Worx Nitro WX177 Series Installation manual

WX177 WX177.X
20V Cordless Brushless
Switchdriver 2.0
SAFETY AND OPERATING MANUAL
ORIGINAL INSTRUCTIONS


3
WX177 WX177.X
20V Cordless Brushless
Switchdriver 2.0
TABLE OF CONTENT
1. SAFETY INSTRUCTIONS
2. COMPONENT LIST
3. TECHNICAL DATA
4. OPERATING INSTRUCTIONS
5. TROUBLESHOOTING
6. MAINTENANCE
7. ENVIRONMENTAL PROTECTION
8. DECLARATION OF CONFORMITY
1. PRODUCT SAFETY
GENERAL POWER TOOL
SAFETY WARNINGS
WARNING Read all safety warnings,
MRWXVYGXMSRWMPPYWXVEXMSRWERHWTIGMƼGEXMSRW
provided with this power tool.
Failure to follow all
instructions listed below may result in electric shock,
ƼVIERHSVWIVMSYWMRNYV]
Save all warnings and instructions for future
reference.
The term “power tool” in the warnings refers to your
mains-operated (corded) power tool or battery-
operated (cordless) power tool.
1. WORK AREA SAFETY
a) Keep work area clean and well lit.
Cluttered or
dark areas invite accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of
ƽEQQEFPIPMUYMHWKEWIWSVHYWX
Power tools
create sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while
operating a power tool.
Distractions can cause
you to lose control.
2. ELECTRICAL SAFETY
a) Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power
tools.
9RQSHMƼIHTPYKWERHQEXGLMRKSYXPIXW[MPP
reduce risk of electric shock.
b) Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators.
There is an increased risk of electric
shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet
conditions.
Water entering a power tool will
increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges
or moving parts.
Damaged or entangled cords
increase the risk of electric shock
.
e) When operating a power tool outdoors, use an
extension cord suitable for outdoor use.
Use of a
cord suitable for outdoor use reduces the risk of
electric shock.
f) If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply.
Use of an RCD reduces the risk
of electric shock.
3. PERSONAL SAFETY
a) Stay alert, watch what you are doing and use
common sense when operating a power tool. Do
not use a power tool while you are tired or under
XLIMRƽYIRGISJHVYKWEPGSLSPSVQIHMGEXMSR
A moment of inattention while operating power
XSSPWQE]VIWYPXMRWIVMSYWTIVWSREPMRNYV]
F 9WITIVWSREPTVSXIGXMZIIUYMTQIRX%P[E]W
wear eye protection.
Protective equipment
such as dust mask, non-skid safety shoes, hard
hat, or hearing protection used for appropriate
GSRHMXMSRW[MPPVIHYGITIVWSREPMRNYVMIW
c) Prevent unintentional starting. Ensure the
switch is in the off-position before connecting to
power source and/or battery pack, picking up or
carrying the tool.
Carrying power tools with your
ƼRKIVSRXLIW[MXGLSVIRIVKMWMRKTS[IVXSSPWXLEX
have the switch on invites accidents.
d) Remove any adjusting key or wrench before
turning the power tool on.
A wrench or a key left
attached to a rotating part of the power tool may
VIWYPXMRTIVWSREPMRNYV]
e) Do not overreach. Keep proper footing and
balance at all times.
This enables better control
of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves
away from moving parts.
0SSWIGPSXLIWNI[IPPIV]
or long hair can be caught in moving parts.
g) If devices are provided for the connection of dust
extraction and collection facilities, ensure these
are connected and properly used.
Use of dust
collection can reduce dust-related hazards.
L(SRSXPIXJEQMPMEVMX]KEMRIHJVSQJVIUYIRXYWI
of tools allow you to become complacent and
ignore tool safety principles.
A careless action
GERGEYWIWIZIVIMRNYV][MXLMREJVEGXMSRSJE
second.
4. POWER TOOL USE AND CARE
a) Do not force the power tool. Use the correct
power tool for your application.
The correct
TS[IVXSSP[MPPHSXLINSFFIXXIVERHWEJIVEXXLI
rate for which it was designed.
b) Do not use the power tool if the switch does not
turn it on and off.
Any power tool that cannot be
controlled with the switch is dangerous and must
be repaired.
c) Disconnect the plug from the power source and/
or the battery pack from the power tool before

