Wow Wow-sound User manual

IP67
FLOATABLE / WATERPROOF
WORLD OF WATERSPORTS
QUICK START
PRODUCT MANUAL
IP67
FLOATABLE / WATERPROOF

CONTROL INSTRUCTIONS
Turn on - Press the Power Button
Turn off - Hold Down the Power Button
Pause/Play – Tap the power button while the speaker is on
Volume Up – Press the “+” button once for an incremental
increase or press and hold to quickly increase.
Volume Down – Press the “-” button once for an incremental
increase or press and hold to quickly increase.
Skip To Next Song – Double tap the “+” button
Go Back To Previous Song – Double tap the “-” button
LED Light - Press the small button under the LED light strip to
turn on / off and to switch brightness settings
Reset Bluetooth Connection - Press the “+” and “-” buttons
together for 5 seconds until you hear 2 beeps
Charging - Lift the rubber cover under the LED light and connect
the AC adaptor included in the package.
+ volume up button
skip to next song
Four 2 in.
active drivers
Four 2 in.
active drivers
- volume down button
back to previous song
power button
pause/play button
carrying handle
LED light button
charge port
levitation stem that
fits most cup holders
passive 4 inch base
carrying handle

SPECIFICATIONS
Power Supply – 13.5V 2A
Battery Life – 50+ hours (varies by volume level, content,
and use of LED light)
Frequency Response – 65Hz – 20kHz
Drivers – 4 x 2 in Mid-range drivers &
1 x 4 in Passive Radiator
Waterproof Rating – IP67
Product Weight – 1.6kg or 3.5lbs (approximately)
Product Dimensions – Φ192mm x 175Hmm or 7.55 in x 6.9 in
Charging Requirements – 100 – 240VAC power adaptor
(included); charges fully within 4 hours
Bluetooth Wireless Range: 20m (66 ft.)
Bluetooth Version – 4.2
Operating Temperature Range - 0 to 50° C or 32 to 122° F
Charging Temperature Range - 0 to 45° C or 32 to 113° F
DEVICE CARE
1. Avoid chemical cleaners, solvents, sunscreen, and insect
repellents that can damage plastic components and finishes
2. Thoroughly rinse the device with fresh water after exposure
to chlorine, salt water, sunscreen, cosmetics, alchohol,
or other harsh chemicals. Prolonged damage to these
substances can damage the case.
360
º
SOUND ULTRA LOUD BLUETOOTH 360
º
LED LIGHT
EZ HOLD HANDLE
FLOATABLE FITS MOST CUP HOLDERS
IP67
DUST/SHOCK/WATER PROOF
1M
30 MIN.
SUBMERSIBLE
30 min.
CONTINUOUS PLAY
50+ HOURS
LITHIUM-ION BATTERY
RECHARGEABLE
LINK 2 SPEAKERS
BIG STEREO SOUND
360
º
SOUND ULTRA LOUD BLUETOOTH 360
º
LED LIGHT
EZ HOLD HANDLE
FLOATABLE FITS MOST CUP HOLDERS
IP67
DUST/SHOCK/WATER PROOF
1M
30 MIN.
SUBMERSIBLE
30 min.
CONTINUOUS PLAY
50+ HOURS
LITHIUM-ION BATTERY
RECHARGEABLE
LINK 2 SPEAKERS
BIG STEREO SOUND
360
º
SOUND ULTRA LOUD BLUETOOTH 360
º
LED LIGHT
EZ HOLD HANDLE
FLOATABLE FITS MOST CUP HOLDERS
IP67
DUST/SHOCK/WATER PROOF
1M
30 MIN.
SUBMERSIBLE
30 min.
CONTINUOUS PLAY
50+ HOURS
LITHIUM-ION BATTERY
RECHARGEABLE
LINK 2 SPEAKERS
BIG STEREO SOUND

WOW-SOUND SPEAKER FLOAT
• Lets the speaker float up out of
the water for greater sound
• Great to use in rough or busy
lake waters or busy pools
• Side grommet for tying off to
your favorite float
FLOATING PHONE HOLDER
• Great for waterproof
protection while using your
phone around water.
• FLOATS ON WATER SURFACE,
do not worry about missing your
device under the water any more.
• Provides waterproof
protection for your smartphone
while maintaining full touch screen
functionality
• Crystal Clear Window on
both sides, perfect for taking
pictures or videos
• Universal: It fits all large
Smartphones up to 6 inches
& your cash, documents, credit
cards, etc, very good for indoor/
outdoor activities, beach,
swimming, boating, kayaking,
watersports, travels
• Easy-to-use with a snap and lock
seal system for FULL FLOATING
WATERPROOF PROTECTION
•
Includes comfortable neck strap
for hands-free transport
The WOW-SOUND SPEAKER
can also float on it’s own!

