WTI Sidewinder SW720-H.264-HD User manual

Sidewinder High Definition IP Cameras
SW720-H.264-HD
Installation and Operation Manual
Including:
Optional X30 Optical Zoom (HD30)
Optional Electric Brakes (ENG)
Optional Nitrogen Pressurization (P)
Optional Connector Interfaces (HV)(AMP)
120VAC and 24VAC Options
REVISION 11-19-14

TABLE OF CONTENTS
INFORMATION.................................................................................................................................3
FCC NOTICE .................................................................................................................................. 3
READ THIS MANUAL..................................................................................................................3
PRODUCT WARRANTY AND REPAIR ...........................................................................................4
PRODUCT WARRANTY.............................................................................................................. 4
REPAIR AUTHORIZATION.......................................................................................................5
RETURNS ....................................................................................................................................... 5
SAFEGUARDS....................................................................................................................................6
GENERAL DESCRIPTION................................................................................................................ 7
MODELS AND FEATURES.............................................................................................................8
INSTALLATION................................................................................................................................9
RECOMMENDED TOOLS FOR PROPER INSTALLATION................................................ 9
INSTALLATION PLANNING ..................................................................................................... 9
DIMENSIONS AND MOUNTING...................................................................................................10
MECHANICAL DIMENSIONS ................................................................................................. 10
MOUNTING .................................................................................................................................11
MOUNTING ACCESSORIES ........................................................................................................ 12
MS SIGNAL CONNECTIONS ....................................................................................................... 18
AMP STYLE SIGNAL CONNECTIONS......................................................................................19
SIGNAL DESCRIPTIONS.............................................................................................................. 21
AC LINE CONNECTIONS......................................................................................................... 21
ETHERNET SIGNAL CONNECTIONS................................................................................... 21
ANALOG VIDEO CONNECTIONS..........................................................................................21
HARD WIRED PTZ SERIAL CONTROL PORT....................................................................21
CAMERA ETHERNET PROTOCOLS AND PORTS.................................................................24
DEFAULT IP ADDRESS............................................................................................................. 24
DEFAULT PORT ADDRESSES................................................................................................. 24
SURGE PROTECTION AND PRESSURIZATION .................................................................... 26
SEALING AND PRESSURIZATION............................................................................................26
SPECIFICATIONS ..........................................................................................................................27
X30 ZOOM IMAGE SENSOR AND LENS............................................................................... 27
X20 ZOOM IMAGE SENSOR AND LENS............................................................................... 27
VIDEO ENCODING ....................................................................................................................28
CAMERA HOUSING MODULE ...............................................................................................28
PAN AND TILT DRIVE ASSEMBLIES ...................................................................................29
ELECTRICAL.............................................................................................................................. 30
ENVIRONMENTAL.................................................................................................................... 30
MECHANICAL............................................................................................................................31
REVISION HISTORY..................................................................................................................... 31
SW720-H.264-HD WTI ~ Page 2 of 31

SW720-H.264-HD WTI ~ Page 3 of 31
INFORMATION
FCC NOTICE
This device complies with Part 15 of the FCC
Rules.
Operation is subject to the following two
conditions:
1.) This device may not cause harmful
interference.
2.) This device must accept any interference
that may be received, including interference
that may cause undesired operation.
READ THIS MANUAL
Every effort has been made to insure that this
WTI system is of the highest quality. This
product has been carefully inspected to
comply with rigid quality standards before
shipment to you. In consideration of your
investment and the desire to obtain full
performance capability engineered into your
new WTI product, we recommend that you
read this manual before attempting to operate
your system.
FOR MORE ASSISTANCE OR MORE
INFORMATION
WTI (Wireless Technology, Inc.)
2064 Eastman Avenue, Suite 113
Ventura, CA 93003-7787
TOLL FREE. 866/gotowti (468-6984)
TEL. [phone]
FAX. [phone]
EMAIL: [email protected]
INTERNET: http://www.gotowti.com
The software / firmware furnished with the
equipment is confidential to and is
copyrighted by Wireless Technology, Inc.
(WTI) It is not to be copied or disclosed in any
manner without the consent of Wireless
Technology, Inc. (WTI). The
software/firmware is furnished to the
purchaser under a license for use on a single
system.
Information furnished by Wireless
Technology, Inc. (WTI) is believed to be
accurate and reliable. However, no
responsibility is assumed by Wireless
Technology, Inc. (WTI)for its use or for any
infringements of other rights of third parties,
which may result from its use. No license is
granted by implications or otherwise under
any patent or patent rights of Wireless
Technology, Inc. (WTI)
©2011 Wireless Technology, Inc. (WTI)
All rights reserved.

