Wyse Mobile Thin Computer User manual

Users Guide
Wyse®Mobile Thin Computer
Issue:110207
PN: 883904-01 Rev. A

ii
Copyright Notice
© 2007, Wyse Technology Inc. All rights reserved.
This manual and the software and firmware described in it are copyrighted. You may not reproduce, transmit,
transcribe, store in a retrieval system, or translate into any language or computer language, in any form or by any
means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, any part of this publication
without express written permission.
End User License Agreement (“License”)
A printed copy of the Wyse Technology End User License Agreement is included in the shipping box and
provided for your reference only. The License at http://www.wyse.com/license as of the purchase date is the
controlling licensing agreement. By copying, using, or installing the software or the product, you agree to be
bound by those terms.
Trademarks
Wyse and Winterm are registered trademarks, and the Wyse logo and Winterm logo are trademarks of Wyse
Technology Inc. ICA is a registered trademark and MetaFrame is a trademark of Citrix Systems Inc. Microsoft
and Windows are registered trademarks of Microsoft Corporation. All other products are trademarks and/or
registered trademarks of their respective companies. Specifications subject to change without notice.
Patents
This product and/or associated software are protected by copyright, international treaties, and various patents,
including the following U.S. patents: 6,836,885 and 5,918,039.
Restricted Rights Legend
You acknowledge that the Software is of U.S. origin. You agree to comply with all applicable international and
national laws that apply to the Software, including the U.S. Export Administration Regulations, as well as
end-user, end-use and country destination restrictions issued by U.S. and other governments. For additional
information on exporting the Software, see http://www.microsoft.com/exporting.
Ordering Information
For availability, pricing, and ordering information in the United States and Canada, call 1-800-GET-WYSE
(1-800-438-9973) or visit us at http://www.wyse.com. In all other countries, contact your sales representative.
FCC Statement
This equipment has been tested and found to comply with the limits for either Class A or Class B digital devices
(refer to "Regulatory Compliance for Thin Computers"), pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and the receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
Shielded interconnect cables and shielded AC power cable must be employed with this equipment to insure
compliance with the pertinent RF emission limits governing this device. Changes or modifications not expressly
approved by the system's manufacturer could void the user's authority to operate the equipment.

iii
Caution
Changes or modifications not covered in this manual must be approved in writing by the
manufacturer’s Regulatory Engineering department. Changes or modifications made without
written approval may void the user’s authority to operate the equipment.
Regulatory Compliance for Thin Computers
EMC and Safety Requirements
Model XX0 thin computers are compliant with the regulatory requirements in the regions listed below.
U.S.A. - FCC Part 15 (class B)
Canada - CAN/CSA-C22 No. 60950
Europe - EN 55022 (class B), EN 61000-3-2 (class A), EN 61000-3-3, EN 90650-1:2000+ALL
Canadian DOC Notices
Class A
This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus set out in
the Radio Interference Regulations of the Canadian Department of Communications.
Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicables aux
appareils numériques de la classe A prescrites dans le Réglement sur le brouillage radioélectrique édicté par le
Ministère des Communications du Canada.
Class B
This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus set out in
the Radio Interference Regulations of the Canadian Department of Communications.
Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicables aux
appareils numériques de la classe B prescrites dans le Réglement sur le brouillage radioélectrique édicté par le
Ministère des Communications du Canada.
IEC/EN Notice
These products conform to the requirements of IEC950 and EN60950.
These products conform to requirements of EN55022 for Class A equipment or EN55022 for Class B equipment
(refer to "Regulatory Compliance for Thin Computers").
Wireless Usage and Requirements
Radio transmitting type devices (RF module) are present in the Model XX0 as an option. These devices operate in
the 2.4 GHz band (i.e. 802.11b/g WLAN & Bluetooth).
As a general guideline, a separation of 20 cm (8 inches) between the wireless device and the body, for use of a
wireless device near the body (this does not include extremities) is typical. This device should be used more than
20 cm (8 inches) from the body when wireless devices are on and transmitting.
Some circumstances require restrictions on wireless devices. Examples of common restrictions include:
•When in environments where you are uncertain of the sanction to use wireless devices, ask the applicable
authority for authorization prior to use or turning on the wireless device.
•Every country has different restrictions on the use of wireless devices. Since your system is equipped with a
wireless device, when traveling between countries with your system, check with the local Radio Approval
authorities prior to any move or trip for any restrictions on the use of a wireless device in the destination
country.
•Wireless devices are not user-serviceable. Do not modify them in any way. Modification to a wireless device
will void the authorization to use it. Please contact the manufacturer for service.

