Woodpecker KSM9-3000/200 User manual

TRANSLATION OF THE ORGINAL VERSION
WOODPECKER
HOKUBEMA Maschinenbau GmbH
Graf-Stauffenberg-Kaserne, Binger Str. 28 | Halle 120
DE 72488 Sigmaringen | Tel. [phone]
E-Mail: [email protected] | Web: https://www.ichbinwoodpecker.de
Operating Manual
Oscillating Edge Sanding Machines
WOODPECKER KSM9-3000/200 and KSM9-3100/150
Machine Types:
KSM9-3000/200 and KSM9-3100/150

BA_WP_KSM9-3000-200-3100-150_EN_22-22.docx
2
Table of Contents
1Introduction ................................................................................................................................................... 6
1.1 Legal Notice ............................................................................................................................................................ 6
1.2 Illustrations ............................................................................................................................................................. 6
2Symbols .......................................................................................................................................................... 6
2.1 General Symbols ..................................................................................................................................................... 6
2.2 Symbols in Safety Instructions ................................................................................................................................ 7
3General........................................................................................................................................................... 8
3.1 Target Group and Previous Experience................................................................................................................... 8
3.2 Requirements for the Operators............................................................................................................................. 8
3.3 Accident Prevention................................................................................................................................................ 8
3.4 General Safety Regulations..................................................................................................................................... 9
3.5 Standard Equipment ............................................................................................................................................... 9
3.6 Available Options.................................................................................................................................................... 9
4Safety............................................................................................................................................................ 10
4.1 Basic Safety Instructions ....................................................................................................................................... 10
4.1.1 Application Area and Intended Use............................................................................................................. 10
4.1.2 Usable Sanding Belts ................................................................................................................................... 10
4.1.3 Modifications and Conversions to the Machine.......................................................................................... 10
4.1.1 Residual Risks .............................................................................................................................................. 11
4.1.2 Observe the Environmental Protection Regulations................................................................................... 12
4.1.3 Organisational Measures ............................................................................................................................ 12
4.1.4 Personnel Selection and Qualification - Basic Duties .................................................................................. 13
4.1.5 Training of Personnel .................................................................................................................................. 13
4.2 Safety Instructions for Specific Phases of Operation ............................................................................................ 14
4.2.1 Normal Operation ....................................................................................................................................... 14
4.2.2 Special work within the Scope of Maintenance Work as well as Troubleshooting in the Workflow .......... 15
4.2.3 Safe Work Practices..................................................................................................................................... 15
4.3 Construction-related Safety Devices..................................................................................................................... 16
4.4 Electrical Safety Devices........................................................................................................................................ 16
4.5 Hazardous Areas ................................................................................................................................................... 17
5Machine Data............................................................................................................................................... 18
5.1 Technical Specifications ........................................................................................................................................ 18
5.2 Correspondence in the Case of Service................................................................................................................. 18
5.3 Emission Levels ..................................................................................................................................................... 19
5.3.1 Noise Information ....................................................................................................................................... 19
5.3.2 Noise Emission Values................................................................................................................................. 19
5.4 Workplace Requirements ..................................................................................................................................... 19
5.5 Dimensions ........................................................................................................................................................... 20
5.5.1 KSM9-3000/200 .......................................................................................................................................... 20
5.5.2 KSM9-3100/150 .......................................................................................................................................... 20
6Installation and Connection ......................................................................................................................... 21

BA_WP_KSM9-3000-200-3100-150_EN_22-22.docx
3
6.1 Check Delivery Conditions .................................................................................................................................... 21
6.2 Transport .............................................................................................................................................................. 21
6.2.1 Unloading with the Forklift Truck................................................................................................................ 21
6.2.2 Setting down with the Forklift Truck........................................................................................................... 21
6.3 Machine Installation ............................................................................................................................................. 22
6.4 Mobile Base (Option)............................................................................................................................................ 22
6.5 Temporary Storage ............................................................................................................................................... 23
6.6 Lashing on a Transport Vehicle ............................................................................................................................. 23
6.7 Connecting the Extraction Unit............................................................................................................................. 24
6.7.1 Automatic Switching of the Extraction (Option) ......................................................................................... 24
6.8 Electrical Connections........................................................................................................................................... 25
6.8.1 Supply Cable and External Fuse Protection................................................................................................. 25
7Machine Overview ....................................................................................................................................... 26
8Machining Possibilities................................................................................................................................. 27
8.1Workpiece Requirements ..................................................................................................................................... 27
8.2 Machining Methods.............................................................................................................................................. 27
8.2.1 Permitted Operations.................................................................................................................................. 27
8.2.2 Improper Operations................................................................................................................................... 27
9Switching the Machine ON and OFF............................................................................................................. 28
9.1 Control Switches ................................................................................................................................................... 28
9.2 Switching ON......................................................................................................................................................... 28
9.3 Switching OFF........................................................................................................................................................ 28
9.4 Emergency Shutdown ........................................................................................................................................... 28
10 Setting up and Adjusting the Machine......................................................................................................... 29
10.1 Mounting, tensioning and replacing the Sanding Belt.......................................................................................... 29
10.2 Height Adjustment of the Table Top..................................................................................................................... 30
10.3 Horizontal Adjustment of the Table Top............................................................................................................... 30
10.4 Adjusting the Inclination of the Sanding Unit ....................................................................................................... 30
10.5 Veneer Sanding Device with Sanding Pad............................................................................................................. 31
10.5.1 Mounting the Veneer Sanding Device......................................................................................................... 31
10.5.2 Disassembly of the Veneer Sanding Device................................................................................................. 31
10.5.3 Calibrating the Veneer Fence (Zeroing)....................................................................................................... 32
10.5.4 Adjusting the Sanding Depth of the Veneer Fences.................................................................................... 32
10.6 Using the Cylindrical Sanding Unit ........................................................................................................................ 33
10.6.1 Preparing the Cylindrical Sanding Unit........................................................................................................ 33
10.6.2 Adjusting the Revolving Turret Head........................................................................................................... 33
10.6.3 Changing the Drum Diameter...................................................................................................................... 34
10.7 Combined Workpiece and Mitre Fence ................................................................................................................ 34
10.7.1 Converting the Fence for high and flat Workpieces.................................................................................... 34
11 Working with the Edge Sanding Machine .................................................................................................... 35
11.1 Machining extra-long Workpieces ........................................................................................................................ 35
11.2 Sanding with the Workpiece Fence....................................................................................................................... 35