4
WX177 WX177.X
20V Cordless Brushless
Switchdriver 2.0
making any adjustments, changing accessories,
or storing power tools.
Such preventive safety
measures reduce the risk of starting the power
tool accidentally.
d) Store idle power tools out of the reach of
children and do not allow persons unfamiliar with
the power tool or these instructions to operate
the power tool.
Power tools are dangerous in the
hands of untrained users.
e) Maintain power tools. Check for misalignment or
binding of moving parts, breakage of parts and
any other condition that may affect the power
tool’s operation. If damaged, have the power tool
repaired before use.
Many accidents are caused
by poorly maintained power tools.
f) Keep cutting tools sharp and clean.
Properly
maintained cutting tools with sharp cutting edges
are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc.
in accordance with these instructions, taking
into account the working conditions and the
work to be performed.
Use of the power tool for
operations different from those intended could
result in a hazardous situation.
h) Keep handles and grasping surfaces dry, clean
and free from oil and grease.
Slippery handles
and grasping surfaces do not allow for safe
handling and control of the tool in unexpected
situations.
5) Battery tool use and care
E6IGLEVKISRP][MXLXLIGLEVKIVWTIGMƼIHF]XLI
manufacturer.
A charger that is suitable for one
X]TISJFEXXIV]TEGOQE]GVIEXIEVMWOSJƼVI[LIR
used with another battery pack.
F9WITS[IVXSSPWSRP][MXLWTIGMƼGEPP]HIWMKREXIH
battery packs.
Use of any other battery packs
QE]GVIEXIEVMWOSJMRNYV]ERHƼVI
c) When battery pack is not in use, keep it away
from other metal objects, like paper clips, coins,
keys, nails, screws or other small metal objects,
that can make a connection from one terminal to
another.
Shorting the battery terminals together
QE]GEYWIFYVRWSVEƼVI
H9RHIVEFYWMZIGSRHMXMSRWPMUYMHQE]FIINIGXIH
from the battery; avoid contact. If contact
EGGMHIRXEPP]SGGYVWƽYWL[MXL[EXIV-JPMUYMH
contacts eyes, additionally seek medical help.
0MUYMHINIGXIHJVSQXLIFEXXIV]QE]GEYWI
irritation or burns.
e) Do not use a battery pack or tool that is damaged
SVQSHMƼIH
(EQEKIHSVQSHMƼIHFEXXIVMIWQE]
I\LMFMXYRTVIHMGXEFPIFILEZMSYVVIWYPXMRKMRƼVI
I\TPSWMSRSVVMWOSJMRNYV]
J(SRSXI\TSWIEFEXXIV]TEGOSVXSSPXSƼVI
or excessive temperature.
)\TSWYVIXSƼVISV
temperature above 130 °C may cause explosion.
g) Follow all charging instructions and do not
charge the battery pack or tool outside the
XIQTIVEXYVIVERKIWTIGMƼIHMRXLIMRWXVYGXMSRW
Charging improperly or at temperatures outside
XLIWTIGMƼIHVERKIQE]HEQEKIXLIFEXXIV]ERH
MRGVIEWIXLIVMWOSJƼVI
.
6) Service
E,EZI]SYVTS[IVXSSPWIVZMGIHF]EUYEPMƼIH
repair person using only identical replacement
parts.
This will ensure that the safety of the
power tool is maintained.
b) Never service battery packs.
Service of
battery packs should only be performed by the
manufacturer or authorized service providers.
DRILL SAFETY WARNINGS
1) Safety instructions for all operations
a) Hold the power tool by insulated gripping
surfaces, when performing an operation where
the cutting accessory or fasteners may contact
hidden wiring.
Cutting accessory or fasteners
contacting a "live" wire may make exposed metal
parts of the power tool "live" and could give the
operator an electric shock.
2) Safety instructions when using long drill bits
a) Never operate at higher speed than the
maximum speed rating of the drill bit. At higher
speeds, the bit is likely to bend if allowed to
rotate freely without contacting the workpiece,
resulting in personal injury.
b) Always start drilling at low speed and with the
bit tip in contact with the workpiece. At higher
speeds, the bit is likely to bend if allowed to
rotate freely without contacting the workpiece,
resulting in personal injury.
c) Apply pressure only in direct line with the bit
and do not apply excessive pressure. Bits
can bend causing breakage or loss of control,
resulting in personal injury.
SAFETY WARNINGS FOR
BATTERY PACK
a) Do not dismantle, open or shred cells or battery
pack.
b) Do not short-circuit a battery pack. Do not store
battery packs haphazardly in a box or drawer
where they may short-circuit each other or be
short-circuited by conductive materials.
When
battery pack is not in use, keep it away from
SXLIVQIXEPSFNIGXWPMOITETIVGPMTWGSMRWOI]W
REMPWWGVI[WSVSXLIVWQEPPQIXEPSFNIGXWXLEX
can make a connection from one terminal to
another. Shorting the battery terminals together
QE]GEYWIFYVRWSVEƼVI
G (SRSXI\TSWIFEXXIV]TEGOXSLIEXSVƼVI%ZSMH
storage in direct sunlight.
d) Do not subject battery pack to mechanical
shock.
e) In the event of battery leaking, do not allow
XLIPMUYMHXSGSQIMRXSGSRXEGX[MXLXLIWOMR

