wysLink WNR205 User manual

USER MANUAL
Version 1.0.0
H.265 NETWORK VEDIO RECORDER

Network Video Recorder Start Guide Ver1.0 1 / 16
Content
Chapter 1. Safety Precautions ............................................................................................................................................ 2
Chapter 2. Product Introduction ........................................................................................................................................ 3
2.1 Products Key Features ......................................................................................................................................... 3
2.2 Real Time Monitoring.......................................................................................................................................... 3
2.3 Storage ................................................................................................................................................................ 4
2.4 Back Up .............................................................................................................................................................. 4
2.5 Video / Capture Image and Playback .................................................................................................................... 4
2.6 Alarm & Exception .............................................................................................................................................. 4
2.7 Other Local Functions ......................................................................................................................................... 5
2.8 Network Functions .............................................................................................................................................. 5
Chapter 3 Operation basics ............................................................................................................................................. 6
3.1 Mouse Operation ................................................................................................................................................. 6
3.2 Input Method Description .................................................................................................................................... 6
3.3 Menu Instruction ................................................................................................................................................. 7
Chapter 4. Operation Introduction ..................................................................................................................................... 9
4.1 System connection ............................................................................................................................................... 9
4.2 Getting Started the NVR .................................................................................................................................... 10
4.3 Setup Wizard ..................................................................................................................................................... 10
4.4 Adding & Connecting a Camera......................................................................................................................... 12
4.5 Other methods to adding a Camera .................................................................................................................... 14
4.6 Local Playback .................................................................................................................................................. 14

Network Video Recorder Start Guide Ver1.0 2 / 16
Chapter 1. Safety Precautions
Be sure to observe the following precautions when using this product:
 Not place objects filled with liquids (such as glass) on NVR.
 NVR will be placed in a well ventilated location.
 Make the NVR work within the allowable temperature and humidity range.
 Battery incorrectly replacing may cause explosion hazard, do not recommend users to directly
replace; For replacement, only to be replaced with the same type or equivalent type of battery.
 When installing, be sure to turn off all power to the device.
This manual may contain technical inaccuracies, or not cover all product features or new functions. It will be
updated according to enhance product features, and will be regularly updated product or process
improvements or described in this manual, updated content will be added in the new version of this manual
without notice.
( Production Model WNR205 is implemented with inside PCB of model NBD-2608NEA, support upto 5M
network camera )

Network Video Recorder Start Guide Ver1.0 3 / 16
Chapter 2. Product Introduction
2.1 Products Key Features
 Support H.264/H.264+/H.265/H.265+Video Stream encoding.
 Each channel supports dual stream compression, in which the mainstream up to 8M/5M resolution,
sub stream supports up to D1 resolution.
 Video encoding parameters independently adjustable for each channel, including resolution, frame
rate, bit rate, image quality, image parameters, ISP parameters. (front end IPC support required)
 Supports composite stream(front end IPC support required) and video stream encoding, composite
stream encoding audio and video synchronization
Video Output Table
PCB Model Maximum Output Resolution
NBD-27xxNEA 1080P
NBD-2604NEA/NBD-2608NEA 2K
NBD-2616NEA/NBD-26xxNGB 4K
2.2 Real Time Monitoring
 Support HDMI, VGA output simultaneously.
 Support HDMI high-definition display, the highest resolution is 4K (3840x2160); supports
high-definition VGA display, the highest resolution of 1920x1080P.
Channel decoding capability table
Model Single
Screen
Four split-Screens Other Screen Maximum
split-screens
NBD-2604NEA 8M 3M 4
NBD-2608NEA 5M 1080P D1 8
NBD-2616NEA 8M 3M D1 16
NBD-27xxNEA 5M 960P D1 4/8/16
NBD-26xxNGB 8M 3M D1 16/25
 Support preview pattern switching, manual switching or automatic polling preview, automatic
polling cycle can be set.
 Able ot mask specified preview channel.
 Support video privacy cover.( front end IPC support required)
 Support video motion detection, video loss detection.( front end IPC support required)

