WURM W-LINK-CAN User manual

W-LINK-CAN
Product information
W-LINK-CAN_V1.70_PI_2018-08_EN Subject to technical changes Page 1 of 4
1 Front view
Receiver unit for W-LINKpro wireless product temperature sensors
2 Features
Internal documentation and alarm for up to 8 wireless sensors
Housing for wall or ceiling installation
Connection to the Wurm system via a communication bus (CAN bus) and Frigodata XP

W-LINK-CAN
Product information
Page 2 of 4Subject to technical changes W-LINK-CAN_V1.70_PI_2018-08_EN
Writing conventions
Symbol
Meaning
CAUTION!
Avoid the described hazard: otherwise minor or medium physical injury or
damage to property will result.
WARNING!
Avoid the described hazard: otherwise there is danger from electric voltage that
could lead to death or serious physical injury.
For your safety
For safe operation and to avoid personal injury and equipment damage through operating error,
always read these instructions, become familiar with the device, and follow all safety instructions on
the product and in this document, as well as the safety guidelines of Wurm GmbH & Co. KG
Elektronische Systeme. Keep these instructions ready to hand for quick reference and pass them on
with the device if the product is sold.
Wurm GmbH & Co. KG Elektronische Systeme accepts no liability in case of improper use or use for
other than the intended purpose.
Target group
These instructions are intended for service technicians.
Intended use
The W-LINK-CAN receiver unit receives temperatures from W-LINKpro
wireless product temperature sensors for documenting and monitoring and
provides them to other devices via the CAN bus.
WARNING!
Danger to life from electric shock and/or fire!
Switch off the power to the entire plant when installing, wiring or removing! Otherwise a
mains voltage and/or external voltage may still be present even if the control voltage is
switched off!
The wiring of the device should be carried out only by a qualified electrician!
Use only the correct tools for all work!
Check all wiring after connection!
Take note of the maximum loads on all connections!
Never expose the device to moisture, for example due to condensation or cleaning
agents!
Take the device out of operation if it is faulty or damaged and is therefore compromising
safe operation!
Do not repair the device yourself! If required, send it in for repair with an exact
description of the fault!
CAUTION!
Electromagnetic interference can cause faults!
Use only shielded data lines and place them far away from power lines!
Software version and validity of the documentation
Software version
Functional upgrade
Page
V1.5
2009-05
Basis of documentation
2011-04
Reception antenna folds to positioning angles 0°, 45° and 90°.
4
V1.70
2017-01
Front view, safety instructions, installation, technical data modified
1-4
2018-08
Documentation updates
This document automatically ceases to be valid if a new technical description is issued.
Manufacturer: Wurm GmbH & Co. KG Elektronische Systeme, Morsbachtalstraße 30, D-42857 Remscheid
For further information, see our website at www.wurm.de

W-LINK-CAN
Product information
W-LINK-CAN_V1.70_PI_2018-08_EN Subject to technical changes Page 3 of 4
3 Installation
Fig. 1 Wall or ceiling installation, drilling dimensions in mm
Wall or ceiling installation
1.
Insert a flat screwdriver into the opening
slit (A) and open both housing panels
(B).
2. Refer to the drilling dimensions of the
four mounting holes (C) and install the
housing on the wall or ceiling.
Access to connections, coding
switch and LEDs
1. Loosen the four screws (D).
2. Open the housing.
(→Chapter 4 "Connections" on page 4)
Fig. 2 Wall installation
Fig. 3 Ceiling installation
Adjusting the antenna
In order to receive a uniform signal, always
place the antenna rod vertically.
• For wall installation: place the antenna
rod vertically. (→Fig. 2)
• For ceiling installation: fold the antenna
rod vertically. (→Fig. 3)
Fig. 4 Setting up the receiver and transmitter
Setting up the receiver and
transmitter
The range of radio waves in the wall area
and in the vicinity of existing objects is
influenced by disruptive scattering or
reflection. To avoid this, install the receiver
and transmitter as follows:
• Do not install on the same wall side in
order to avoid radio propagation along a
wall surface
• Install on opposite or adjoining wall
surfaces (→Fig. 4)
• Install the receiver with a distance of at
least 50cm to other transmitters and
high-frequency sources of interference
such as GSM, DECT, wireless LAN or
computer, audio and video systems
• Tip: Improve reception by moving the
transmitter and receiver
Note!
•
Further installation instructions can be found in the W-LINKpro System Description.

W-LINK-CAN
Product information
Page 4 of 4Subject to technical changes W-LINK-CAN_V1.70_PI_2018-08_EN
4 Connections
WARNING! Danger of death from electric shock and/or fire!

The wiring of the device should be carried out only by a qualified electrician!
Note!
•Open the housing to access the connections,
coding switches and LEDs. (→Chapter 3
"Installation" on page 3)
No.
Function
Description
1
CAN bus connection
2
CAN bus terminating resistor
3
Coding switch
1-7
CAN address: for determining the CAN address in binary coding. The
address is the sum of the weights of the switches set to "ON".
Example: to set address 40, slide switches 4 and 6 to ON. The sum of the
weights 8+32 is 40.
Coding switch
1
2
3
4
5
6
7
Weight at ON setting
1
2
4
8
16
32
64
8
Baud rate:
ON = 20kBit/s (fixed)
OFF= Automatic mode
4
Status LEDs
(from left to right)
1
Operating voltage and ready for use (flashes 1x per second)
2
No function
3
No function
4
No function
5
Receipt of a wireless telegram
6
CAN bus reception LED
7
CAN bus transmission LED
5
Mains power supply
230V
5 Technical data
Power supply
230V~, +10% / -15%, approx. 3VA
Display
Visible with housing open:
1 x LED, operation indicator
2 x LED, CAN bus data traffic
1 x LED, wireless reception
Communication
3-wire CAN bus interface
Dimensions
(WxHxD) 120 x 90 x 50mm
Fastening
Wall or ceiling installation
Ambient temperature
Operation: 0...+55°C, storage: -25…+70°C
Weight
About 350g
Reception antenna
Folds to positioning angles 0°, 45° and 90°
Technology
EnOcean, RCM
Transmission frequency
868.3MHz
Range
Building: approx. 30m, open area: approx. 300m
CE conformity
EU conformity as defined in
- 2014/53/EU (Radio Equipment Directive)
General approval for wireless operation applies for all EU countries and Switzerland.
RoHS II
Valid from
Version 1.70