BA_WP_KSM9-3000-200-3100-150_EN_22-22.docx
4
11.3 Angle Machining with inclined Sanding Unit......................................................................................................... 36
11.4 Sanding on the Cylindrical Sanding Unit ............................................................................................................... 36
11.5 Sanding Angles and Chamfers on the Sanding Pad............................................................................................... 37
11.5.1 Sanding Angles on the Sanding Pad ............................................................................................................ 37
11.5.2 Sanding Chamfers on the Sanding Pad........................................................................................................ 37
11.5.3 Sanding off Veneer Protrusions................................................................................................................... 37
12 Troubleshooting ........................................................................................................................................... 38
13 Maintenance and Inspection........................................................................................................................ 39
13.1 Cleaning ................................................................................................................................................................ 39
13.2 Lubrication ............................................................................................................................................................ 39
13.3 Checking the Function of the Emergency Stop Button ......................................................................................... 39
13.4 Checking the Safety Labels.................................................................................................................................... 40
13.5 Readjusting the Turntable..................................................................................................................................... 40
13.6 Taking the Machine out of Operation / Storage ................................................................................................... 40
13.7 Average Situations / Emergencies ........................................................................................................................ 40
14 Electrical Circuit Diagram ............................................................................................................................. 41
15 Options and Accessories .............................................................................................................................. 42
15.1 Sanding Belts for KSM9-3000/200 ........................................................................................................................ 42
15.2 Sanding Belts for KSM9-3100/150 ........................................................................................................................ 42
15.3 Further Options..................................................................................................................................................... 42
16 Disassembly and Scrapping.......................................................................................................................... 43
EU - Declaration of Conformity............................................................................................................................. 44

BA_WP_KSM9-3000-200-3100-150_EN_22-22.docx
5
List of Figures
Figure 1: Veneer sanding device with sanding pad .................................................................................................................... 6
Figure 2: Name plate................................................................................................................................................................ 18
Figure 3: Working areas ........................................................................................................................................................... 19
Figure 4: Dimensions - KSM9-3000/200................................................................................................................................... 20
Figure 5: Dimensions - KSM9-3100/150................................................................................................................................... 20
Figure 6: Unload with Forklift truck.......................................................................................................................................... 21
Figure 7: Setting down with forklift truck................................................................................................................................. 21
Figure 8: Mobile base components.......................................................................................................................................... 22
Figure 9: Suction nozzle............................................................................................................................................................ 24
Figure 10: Main switch housing................................................................................................................................................ 25
Figure 11: Direction of rotation of the drive drum (top view).................................................................................................. 25
Figure 12: Machine overview - main components ................................................................................................................... 26
Figure 13: Control switches...................................................................................................................................................... 28
Figure 14: Fence locking springs............................................................................................................................................... 29
Figure 15: Lever receptacle (top view)..................................................................................................................................... 29
Figure 16: Tensioning sanding belt........................................................................................................................................... 29
Figure 17: Mounting, tensioning and replacing of the sanding belt......................................................................................... 29
Figure 18: Adjusting the table top and the sanding unit.......................................................................................................... 30
Figure 19: Scale and clamping lever......................................................................................................................................... 30
Figure 20: Handwheel .............................................................................................................................................................. 30
Figure 21: Aggregate inclined by 45°........................................................................................................................................ 30
Figure 22: Insert sanding pad................................................................................................................................................... 31
Figure 23: Receptable on sanding pad ..................................................................................................................................... 31
Figure 24: Centring pin in machine .......................................................................................................................................... 31
Figure 25: Calibrate veneer fences to zero position................................................................................................................. 32
Figure 26: Direction of rotation of the drive drum................................................................................................................... 32
Figure 27: Sanding cover .......................................................................................................................................................... 33
Figure 28: Side table height...................................................................................................................................................... 33
Figure 29: Side turntable height.............................................................................................................................................. 33
Figure 30: Cylindrical sanding components.............................................................................................................................. 33
Figure 31: Fold table to 45° ...................................................................................................................................................... 34
Figure 32: Change sanding drum.............................................................................................................................................. 34
Figure 33: Turret head engaged............................................................................................................................................... 34
Figure 34: Convert fence for flat workpieces ........................................................................................................................... 34
Figure 35: Remove left cover (B).............................................................................................................................................. 35
Figure 36: Open right cover (C) ................................................................................................................................................ 35
Figure 37: Sanding at right angles ............................................................................................................................................ 35
Figure 38: Sanding mitres......................................................................................................................................................... 35
Figure 39: Sanding an inner radius........................................................................................................................................... 36
Figure 40: Sanding an outer radius........................................................................................................................................... 36
Figure 41: Sanding angles on sanding pad ............................................................................................................................... 37
Figure 42: Sanding chamfers on sanding pad.......................................................................................................................... 37
Figure 43: Sanding off veneer protrusions .............................................................................................................................. 37
Figure 44: Align table top ......................................................................................................................................................... 40
Figure 45: Turntable locking pin............................................................................................................................................... 40
Figure 46: Locking bolt adjusting screw ................................................................................................................................... 40
Figure 47: Electrical circuit diagram ......................................................................................................................................... 41
Revisions:
Revision
Editor
Modification
Date
001
AG
Original manual translated
30.05.2022

