Wright Manufacturing VKX2-3(R,SC,B Guide

DO NOT REMOVE!
Except By Owner/User
IMPORTANT SAFETY AND OPERATIONS
INFORMATION INSIDE
---------------------------------------
VKX2-3(R,SC,B)
VKX2-3(R,B)-15
VELKE X2 PACKING LIST:
VELKEX2:
2WHEELASSEMBLIES
FOOTPLATEWITH 2 SPANNERS, 2WASHERS,2 L1NCHPINS
18"ARM FORVKX2-3(R,SC,B)WITH INTERMEDIATE PIVOT
(15"ARM FORVKX2-3(R,B)-15 WITH INTERMEDIATEPIVOT)
HITCH
ADAPTERPLATE
TWO 3/8" x 1 1/4" BOLTS, LOCKNUTS
REMAINING HARDWARE IN KIT:
BAG
SNAP
CHAIN
TWO 3/8" x 1" BOLTS, LOCKNUTS
ONE 5/16" x 1" BOLT
ONE5/16"LOCKNUT
LITERATUREBAG
BAG
THIS DOUBLE-SIDED 3 PAGE PACKAGE:
•DO NOTREMOVEWARNING/PACKING LIST
•PARTS LISTWITH DIAGRAM
•SAFETYWARNINGS
•INSTALLATION INSTRUCTIONS
LUBRICATION WARNING
C84BEST "Four best workers..," FLYER
WARRANTY
©1991
-
2008 Wright Manufacturing,
Inc. All Rights Reserved. Vel e, PRO 1, X2, SuperPro, Grass Gobbler, Leaf Gobbler, and Turbo Ten are trademar s of Wright Man
ufacturing, Inc.
4600X Wedgewood Blvd., Frederick, Maryland, 21703 U.S.A.
ph. 301.360.9810 fax.[phone]

Velke™ Sulky: PRO1 & X2 Parts List



Wright Manufacturing Inc. 4600X Wedgewood Blvd., Frederick, Maryland, 21703 U.S.A. – phone [phone] - fax [phone]
© 1991-2010 Wright Manufacturing, Inc. All Rights Reserved Velke, Velke Pro1, Velke X2 are trademarks of Wright Manufacturing Inc.
Pro1
REF#
X2
REF# PART#
Color Code: R=red, SC=orange, B=black
DESCRIPTION
1 VK200-2 (R,SC,B) VELKE SULKY, PRO 1 w/18" square tube arm [specify R,SC,B]
1 VK200-2 (R,B)-15 VELKE SULKY, PRO 1 w/15" square tube arm [specify R,B]
1 VK200-2WV VELKE SULKY,PRO 1 for Wright Velke Mower [adpt.& chain kit n/inc.]
1X VKX2-3 (R,SC,B) VELKE SULKY, X2 w/18" square tube arm [specify R,SC,B]
1X VKX2-3 (R,B)-15 VELKE SULKY, X2 w/15" square tube arm [specify R,B]
1X VKX2-3WV VELKE SULKY,X2 for Wright Velke Mower [adpt.& chain kit n/inc.]
2 VKWHEEL Wheel Assy., w/ centered hub & spanner 9x3.50-4
2X VKXWHEEL Wheel Assy., w/ offset hub & spanner 9x3.50-4
2X 72310001(VKXWHEEL 11") Wheel Assy., w/ offset hub & spanner 4.10x3.50-4
2a VKTIRE 9x3.50-4 Ply Turf Tread Tire
2Xa 72320001(VKXTIRE 11") 4.10x3.50-4 Ply Turf Tread Tire
2b VKTUBE 9x3.50 Tube for VKTIRE
2Xb 72320002 (VKXTUBE 11") 4.10x3.50 Tube for 11" VKXTIRE
2c VKRIM/HUB 4" x 2.25" 3 Piece Rim/Centered Hub Assy. (w/o bearings)
2Xc VKXRIM/HUB 4" x 2.25" 3 Piece Rim/Offset Hub Assy. (w/o bearings) 9"&11"tire
2d VKBRGKIT Bearing Kit PRO 1 (w/Roller Bearing, Retainers & Spanner)
2Xd VKXBRGKIT Bearing Kit X2 (w/Roller Bearing, Retainers & Spanner)
2e VKSPNNR Spanner, 3/4" O.D.
2Xe VKXSPNNR Spanner, 1" O.D.
2f VKRLBRG Roller Bearing, 3/4" I.D.
2Xf VKXRLBRG Roller Bearing, 1" I.D.
2g VKBRGRTNR Bearing Retainer, 3/4" I.D. (2 required)
2Xg VKXBRGRTNR Bearing Retainer, 1" I.D. (2 required)
2h VKWHLZERK Grease Fitting For VKWHEEL & VKXWHEEL
3 VKPLAT2-2 (R,SC,B,WV) Foot Platform PRO 1 (w/decals) [specify R,SC,B,WV]
3X VKXPLAT2-2 (R,SC,B,WV) Foot Platform X2 (w/decals, bushings, zerk) [specify R,SC,B,WV]
4 VKAXLE2-2 Axle Bolt (w/spacers and self locking nut)
4X VKXLPIN Linch Pin for X2 axle
5 VKARM2-2(R,SC,B) Arm, 18" square tube (w/ bushings & grease fitting0 [specify R,SC,B]
5 VKARM2-2WV
Arm, 18" square tube (w/ bushings & grease fitting) for Wright Velke Mower with
deployment latch
6 VPIVOTBUSH Bronze Bushing pivot(s) (PRO1 req. 2; X2 req. 4)
7 VHITCHBUSH Bronze Bushing for hitch (2 required)
8 VKHITCH2-2-BLK Hitch (w/ bushings & grease fitting) [Black]
9 VELKIT2-2 Snap & Chain Kit (includes chain, snap, nut, bolt)
9a VSNAP Spring Snap for chain
10 VKPIN2-2 Clevis pin for hitch, w/ hair pin & roll pins
11 VADAPTER Adapter plate for hitch height adjustment
12 VK-ADPT-FE 14.25" Adapter to mount VELKE to Ferris Hydro Walk
VK-ADPT-FE16 16.375" Adapter to mount VELKE to Ferris Walkbehinds
VK-ADPT-FE29 29.25" Adapter to mount VELKE to Ferris Walkbehinds
13 VK-ADPT-HN U-Bolt kit for attaching VELKE to Honda Hydro
not shown VK-ADPT-JD For John Deere Hydro Walkbehinds w/hydro tank in frame (must use 15" arm)
14 VKARM-SHORT (R,B) Optional SHORT 15" square tube arm (w/bushings) [specify R,B]
15 VKLABEL Decal set for VELKE PRO 1 Sulky (incl. all three)
15X X2-VKLABEL Decal set for VELKE X2 Sulky (incl. 2 labels)
16 VKSPCKIT Spacer kit (includes both sizes needed, 4 total)
16X VKXSPCKIT Spacer kit (includes both sizes needed, 6 total)
17X VKXPIVPIV-BLK Intermediate Pivot (Black Only)
18X VKXPROTEC Protective cover (for fold-up feature)
19 15990010 E Clip 7/8": (PRO 1 req. 1; X2 req. 2) (Supercedes Cotter Pin)
20 76490060 Decal, Sulky Reverse Warning
x x CB4BEST 4-Color Sales Flyer, "Four best workers…"
x x COMMON: Other common hardware should be purchased locally. All bolts must be grade 5.

