WORKSWELL SMARTIS-FS User manual

Quick Start Guide

Phone numbers
E
-
mail and Web
ID
Headquarters
+420
725
877 063
[email protected]
Reg. No.
:
29048575
Libocka 653/51b
+420
725
955
464
www.workswell.eu
VAT No.
CZ29048575
Prague, Czech Republic
Revision 1.0 EN, 17.1.2017
All pictures are only for illustration
.
Real values may vary
.
What else do you need?
User Manual
Confirm that the package contains the items listed below and can be
extended by additional accessories such as temperature filter, lens etc.
Before you start using your Workswell SMARTIS-FS infrared camera, make
sure that you have all the equipment listed below to hand.
User Manual is available in electronic form on the website:
https://www.workswell-thermal-camera.com/thermal-imaging-camera-
smartis-fire-safety/
Package Content

SMARTIS infrared camera
–
640 or 336px camera head
One specific lens mounted on the camera
Standard Calibration certificate
Quick start guide
Download Card

Pigtail p
ower
supply cable
(
100
to
240
V
DC,
0,5
A)
Ethernet UTP cable
M12-8P cables for connect Digital outputs, Analog outputs
or Digital triggers
- these cables are available on the link below:
https://www.sick.com/cz/en/dol-1208-g02mc/p/p321150

Phone numbers
E
-
mail and Web
ID
Headquarters
+420
725
877 063
[email protected]
Reg. No.
:
29048575
Libocka 653/51b
+420
725
955
464
www.workswell.eu
VAT No.
CZ29048575
Prague, Czech Republic
Workswell SMARTIS
Revision 1.0 EN, 17.1.2017
All pictures are only for illustration.
Real values may vary
.
1) First unscrew the 3 screws of the rear part of HTG housing
2) The cable glands that we will need to use must be enabled and the
blind flangs can be removed.
SMARTIS
inputs and outputs
Connect
the SMARTIS FS camera
Cable gland
RJ45

Phone numbers
E
-
mail and Web
ID
Headquarters
+420
725
877 063
[email protected]
Reg. No.
:
29048575
Libocka 653/51b
+420
725
955
464
www.workswell.eu
VAT No.
CZ29048575
Prague, Czech Republic
Revision 1.0 EN, 17.1.2017
All pictures are only for illustration
.
Real values may vary
.
3) Power, ethernet, and other cables that we use must be passed
through the cable glands.
4) The pigtail power cable connect to the clip on PCB board according
the picture below.
5) The Ethernet UTP cable connect to the RJ45 canector on the camera
6) The M12-8pin cables connect as needed
A
Detail
A

Phone numbers
E
-
mail and Web
ID
Headquarters
+420
725
877 063
[email protected]
Reg. No.
:
29048575
Libocka 653/51b
+420
725
955
464
www.workswell.eu
VAT No.
CZ29048575
Prague, Czech Republic
Workswell SMARTIS
Revision 1.0 EN, 17.1.2017
All pictures are only for illustration.
Real values may vary
.
Focusing the infrared
camera
First connection
1. Connect SMARTIS to Power Supply.
2. Connect your SMARTIS to your PC Ethernet port.
3. Set your computer IP address as static:
How to set up a static IP address on your PC is available at the following
link:
https://www.howtogeek.com/howto/19249/how-to-assign-a-static-ip-
address-in-xp-vista-or-windows-7/
a. IP address: 10.0.0.1
b. Netmask: 255.255.255.0
4. Connect to SMARTIS with web browser at http://10.0.0.225/
5. Log in as Admin, password 1234
Unplug your SMARTIS from power supply.
Short distance Long distance

Phone numbers
E
-
mail and Web
ID
Headquarters
+420
725
877 063
[email protected]
Reg. No.
:
29048575
Libocka 653/51b
+420
725
955
464
www.workswell.eu
VAT No.
CZ29048575
Prague, Czech Republic
Revision 1.0 EN, 17.1.2017
All pictures are only for illustration
.
Real values may vary
.