BA_WP_KSM9-3000-200-3100-150_EN_22-22.docx
6
1Introduction
The purpose of this document is to acquaint the user with
the edge sanding machine and enable him to use it to the
full extent of its intended capabilities. Additionally it con-
tains important information to operate the machine safely,
properly and economically.
Observance of the manual helps to avoid hazards, reduce re-
pair costs and downtimes and increase the reliability and
service life of the machine.
Furthermore, this operating manual serves to supplement
instructions based on national regulations for accident pre-
vention and environmental protection.
Figure 1: Veneer sanding device with sanding pad
This operating manual must always be available at the place of use of the machine. It must be
read and followed by every person who is assigned to work on the machine, e.g.
•during operation, including set-up, troubleshooting in the work process, removal of pro-
duction waste and maintenance,
•during maintenance (servicing, inspection, repair)
•and/or during transport.)
Apart from the operating manual and the legally binding accident prevention provisions applicable in the country
and place of use, the recognized technical regulations for safe and proper work must also be observed.
1.1 Legal Notice
WOODPECKER is a brand of Hokubema Maschinenbau GmbH. All contents of these operating instructions are
subject to the rights of use and copyright of HOKUBEMA Maschinenbau GmbH. Any reproduction, modification,
further use and publication in other electronic or printed media, as well as their online publication, requires the
prior written consent of HOKUBEMA Maschinenbau GmbH.
1.2 Illustrations
All photos, figures and graphics contained in this document are for illustration and better understanding only
and may differ from the current state of the product. Title photos and general views may also include optional
components and special accessories.
2Symbols
2.1 General Symbols
Symbol
Meaning

Indicates passages within this operating manual that must be particularly observed in order to
prevent malfunctions or damage to the lift table.

Refers to chapters, sections, or figures within this document.

Refers to an external document or a third-party source.

BA_WP_KSM9-3000-200-3100-150_EN_22-22.docx
7
2.2 Symbols in Safety Instructions
Symbol
Safety Instruction
General danger symbol, which requires the highest attention!
Failure to observe may result in damage to the equipment, serious injury or even death.
Warning of possible danger from forklift traffic!
Non-observance may result in life-threatening injuries.
Warning indicates a possible hazard under suspended loads!
Non-observance may result in life-threatening injuries.
Warning indicates a possible fall hazard!
Non-observance of these instructions may result in serious injuries.
Warning indicates a possible cutting hazard!
Risk of personal injury and possibly additional damage to equipment.
Reference to the obligation to wear protective gloves!
Non-observance of these instructions may result in personal injury.
Reference to the obligation to wear hearing protection!
Non-observance of these instructions may result in personal injury.
Reference to the obligation to wear protective goggles!
Non-observance of these instructions may result in personal injury.
Reference to the obligation to wear a respiratory protection mask!
Non-observance of these instructions may cause breathing difficulties and lung damage.
Reference to the obligation to wear safety shoes!
Non-observance of these instructions may result in personal injury.
Possible dangerous crushing hazard in the area of stationary objects!
Risk of personal injury and possibly additional equipment damage.
Reference to a possible crushing hazard!
Non-observance increases the risk of injury to hands and fingers!
This symbol warns of the dangers of electric voltage!
Failure to observe may result in damage to the equipment, serious injury or even death.
Fire hazard! Do not smoke and do not ignite open fire.
Access for unauthorized persons prohibited!
Risk of personal injury and possibly additional equipment damage.
This safety notice indicates a possible dangerous pull-in hazard!
Wearing loose clothing, jewellery as well as long untied hair is prohibited!
Risk of personal injury and possibly additional damage to property.