CHARGING THE STEREO
To prevent corrosion, thoroughly dry the power port and the
surrounding area before charging.
You should fully charge the battery before you use the stereo
for the first time. Charging a fully depleted battery takes about
4 hours.
1.Open the silicon cover underneath the portion
of the LED light under the control panel.
2.Plug the power cable included with the speaker
into the power port.
3.Plug the AC power adaptor into a standard wall outlet.
A.When charging the small round LED light next
to the power port will be orange.
B.When fully charged the light will turn green.
4.Once finished charging remove the power cable.
5.Close the silicon cover completely.
NOTE: The silicon cover must be closed securely
to achieve the IP67 water rating
For more information about the features
discussed in the manual, please refer to
our website at www.wowwatersports.com
CONNECTING DEVICES
Connecting your WOW-SOUND speaker to compatible devices.
You can play media from a compatible Bluetooth device using
the Bluetooth wireless connection.
1.Enable Bluetooth on your compatible Bluetooth device.
2.Bring the compatible Bluetooth device within 20 m (66 ft.)
of the speaker.
3. On the speaker press the power button. The small round
LED light next to the power port will blink slowly.
4.Once the speaker is discoverable in pairing mode the
small round LED light will start blinking faster.

5. On your compatible Bluetooth device select WOW-SOUND
from the list of discoverable devices.
a. If your compatible Bluetooth device does not connect
to the stereo, repeat the above steps and try again
6.Start playing music from your Bluetooth device.
COMMON PAIRING TROUBLE SHOOTING ISSUES:
1. If your WOW-SOUND speaker is not discoverable on your
device, press the “+” and “-“ buttons together for 5 seconds
until you hear 2 beeps. This will disconnect any previous
pairings and reset you’re speaker for a new pairing.
You may need to turn Bluetooth off from your device
and then turn it back on as well.
2. Once reset, please follow steps 1-6 above.
3. If you are still having problems, try turning your speaker
off and then on again and repeat steps 1-6 above.
TRUE WIRELESS WOW STEREO SOUND MODE
1.TrueWireless WOW Stereo Sound Mode.
When Connecting 2 WOW Sound Speakers
one speaker becomes the left and one
becomes the right so you have
true WOW stereo sound.
Follow the instructions below to activate.
2. Make sure both speakers are turned off and not
connected to any bluetooth device.
3. Turn on the first speaker (master) and connect
it to your bluetooth device
4. Turn on the second speaker (servant) but do NOT
connect it to your bluetooth device
5. On the first speaker press the “+” and “-” buttons at
the same time. This enables the True Wireless feature.
360
º
SOUND ULTRA LOUD BLUETOOTH 360
º
LED LIGHT
EZ HOLD HANDLE
FLOATABLE FITS MOST CUP HOLDERS
IP67
DUST/SHOCK/WATER PROOF
1M
30 MIN.
SUBMERSIBLE
30 min.
CONTINUOUS PLAY
50+ HOURS
LITHIUM-ION BATTERY
RECHARGEABLE
LINK 2 SPEAKERS
BIG STEREO SOUND

6. On the second speaker press the “+” and “-” buttons at
the same time. This connects the servant to the master.
7. You will hear “True Wireless Connected” which means
they are connected
8. Turn on your music
9. If the servant speaker disonnects you can reconnect it
by hitting the “+” and “-” buttons at the same time as
long as the master is still in the True Wireless mode.
10. Note 1: At this time the Bluetooth chipset only has the
capability for the 2 speakers to be about 5 meters or
15 feet apart but the farther apart they are the less
stable the connection is.
11. Note 2: Your device can still be 30 meters away from
the first speaker as long as there are no obstructions
REGISTERING YOUR WOW-SOUND SPEAKER
Help us better support you by filling out our
registration form found in your speaker packaging
or online at www.wowwatersports.com
Please keep the original sales receipt or
a photocopy in a safe place
www.facebook.com/towables
WOW Sports LLC.
Designed and Engineered in the USA
MADE IN CHINA
Email Address:
[email protected]
www.wowwatersports.com
Phone: [phone]
WARRANTY:
World of Watersports warrants, to the original purchaser only, that their high
performance products, when used for normal recreational purposes, are free
from defects in material and workmanship for a period of 1 year from the date of
purchase. Any implied warranties are also limited in duration to the 1 year period
from the original date of purchase. Our warranty excludes products for rental,
for hire, and other uses not considered normal recreational purposes. World
of Watersports will not be held liable for incidental or consequential damages.