PRODUCT WARRANTY AND REPAIR
PRODUCT WARRANTY
We appreciate your purchase of Wireless Technology, Inc. (WTI) security products. We
take pride in the quality of our products and have manufactured each new WTI product to
exacting quality standards. In normal use, it will provide you with years of satisfactory
performance. However, should you experience difficulty; you are protected under the
provisions of this warranty.
WTI warrants to the original user a product that is free of defects in materials and
workmanship in normal use. WTI warrants to the original user that WTI’s products will
be free of defects in materials and workmanship in normal use for a period of 24 months
from the date of sale. WTI’s obligation under this warranty shall be limited to the repair,
including all necessary parts and the cost of labor connected therewith, or at our option,
the replacement of any product that shows evidence of a manufacturing defect within the
warranty period. This warranty is extended to all WTI products purchased and used
within the United States of America and is valid only when service is rendered by the
authorized WTI (Wireless Technology, Inc.) Warranty Station.
This warranty shall not apply to appearance or accessory items including, but not limited
to, knobs, connectors, cabinets and connecting cables. This warranty shall not, in
addition, apply to repairs or replacements necessitated by any cause beyond the control of
WTI including, but not limited to, acts of nature, improper installation, misuse, lack of
proper maintenance, accident, voltage fluctuations, unauthorized repairs or modifications.
This warranty becomes void in the event serial numbers are altered, defaced or removed,
or an attempt is made to field service or alter performance of any WTI products.
WTI reserves the right to make changes in design, or to make additions to, or
improvements upon, products without incurring any obligation to install the same on
products previously manufactured.
The foregoing is in lieu of all other warranties expressed or implied and WTI neither
assumes nor authorizes any person to assume for it any other obligation or liability in
connection with the sale of our products. In no event shall WTI or its Authorized Dealers
be liable for special or consequential damage arising from the use of this product, or any
delay in the performance of this warranty due to causes beyond its control.
SW720-H.264-HD WTI ~ Page 4 of 31

PRODUCT WARRANTY AND REPAIR
REPAIR AUTHORIZATION
Please contact Wireless Technology, Inc. (WTI), to obtain a repair authorization number
(RA) and provide the following information:
1.) Product Model & Serial Numbers
2.) Date of shipment, purchase order number, sales order number or WTI invoice
number.
3.) Details of the defect or malfunction. If there is a dispute regarding the warranty or
product, which does not fall under the warranty conditions stated within the
description of the written warranty, please include a written explanation with the
product when returned.
SHIP FREIGHT PRE-PAID TO:
WTI (Wireless Technology, Inc.)
2064 Eastman Avenue, Suite 113
Ventura, CA 93003-7787
TEL [phone]
FAX [phone]
RETURNS
No unauthorized returns will be accepted. All returns must have an authorized (RA)
number issued by the factory (CA number if returned for credit and RA number if
returned for repair). Products returned for repair or credit will be rejected if no
authorization number has been issued or freight has not been pre-paid. All merchandise
returned for credit will be subject to a 20% restocking and refurbishing charge.
SW720-H.264-HD WTI ~ Page 5 of 31

SAFEGUARDS
IMPORTANT SAFEGUARDS
1.) Read Instructions. It is important to read all safety and operating instructions
before installing or using this equipment.
2.) Retain Instructions. Retain this manual and any supplements for future reference.
3.) Follow Instructions. Follow all instructions herein for use of this equipment.
4.) Heed all warnings. Adhere to all warnings on the equipment, and in this manual.
5.) To reduce the risk of electric shock or equipment damage, work on the unit only
when the power is shut off and is unplugged from its power source to prevent
accidental activation. Also take precautions to avoid contact between the
equipment and other electrical wires or power sources that may be present at the
installation site.
SW720-H.264-HD WTI ~ Page 6 of 31