BA_WP_KSM9-3000-200-3100-150_EN_22-22.docx
8
3General
The edge sanding machines KSM9-3000/200 and KSM9-3100/150 are produced according to the current state of
the art and placed on the market as a complete machine. All legal and normative regulations were observed. The
two models are identical in design and operation, but they differ in the following points:
•Version KSM9-3000/200 with a belt length of 3000 mm and belt width of 200 mm.
•Version KSM9-3100/150 with a belt length of 3100 mm and belt width of 150 mm. In addition, this
model has a revolving turret head with three different contact drums (Ø 60, 100 and 120 mm) for more
flexible working on the cylindrical sanding unit.
3.1 Target Group and Previous Experience
This operating manual is intended for the operating and maintenance personnel of the machine. The operating
personnel is to be determined by the operator and must further meet the following requirements:
•Basic technical knowledge (e.g. apprenticeship as carpenter, machine fitter, etc. and/or practice in operat-
ing woodworking machines)
•Reading and understanding these operating and maintenance instructions
In order to acquire the knowledge required to operate this machine, the operator must ensure the following
measures:
•Product training for every operator (also possible external personnel)
•Regular safety instruction
3.2 Requirements for the Operators
•The edge sanding machine may only be operated by trained personnel who have also read this manual.
•Inspection, maintenance, cleaning and repair may only be performed by technical specialists
with product-specific training and mechanical and/or electrical training.
•Specialists with product-specific training are to be commissioned and held responsible for
planning and checking the work.
•The national protective regulations for employees must be observed .
•The operator is responsible for the safe use of the machine.
•The legal minimum age must be observed.
3.3 Accident Prevention
To avoid accidents, the following rules must be observed for operation:
•Prevent unauthorized persons from gaining access to the machine.
•Keep unauthorized persons away from the danger areas.
•Repeatedly inform present other persons about existing residual risks (see section 4.1.3).
•Conduct and record regular training & instruction for persons who must be in the area of the machine.
•New employees must be trained internally to work on a thickener and this training must be documented.

BA_WP_KSM9-3000-200-3100-150_EN_22-22.docx
9
3.4 General Safety Regulations
In general, the following safety regulations and obligations apply when handling the edge sanding machine:
•The edge sanding machine may only be operated in a technically perfect and clean condition.
•It is prohibited to remove, modify or bypass any protective, safety or monitoring equipment.
•It is forbidden to modify or alter the machine without the written approval of the manufacturer / supplier.
•Faults or damage must be reported to the operator immediately, eliminated without delay and repaired if
necessary.
•For repairs, only original spare parts may be used.
•All protective, safety and monitoring devices must be regularly checked and maintained by the operator.
•Only instructed, trained or qualified persons may work on this machine.
•Maintenance work must be carried out and documented in accordance with the maintenance instruc-
tions.
•After maintenance or repair, the machine may only be started with all protective devices fitted. A respon-
sible person must be defined for this purpose, who checks that the guards have been properly installed.
•For the operation of edge sanding machine, the respective national safety regulations for employees as
well as the national safety and accident prevention regulations apply.
3.5 Standard Equipment
•Veneer sanding device with grooved infeed ruler for sanding overlapped veneers
•Powerful main motor with 4 kW and additional 0.25 kW motor for belt oscillation
•Cylindrical sanding unit with adjustable end table for concave or convex edges
•Revolving turret head
1
with 3 cylindrical sanding drums (ø 60, 100, 120 mm)
•Height adjustable workpiece table (maximum 230 mm)
•Extendable table widening with roller support
•Combined workpiece and mitre fence ± 60°
•Workpiece table with planed surface
•Inclinable sanding unit (maximum 45°)
•Rubber-coated sanding drums
3.6 Available Options
•Switching contact for automatic switching of the extraction system
•Matching sanding belts with different grits
•Mobile base with separate lifting rod
The article numbers can be found in chapter 15 “Options and Accessories”.
1
For constructional reasons, the rotary star turret is only available for model KSM9-3100/150.

BA_WP_KSM9-3000-200-3100-150_EN_22-22.docx
10
4Safety
4.1 Basic Safety Instructions
Woodworking machines can be dangerous if used improperly. Therefore, observe the safety instructions listed
in this chapter and the accident prevention regulations of your employer's liability insurance association!
The manufacturer accepts no liability for damage and malfunctions resulting from failure
to observe these operating instructions.
4.1.1 Application Area and Intended Use
The edge sanding machines are used exclusively for sanding wood and wood-like materials
(e. g.: fibreboard, chipboard, plywood, laminated and non-laminated boards, plastics, etc.).
This machine is not suitable for sanding metal, mineral materials as well as plastics and
waste wood in which nails, screws etc. may be contained.
The machine may only be operated on a level, firm surface with a minimum load-bearing
capacity of 1,000 kg/m².
Any processing of other materials requires prior consultation with the manufacturer and his approval.
Improper use can lead to danger to persons and to a defect or damage to the machine.
The machine is not suitable for operation outdoors or in potentially explosive environments.
•Permissible ambient temperature: +1 to +40° C
•Permissible humidity: max. 90 %
•Operating altitude: max. 1000 m above sea level
Intended use also includes connecting the machine to an adequately dimensioned extraction system and observ-
ing the operating, maintenance and servicing conditions specified in the operating manual. Any other use is con-
sidered improper and is prohibited.
4.1.2 Usable Sanding Belts
The machine is designed for operation with conventional paper sanding belts. To ensure the quality of the sand-
ing belt in the long term during storage and keeping, it should be stored or kept at a temperature of +5 … +25° C
and a humidity of 50 … 60 %.
•KSM9-3000/200 →belt length = 3000 mm | belt width = 200 mm
•KSM9-3100/150 →belt length = 3100 mm | belt width = 150 mm
You will find suitable sanding belts for your machine in chapter 15 “Options and Accessories”.
4.1.3 Modifications and Conversions to the Machine

Unauthorised conversions and modifications to the machine are strictly prohibited for safety
reasons. This will invalidate the CE declaration of conformity! The manufacturer is not liable
for any resulting damage. The risk for this is borne exclusively by the operator/user.