iv
Cable Notice
The use of shielded I/O cables is required when connecting this equipment to any and all optional peripheral or
host devices. Failure to do so may cause interference and violate FCC and international regulations for
electromagnetic interference.
Device Power Supply
Model XX0 thin computers use an external power adapter. Use only with Wyse approved power adapters (refer
to the Wyse Web site).
Caution
Replace power adapter with the same or equivalent type as recommended by the manufacturer.
Battery Information
Model XX0 thin computers contain a replaceable battery. The battery is designed to work with your Wyse thin
computer. Do not use a battery from other thin computers with your thin computer. Replace the battery only with
a compatible battery purchased from Wyse (refer to the Wyse Web site).
Warning
There is a risk of explosion if the battery is replaced by an incorrect type. Always dispose of used
batteries according to the instructions accompanying the battery.
Caution
Misuse of the battery may increase the risk of fire of chemical burn. Do not puncture, incinerate,
disassemble, or expose the battery to temperatures above 65°C (149°F). Keep the battery away
from children. Handle damaged or leaking batteries with extreme care. Damaged batteries may
leak and cause personal injury or equipment damage.

Contents
1 About This Guide
About this Guide 1
Organization of this Guide 1
Important Safeguards 2
Caution Statements 2
Wyse Technical Support 3
Links to Related Documentation and Services 3
2 Introducing Your Thin Computer
Check the Package Contents 5
Features 5
Inside View 6
Front View 6
Back View 7
Right Side View 7
Left Side View 8
Bottom View 8
3 Getting Started
Setting Up Your Thin Computer 9
Step 1 - Install the Battery 9
Step 2 - Connect the Power Cable 9
Step 3 - Turn On the Thin Computer 10
Turning Off the Thin Computer 10
Removing the Battery 10
Adjusting the Volume 11
Adjusting the Brightness 11
System Indicator Lights 11
Keyboard Function Keys for System Control 12
Numeric Keypad 13
Touch Pad 13
Dragging 14
Scrolling 14
Touch Pad Precautions 14
Connecting a Printer 14
Power Management 15
Calibrating the Battery 15
Monitoring Battery Power 15
Low Battery Alarms 16
Battery Charging 16
When to Replace the Battery 17
Changing the Battery 17
Power Saving Modes 17
Stand by Mode 17
Initiating Stand by Mode 18
Power Button Settings 18

vi
Power Saving Tips 18
Heat Considerations 18
Graphics System 19
Screen Controls 19
Connecting to an External Monitor 19
Dual Displays 20
4 Making Connections
Wired Net/LAN 21
Wi-Fi 21
Making a Connection 21
Adding a Certificate 22
Express Card 22
Installing a Card 22
Removing a Card 23
Express Card Size Restrictions 23
Bluetooth 23
Creating a Partnership Between Phone and Thin Computer 23
Thin Computer Setup for Windows Bluetooth DUN 25
Disconnecting Windows Bluetooth DUN 28
5 Using the BIOS Setup Utility
Using the BIOS Setup Utility 29
BIOS Setup Menu 29
Starting the BIOS Setup Utility 29
Navigating and Entering Information in BIOS 29
Main Menu 30
Advanced Menu 31
Boot Menu 31
Security Menu 32
Exit menu 32
Changing the User Password 33
Changing the Supervisor Password 33
Resetting the CMOS to Default Settings 33
Exiting and Saving 33
6 Establishing a Server Environment
Setting Up Access to the Enterprise Servers 35
7 Frequently Asked Questions
List of Figures
List of Tables