GENERAL DESCRIPTION
The Sidewinder SW720-H264-HD is a pan-tilt-zoom camera system that provides high
definition color video in a variety of resolutions, up to 1080p30, over an Ethernet
connection, using H.264 or MJPEG video compression. The camera provides 360 degree
continuous rotation in both the pan and tilt axes, and provides an optical zoom
magnification of 20 times or 30 times. A self-cleaning hydrophilic coating is provided on
the front lens window of the camera to ensure clear, crisp video images and to reduce
maintenance. An electrically conductive Indium-Tin-Oxide coating is provided on the
inside of the front lens window to heat it and prevent fogging.
The Sidewinder SW720-H.264-HD camera operates on AC line voltages within a voltage
range of 85VAC to 265VAC and an operating frequency of 47Hz to 63Hz. Optional
24VAC power is also available (Side Egress Only). Ethernet 10/100Base-T
communication is used for transport of the video and control signals. Power and Ethernet
signals are provided via a 36 inch long bottom egress umbilical cable bundle using an
outdoor rated SJOOW #18x3 power cable, an outdoor rated shielded CAT-5e Ethernet
cable and an RG-59 video cable. The camera umbilical cable is terminated with an 18 Pin
MS style male connector or a 16 Pin AMP connector. An optional side egress connector
arrangement is also available.
The Sidewinder SW720-H264-HD camera is capable of supporting an H.264 and a
second H.264 or MJPEG compressed video stream simultaneously. Support is provided
for unicasting and multicasting.
The SW720-H264-HD camera provides Ethernet ports for support of industry standard
PTZ control protocols such as Pelco D, COHU, NTCIP, ONVIF and others. Legacy
support for physical camera control units can be implemented using serial port to
Ethernet converters.
Signals wiring for an RS-485 serial data port and analog NTSC video output are both
provided to support upgrading legacy camera installations or for replacing cameras with
similar signal interfaces from other manufacturers.
SW720-H.264-HD WTI ~ Page 7 of 31

MODELS AND FEATURES
The Sidewinder High Definition IP cameras are available with several signal connector
arrangements, two different block cameras, optional electric brakes and optional
pressurization. The following table provides a quick reference to the major features
available in each camera model.
MODEL
36 INCH MS UMBILICAL 36 INCH AMP UMBILICAL SIDE EGRESS MS X20 ZOOM BLOCK CAMERA X30 ZOOM BLOCK CAMERA PRESSURIZATION ELECTRIC BRAKES
SW720-H.264-HD x x
SW720-H.264-HD-ENG x x x
SW720-H.264-HD30 x x
SW720-H.264-HD30-ENG x x x
SW720P-H.264-HD x x x
SW720P-H.264-HD-ENG x x x x
SW720P-H.264-HD30 x x x
SW720P-H.264-HD30-ENG x x x x
SW720HV-H.264-HD x x
SW720HV-H.264-HD-ENG x x x
SW720HV-H.264-HD30 x x
SW720HV-H.264-HD30-ENG x x x
SW720AMP-H.264-HD x x
SW720AMP-H.264-HD-ENG x x x
SW720AMP-H.264-HD30 x x
SW720AMP-H.264-HD30-ENG x x x
SW720-24-H.264-HD x x
SW720-24-H.264-HD30 x x
SW720P-24-H.264-HD30 x x x
SW720-H.264-HD WTI ~ Page 8 of 31