BA_WP_KSM9-3000-200-3100-150_EN_22-22.docx
11
4.1.1 Residual Risks
The machine is built according to the latest state of the art and the recognised safety rules. Nevertheless, the
use of the machine may cause danger to life and limb of the user or third parties or damage to the machine and
other equipment. Due to the construction of the machine, the following residual risks can occur even when used
as intended and despite compliance with all relevant safety regulations:
Reading and applying the operating manual is mandatory for the operating personnel.
Be alert to possible crushing hazards:
a) when transporting the machine by lift truck / forklift truck →between forks & pallet / machine
b) when picking up the machine →between machine / pallet and floor
c) when lowering the machine →between machine and fixed equipment
Be alert to possible crushing hazards when lowering the machine (from the cargo pallet to the
floor) with a lift truck / forklift truck.
Make sure that no objects fall from the lift truck / forklift truck.
Do not leave any objects / tools on the machine.
It is strictly prohibited to ride on the machine during a lifting operation (with the lift truck / fork-
lift truck). There is a danger of falling!
Unauthorised persons are not allowed to enter the installation area of the machine
(responsibility of the operator).
Be aware of possible tripping and slipping hazards on the floor. Prevent possible hazards by
keeping the floor dry and clean and by using anti-slip floor coverings around the machine.
Be aware of the danger from falling objects such as workpieces, tools or similar. Therefore, wear
safety shoes, especially when transporting and setting down the machine.
Pay attention to the existing danger of cutting and abrasion at the exposed parts of the sanding
belt. Never touch or handle the running sanding belt.
Be aware of the danger of snow from chips and splinters and never remove them from the dan-
ger area by hand. Use suitable aids, e.g. hand brushes.
Be aware of a possible danger of being drawn in by moving and rotating machine and tool parts.
This can cause pieces of clothing or hair to be caught. Always wear close-fitting clothing and wear a
hair net if necessary. Generally avoid jewellery, loose clothing and untied long hair.
Danger from electric shock! There are hazards when working on the electrical system.
This work must only be carried out by qualified personnel!
Danger from electric shock! It is strictly forbidden to bypass safety devices (e.g. safety switches).
Electrical equipment must be maintained and cleaned regularly.
Pay attention to the danger of crushing on workpiece guides and moving machine parts.
Make sure that no unauthorised persons are in the area of the machine.
Be aware of the risk of injury from flying tool parts in the event of tool breakage.
Therefore wear protective goggles.
Be aware of the risk of injury from flying workpiece parts and chips, splinters and dust coming
out of the machine. Therefore wear protective goggles.
Be aware of the increased noise emission and wear hearing protection.
Be aware of the increased dust generation. Use the extraction system and wear a dust mask if
necessary.
The emergency stop button switch must always be freely accessible and must not be blocked
with objects. Check the function of the emergency stop button daily (before starting work).
Fire hazard due to wood dust in connection with flying sparks and/or open fire!
Increased ignition hazard with workpieces containing metal inclusions (screws, nails, etc.).

BA_WP_KSM9-3000-200-3100-150_EN_22-22.docx
12
4.1.2 Observe the Environmental Protection Regulations
During all work with the machine, the environmental protection regulations, obligations and laws for waste
avoidance and proper recycling and/or disposal applicable at the place of use must be observed. This applies in
particular to installation, repair and maintenance work involving substances that could pollute the groundwater
(e.g. hydraulic oils and cleaning agents and liquids containing solvents). In any case, prevent them from seeping
into the ground or entering the sewage system.
Store and transport the above-mentioned hazardous substances only in suitable con-
tainers. Avoid leakage of hazardous substances by using suitable collection contain-
ers. Ensure that the above-mentioned substances are disposed of by a qualified dis-
posal company.
4.1.3 Organisational Measures
Always keep this operating manual within easy reach and at the place of use of the machine.
In addition to the operating manual, observe and instruct on generally applicable legal and other binding
regulations for accident prevention and environmental protection.
Supplement the operating manual with further instructions, including supervisory and reporting duties, to
take account of special operational features (e.g. with regard to work organisation, work processes, per-
sonnel employed).
Before starting work on the machine, the person responsible for its operation must have read the operat-
ing instructions, especially the chapter "Safety Instructions". This applies in particular to personnel who
only occasionally work on the machine.
Check that work is carried out in a safety-conscious and hazard-conscious manner and in compliance with
the operating manual.
Operators must not wear open long hair, loose clothing or jewellery (including rings). There is a risk of in-
jury, e.g. by getting caught or drawn in.
Observe the safety instructions and danger warnings on the machine and keep them complete and in legi-
ble condition.
In case of safety-relevant changes to the machine or its operating behaviour, shut down the entire system
immediately and report the fault to the responsible office/person.
Use personal protective equipment as necessary or required by regulations.
Do not make any modifications, additional attachments or conversions to the machine without the manu-
facturer's approval! This will compromise safety and invalidate the manufacturer's warranty and any liabil-
ity claim. The same also applies to the installation and adjustment of safety devices and valves and to
welding work on load-bearing part.
Spare parts must meet the technical requirements specified by the manufacturer. The exclusive use of
original spare parts ensures this. Therefore, only use original spare parts from the manufacturer.
Observe the fire alarm and firefighting possibilities. Make the location and operation of fire extinguishers
(fire class ABC) known. Do not use water!