1About This Guide
The Wyse X90 and X90e are the newest wireless mobile thin computers in the Wyse X
class of mobile thin computers. The Wyse X90 and X90e use the Windows™ XP
Embedded (XPe) operating system. These thin computers provide access to applications,
files, and network resources made available on machines hosting Citrix™ ICA and
Microsoft™ RDP session services. Generally the keyboard, mouse, audio/video, and
display data are transmitted over the network between the thin computer and session
servers. Locally installed software permits remote administration of the thin computers
and provides local maintenance functions.
About this Guide
This users guide is written primarily for desktop users. It contains detailed information you
will need to use and troubleshoot the mobile thin computer.
Organization of this Guide
This guide is organized as follows:
Chapter 2, "Introducing Your Thin Computer," provides package contents, features, and
detailed views of your mobile thin computer.
Chapter 3, "Getting Started," provides information on setting up and using your thin
computer, power management, and the graphics system.
Chapter 4, "Making Connections," provides information about the various ways your thin
computer makes connections.
Chapter 5, "Using the BIOS Setup Utility," provides instructions for using the BIOS menus
available on your thin computer.
Chapter 6, "Establishing a Server Environment," contains information on the network
architecture and enterprise server environment needed to provide network and session
services enabling Wyse XX0 thin computers network connection. It also includes
information to help you to address important considerations when configuring access to
the server environment and when configuring the services to be provided by the server
environment.
Chapter 7, "Frequently Asked Questions," contains information and help on installation,
setup, conflicts, and general troubleshooting.

2Chapter 1
Important Safeguards
Please adhere to the following important safeguards:
• Follow all warnings and instructions noted in this documentation and in the Windows
Help program.
• The first time you use your thin computer, we recommend that you carefully read the
"Introducing Your Thin Computer" section of this manual and initialize the battery to
ensure optimum battery performance.
• To clean your thin computer, first disconnect it from the electrical outlet, and then use a
soft cloth dampened with water for cleaning. Do not use aerosols, solvents, or strong
detergents.
• Do not use the thin computer near open water or other liquids. Never spill liquid onto
the thin computer.
• Do not place the thin computer in an unstable location where it might slip or be
knocked over. Serious damage could result from a fall.
• Slots and openings in the system cabinet are for ventilation purposes. Do not block or
cover these openings or the system could overheat. Do not use or store the thin
computer near a source of heat or dust.
• On the bottom of this thin computer, there is a label with information on the power
requirements of this system. These requirements must be followed. If you are unsure
of your local power supply, consult your dealer or local power company.
• Do not step on or place anything on the power cable or power adapter.
• If you use the thin computer with an extension cord, ensure that the total ampere
ratings of all the devices sharing the extension do not exceed the rating of the
extension cord or the rating of the wall outlet.
• Never push foreign objects into the thin computer through any of the slots or openings.
Dangerous voltages are present, which could cause electric shock or fire, or damage
sensitive components.
• For best results, use a power strip with a built-in surge protector. Do not use inferior
extension cords as this may result in damage to your thin computer.
Caution Statements
Improper connection or use of this product could result in component failure or undesired
interference. Read the following caution statements before setting up and operating your
thin computer.
Setup
• Do not force a connector into its socket. If any undue resistance is encountered,
ensure that the connector is correctly oriented to the receptacle.
• The main unit is not user serviceable; opening or accessing the case may violate your
warranty.
• For wireless usage and requirements, refer to the regulatory notices in the thin
computer’s documentation.
Venting and Care
• Allow sufficient space around your thin computer for ventilation; do not place your thin
computer in any enclosure that restricts airflow around the device, such as a closed
briefcase, while the computer is turned on. Restricting airflow can damage your thin
computer or cause a fire; do not place any objects on the device or block the vent holes

