Operating Instructions and Parts Manual 68179
3-1/2 GALLON (13L) PARTS WASHER
Please read and save these instructions.
Read through this owner’s manual care-
fully before using product. Protect your-
self and others by observing all safety
information, warnings, and cautions.
Failure to comply with instructions could
result in personal injury and/or damage to
product or property. Please retain instruc-
tions for future reference.
UNPACKING
After unpacking unit, inspect
carefully for any damage that may
have occurred during transit. Check
for loose, missing, or damaged parts.
Shipping damage claim must be filed
with carrier.
SPECIFICATIONS AND DIMENSIONS
Maximum Capacity Working Capacity Assembled Dims (Inches)(CM) Weight
Model Gallons Gallons Length Width Height (Lbs) (Kgs)
68179 3.5 (13L) 3 (11L) 18” x 13 1/2”x 9” (45.7 x 34.3 x 22.9cm) 14 6.4
SAFETY RULES
1. Know your tool. Read this manual carefully. Learn the tool’s applica-
tions and limitations, as well as, potential hazards specific to it.
2. Ground all tools. If the tool is equipped with three-pin plug, it
should be plugged into a three-pin electrical socket. Never
remove the ground pin. Failure to properly ground unit could
result in severe electrical shock and / or death.
3. Do not abuse cord. Never use the cord to carry tools or pull the
plug from an outlet. Keep cord away from heat, sharp edges or
moving parts. Replace damaged cords immediately. Damaged
cords increase the risk of electric shock.
4. Keep work area clean and well lit. Cluttered or dark work areas
invite accidents.
5. Keep children away. All children should be kept away from the
work area. Never let a child handle a tool without strict adult
supervision.
6. Do not operate this tool if under the influence of alcohol or
drugs. Read warning labels on prescriptions to determine if your
judgment or reflexes are impaired while taking drugs. If there is
any doubt, do not attempt to operate.
7. Use safety equipment. Eye protection should be worn at all
times when operating this tool. Use ANSI approved safety
glasses. Everyday eyeglasses are NOT safety glasses. Dust
mask, non-skid safety shoes, hard hat, or hearing protection
should be used in appropriate conditions.
FOR GENERAL QUESTIONS ABOUT OUR PRODUCTS,
YOU CAN CALL OUR TOOL EXPERTS TOLL-FREE AT
CALL 1-888-996-8665 (1-888-996-TOOL) OR
EMAIL: [email protected]
WESELLTOOLS.COM
4/13
2013 ©WE SELL TOOLS

2
Operating Instructions and Parts Manual 68179
3-1/2 GALLON (13L) PARTS WASHER
8. Wear proper apparel. Loose clothing, gloves, neckties, rings,
bracelets, or other jewelry may present a potential hazard when
operating this tool. Keep all apparel clear of the tool.
9. Don’t overreach. Keep proper footing and balance at all times
when operating this tool.
10. Always disconnect the tool from power source before making
any adjustments, storing, servicing, or changing accessories.
Such preventative safety measures reduce the risk of starting
the tool accidentally.
11. Do not use the tool if the switch does not turn it on and off.
Any tool that cannot be controlled with the switch is dangerous
and must be repaired.
12. Check for damage. Check your tool regularly. If part of the tool
is damaged it should be carefully inspected to make sure that it
can perform its intended function correctly. If in doubt, the part
should be repaired. Refer all servicing to a qualified technician.
Consult your dealer for advice.
13. Keep away from flammables. Do not attempt to operate this
tool near flammable materials or combustibles. Failure to
comply may cause serious injury or death.
14. Store idle tools out of the reach of children and untrained per-
sons. Tools may be dangerous in the hands of untrained users.
GETTING STARTED
Unpack your WST 3-1/2 Gallon (13L) Parts Washer. After unpack-
ing the unit, inspect carefully for any
damage that may have occurred during transit.
Check for any loose, missing or damaged parts.
POWER SOURCE CONNECTION
POWER REQUIREMENTS
This product is designed to operate on a properly grounded 120
volt, 60Hz, single-phase alternating current (AC) power source
fused with a 20 amp time delayed fuse or circuit breaker. It is
recommended that a qualified electrician verify the ACTUAL VOLT-
AGE at the receptacle into which the product will be plugged and
confirm that the receptacle is properly fused and grounded.
DO NOT OPERATE THIS PRODUCT if the ACTUAL power
source voltage is less than 105 volts AC or greater than 132 volts
AC. Contact a qualified electrician if this problem exists. Improper
performance and/or damage to the product will result if operated
on inadequate or excessive power.
CONNECT TO POWER SOURCE
Consult a qualified electrician for proper installation of receptacle
at the power source.
This product must be grounded while in use to protect the operator
from electrical shock. If you are not sure if your outlet is properly
grounded, have it checked by a qualified electrician. Do not cut off
the grounding prong or alter the plug in any way and do not use
any adapters between the product’s power cord and the power
source receptacle. Make sure the POWER switch is OFF then
connect the power cord to a properly grounded 120V, 60Hz, single
phase, 20 amp power source.
EXTENSION CORDS
For optimum performance, an extension cord should not be used
unless absolutely necessary. If necessary, care must be taken in
selecting an extension cord appropriate for use with your specific
product. Select a properly grounded extension cord that will mate
directly with the power source receptacle and the power cord
without the use of adapters. Make certain that the extension is
properly wired and in good electrical condition. Extension cords
must be a minimum # 12 gauge cord. Do not use an extension cord
over 25 ft. (7.6m) in length.
WHEN INSTALLING YOUR PARTS WASHER
1. Sit it on a firm, flat, level surface in a well ventilated area and
away from any open flames.
2. Fill only with a non-flammable water-based degreaser or cleaning
agent, such as Simple Green to just below the level of the parts
shelf (approximately 3 gallons).
3. Follow the degreaser manufacturer’s instructions carefully.
4. Do not fill with flammable solvents such as kerosene, gasoline, etc.
WARNING
High voltage danger from power source!