BA_WP_KSM9-3000-200-3100-150_EN_22-22.docx
13
4.1.4 Personnel Selection and Qualification - Basic Duties
•The machine design and operation is intended for right-handers.
•Work on and with the machine may only be carried out by reliable personnel.
Observe the legal minimum age!
•Only use trained or instructed personnel. Clearly define the responsibilities of the personnel for operating,
setting up, maintaining and repairing!
•Ensure that only authorised personnel work on the machine!
•If personnel to be trained or apprenticed have to work on the machine, this may only be done under the
constant supervision of an experienced resp. qualified person.
•Work on the electrical equipment of the machine may only be carried out by a qualified electrician or by
untrained persons under the direction and supervision of a qualified electrician in accordance with the elec-
trotechnical regulations.
4.1.5 Training of Personnel
All machine operators must be adequately trained in the operation and maintenance of the machine. In partic-
ular, the training must include the following:
•General rules for the use of the machine, proper operation, correct adjustment of the machine and the use
of other accessories.
•Proper handling of workpieces during the machining process. Correct position of the hands to the workpiece
and to the sanding belt during and after machining.
•The personnel must be informed about hazards, risks and appropriate protective measures.
•The personnel must be trained in the area of regular checks of the guards and protective devices.
•The personnel must be trained in the use of the guards and protective devices.

BA_WP_KSM9-3000-200-3100-150_EN_22-22.docx
14
4.2 Safety Instructions for Specific Phases of Operation
The machine must not be used if the sanding belt is defective or damaged.
Defects and damage to the machine are to be reported immediately after detection.
Sufficient lighting (at least 500 lux) around the machine must be ensured!
Any mode of operation that compromises safety is prohibited!
4.2.1 Normal Operation
Guards: Take measures to ensure that the machine can only be operated in a safe and functional condition.
Only operate the machine when all guards and safety-related devices such as sanding belt guards, emer-
gency stop system, sound insulation, extraction system and workpiece fence are present and functional.
Adjustments: Adjustment and set-up work should only be carried out by instructed personnel who are
familiar with the operation of the machine.
Workpiece: Inspect the workpiece for foreign inclusions (especially metal, screws, nails, etc.) as well as
knots, twists and other irregularities before machining.
Since the machining force of the machine acts in the direction of the belt movement, it is essential to pre-
vent the risk of workpiece kickback. Therefore, use the workpiece resp. mitre fence whenever possible
(especially with small workpieces).
When sanding, hold the workpiece firmly with both hands and press it against the fence. Only then feed
the workpiece to the sanding belt. Only process workpieces that can be held and fed securely with both
hands.
Large workpieces: Very large, long and wide workpieces that protrude beyond the table top must be addi-
tionally supported (e.g. table extension, table widening, support rollers, lift table, etc.).
Small workpieces: For small, short and narrow workpieces, always work with the workpiece fence and, if
necessary, with additional feeding aids. Sand small workpieces on the right side in the feed area of the
driven sanding drum and secure them with the fence. Do not machine workpieces < 100 х 30 х 15 mm
without a feeding aid!
Machine condition: Check the machine for externally visible damage and defects at least once per shift!
Any changes that have occurred (including those in the operating behaviour) must be reported immedi-
ately to the responsible office or person! If necessary, stop and secure the machine immediately!
Extraction: The machine must be connected to an effective extraction system. This requires an extraction
rate of at least 1800 m3/h at a speed of 25 ... 30 m/s.
Work area: An obstacle-free work area around the machine is essential for safe operation. The floor
should be level, well maintained and free from debris such as chips and cut-off workpieces.
Sanding area during operation: Always cover the unused areas of the sanding belt with the existing sand-
ing belt guards.
Sanding of angles, chamfers and veneer edges: Use the veneer sanding device for these operations. This
consists of an insertable sanding pad and two foldable veneer fences.
Lighting: The workplace must be sufficiently bright with general or local lighting.
Cleaning: After the end of the work shift, the machine must always be cleaned to remove dust and chips.
Cleaning with water is not permitted either when the machine is switched on or off.
Work interruptions: Switch off the machine even during short interruptions! Never leave the machine
running unattended!
At the end of work: Before leaving the machine, switch off the main switch and release the tension on the
sanding belt. Never leave the machine unattended in an unsecured state.