5
WX177 WX177.X
20V Cordless Brushless
Switchdriver 2.0
or eyes. If contact has been made, wash the
affected area with copious amounts of water
and seek medical advice.
f) Keep battery pack clean and dry.
g) Wipe the battery pack terminals with a clean dry
cloth if they become dirty.
h) Battery pack needs to be charged before use.
Always refer to this instruction and use the
correct charging procedure.
i) Do not maintain battery pack on charge when
not in use.
j) After extended periods of storage, it may
be necessary to charge and discharge the
battery pack several times to obtain maximum
performance.
O 6IGLEVKISRP][MXLXLIGLEVKIVWTIGMƼIH
by Worx. Do not use any charger other than
XLEXWTIGMƼGEPP]TVSZMHIHJSVYWI[MXLXLI
IUYMTQIRX
l) Do not use any battery pack which is not
HIWMKRIHJSVYWI[MXLXLIIUYMTQIRX
m) Keep battery pack out of the reach of children.
n) Retain the original product literature for future
reference.
S 6IQSZIXLIFEXXIV]JVSQXLIIUYMTQIRX[LIR
not in use.
p) Dispose of properly.
U (SRSXQM\GIPPWSJHMJJIVIRXQERYJEGXYVI
capacity, size or type within a device.
r) Keep the battery away from microwaves and
high pressure.
SYMBOLS
8SVIHYGIXLIVMWOSJMRNYV]YWIV
must read instruction manual
Warning
Wear ear protection
Wear eye protection
Wear dust mask
Batteries may enter water cycle if
disposed improperly, which can be
hazardous for ecosystem. Do not
dispose of waste batteries as unsorted
municipal waste.
Do not burn
Wear protective gloves
Li-I on
Li-Ion battery. This product has been
marked with a symbol relating to
‘separate collection’ for all battery
packs and battery pack. It will
then be recycled or dismantled in
order to reduce the impact on the
environment. Battery packs can be
hazardous for the environment and
for human health since they contain
hazardous substances.
Drilling
Screwdriving
Great torque
Small torque
Wood
Metal
High speed
Low speed

6
WX177 WX177.X
20V Cordless Brushless
Switchdriver 2.0
Lock
Waste electrical products must
not be disposed of with household
waste. Please recycle where
facilities exist. Check with your local
authorities or retailer for recycling
advice.