3
Operating Instructions and Parts Manual 68179
3-1/2 GALLON (13L) PARTS WASHER
WHEN USING YOUR PARTS WASHER
1. Wear suitable protective clothing, gloves and goggles.
2. Clean off any accidental splashes of degreaser on skin im-
mediately, following the degreaser manufacturer’s instructions
carefully. Seek medical attention if necessary.
3. Keep work area tidy and mop up any accidental spills of
degreaser.
WHEN NOT IN USE
1. Switch off pump, close the lid and disconnect from the
electrical supply.
2. Disconnect from the electrical supply before carrying out any
maintenance or cleaning on the parts washer.
The pump of your parts washer may be damaged if you use
solvents like perchloroethylene or trichloroethylene.
ELECTRICAL CONNECTIONS
Plug into a standard 120 volt grounded plug.
This appliance must be grounded.
OPERATION
Always wear protective clothing, gloves and goggles when using
your Parts Washer.
1. Open the parts washer lid and place parts to be washed on the
parts shelf.
2. Position the flexible nozzle so that it is directly above your parts.
3. Turn the power switch to the ON position.
4. Clean parts as needed.
5. Turn power switch to the OFF position.
6. Keep work area tidy and mop up any accidental spills of
degreaser.
MAINTENANCE
1. The lid incorporates a fusible link to close the lid in the event of
a fire. This link is non-resetting and must be replaced once it has
been triggered.
2. Make sure the holes in the removable parts shelf are free of debris.
3. Do not allow the level of liquid in the parts washer to fall below
the pump inlet, as damage to the pump can result.
4. Change degreaser as needed.
TROUBLE SHOOTING
The only trouble you should ever experience with your Parts
Washer is reduced volume flow or no flow of cleaning liquid from
the flex hose nozzle. The probable cause is:
1. Foreign matter in the flex hose.
2. Low fluid level (not reaching the pump inlet).
3. Blocked/dirty filter.
4. Air in the pump. You can turn on and turn off the parts washer
for several times or knock on the pump housing for several times
to fix this problem.
LIMITED 90 DAY WARRANTY
If within 90 days from date of purchase, this product fails due to a
defect in materials or workmanship, return the product with proof
of purchase, prepaid, to WST Warranty Dept., 2648 Broad Avenue
Memphis, TN 38112, for replacement with an item of equal or
greater value. This warranty excludes incidental/consequential
damages and failures due to misuse, abuse or normal wear and
tear. This warranty gives you specific legal rights, and you may
also have other rights, which vary, from state to state. WST will
not be responsible for any consequential or incidental damages
arising from the breach of this or any other warranty, whether
expressed, implied or statutory. Some states do not allow the
exclusion or limitation of consequential or incidental damages, so
the above exclusion may not apply to you. This warranty gives you
specific legal rights, and you may also have other rights which vary
from state to state.
ALWAYS WEAR SAFETY GOGGLES.
WARNING
WARNING
WARNING
Clean off any accidental splashes of degreaser
on skin immediately, following the degreaser manufacturer’s
instructions carefully.
Seek medical attention if necessary.

4
Operating Instructions and Parts Manual 68179
3-1/2 GALLON (13L) PARTS WASHER
PARTS LIST AND DIAGRAM
Reference No. Description ............................ Qty
1 68179-01 Tank ........................................1
2 68179-02 Fusible Linked Lid Arm .........................1
3 68179-03 Shaft........................................1
4 68179-04 Rivet .......................................4
5 68179-05 Lid..........................................1
6 68179-06 Heavy Duty Removable Work Shelf ...............1
7 68179-07 Cord Flange ..................................1
8 68179-08 Flexible Metal Nozzle .........................1
9 68179-09 O-ring ...................................... 1
10 68179-10 Connector ...................................1
11 68179-11 O-ring .......................................1
12 68179-12 Pump .......................................1
13 68179-13 Strain Relief .................................1
Reference No. Description ............................ Qty
14 68179-14 M4x10 Screw ................................5
15 68179-15 M4 Nut .....................................5
16 68179-16 Flat Washer ..................................5
17 68179-17 Spring Washer ...............................5
18 68179-18 Power Cord ..................................1
19 68179-19 Switch Box ..................................1
20 68179-20 Switch .....................................1
21 68179-21 Plastic Feet ..................................4
22 68179-22 M5x30 Screw ................................1
23 68179-23 M5 Nut .....................................1
24 68179-24 Flat Washer ..................................1
25 68179-25 Rubber Strain Relief ...........................1
WE SELL TOOLS
Memphis, TN 38028
Made in China
FOR GENERAL QUESTIONS ABOUT OUR PRODUCTS,
YOU CAN CALL OUR TOOL EXPERTS TOLL-FREE AT
CALL 1-888-996-8665 (1-888-996-TOOL) OR
EMAIL: [email protected]
WESELLTOOLS.COM