BA_WP_KSM9-3000-200-3100-150_EN_22-22.docx
15
4.2.2 Special work within the Scope of Maintenance Work as well as Troubleshooting in
the Workflow
Observe maintenance and inspection activities prescribed in chapter 13!
These activities, as well as all other repair work, may only be carried out by qualified personnel!
For all work concerning operation, production adjustment, conversion or setting of the machine and its
safety-related equipment as well as maintenance and repair, observe switch-on and switch-off procedures
according to the operating manual and instructions for maintenance work!
Secure the machine against unexpected restarting during maintenance and repair work.
➔Lock the main switch with a padlock!
Always tighten screw connections that have been loosened during maintenance and repair work!
If it is necessary to dismantle safety equipment during set-up, maintenance and repair, the safety equip-
ment must be reassembled and checked immediately after completion of the maintenance and repair
work!
Ensure safe and environmentally friendly disposal of operating and auxiliary materials (e.g. oils) and re-
placement parts (e.g. electronic components). See chapter 16 “Disassembly and Scraping”.
4.2.3 Safe Work Practices
Wear personal protective equipment (safety goggles, safety shoes, hearing protection, dust mask).
Always work with all protective devices! These must be in the right places and in perfect working order.
Defective guards must be replaced immediately.
Do not start sanding until the sanding belt drive has reached full speed.
Before starting work, check that the running direction and oscillation of the sanding belt are set correctly.
Prevent workpieces (especially small ones) from being flung away in the running direction. Whenever pos-
sible stop them against the workpiece fence resp. mitre fence - against the running direction of the sand-
ing belt - and/or secure them with additional stop aids.
Only use approved sanding belts suitable for operation on an edge sanding machine.
Before installing a sanding belt, make sure that the sanding drum coatings are clean and free of dust.
Only use intact sanding belts! Replace defective or damaged sanding belts immediately.
Never clean the sanding belt when it is installed. Remove it before cleaning!
Damaged or defective machine parts and/or accessories must be replaced immediately.
Always position the worktable as close as possible to the sanding belt.

BA_WP_KSM9-3000-200-3100-150_EN_22-22.docx
16
4.3 Construction-related Safety Devices
The machine construction already includes the following safety precautions:
•Guards on the sanding drums: They prevent contact with the rotating sanding belt and at the same time
serve as suction end pieces for the associated extraction unit.
•Extraction system: Collects the dust produced during operation and is connected to the suction nozzles of
the left and right sanding drum guards.
•Rear sanding belt cover: Prevents contact of the rotating sanding belt from the rear of the machine.
•Veneer fences left and right: They serve to support and guide the workpiece when sanding edges and sur-
faces. The infeed fence (right) is grooved so that veneer protrusions can be sanded flat.
•Workpiece and mitre fence: Protects the workpiece from being knocked back by placing it against the sand-
ing belt and ensures that the workpiece is safely fed to the sanding belt.
•Tilting sanding unit by 45°: Enables safe and direct sanding of angles on the table top without the need for
additional auxiliary devices and workpiece supports.
•Dynamic balancing of the sanding belt drum: Reduces vibrations during work and ensures a good surface
finish during processing.
•Sanding belt oscillation: Ensures optimum and efficient use of the sanding belt.
4.4 Electrical Safety Devices
•Emergency stop push-button: In case of danger, the centrally accessible emergency stop button immediately
puts the machine out of operation.
•Lockable main switch: The main switch can be locked with a padlock to protect the machine (e.g. during
adjustment, repair and maintenance work) against unintentional or unauthorised restarting of the machine.
•Motor standstill in less than 10 seconds: When the grinding drive is switched off via the off switch, main
switch or when the emergency stop button is pressed, a standstill of the sanding belt drive in a period of less
than 10 seconds is guaranteed.
•Undervoltage protection: In the event of a voltage interruption, the machine is brought to a standstill, where
it remains even when the voltage is restored. To put the machine back into operation, it must be switched
on again.
•Protection against electric shock: The housing of the machine and the drives are protected against electric
shock with a neutral line.
•Dust and water protection: The control cabinet is protected against dust and splash water with protection
class IP54. The two motors (main drive and oscillation) are protected against dust and water jets from any
angle with IP55 protection.
•Short-circuit protection: The machine has an overload protection for the drive unit (thermal off switch).

BA_WP_KSM9-3000-200-3100-150_EN_22-22.docx
17
4.5 Hazardous Areas
Hazard
Area/Action
Risk
Avoidance
Cutting & Abra-
sion Hazard
On all non-covered
areas of the sanding
belt
Minor to severe injuries
such as cuts and abra-
sions on hands and fin-
gers.
•Use all sanding covers available for
the operation and keep hands out
of uncovered areas.
•Do not touch or handle the running
sanding belt.
Danger of
being drawn in
On the right-hand
drive drum in the
feed area of the
sanding belt.
When using the in-
sertable sanding pad
between the sanding
pad and the right-
hand infeed ruler.
Increased risk of injury or
even death by pulling in
hands, fingers, clothing,
watches, jewellery and
long hair.
•Use all sanding covers available for
the operation and keep hands out
of uncovered areas.
•Use the workpiece resp. mitre fence
whenever possible.
•Position the worktable as close as
possible to the sanding belt.
•Keep hands out of the dangerous
catchment area.
•Never wear gloves when the sand-
ing belt is running.
•Watches, jewellery, necklaces and
long hair are prohibited!
•Wear tight-fitting clothes and a hair
net if necessary.
Crushing Hazard
On all moving parts,
guides, fences and
additionally used
clamping and ten-
sioning devices.
Mild to severe injuries,
bruises and/or broken
bones on hands and fin-
gers.
•Keep hands out of danger areas
(e.g. between workpiece and work-
piece fence).
Risk of
Kickback
On the running
sanding belt.
Increased risk of injury or
even death due to work-
pieces and/or workpiece
parts knocking away or
kicking back.
•Use the workpiece resp. mitre fence
whenever possible.
•Sanding small workpieces on the
right side at the driven drum.
•Use all sanding covers available for
the operation.
•Only machine parts that can be held
and guided safely with both hands.
•Wear safety goggles or face protec-
tion.
Tipping Hazard
With large, long, wide,
heavy workpieces and
when the workpiece
support surface is too
small.
Mild to severe injuries
such as bruises and/or
broken bones all over
the body.
•Provide additional support for large,
long, wide and heavy workpieces
(e.g. table extension, support roll-
ers, lift table, etc.).
Ejection Hazard
On the left-hand
sanding drum in the
exit area of the run-
ning sanding belt.
Increased risk of injury,
especially face and eye
injuries due to ejected
parts.
•Use all sanding covers available for
the operation .
•Do not look into the exit area of the
left sanding drum.
•Wear safety goggles or face protec-
tion.
Electric Shock
Hazard
On the electrical sys-
tem and all energised
components.
Electric shocks with in-
creased risk of injury or
even death.
•Avoid wetness / humidity
•Have defective parts / cables / con-
nections repaired immediately (only
by a qualified electrician!)
•Do not touch energised parts.
•During maintenance and repair
work, switch off the main switch
and lock it.