INSTALLATION
RECOMMENDED TOOLS FOR PROPER INSTALLATION
1) Tie wraps to secure cable runs.
2) Set of open end wrenches including 7/16” for mounting bolts.
3) Cordless power drill for mounting some brackets.
4) Safety cable recommended (prevents camera falling during overhead
installations).
5) Self-sealing connector tape to weatherproof all cable connections.
INSTALLATION PLANNING
1) The maximum cable length that should be planned for is 100 meters, based on the
limit for 10/100Base-T Ethernet connections.
2) The Sidewinder SW720-H264-HD camera draws up to 50 Watts maximum,
which translates to about 0.59 Amps at the low line voltage limit of 85VAC.
3) Be sure to verify that there are no physical obstructions that might prevent the
camera from turning freely in all directions.
4) Be sure to verify that there are no physical obstructions in the way of any required
viewing directions.
5) Be sure that there is access to the end of the umbilical cable on the bottom of the
camera to facilitate connecting and disconnecting the camera while it is in place
on the mounting bracket or pole.
UNPACKING
Please examine the equipment carefully when unpacking the shipping container. If any
damage is noted please be sure to file a claim with the carrier. WTI is not responsible for
any damage that occurs during shipping. Please verify that all of the contents are present
and carefully check the packing material for any loose items before recycling it.
EQUIPMENT SUPPLIED WITH UNIT
1.) Camera
2.) 4 each ¼-20 x ¾” mounting screws with washers
3.) Quick Start Manual
EQUIPMENT THAT MAY BE REQUIRED, BUT NOT SUPPLIED WITH UNIT
1.) Mating connector and strain relief for umbilical extension cable
2.) Camera mounting bracket
3.) Interconnect cables
4.) Video monitor
5.) PC or laptop computer
6.) Setup software
SW720-H.264-HD WTI ~ Page 9 of 31

DIMENSIONS AND MOUNTING
MECHANICAL DIMENSIONS
BOTTOM EGRESS
SIDE EGRESS
SW720-H.264-HD WTI ~ Page 10 of 31

MOUNTING
The Sidewinder SW720-H264-HD camera should normally be mounted in an upright
orientation, as shown above. The camera may also be mounted upside down if desired,
but a cover of some sort should be placed over the bottom of the camera, extending out to
about 6 inches past the camera all around, to prevent debris, dirt or snow and ice from
accumulating on the bottom of the camera housing, since the conical shaped profile of the
camera will no longer be able to naturally shed material to the sides. The camera may
NOT be mounted with the base facing horizontally.
The base of the Sidewinder SW720-H.264-HD camera has four ¼-20 screw holes that are
equally spaced, 90 degrees apart, on a 4.75” diameter circle, as shown in figure 2 (Note
that 24VAC versions of the Sidewinder camera will have 5/16” mounting screws). If
mounting screws other than those provided with the camera are used, the length of the
mounting screws should be selected so that the screws penetrate no more than 0.75 inches
into the base.
SW720-H.264-HD WTI ~ Page 11 of 31

MOUNTING ACCESSORIES
WTI manufactures several different mounts for the Sidewinder SW720A that allow the
camera to be attached to pole tops, horizontal poles, vertical poles and walls. The
Sidewinder SW720-H.264-HD camera is supplied with a 36 inch umbilical cable to allow
the cable to be routed through the camera mount before the actual physical installation of
the camera.
SWWM1 – Wall Mount Option
SW720-H.264-HD WTI ~ Page 12 of 31

SWWM1 + SWVPA – Wall Mount with Vertical Pole Adapter
SW720-H.264-HD WTI ~ Page 13 of 31