1
2
3
4
11
5
7
7
9
6
8
10

2
1
B1
A3
A2A1
2
1
G=
A4 =
D
33
B2
2
1

D
C
D
B3
1
1
2
2
E1
E3
E2
2
1

F
H
G=
G2 =
~
G=
G1 =
/
I

11
WX177 WX177.X
20V Cordless Brushless
Switchdriver 2.0
2. COMPONENT LIST
1. TWO-SPEED GEAR CONTROL
2.
FORWARD/REVERSE ROTATION CONTROL
3. ON/OFF SWITCH TRIGGER
4. SOFT GRIP HANDLE
5. ELECTRONIC TORQUE-ADJUSTING INTER-
FACE
6. LED LIGHT
7. 1/4” (6.35mm) HEX QUICK RELEASE CHUCK
8. DUAL CHUCKS ROTATING PLATE
9. ROTATING PLATE RELEASE BUTTON
10. BATTERY PACK*
11. BATTERY PACK RELEASE BUTTON*
*Not all the accessories illustrated or described are
included in standard delivery.
3. TECHNICAL DATA
Type WX177 WX177.X (1-designation of machinery,
representative of Cordless Drill)
WX177 WX177.X**
Rated voltage 20V Max***
No load speed QMR
Clutch positions 9+1
Max torque 50N.m
Chuck capacity ƉQQ
Max.
drilling
capac-
ity
Steel 13mm
Wood 40mm
Machine weight
(bare tool) 0.82kg
**X=1-999, A-Z, M1-M9 there are only used for
different customers, there are no safe relevant
changes between these models.
***Voltage measured without workload. Initial battery
voltage reaches maximum of 20 volts. Nominal volt-
age is 18 volts.
SUGGESTED BATTERIES
AND CHARGERS
Category Model Capacity
20V Battery WA3551 2.0 Ah
20V Charger WA3880 2.0 A
We recommend that you purchase your accessories
from the same store that sold you the tool. Refer to
the accessory packaging for further details. Store
personnel can assist you and offer advice.
NOISE INFORMATION
A weighted sound pressure LpA: 72dB(A)
A weighted sound power LwA: 83dB(A)
KPA& KWA 5dB (A)
Wear ear protection.
VIBRATION INFORMATION
Vibration total values (triax vector sum) determined
according to EN 62841:
Drilling into metal
Vibration emission value
EL(!QWs
9RGIVXEMRX]/!QWs
The declared vibration total value and the declared
noise emission value have been measured in
accordance with a standard test method and may be
used for comparing one tool with another.
The declared vibration total value and the declared
noise emission value may also be used in a
preliminary assessment of exposure.
WARNING: The vibration and noise emissions
during actual use of the power tool can differ
from the declared value depending on the ways in
which the tool is used especially what kind of
workpiece is processed dependant on the following
examples and other variations on how the tool is
used:
How the tool is used and the materials being cut or
drilled.
The tool being in good condition and well
maintained.
The use of the correct accessory for the tool and
ensuring it is sharp and in good condition.

12
WX177 WX177.X
20V Cordless Brushless
Switchdriver 2.0
The tightness of the grip on the handles and if any
anti vibration and noise accessories are used.
And the tool is being used as intended by its design
and these instructions.
This tool may cause hand-arm vibration syndrome if
MXWYWIMWRSXEHIUYEXIP]QEREKIH
WARNING: To be accurate, an estimation of
exposure level in the actual conditions of use
should also take account of all parts of the operating
cycle such as the times when the tool is switched off
and when it is running idle but not actually doing the
NSF8LMWQE]WMKRMƼGERXP]VIHYGIXLII\TSWYVIPIZIP
over the total working period.
Helping to minimise your vibration and noise
exposure risk.
Always use sharp chisels, drills and blades.
Maintain this tool in accordance with these
instructions and keep well lubricated (where
appropriate).
If the tool is to be used regularly then invest in anti
vibration and noise accessories.
Plan your work schedule to spread any high vibration
tool use across a number of days.
Recommended pilot-hole size for Screws
Ø3mm 3.5mm 4mm 4.5mm
Ø1.5mm 2mm 2.5mm 3mm
Ø5mm 6mm 8mm
Ø3mm 3.5mm QQQQ
4. OPERATING
INSTRUCTIONS
NOTE: Before using the tool, read the
instruction book carefully.
INTENDED USE
The machine is intended for drilling (including
pilot hole) in wood, metal and plastic as well as for
driving and removing fasteners.
ASSEMBLY AND
OPERATION
ACTION FIGURE
STARTING THE MACHINE FOR THE
FIRST TIME
Removing the Battery Pack
See Fig.
A1
Charging the Battery Pack
More details can be found in charger’s
manual
See Fig.
A2
Installing the Battery Pack and Starting
the Machine
As you install the battery pack, the LED
light will turn on, the light turns on, a
boot screen will appear. After a while,
the screen will show number"1".
See Fig.
A3,A4
PREOPERATION SETUP
-RWXEPPMRKEƉQQLI\
SCREWDRIVING bit
The machine is ideally inserted with one
drilling bit and one screw driving bit.
%JXIV]SYWXEVXXLIQEGLMRIJSVXLIƼVWX
time, the default mode is screw driving
at torque level 1.
-RWIVXEƉQQLI\
SCREWDRIVING bit into the chuck
locking sleeve.
See Fig.
B1
Installing the DRILL bit
4PEGIJSV[EVHVIZIVWIVSXEXMSRGSRXVSP
in
the middle position, push the dual chuck
release button to the bottom and rotate
the dual chuck . The light goes off and
the light turns on.
-RWIVXEƉQQLI\(6-00FMX
into the other chuck locking sleeve.
See Fig.
B2,B3
Rotating the dual chuck enables the
working mode to the corresponding bit. See Fig. C

