THE INTEGRITY OF THE SURFACE FINISHES.
*IF IN A MARINE/SEASIDE ENVIRONMENT, THE MAINTENANCE
PROCEDURES DESCRIBED ABOVE MUST BE FOLLOWED MORE
FREQUENTLY. PROBLEMS RESULTING FROM FAILURE TO MAINTAIN
THE PRODUCTS ARE NOT COVERED UNDER WARRANTY.
Distributor: Shadescapes Americas TEL: [phone] www.shadescapesamericas.com [email protected] © PROTRADE & WOODLINE cc. 2000

SUNBRELLA CANOPY FABRIC
care and cleaning
One of the best ways to keep Sunbrella®fabrics
looking good and to delay deep or vigorous
cleaning is to properly maintain the fabrics. This
can be accomplished by simply brushing o dirt
before it becomes embedded in the fabrics,
wiping up spills as soon as they occur or spot
cleaning soon after stains occur.
General or light cleaning
• Brush o any loose dirt.
• Prepare a cleaning solution of 2 ounces
(1/4 cup) mild soap per gallon of
lukewarm water (less than 100° F/38°C).
• Use a sponge or a soft bristle brush to clean.
• Allow cleaning solution to soak into fabric.
•Rinse thoroughly to remove all soap residue.
• Allow fabric to air dry.
Spot cleaning
• Apply a light mist of mild soap and
water using a spray bottle.
• Work the solution into the stain by
lightly scrubbing the area with a
sponge or very soft bristle brush.
•Rinse thoroughly to remove all soap residue.
• Blot excess moisture with a clean,
soft towel or sponge.
• Wet-vacuum or blot excess water.
• Air dry. Repeat steps 3 and 4 until
all soap residue is removed.
For removable Sunbrella fabric
Hand washing
• Soak fabric in a solution of 1/4 cup mild
soap per gallon of lukewarm water.
• Use a sponge or a soft bristle
brush as necessary.
• Rinse thoroughly to remove all soap residue.
• Air dry.
Machine washing
Machine wash in cold water (less than
100° F/38°C). Depending on wash load size,
use normal amounts of mild laundry soap and
add 8 ounces (1 cup) of bleach.
Allow fabric to air dry.
Heavy cleaning for
stubborn stains and mildew
Sunbrella fabric does not promote mildew
growth, however, mildew may grow on dirt and
other foreign substances that are not removed
from the fabric. To clean mildew, or other
stubborn stains:
• Prepare a solution of 8 ounces (1 cup)
of bleach and 2 ounces (1/4 cup) of
mild soap per gallon of clean water.
• Spray on entire area and allow to soak
into the fabric for 15 minutes.
• Remove stain with a sponge, clean
towel or very soft bristle brush.
•Rinse thoroughly to remove all soap residue.
• Allow fabric to air dry.
• If stain and/or mildew are severe,
bleach quantities may be increased.
Re-treating the
fabric for ease of cleaning
Sunbrella fabrics have a special finish that
enhances water repellency. The finish is
designed to last for several years of normal use,
but may be refreshed after a thorough cleaning
or extended use.
Glen Raven recommends 303 High Tech Fabric
Guard as the preferred re-treatment product
™
for Sunbrella fabrics.
Applying 303 High Tech
Fabric Guard™
303 should be applied to Sunbrella fabrics
after each thorough cleaning, which typically
removes the original finish and reduces the
fabric’s water repellency.
• Clean Sunbrella fabric, using one
of the cleaning methods.
• Allow Sunbrella to completely air dry.
• Apply 303 Fabric Guard in a well-ventilated
area following instructions on the container.
• Apply 303 in a thin, even coat and
allow fabric to dry completely.
• Apply a second thin, even coating
of 303. Two light coatings are more
eective in restoring fabric water
resistance than a single heavy coating.
• A 15-ounce bottle provides coverage
of up to 50 square feet of fabric.
For more information,
visit www.303products.com.
Professional cleaners
In evaluating the services of a professional firm,
you should inquire about the firm’s experience in
working with Sunbrella fabrics and knowledge of
cleaning and re-treatment requirements.
DO NOT dry clean Sunbrella fabrics.
Helpful hints
Protect the area around your Sunbrella fabric when
using a bleach solution – bleach may discolor non-
Sunbrella fabrics. Always rinse Sunbrella thoroughly
to completely remove bleach.
Sunbrella fabric air-dries very quickly.
Machine drying is not necessary.
If fabric has some wrinkling, use an iron, if
necessary, but only on the synthetic* setting.
As some irons exceed the recommended
100° F/38°C temperature on the synthetic
setting, test a small inconspicuous area before
ironing entire piece.
DO NOT use a steamer or iron set to steam setting.
*Synthetic fabric heat settings normally do not exceed 150°F/66°C.
• This warranty protects the original
purchaser of Sunbrella fabric.
• This warranty protects against Sunbrella
fabric becoming unserviceable due to
color or strength loss from normal usage
and exposure conditions, including
sunlight, mildew, and atmospheric chemicals.
• This warranty covers Sunbrella fabric only.
• This warranty does not cover normal care
and cleaning; damage from misuse, or abuse,
improper installation, or costs associated with
replacement of the fabric, including labor
and installation.
• Glen Raven’s liability is expressly limited to
this warranty. Glen Raven reserves the right
to inspect the fabric submitted for the claim.
• Glen Raven will supply new equivalent fabric
to replace the fabric that becomes
unserviceable.
• Sunbrella is normally a component of an end
product such as an awning, umbrella, or cushion.
Consumers and end-users should contact the
fabricator, dealer, or retailer from whom you
purchased the end product.
•
the original purchase date.
FABRIC WARRANTY
Glen Raven Custom Fabrics, LLC
1831 North Park Avenue, Glen Raven, NC 27217 USA
t. 336.221.2211 / f. 336.586.1169
www.sunbrella.com
SUNBRELLA IS A REGISTERED TRADEMARK OF GLEN RAVEN, INC.
®
6|6