Network Video Recorder Start Guide Ver1.0 4 / 16
2.3 Storage
Model Number of HDDs
NBD-26xxNEA 2
NBD-27xxNEA 1
NBD-26xxNGB 2
2.4 Back Up
 Support for backup via USB interface
 Support for external SATA burner for backup
 Supports remote backup over the network
 Backup support playback for editing
2.5 Video / Capture Image and Playback
 Support write cycle and acyclic write modes.
 Video trigger modes include manual, schedule, alarm, motion detection.
 Support for local playback on any area of electronic amplification
 Support play, rewind, fast forward, slow-motion, pause and capture image
 Supported by channel number, video type, file type, and other conditions incident to retrieve and
playback of video data.
 Support local playback backup file
Playback Function Table
Model Single-Screen Four Split-Screen
NBD-2604NEA
NBD-2616NEA
NBD-26xxNGB
8M 3M
NBD-2608NEA 5M 1080P
NBD-27xxNEA 5M 960P
2.6 Alarm & Exception
 Support arm time alarm input / output settings (Except H265 Series)
 Support video loss alarm, video motion detection alarm, video tampering, unauthorized access to
alarms, network disconnection alarm, IP conflict warning, hard disk error and hard disk full alarm.
 Various alarm can trigger pop-up alarm screen, sound warning, send messages, trigger the alarm
output and preview prompts alarm warning sound can trigger a variety of abnormalities, send
messages and trigger the alarm output.

Network Video Recorder Start Guide Ver1.0 5 / 16
 Support linkage PTZ settings and automatic cruise corresponding channel, track
2.7 Other Local Functions
 The user can through the front panel buttons, mouse, remote control, keyboard and other special
operations
 Three privileged user management, the administrator can create multiple operating users and set their
permissions, the permissions can be refined into the channel.
 Complete operation, alarm, abnormal and information logging and retrieval.
 Support alarm triggered manually cleared
 Support for importing device configuration information / export operation
 Supports simple recovery and full recovery of system configuration
2.8 Network Functions
 Support TCP / IP, DHCP, PPPoE, NTP ,P2P, and DDNS protocol
 Support IE browser for remote preview & play back
 Support remote access and configuration parameters, support for export and import remote device
parameters
 Support remote access to equipment operating status, system log and alarm status
 Support remote format the hard disk, upgrade, reboot the system, such as maintenance operations
 Support remote PTZ control
 Supported by IOS, Android mobile terminal for remote monitoring
 Support the use of CMS to manage multiple devices through the Internet.

Network Video Recorder Start Guide Ver1.0 6 / 16
Chapter 3 Operation basics
3.1 Mouse Operation
Note: If the mouse is not detected after the startup, the mouse is generally not compatible with NVR l,
replace the mouse.
3.2 Input Method Description
Icon Note
English-sensitive switch button
Input method switch button
When Chinese input, page forward
When Chinese input, back flip

Network Video Recorder Start Guide Ver1.0 7 / 16
Current language
Switch to symbol selection page
3.3 Menu Instruction
Main Menu
 Note: The "_" is appeared when the mouse move to any option on menu, for example, when the
mouse move to ;
 The system will transfer to corresponding page when click options on main menu;
 Right clicking on the main menu can transfer to preview page;
System Setting Page

Network Video Recorder Start Guide Ver1.0 8 / 16
Icon Name Note
Menu User can enter the corresponding lower menu when
positioning a menu icon
Check Box Select or non select corresponding functions
Drop Down Box At least two options, only one option can be selected
Setting Click to edit or set page
Default Default all setting
Apply Click to save current settings, interface remains in the
current settings
Exit Exit current page same as right click on mouse
Preview Click and back preview page directly
Click or right click mouse can pop up reminder box when the parameter is unsaved:
Yes: save current setting and exit current menu
Cancel: cancel current setting and exit current menu

Network Video Recorder Start Guide Ver1.0 9 / 16
Chapter 4. Operation Introduction
4.1 System connection
Important: Please make sure the LAN cable is straight through wiring type, NOT cross over type.