SWPTM1 – Pole Top Mount
SW720-H.264-HD WTI ~ Page 14 of 31

SWHPM1 – Horizontal Pole Mount
SW720-H.264-HD WTI ~ Page 15 of 31

15-4-1430 – 6”x6”x3/8” Square Mounting Plate
SW720-H.264-HD WTI ~ Page 16 of 31

15-4-913 – 6”Round Riser Mounting Base
SW720-H.264-HD WTI ~ Page 17 of 31

120VAC MS SIGNAL CONNECTIONS
The Sidewinder SW720-H.264-HD is provided with a 36 inch umbilical cable and is
available with an 18 pin MS Style connector at the end. The umbilical cable provides the
power and Ethernet data and control signals for the camera. The umbilical cable exits
through the bottom of the camera housing. These connector pin outs are for all SW720-
H.264-HD models except for 24VAC and AMP connector models.
Mating Connector
Female MS Connector - Style MIL-DTL-26482
Amphenol P/N MS3116F-14-18S
Shell Size 14 - 18 Contact Pattern
PIN Signal Description Wiring Color Code and Wire
Recommendations
A Analog Video Shield RG-59U Shield
B
C
D Ethernet Tx+ Orange/White CAT-5e
E Ethernet Tx- Orange CAT-5e
F Ethernet Rx+ Green/White CAT-5e
G AC Safety Ground SJOOW Green (18 AWG)
H Ethernet Rx- Green CAT-5e
J
K
L Analog Video Output RG-59U Center
M RS-422 RX + Brown CAT-5e
N RS-422 RX - Brown/White CAT-5e
P RS-422 Data Shield CAT-5e Shield (Belden 1300A)
R RS-422 TX - Blue/White CAT-5e
S RS-422 TX + Blue CAT-5e
T AC Line Neutral (low) SJOOW White (18 AWG)
U 85-265 AC Line Input (high/hot) SJOOW Black (18 AWG)
SW720-H.264-HD WTI ~ Page 18 of 31

24 VAC MS STYLE SIGNAL CONNECTIONS
SW720-24-H.264-HD - Side egress 18 Pin MS style connector
SW720-24-H.264-HD30 - Side egress 18 Pin MS style connector
SW720P-24-H.264-HD30 - Side egress 18 Pin MS style connector
Mating Connector
Female MS Connector - Style MIL-DTL-26482
Amphenol P/N MS3116F-14-18S
Shell Size 14 - 18 Contact Pattern
PIN Signal Description Wiring Color Code and Wire Recommendations
A Chassis Ground Overall Shield Drain Wire
B Ethernet TX+ CAT-5 Orange/White
C Ethernet TX- CAT-5 Orange
D 24 VAC - 1 White 20 AWG Minimum
E 24 VAC - 1 White 20 AWG Minimum
F 24 VAC - 2 Black 20 AWG Minimum
G
H Analog Video Shield RG-59U Shield
J RS-422/485 Rx- CAT-5 Brown/White
K RS-422/485Tx- CAT-5 Blue/White
L Data Ground Data Cable Shield
M RS-422/485 Tx+ CAT-5 Blue
N Ethernet RX- CAT-5 Green
P AC Safety Ground Green 20 AWG Minimum
R 24 VAC - 2 Black 20 AWG Minimum
S Analog Video Output RG-59U Center
T RS-422/485 Rx+ CAT-5 Brown
U Ethernet RX+ CAT-5 Green/White
SW720-H.264-HD WTI ~ Page 19 of 31

120VAC AMP STYLE SIGNAL CONNECTIONS
SW720AMP-H.264-SD - 36 inch umbilical cable with a 16 pin AMP style connector
Mating Connector
AMP Connector - P/N 206037-1
Clamp – P/N 1310307
16 Contact Pattern
Female Pins – 3 each – P/N 66565-4 - #20-24
Female Pins – 12 each – P/N 66109-4 - #24-26
PIN Signal Description Wiring Color Code and Gauge
Recommendations
1 Analog Video Output RG-59U Center
2 Analog Video Shield RG-59U Shield
3 Data Ground Cat-5e Data Cable Shield
4 RS-485 Tx- CAT-5e Blue/White
5 RS-485 Tx+ CAT-5e Blue
6 RS-485 Rx+ CAT-5e Brown
7 RS-485 Rx- CAT-5e Brown/White
8 Ethernet TX+ CAT-5e Orange/White
9 Ethernet TX- CAT-5e Orange
10 Ethernet RX+ CAT-5e Green/White
11 Ethernet RX- CAT-5e Green
12 85-265 AC Line Hot SJOOW Black (18 AWG)
13 AC Line Neutral SJOOW White (18 AWG)
14 spare
15 115 VAC Safety Ground SJOOW Green (18 AWG)
16 Spare
SW720-H.264-HD WTI ~ Page 20 of 31
