Woodson Starline Snack Master 25 Series User manual

A guide on the use, care and maintenance
of your quality Woodson Starline product
Models:
W.CVS.M.25, W.CVS.M.25L, W.CVS.L.30, W.CVS.L.30L
Specication, Installation
and Operation Manual
Snack Master Series 25 & 30

Page 1
www.stoddart.com.au
Index
Introduction
Your New Woodson Starline Product 3
Optional 3
Product Overview 3
Features 3
Installation
Setting Up 8
Handling
Unpacking
Positioning
Electrical Connection 7
Information
Specication
Attention 4
General Precautions 4
Technical Specifications 7
General Drawing 5-6
Service
W.CVS.M.25
Hot Surfaces
W.CVS.L.30
Operation
General Recommendations 9
Operating Instructions 10
First Time Operation
Initial adjustments
Cleaning 11-12
Corrosion Protection
General Information
Surface Finish
Cleaning Schedule
Materials Required
Cleaning Procedure - Conveyor and Crumb Tray
Cleaning Procedure - External Surfaces
Troubleshooting 13

Page 2
www.stoddart.com.au
Index
Notes
Notes 17
Warranty
Commercial Warranty 14
Consumer Warranty 14
Warranty Clarification 14
Warranty Claim Procedure 15
Timing of Warranty Services 15
General Maintenance and Repairs 15
Warranty Request Form 16
Contact
Stoddart Service Department 18

Introduction
Page 3
www.stoddart.com.au
Y
our New Woodson Starline Product:
Woodson Starline equipment has been designed to give maximum and efficient performance and while integrating a user friendly
operating system for all staff and end users.
By using, caring and maintaining your product according to these instructions, your Woodson Starline product should give you many
years of reliable service.
Optional:
Woodson Starline highly recommends the use of steel trays when required.
Product Overview:
Configuration may vary according to model.
Thank you for purchasing a Woodson Starline product.
A
t Stoddart, we take pride in manufacturing the Woodson Starline product line and are committed to standing behind our customers and
products 100%. Should you ever need assistance, please contact the Stoddart Service Department at 1300 307 289.
Conveyor
Exit Rack
Control Panel
Height Adjustment
Rating Plate

Specication
Page 4
www.stoddart.com.au
A
ttention
General Precautions
• This product is not designed for household or domestic use and should not be used for this purpose.
• Only use this appliance with voltage specified on the rating label.
• Do NOT remove any cover panels that may be on the appliance.
• This unit is NOT waterproof. Do NOT use jet sprays or hoses to the exterior of the appliance.
Service
• Qualified personnel, specifically trained in the following instructions, can perform service of the appliance.
• Stoddart, one of our agents, or a similarly qualified person(s) should carry out any and all repairs, maintenance and services.
H
ot Surfaces
• This unit can get very hot. Ensure everyone is aware that the appliance is operating and take care to avoid contact with hot
surfaces.
Disclaimer:
The manufacturer and distributor cannot be held responsible or liable for any injuries or damages of any kind occurred
to persons, appliances or others, due to abuse and misuse of this appliance in regards to installation, un-installation,
operation, servicing or maintenance, or lack of conformity with the instructions indicated in this documentation.
All appliances made by the manufacturer are delivered assembled, where possible, and ready to install. Any installation,
un-installation, servicing, maintenance and access or removal of any parts, panels or safety barriers that is not
permitted, does not comply in accordance to this documentation, or not performed by a TRAINED AND AUTHORISED
SPECIALIST will result in the IMMEDIATE LOSS OF THE WARRANTY.
The manufacturer cannot be held responsible or liable for any unauthorized modifications or repairs. All modifications
or repairs must be approved by the manufacturer in writing before initiating. All modifications or repairs performed to
this appliance must be performed at all times by a TRAINED AND AUTHORISED SPECIALIST.
Carefully read this instruction booklet, as it contains important advice for safe installation, operation and maintenance. Keep this booklet
on hand in a safe place for future reference by other operators or service technicians.
