WYSS TUMBLER 6550 User manual

Unpacking: see page 6
Débridage: voir page 23
Entfernen der Transportsicherung: s. S. 40
Disimballo: vedere pagina 57
INSTRUCTION BOOKLET
MODE D’EMPLOI
GEBRAUCHSANWEISUNG
LIBRETTO ISTRUZIONI
D
F
GB
I
Tumble Dryer
Seche-Linge
Wäschetrockner
Asciugabiancheria
TUMBLER 6550
125987711
D
F
GB
I
125987711.qxp 2007-06-25 10:45 Page 1

2
Contents
Dear customer,
Please read these operating instructions carefully and pay particular attention to the safety notes indicated in
the first pages.
We recommend that you keep this instruction booklet for future reference and pass it on to any future owners.
Transport damages
After unpacking the machine please check it is not damaged. If in doubt, do not start it but contact your local
Service Centre.
The symbols you will see on some paragraphs of this booklet have the following meaning:
The warning triangle emphasize information that is particularly important for your safety or correct
functioning of the appliance.
The information marked with this symbol provides additional instructions and practical tips on the use of
the appliance.
Tips and information about economical and ecological use of the machine are marked with this symbol.
Our contribution to the protection of the
environment: we use recycled paper.
Important safety information ......................3
Disposal ..............................................................3
Tips for environmental protection ............4
Technical specifications................................4
Description of the appliance ......................4
Adjusting the level of conductivity ..........5
Installation ..........................................................6
• Unpacking ............................................................6
• Positioning ............................................................6
• Electrical connection ............................................6
• Stacking kit............................................................6
• Door reversal ........................................................6
• Connecting a drain hose ......................................7
Use ........................................................................8
• The control panel ............................................8-10
• Programme Chart ..............................................11
• Operating sequence............................................12
• Useful hints ........................................................13
Maintenance and Cleaning ........................14
• External cleaning ................................................14
• Cleaning the door................................................14
• Cleaning the filters ..............................................14
• Cleaning the condenser unit ..............................14
• Emptying the water reservoir ..............................15
• Cleaning the air intake grille................................15
Something not working? ............................16
Guarantee Conditions............................17
Service ....................................................18
125987711.qxp 2007-06-25 10:45 Page 2

ENGLISH
3
Important safety information
Installation
• This appliance is heavy. Care should be taken
when moving it.
• Any electrical work required to install this
appliance should be carried out by a qualified
electrician or competent person.
• Any electrical work required to install this
appliance should be carried out by a qualified
electrician or competent person.
• Care must be taken to ensure that the appliance
does not stand on the electrical supply cable.
• If the machine is situated on a carpeted floor, please
adjust the feet in order to allow air to circulate freely.
Use
•Do not overload the appliance (see programme chart).
• Clothes which are dripping wet should not be
placed in the dryer.
• As some bulky items such as duvets and
eiderdowns should be dried in large commercial
machines because of their bulk, check with the
manufacturer of the item if it is suitable for drying
in a domestic machine, even if the dry weight of
the item is within the limit advised.
• Please make sure that no gas lighters have
accidentally been left in pockets of garments to be
loaded into appliance.
•Danger of explosion: Never tumble dry items that have
been in contact with inflammable solvents (petrol,
methylated spirits, dry cleaning fluid and the like). As these
substance are volatile, they could cause an explosion.
Only tumble dry items washed with water.
• Risk of fire: items that have been spotted or soaked with
vegetable or cooking oil constitute a fire hazard and
should not be placed in the tumble dryer
• If you have washed your laundry with stain
remover you must execute an extra rinse cycle
before loading your tumble dryer.
• In order to avoid danger of fires caused by excessive
drying, do not use appliance to dry the following items:
Cushions,quiltsandthelike(theseitemsaccumulateheat).
Items containing rubber foam or materials similar
to rubber foam.
• Leave the door slightly ajar when the appliance is not
being used. This will allow the seal to be preserved.
• Clean fluff filters after using tumble dryer. To
prevent fire risks, do not use the appliance if the
fluff filters are damaged.
• Do not allow fluff to accumulate around the dryer.
General safety
• It is dangerous to alter the specifications or
attempt to modify this product in any way.
• •Under no circumstances should you attempt to
repair the machine yourself. Repairs carried out by
inexperienced persons may cause injury or serious
malfunctioning. Contact your local Service Centre.
Always insist on genuine Electrolux spare parts.
Child safety
• Children are often not aware of how dangerous
electrical appliances can be. When the machine is
working, children should be carefully supervised
and not be allowed to play with the appliance.
• The packaging components (e.g. plastic film, polystyrene)
can be dangerous to children - danger of suffocation!
Keep them out of children’s reach.
• Makesurethatchildrenorpetsdonotclimbintothedrum.
• When the appliance is to be scrapped, cut off the
electrical supply cable and destroy the plug with
the remaining cable. Disable the door catch in
order to prevent children from becoming trapped
inside while playing.
These warnings have been provided in the interest of safety. You MUST read them carefully before installing or
using the appliance.
• Packaging materials
The materials marked with the symbol are recyclable.
This means that they can be recycled by disposing
of them properly in appropriate collection containers.
Check with your local Council or Environmental
Health Office to see if there are facilities in your
area for re-cycling this appliance.
When the appliance is to be scrapped, cut off the power
supply cable and make the door closing device unusable
to prevent young children from being trapped inside.
• Machine
Use authorised disposal sites for your old appliance.
Help to keep your country tidy!
•Old appliance
The symbol on the product or on its packaging
indicates that this product may not be treated as household
waste. Instead it shall be handed over to the applicable
collection point for the recycling of electrical and electronic
equipment. By ensuring this product is disposed of
correctly, you will help prevent potential negative
consequences for the environment and human health,
which could otherwise be caused by in appropriate waste
handling of this product. For more detailed information
about recycling of this product, please contact your local
city office, your household waste disposal service or the
shop where you purchased the product.
Disposal
125987711.qxp 2007-06-25 10:45 Page 3