BA_WP_KSM9-3000-200-3100-150_EN_22-22.docx
18
5Machine Data
5.1 Technical Specifications
Table size
L x B = 960 x 350 mm
Table height
adjustable until 220 mm
Sanding belt length
KSM9-3000/200: 3000 mm
KSM9-3100/150: 3100 mm
Sanding belt width
KSM9-3000/200: 200 mm
KSM9-3100/150: 150 mm
Sanding belt
back wall
KSM9-3000/200: 1050 x 240 mm
KSM9-3100/150: 1050 x 200 mm
Sanding drums
with rubber coating
Belt speed
20 m/s
Rotational speed
2840 rpm
Oscillation stroke
20 mm
Sanding unit
inclinable in the range 90 ... 45°
Workpiece fence range
± 60° angle adjustable
Main motor
4.0 kW / 5.5 HP (400 V)
Protection class
circuits IP54 / motors IP55
Oscillation motor
0.25 kW
Revolving turret head2
Ø 60, 100 and 120 mm
Suction nozzle
Ø 140 mm
Dimensions
refer to section 5.5
Space requirement
refer to section 5.4
Weight
approx. 400 kg
HOKUBEMA Maschinenbau GmbH
Graf-Stauffenberg-Kaserne
Binger Str. 28 | Halle 120
DE-72488 Sigmaringen (Germany)
Tel.: [phone] / 755-0
Fax: [phone] / 755-2 22
Figure 2: Name plate
5.2 Correspondence in the Case of Service
Please, in case of technical problems, contact your dealer or the manufacturer's service department. In corre-
spondence or during a telephone call regarding the purchased machine, you should have the following data at
hand:
•Manufacturer number of the machine
•Voltage and frequency
•Date of manufacture
•Detailed description of the fault
•Detailed description of the type of machining carried out
•General operating time of the machine in working hours
•In case of questions regarding the electrical system, the information on the machine's type plate is
also required.
2
For constructional reasons, the rotary star turret is only available for model KSM9-3100/150.

BA_WP_KSM9-3000-200-3100-150_EN_22-22.docx
19
5.3 Emission Levels
5.3.1 Noise Information
The values given are emission levels and therefore do not necessarily represent safe workplace values. Alt-
hough there is a correlation between emission and immission levels, it cannot be reliably deduced whether ad-
ditional precautionary measures are necessary or not.
Factors that may affect the current immission level at the workplace include the duration of exposure, the na-
ture of the workspace, other noise sources, etc., e.g. the number of machines and other activities in the vicin-
ity. The permissible workplace values can also vary from country to country.
However, this information should enable the user to make a better assessment of hazard and risk.
5.3.2 Noise Emission Values
Noise Emission Explanation
Weighted level: Noise pressure at idle state
LpfA = 83 dB
Uncertainty at the К = 2 dB
Weighted level of noise power at the workplace
LwA = 101 dB
Uncertainty - К= 2 dB at error limit interval 95 %
The workplace-related noise emission values of the machine exceed 85 dB(A)!
Therefore, suitable hearing protection must be provided to the personnel!
5.4 Workplace Requirements
The effective space requirement usually depends on the dimensions of the machine and the dimensions of the
workpieces to be processed. In general, provide sufficient space around the machine and also calculate the re-
quired workplace for the operating, maintenance and auxiliary personnel as well as for the infeed and outfeed
of the workpieces.
•Choose a suitable place for the ma-
chine and consider the working areas
shown in the figure for sanding straight
surfaces and edges as well as curves.
•The chosen location must guarantee a
suitable connection to the mains sup-
ply and to the extraction system.
•Sufficient lighting (min. 500 lux) must
be ensured. The lighting must not daz-
zle and a stroboscopic effect must be
avoided.
•Make sure that the floor can support
the load of the machine.
Figure 3: Working areas
•The machine must be levelled with a machine spirit level.
•A clearance of at least 0.8 m must be ensured around the machine.
•Sufficient space must be ensured for the feeding of large and long workpieces.
A
A= Working area for sanding straight surfaces and edges
B= Workstation for sanding curves
B

BA_WP_KSM9-3000-200-3100-150_EN_22-22.docx
20
5.5 Dimensions
5.5.1 KSM9-3000/200
Figure 4: Dimensions - KSM9-3000/200
5.5.2 KSM9-3100/150
Figure 5: Dimensions - KSM9-3100/150
•All dimensions are given in millimetres
•The dimensions given are rounded approximate dimensions
•We reserve the right to make dimensional and design changes
1900
900
1300
2000
900
1250