About This Guide 3
under the device. Find environmental operating specifications in the thin computer’s
datasheet located at http://www.wyse.com/products.
• Do not allow your thin computer to rest directly on exposed skin for extended periods of
time during operation. The base surface temperature will rise during normal operation
(particularly when AC power is used). Prolonged contact with exposed skin can cause
discomfort or a burn.
Power Sources
• To ensure regulatory compliance, use only the power adapter included in the shipping
carton, or a Wyse-approved equivalent, with your thin computer. Refer to the regulatory
notices in your thin computer’s documentation.
• You can connect the power adapter at any time with the thin computer turned either on
or off.
• Do not hard reset your thin computer by holding down the power button during normal
operation.
• When turning off your thin computer, be sure to perform a complete shutdown (via the
user interface). Do not disconnect the AC power cable, DC power adapter cable, or
shut off power at a circuit breaker (including power strips), etc., to turn off the device.
• Surge protectors for electrical devices are recommended in areas of lightning.
However, when lightning is occurring, your equipment should be properly shut down
and unplugged from AC power until the storm has passed.
• Dispose of your battery properly when it no longer holds a charge or is damaged.
Contact your local waste or environmental agency for instructions.
Warning
The X class mobile thin computers contain a replaceable battery. There is a
risk of explosion if the battery is replaced by an incorrect type. Always
dispose of used batteries according to the instructions accompanying the
battery.
Wyse Technical Support
To access Wyse technical resources, visit http://support.wyse.com.If you still have
questions, you can submit your questions using the Wyse Self-Service Center or call
Customer Support at 1-800-800-WYSE (toll free in U.S. and Canada). Hours of operation
are from 6:00 am. to 5:00 pm. PST, Monday through Friday.
To access international support, visit http://www.wyse.com/global
Links to Related Documentation and Services
Wyse mobile thin computer features can be found in the Datasheet for your specific thin
computer model. Datasheets are available on the Wyse Web site at:
http://www.wyse.com/products.
Administrator and User documentation for your thin computer model are available on the
Wyse Web site at: http://www.wyse.com/manuals.
Wyse Thin Computing Software is available on the Wyse Web site at:
http://www.wyse.com/products/software.
If you need to upgrade your XPe operating system, contact Wyse Customer Support at:
http://support.wyse.com.

4Chapter 1
This page intentionally blank.

2Introducing Your Thin Computer
This section provides package contents, features, and detailed views of your thin
computer.
Check the Package Contents
After opening the package, carefully inspect the contents. If any of the items is missing or
appear damaged, contact your dealer. The shipping carton should contain the following:
• Thin computer
• Battery
• Power adapter with AC power cable
Caution
When purchasing any of the accessories listed above, purchase only those
accessories that are approved for use with your thin computer. The above
accessories are proprietary items. Your system vendor can obtain these
approved accessories. If you use items that are not approved for use with
this thin computer, you may cause your thin computer to malfunction, or to
emit or receive electromagnetic radiation in excess of local regulations. For
non-proprietary accessories such as PC cards or printers, ensure that the
accessory functions properly in your thin computer before making the
purchase. Your system vendor may be able to recommend reliable brands
and models.
Features
Features that the thin computer include:
•LAN Capability - A built-in 10/100 Mbps Ethernet port allows you to access the
Internet or a local area network (LAN).
•LCD - Your thin computer has an easy-to-view WXGA LCD panel.
•Built-in Stereo Speakers - The stereo speakers and enable you to run a variety of
multimedia applications.
•Convenient Audio Control - The conveniently located audio control keys enable you
to easily adjust the volume to the stereo speakers.
•Launch Key and Function Keys - One Instant on hot keys gives you quick access to
a variety of applications. Function keys give you easy control of power management,
volume, and your display.

6Chapter 2
Inside View
Front View
(1) Wireless LAN and Bluetooth on/off switch - Enables the wireless functions to be
turned off if needed during air travel or similar situation.
(2) Microphone in - Connect a microphone to this port to record.
(3) Line out/Headset out - Connect a stereo headset or external speakers to this port to
listen to multimedia.
(1) Display (4) Touch pad buttons
(2) Power on/off button (5) Touch pad
(3) Keyboard (6) System indicator lights

Introducing Your Thin Computer 7
Back View
(1) LAN RJ-45 network port - With the built-in Ethernet LAN combo, you can make LAN
connections. Connection speed is up to 100 Mbps.
Right Side View
(1) Express 34/54 card slot* - This slot is where an Express 34/54 card is inserted.
(2) USB 2.0 ports - Use for attaching monitors, input devices, scanners, and other
devices to a PC. USB devices can be chained together on a single cable.
(3) VGA external video display port - The 15-pin VGA port can be used to connect your
thin computer to an external monitor (see "Graphics System").
*Express card slot accepts either ExpressCard/34 or ExpressCard/54 formats.
Note
The USB 2.0 port constantly supplies 5V power to the external USB device
even when the system is at power off state. This enables external USB
device to be charged at any time without turning on the system. To prevent
draining the battery power when the system is power off, remove the external
USB device when not in use.