13
WX177 WX177.X
20V Cordless Brushless
Switchdriver 2.0
Removing the Bit
4YPPXLIƉQQ,I\HVMZIGLYGO
forward to release the bitRemoving the
Bits.
See Fig. D
OPERATION
*SV[EVH6IZIVWI6SXEXMSR'SRXVSP
1.) To lock the trigger, push the control
switch to the center position. The trigger
will not work when the control switch
is in
the locked position. (E1)
2.) For forward (clockwise) rotation,
push
the control switch in the direction
shown.
Check the direction of rotation before
use. (E2)
3.) For reverse (counterclockwise)
rotation, push the control switch in the
direction shown. Check the direction of
rotation before use. (E3)
WARNING: Never change the
direction of rotation when the
chuck is rotating, wait until it has
stopped!
See Fig.
E1, E2, E3
Two-speed Gear Control
Push the speed gear control switch
back
to “1” for low speed.
Push the speed gear control switch
forward to “2” for high speed.
WARNING: To prevent gear
damage, always allow the
chuck to come to a complete stop
before changing gears.
See Fig. F
(VMPPMRKHVMZMRK1SHIERH8SVUYI
Setting
Press the drill digital keypad to toggle
between screwdriving and drilling
modes.
Press the screwdriving digital keypad to
EHNYWXXSVUYIPIZIP
Short press for single level change, long
press for consecutive level change.
See Fig.
G1,G2
ON/OFF SWITCH
1.) To power the tool, pull the trigger.
NOTE: An LED is turned on when the
trigger is pulled.
2.) To vary the driving speed, increase or
decrease pressure on the trigger. The
further the trigger is pulled, the greater
the speed, up to the maximum speed
set
by the speed control switch.
3.) To stop the tool, release the trigger
and the electric brake stops the tool
instantly.
WARNING: Do not operate for
long periods at low speed, or
excess internal heat will be produced.
See Fig. H
USING THE LED LIGHT
WARNING: To turn on the
PMKLXTVIWWXLI3R3JJ7[MXGL
ERHQEOIWYVIXLI*SV[EVH6IZIVWI
6SXEXMSR'SRXVSPMWSRVMKLXPIJXTSWMXMSR
LED lighting increases visibility-great
for dark or enclosed area. LED is also
EFEXXIV]GETEGMX]MRHMGEXSV-X[MPPƽEWL
when power gets low.
The tool and battery pack are equipped
with a protection system. When the LED
0MKLXMWUYMGOP]ƽEWLMRKERHXYVRSJJ
the system will automatically cut off
power to the tool to extend battery life.
The tool will automatically stop during
STIVEXMSRMJXLIXSSPERHSVFEXXIV]TEGO
are placed under one of the following
conditions:
• Overloaded: The tool is operated
in a manner that causes it to draw
an abnormally high current. In this
situation, release the Trigger Switch on
the tool and stop the application that
caused the tool to become overloaded.
Then pull the Trigger Switch again to
restart.
• Overheated: Under the condition
above, if the tool does not start, the Tool
and Battery Pack are overheated. In this
situation, let the Tool and Battery Pack
cool before pulling the Trigger Switch
again.
• Low battery voltage: The remaining
Battery capacity is too low and the tool
will not operate. In this situation, remove
and recharge the Battery Pack.
See Fig. H