W
ARNING!!
READ THIS BEFORE USING
W
ARNING!!
READ THIS BEFORE USING
VELKE SAFETY WARNINGS
1. Do not use the Velke Sulky until you are completely familiar with the
operation of the particular mower that it is attached to. We
recommend at least one month experience walking behind the mower
before riding.
2. Make sure all safety equipment provided with the mower is in
operating order. This includes operator presence devices that will
shut the mower off in case you let go of the handles.
3. Wear thick-soled, high-top leather work boots. No bare feet!
4. Do not attempt to operate the mower in reverse gear while standing
on the Velke sulky.
5. Operate the mower at slower speeds until you become familiar with
how the Velke sulky handles. It won’t be long before it becomes
natural. Some users compare it to skiing.
6. Do not operate the mower faster than you could walk comfortably.
Speeding is dangerous even when trotting (or running) behind a
mower. Sudden stops from excessive speed may cause serious injury.
The Velke will make you more efficient by just maintaining a healthy
pace through the day without speeding.
7. Never use any mower near and by-standers in case you lose control or
objects are thrown from the mower.
8. Do not allow inexperienced people to use the Velke until they have
read and understand this sheet, and have significant experience
walking behind a commercial/industrial mower.
9. Do not use the Velke sulky if any parts become loose. Examine the
moving parts each time you use it. Look for loose or missing bolts,
cotter or hair pins and replace immediately.
W
right Manufacturing, Inc., the manufacturer of the Velke sulky, thanks
you for purchasing this new product. We’re working to help you make
money. Please write or call us if you would like to receive product update
information or if you have any questions about its use or installation.
We’re here to give you 100% satisfaction. Our local Velke dealers are
authorized to service and sell our product in your area. Please give them
your support.
4600X Wedgewood Blvd.,
Frederick, Maryland, 21703
U.S.A.
ph. 301.360.9810
fax.[phone]
©1991-2008 Wright Manufacturing, Inc. All Rights Reserved. Velke, PRO 1, X2, SuperPro, Grass Gobbler, Leaf Gobbler, and Turbo Ten are trademarks of Wright Manufacturing, Inc.