8Chapter 2
Left Side View
(1) Kensington lock slot - Your thin computer includes a Kensington lock hole to be used
with a standard Kensington lock. You can connect the thin computer to a large object with
the Kensington lock to prevent theft of your thin computer. See the documentation that
comes with your Kensington lock for more information.
(2) Power adapter input - Connect the DC power cable from the power adapter to this
port.
(3) Smart card slot* - Insert card with electrical contacts facing upwards.
*Smart card slot is a feature for X90e.
Bottom View
(1) Speaker
(2) Battery release latch - Slide and hold to unlatch.
(3) Battery
(4) Battery lock - Slide to unlock.

3Getting Started
This section provides information on setting up and using your thin computer, power
management, and the graphics system.
Setting Up Your Thin Computer
To quickly set up your thin computer follow the next three simple steps.
Step 1 - Install the Battery
With your thin computer turned off, insert battery in the battery compartment located on
the underside of the thin computer and secure it by sliding the latches.
1. Slide the battery lock (3) to unlock.
2. Slide and hold the battery release latch (1) as you gently insert the battery (2) into the
battery compartment. Make sure the battery is properly orientated.
3. Make sure that the battery lock (3) locks back into position.
Figure 3-1 Battery Latches
Note
The battery is not fully charged. Allow your battery to fully charge before
using it in battery mode (without the power adapter). Calibrating the battery
before use is also highly recommended (see “Calibrating the Battery” ).
Step 2 - Connect the Power Cable
Plug the power adapter connector to the thin computer as shown. Plug the AC power
cable to the power adapter, and then plug the other end of the power cable to a wall outlet.

10 Chapter 3
Figure 3-2 Connecting the Power Cable
Note
You can connect the power adapter at any time with the thin computer turned
either on or off.
Step 3 - Turn On the Thin Computer
Raise and adjust the lid, and press the power on/off button for two seconds. When you
release the power on/off button, the power LED on the system indicators turns on.
After power-on, the thin computer initially goes through several boot sequence procedures
before the operating system loads. See "Setting Up Access to the Enterprise Servers" for
information about setting up your server environment. Additional information is available in
the thin computers’ operating system documentation, Administrators Guide: Wyse®9
Series, Based on Microsoft®Windows®XP Embedded.
Turning Off the Thin Computer
Press the power on/off button for two seconds, or go to Start | Turn Off Computer and
click Turn Off.
Removing the Battery
With your thin computer turned off, slide the battery lock to unlock, and then slide and hold
the battery release latch to gently pull the battery out of the battery compartment.
Caution
Before removing battery, turn off the thin computer and disconnect the power
adapter from the electrical outlet.

Getting Started 11
Adjusting the Volume
There are two ways in which to adjust the volume:
• You can adjust the volume with the hot key combinations as follows:
•Fn + F8 decreases the volume
•Fn + F9 increases the volume
•Fn + F10 mutes the volume
• Alternatively, you can adjust the volume with the Windows volume control applet
located on the taskbar.
Adjusting the Brightness
Use the following hot key combinations to adjust the display panel brightness:
•Fn + F6 decreases the brightness
•Fn + F7 increases the brightness
System Indicator Lights
The system indicator lights for status and power are in the lower right corner of the
keyboard. The status indicators light up when a particular function of the thin computer is
active. Each indicator is marked with a symbol. The power indicators show which power
source the system is using. The power indicators remain active and viewable even when
the display panel is closed.
Table 3-1 System Indicator Lights for Status and Power
Icon Color Description
Blue
Blue flash
Thin computer is powered on
Thin computer is in sleep mode
Blue Wireless signal is enabled
Green Flash drive activity
Green Keyboard NumLk is on
Green Keyboard Caps Lock is on
Orange
Green
Battery is charging
Battery is fully charged