14
WX177 WX177.X
20V Cordless Brushless
Switchdriver 2.0
SLEEP MODE AND REACTIVATION
When the Switchdriver is left without
any operation for 15 seconds, it will
enter sleep mode automatically.
By pressing FYXXSRSVXLISR
off switch, the Switchdriver will be
reactivated.
See Fig. I
5. TROUBLESHOOTING
1). THE DRILL DOES NOT TURN ON WHEN THE ON/
OFF SWITCH TRIGGER IS PULLED?
8LI*SV[EVH6IZIVWI6SXEXMSR'SRXVSP[LMGLMW
above the trigger, is positioned in the lock function.
9RPSGOXLI*SV[EVH6IZIVWI6SXEXMSR'SRXVSPF]
putting it into the required rotation position. Push
the trigger and the drill will start to rotate.
2). REASONS FOR DIFFERENT BATTERY PACK
WORKING TIMES
Inappropriate charging time or leaving the Battery
Pack without using for a prolonged time will reduce
the Battery Pack capacity. This can be corrected
by charging & working with your drill several times.
Heavy working conditions such as driving large
screws into hard wood will use up the Battery
Pack energy faster than that in lighter working
conditions. Do not re-charge your Battery Pack
below 0°C(32°F) and above 45°C (113°F) as this will
affect performance.
The ambient temperature range for the use and
storage of tool and battery is 0°C-45°C.
The recommended ambient temperature range for
the charging system during charging is 0°C-40°C.
3). THE DRILL CHUCK DOES NOT ACCEPT A
DRILLING OR DRIVING BIT?
8LI7;-8',(6-:)6MWIUYMTTIH[MXLHYEPƉ
6.35mm) hex drive chucks and will only accept bits
[MXLEƉQQLI\WLERO
4). WHY DOES THE DRILL NOT WORK AFTER
ROTATING THE DUAL CHUCK?
The drill can work only when the Dual Chucks
Rotating Plate is in right position as shown in Fig.
B2. When the Dual Chucks Rotating Plate reaches
proper position, you can hear a “click” sound.
6. MAINTENANCE
Remove the battery pack from the tool before
carrying out any adjustment, servicing or
maintenance.
Your tool requires no additional lubrication or
maintenance.
There are no user serviceable parts in your power
tool. Never use water or chemical cleaners to clean
your power tool. Wipe clean with a dry cloth. Always
store your power tool in a dry place. Keep the motor
ventilation slots clean. Keep all working controls
free of dust. Occasionally you may see sparks
through the ventilation slots. This is normal and will
not damage your power tool.
7. ENVIRONMENTAL
PROTECTION
Waste electrical products must not be disposed
of with household waste. Please recycle where
facilities exist. Check with your local authorities
or retailer for recycling advice.

15
WX177 WX177.X
20V Cordless Brushless
Switchdriver 2.0
8. DECLARATION OF
CONFORMITY
We,
Positec Germany GmbH
Postfach 32 02 16, 50796 Cologne, Germany
Declare that the product,
Description Battery-powered Drill
Type WX177 WX177.X (1-designation of machinery,
representative of Cordless Drill)
Function Drilling/Tightening and loosening screws,
nuts
Complies with the following Directives,
2006/42/EC
2011/65/EU&(EU)2015/863
2014/30/EU
Standards conform to
EN 55014-1, EN 55014-2, EN 62841-1,
EN 62841-2-1
8LITIVWSREYXLSVM^IHXSGSQTMPIXLIXIGLRMGEPƼPI
Name Marcel Filz
Address Positec Germany GmbH
Postfach 32 02 16, 50796 Cologne, Germany
Allen Ding
(ITYX]'LMIJ)RKMRIIV8IWXMRK'IVXMƼGEXMSR
Positec Technology (China) Co., Ltd.
18, Dongwang Road, Suzhou Industrial
Park, Jiangsu 215123, P. R. China

Copyright © 2022, Positec. All Rights Reserved.
AR01614401
After-sales Service and Application
At www.worx.com you can order spare parts or
arrange the collection of a product in need of
servicing or repair.
Tel. Service: 0345 202 9679
E-Mail: [email protected]
www.worx.com
DECLARATION OF
CONFORMITY
We,
Positec (UK & Ireland) Ltd.
PO Box 6242, Newbury, RG14 9LT, UK
On behalf of Positec declare that the product
Description Battery-powered Drill
Type WX177 WX177.X (1-designation of machinery,
representative of Cordless Drill)
Function Drilling/Tightening and loosening screws,
nuts
Complies with the following regulations,
Supply of Machinery (Safety) Regulations 2008
Electromagnetic Compatibility Regulations 2016
The Restriction of the Use of Certain Hazardous
7YFWXERGIWMR)PIGXVMGEPERH)PIGXVSRMG)UYMTQIRX
Regulations
Standards conform to
BS EN 62841-1, BS EN 62841-2-1, BS EN 55014-1,
BS EN 55014-2
8LITIVWSREYXLSVM^IHXSGSQTMPIXLIXIGLRMGEPƼPI
Name: Jim Kirkwood
Address:Positec (UK & Ireland) Ltd.,
PO Box 6242, Newbury, RG14 9LT, UK
Allen Ding
(ITYX]'LMIJ)RKMRIIV8IWXMRK'IVXMƼGEXMSR
Positec Technology (China) Co., Ltd
18, Dongwang Road, Suzhou Industrial
Park, Jiangsu 215123, P. R. China
This manual suits for next models
2
Table of contents
Other Worx Nitro Drill manuals