Description of the appliance
4
To save energy and to help protect the environment,
we recommend that you follow these hints:
• Try to load the maximum capacity of the machine
as small loads are uneconomical.
• Always load well spun laundry. The higher the spin
speed, the lower the electricity consumption and
the shorter the drying times.
• Do not over-dry laundry, this avoids creasing and
saves energy.
Select the drying time/section according to the type
of laundry and the required degree of dryness.
• To utilize the maximum load, laundry which is to be
dried ready to put away (store dry) can be dried
together with items to be ironed. To do this, select
the time for iron-dry, remove the iron-dry items at
the end of the programme and then finish-dry the
rest of the load.
• Clean the filters regularly to avoid excessive drying
times and high electricity consumption.
• Ventilate the room well. The room temperature
should not exceed +35°C during drying.
Tips for environmental protection
Technical specifications
DIMENSIONS: Height 85 cm
Width 60 cm
Depth 58 cm
ELECTRICAL CONNECTION: 220-230 V/50 Hz
MAX. POWER ABSORBED: 2350 W
MIN. FUSE RATING: 10 A
MAX. DRYING CAPACITY: Cotton, linen 6 kg
Synthetics 3 kg
CONSUMPTION: Cotton, linen 3.36 kWh (6.5 kg store dry)
Cotton, linen 2.70 kWh (6.5 kg iron dry)
Synthetics 1.20 kWh (3 kg store dry)
This appliance complies with the following E.E.C. Directives:
- 73/23 EEC of 19.2.73 (Low Voltage Directive) and subsequent modifications;
- 89/336 EEC of 3.5.89 (Electromagnetic Compatibility Directive) and subsequent modifications.
01 Table top
02 Time selector dial
03 Control panel
4 Water reservoir
5 Drum light
06 Fluff filters
07 Rating Plate
08 Condenser Unit
09 Adjustable feet
0
12
8
9
3
76
4
5
6
J
30
60
90
125987711.qxp 2007-06-25 10:45 Page 4

5
ENGLISH
Adjusting the level of conductivity
Water contains, a variable quantity of limestone and
mineral salts of which quantities vary according to
geographical locations thus varying its conductivity
values.
Relevant variations of the conductivity of the water
compared to those prefixed by the factory could
slightly influence the residual humidity of the laundry
at the end of the cycle.
Your dryer allows you to regulate the sensitivity of
the drying sensor based on conductivity values of
the water by using the following procedure.
Procedure:
Turn the programme selector dial to switch on the
appliance
In selection mode press simultaneously the buttons
3and 6until «C0» appears on the digits.
Adjusting the level of conductivity:
Press the button 5 sequentially: the level of
conductivity is indicated by the lighting of the
horizontal hyphens.
123456
123456
Normally, the appliance is factory-set to the
highest level; however, certain models may be
configured differently.
Memorizing the new setting:
Simultaneously press down the buttons 3and 6until
the previous drying cycle time appears again on the
display and the buzzer sounds.
Display Conductivity
degree Approximative value (µS/cm)
CC00Low < 300
CC00Medium 300 - 600
CC00High > 600
