WH-110/ WH-H230/ WH-H260 Network Camera
Hardware User Manual

Notices
This user manual is intended for administrator and user of IP network cameras.
Operational instructions & network configuration are elaborated. Prior
knowledge about network setup and configuration will be helpful.
IMPORTANT
zCheck PC specification requirements.
zCheck OS platform requirements.
zInstall NVR2 video surveillance software before you start working with
IP network camera.
zRead special notes and important configuration information.
WH-110/ WH-H230/ WH-H260 network camera User Manual

TABLE OF CONTENTS
1. INTRODUCTION
1.1 PRODUCT OVERVIEW
WH-110/ WH-H230/ WH-H260 fixed IP network camera is a professional
IP surveillance application. With embedded web viewer, streaming video/audio
over network can be accessed like browsing a website. It is also capable of
encoding MPEG4 stream, the only digital surveillance product in the market with
proprietary design for "Ease-of-use", "Reliability", and "Manageability".
1.2 PACKAGE CONTENTS
IP Camera SoftwareCD
Power connector PowerAdaptor
WH-110/ WH-H230/ WH-H260 network camera User Manual

1.3PHYSICAL DESCRIPTION
Back Panel
1. Power Socket
DC12V 1A
2. Video Out
3. Reset Button
4. LAN/WAN RJ45 Port
10/100 Mbps auto sensing, fast Ethernet port for secure
Local Network or WAN for FTTH or xDSL connectivity
5. DI/DO
DO: Logic Level 0:0~0.5V; Logic Level 1: 2.8~3.3V
4
1
2
3
5
WH-110/ WH-H230/ WH-H260 network camera User Manual

Side Panel
1. Auto Iris
2. V.D D.D
Video Driver or Digital Driver
3. VR
Variable Resistant adjustment
4. DIP Switches for CCD Functions
Auto Electronic Shutter Speed Mode
AES On 1/50 (60) sec. ~ 1/100,000 sec;
AES Off: 1/50 (60) sec.
Back Light Compensation
ON/OFF (Switchable)
Flickless
ON/OFF (Switchable)
WH-110/ WH-H230/ WH-H260 network camera User Manual

2 Hardware Installation
Make sure network environment
Default IP of IP network camera is 192.168.1.2 Please make sure IP
network camera and your PC are in the same network segment before
running the installation.
Please set the number
from 2 to 254.
e.g. 192.168.1.115
WH-110/ WH-H230/ WH-H260 network camera User Manual

Connect necessary cables
The Ethernet cable and power cable are necessary for previewing function.
Make sure all cables are correctly and firmly connected.
1. Connect an analog monitor to IP network camera Video Out (BNC connector)
2. Connect the power adaptor to IP network camera
3. Connect IP Camera LAN/WAN port to an Ethernet hub (RJ45 connectors)
4. Connect a PC to the Ethernet hub (RJ45 connectors)
WH-110/ WH-H230/ WH-H260 network camera User Manual

3. SOFTWARE CD
Software CD in the package contains the following:
I. NVR2 IP video surveillance software
II. NVR video surveillance software User Manual
III. Firmware binary file
IV. IP Network Camera Manual
V. IP Setting
4. BEFORE YOU INSTALL SOFTWARE
zPC running Microsoft Windows 2000 or above is only capable of running
NVR2 video surveillance software.
zPLEASE go through NVR user’s manual before installation to check further
PC requirements in order to ensure smooth software operation.
WH-110/ WH-H230/ WH-H260 network camera User Manual

5. LANGUAGE SUPPORT
Chinese Traditional、English、French Standard、German、Italian、
Portuguese、Turkish
NOTE
NVR setup will auto-run when inserting CD. Pay attention to dialog box
questions before you press OK button.
World Helmsman Technology Co., Ltd.
3F-5, No.81, Sec.1, Hsin Tai Wu Rd., Hsichih,
Taipei Hsien 22101, TAIWAN
Tel: [phone] Fax:[phone]
[e-mail] www.wh-tech.com
WH-110/ WH-H230/ WH-H260 network camera User Manual