12 Chapter 3
Keyboard Function Keys for System Control
The numeric keypad numbers and symbols are printed in blue on the keypad keys. Press
and hold the Fn key while pressing the appropriate function key (press Fn + NumLk to
enable or disable the numberic keypad).z
Table 3-2 Keyboard Function Keys for System Control
Icon Key Description
Fn Fn Function Key
Fn + F3 Backlight - on/off
Fn + F4 stand by mode
Fn + F5 Display switch - LCD / CRT/ LCD+CRT
Fn + F6 Brightness - decrease
Fn + F7 Brightness - increase
Fn + F8 Volume - decrease
Fn + F9 Volume - increase
Fn + F10 Volume Mute - on/off
Num Lk Fn + NumLk Number lock - on/off
Scr Lk Fn + ScrLk Scroll lock - on/off
Pg Up Fn + ↑Page up
Pg Dn Fn + ↓Page down
Home Fn + ←Home
End Fn + →End

Getting Started 13
Numeric Keypad
The embedded numeric keypad consists of sixteen keys that make number intensive input
more convenient. Press NumLk to enable or disable the numeric keypad.
Figure 3-3 Numeric Keypad
Touch Pad
The touch pad is a pressure-sensitive pointing device that provides all the features of a
two-button mouse. Its primary function is to move the cursor around the screen.
Figure 3-4 Touch Pad
Touchpad Touch pad buttons
To use the touch pad:
1. Place your fingers on the keyboard in the normal typing position. The touch pad is
easily accessible by moving either your left or right thumb off the space bar and on to
the touch pad.
2. Gently move your thumb across the pressure-sensitive touch pad in the direction you
want the cursor to move. The pad detects the change in pressure and moves the
cursor in the corresponding direction.
3. The touch pad offers another method of making selections in a software program. It is
called double-tapping. This function corresponds to double-clicking with a mouse.
Once the cursor has been moved to the object you want to select, lightly double-tap the

14 Chapter 3
pressure-sensitive touch pad. This double-tapping on the touch pad will select the
desired item and prompt the software to perform the related operation.
4. The buttons located directly below the touch pad are the same in function as those on
a two-buttoned mouse. Clicking these buttons makes selections, drags objects, or
performs a variety of other functions depending on the software. To select an object,
first move the pointer over the object you want to select, and then press the left button
one time. The functions of these buttons are software specific.
5. Double-clicking is a common technique for selecting objects or launching programs
from icons. Once you have moved the pointer over the object you wish to select,
rapidly press the left button two times. This action is commonly referred to as
“double-clicking” an object.
Dragging
There are two ways to drag:
• Move the pointer to the desired location then press down the left button. While still
holding down the left button, move the pointer to the desired location. Release the
button.
• Move the pointer to the desired location. Tap the touch pad twice quickly as if you were
double-clicking; however do not remove your finger after the second tap. Move the
cursor to the desired location. Lift your finger to finish dragging.
Adjust the touch pad settings by selecting Settings | Control Panel | Mouse | Buttons.
These settings allow you to change the orientation of the touch pad from right-handed to
left-handed and fine tune the pointer movement and timing of clicks.
Scrolling
If you are scrolling through a document, you may find that using the scrolling line is more
restful to your hand than holding down a mouse button. Scrolling lines are located on the
touch pad.
Touch Pad Precautions
The touch pad is a pressure-sensitive device. If not properly cared for, it can be easily
damaged. Please take note of the following precautions:
• Make sure the touch pad does not come into contact with dirt, liquids or grease.
• Do not touch the touch pad if your fingers are dirty.
Do not rest heavy objects on the touch pad or the touch pad buttons.
Connecting a Printer
To connect a printer to your thin computer via the USB port, you will need a USB-to-printer
adapter cable. Before use, you may need to install the driver for the printer.