Network Video Recorder Start Guide Ver1.0 10 / 16
4.2 Getting Started the NVR
 Step 1: Connect NVR to monitor
 Step 2: Connect power adaptor.
The boot screen will be displayed after the device is turned on. After waiting for few minute, the boot can
be successful.
4.3 Setup Wizard
 After the device is turn on, it will enter the setup wizard page, if there is no hard disk or the hard disk
is not formatted, the device will prompt, and the buzzer will alarm
 Click change password box to change password
 Note: If user does not click change password, then enter admin password to next step
 The default account is "admin", no password for default account. To protect your personal privacy
and data, it is recommended to modify the default password
 Click [next] button, this page allows some simple configuration of the NVR: Modify language,
change time, open/close wizard, open /IPC time synchronization function.

Network Video Recorder Start Guide Ver1.0 11 / 16
 Click [next] to enter network configuration page
 This page allows user to configure network parameters such as the IP address of the device. Select
the [Enable Automatic IP Acquisition] function and click the [Update] button. If there is a DHCP
server in the LAN, the IP address will be obtained from the DHCP server.
 If the local area network has a DHCP server (router), it is recommended to enable the automatic
acquisition of IP functions. Please note the IP addresses should not conflicted.
 If user wants to use a computer to access the device with the LAN, user can directly open the
browser and input device's IP address. Please refer to the chapter 5 [Web Access]
 Click [next] to enter P2P page
 P2P UID QR code on the left and APP QR code on the right. For download APP, please open the
mobile browser and scan the APP QR code.
 After the APP is installed, use the APP to scan the left QR code to add the UID. After the UID is
added, user can remotely preview and playback through the device.
 Note: only the status of internet is "ready", user can use APP for remote preview and playback.

Network Video Recorder Start Guide Ver1.0 12 / 16
4.4 Adding & Connecting a Camera
 Follow the wizard's instructions and click the [Configure Camera] button to enter the device
management page.
 The added camera device is displayed on this page. Click the device search button to add new device.
Click the [Search] button to search for devices in the LAN

Network Video Recorder Start Guide Ver1.0 13 / 16
Button introduction：
Refresh current device list
Modify the device IP (valid only for IP address), this option is gray when
selected as UID
Click to add page manually
There are multiple protocols inside. When adding, user needs to select the
corresponding protocol.
After select, the added device will not be displayed. After canceling the
option, the added device can be searched and added again.
Add all searched devices
Only add the selected device (white box before the serial number)
 The device can be previewed after added：
 The network disconnection prompt will appear if the camera password or camera information is
incorrect.
 The screen will be displayed when the camera is working, the NVR is recording with a hard disk,
and the blue dot is displayed in the upper right corner.
 The white screen shows the NVR logo means there is no camera be added.
Note:
 When the channel notices the network is disconnected, please check the camera IP and NVR IP
address are on the same network or no, and the account and password are correct or no.
 When the camera cannot be found, please check the camera IP and NVR IP address are on the same
network segments. The ONVIF camera cannot be searched across segments.
 The IP address of the NVR should not conflict with other devices in the LAN.

Network Video Recorder Start Guide Ver1.0 14 / 16
4.5 Other methods to adding a Camera
 Method 1: Click the white screen channel, use [+] in the lower right corner to enter the add page.
 Method 2: Click the Channel Management button on the toolbar , user can add new camera in
channel management page
 For more details about add a camera, please see 4.4 Adding & Connecting a Camera
4.6 Local Playback
Right click on preview page will pop up toolbar
Click video playback button, select [playback by time]

Network Video Recorder Start Guide Ver1.0 15 / 16
Icon Description：
Icon Description Icon Description
Single Screen/ Four
Split-Screen
Start/Stop Cut

Network Video Recorder Start Guide Ver1.0 16 / 16
Rewind/Pause Play/Pause
Deceleration Playback Accelerated playback
Electronic amplification Full Screen
Timeline reduced Timeline enlarge
Restore the default
Timeline
Backup video
Left Timeline Right Timeline
Set the time to start
playback
Exit playback page
