XDL5SIGMA 2 COMPUTER
Xerox Data Systems
Reference Manual

XDS SIGMA 2 INSTRUCTIONS
Instruction name Mnemonic Operation code Page
---------
Add ADD 1010 RIXS D 14
Logical AND AND 1001 RIXS D 15
Branch B 0100 RIXS D 15
Branch if Accumulator Negative BAN 0110 ins D 16
Branch if Accumulator Zero BAZ 0110 010S D 16
Branch if Extended Accumulator Negative BEN 0110 lIDS D 17
Branch on Incrementing Index BIX 0110 OIlS D 17
Branch if No Carry BNC 0110 001S D 17
Branch if No Overflow BNO 0110
ODDS D 17
Branch on Incrementing Index and No Carry BXNC 0110 101S D 17
Branch on Incrementing Index and No Overflow BXNO 0110 100S D 17
Compare CP 1101 RIXS D 16
Divide (optional) DIY 0101 RIXS D 15
Increment Memory 1M 1111 RIXS D 15
Load Accumulator LDA 1000 RIXS D 14
Load Index LDX 1100 RIXS D 14
Multiply (optional) MUL 0011 RIXS D 15
Register Add RADD 0111 1100
a
18
Register Add and Carry RADDC 0111 1110
a
19
Register Add and Increment RADD!
0111
1101 a
19
Register AND RAND 0111 0000 018
Register AND and Carry RAN DC
0111
0010 019
Reg ister AN D and Increment RAND! 0111 0001 019
Reg ister Copy RCPY
0111 0100 18
Register Copy and Carry RCPYC 0111 0110 19
Register Copy and Increment RCPYI 0111 0101 18
Read Direct RD 0001 RD(S D20
Register Exclusive OR REOR 0111 1000
a
18
Register Exclusive OR and Carry REORC 0111 1010
a
19
Register Exclusive OR and Increment REORI 0111 1001 019
Register OR ROR 0111 0100 018
Register OR and Carry RORC 0111 0110 019
Register OR and Increment RORI
0111 0101 019
Shift S0010 RIXS D 15
Store Accumu I ator STA 1110 RIXS D 14
Sub trac t SUB 1011 RIXS D 15
Write Direct WD 0000 RIXS D 21

Price: $2.00
XDS SIGMA 2 COMPUTER
REFERENCE MANUAL
900964F
December 1969
XJD:5
Xerox Data Systems/70l South Aviation Boulevarcl/EI Segundo, California 90245
© 1966,1967,1966,1969, Xerox Data Systems, Inc. Printed in U.S.A.

REVISION
This publication, XDS 9009 64F, is a revision of the XDS Sigma 2 Computer Reference
Manual, XDS 9009 64E (dated May 1969). The primary revision is the addition of Appen-
dix D describing the Watchdog Timer. A change in text from that of the previous manual
is indicated by a vertical line in the margin of the page.
RELATED PUBLICATIONS
Title
XDS Sigma 2/3 Symbol Reference Manual
XDS Sigma 2/3 Extended Symbol Reference Manual
XDS Sigma 2/3 Basic FORTRAN/Basic FORTRAN IV Reference Manual
XDS Sigma 2 Mathematical Routines Technical Manual
XDS Sigma 2 Stand-Alone Systems Reference Manual
XDS Sigma 2/3 Basic Control Monitor Reference Manual
XDS Sigma 2/3 Real-Time Batch Monitor Reference Manual
XDS Sigma Interface Design Manual
ALL SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE
ii
Publication No.
90 1051
90 1052
900967
90 1036
90 1047
90 1037
90 1037
900973

CONTENTS
1.
SYSTEM DESIGN FEATURES SELECT 31
REGISTER 31
General Characteristi cs 2MEMORY 31
Real-Time and Mul tiusage Features 3INTERRUPT/INCREMENT ADDRESS 31
4INITIALIZE 31
2. SYSTEM ORGANIZATION COMPUTE 31
Information Format 4Initial Loading Procedure 32
Core Memories 4
Central Processing Unit
5
Register Block
5
APPENDIXES
Arithmetic and Control Unit
5
Instruction Format
7 A. REFERENCE TABLES 33
Effective Address Computation
7
XDS Standard Symbols and Codes 33
Instruction Timing 8XDS Standard Character Sets 33
Interrupt System 8Control Codes 33
Internal Interrupt Levels 8Special Code Properties 33
External Interrupt Levels 10 XDS Standard 8-Bit Computer Codes (EBCDIC) __ 34
Interrupt Level States 10 XDS Standard 7-Bit Communication Codes
Interrupt System Control
11
(USASCII) 34
Interrupt Priority Sequence 12
Interrupt Routine Entry and Exit 12 XDS Standard Symbol-Code Correspondences-- 35
Hexadecimal Arithmetic 39
Counter Interrupt Processing 12 Addition Table 39
CPU Interrupt Recognition 13 Multiplication Table 39
Protection System 13 Table of Powers of SixteenlO 40
3. INSTRUCTION REPERTOIRE 14 Table of Powers of Ten16 40
Hexadecimal-Decimal Integer Conversion Toble.L; 41
Memory Reference Instructions 14 Hexadecimal-Decimal Fraction Conversion Toble.L 47
Conditional Branch Instructions 16 Table of Powers of Two 51
Copy Instruction 17 Mathematical Constants 51
Direct Control Instructions 19 B. INSTRUCTION EXECUTION CYCLE 52
4. INPUT/OUTPUT OPERATIONS 22 C. MEMORY ADDRESSING 54
Byte-Oriented I/O System 22 External Memory Adapter Model 54
Device Number 22 External Memory Adapter Model 2 54
I/o Control Doublewords 22 Conti nuous Addressing 54
Operational Status Byte 23 D. WATCHDOG TIMER
Device Orders 24 55
I/O Tables 24 INDEX 56
Device Interrupts 25
I/O Instructions 25
ILLUSTRATIONS
Device Status Byte 26
External Interface System 27 Frontispiece - SIGMA 2 Computer System iv
Direct-to-Memory Interface 28
1.
SIGMA 2 System Configuration 1
5.
OPERATOR CONTROLS 29 2. SIGMA 2 Central Processing Unit_
6
3. Interrupt Level Operation _____________
11
Control Panel 29 4. Interrupt Priority Chain 12
POWER 29
5.
I/O Control Doublewords and I/o Tables _~ __ 25
PHASE 29 6. SIGMA 2 Processor Control Pane
I
29
PROTECT PROGR 29 7. SIGMA 2 Instruction Execution Diagram 53
INTERRUPT INHIBIT 29
O'FLOW 29
TABLES
CARRY 29
PARITY ERROR 30
1.
Effective Address Computation and Timing ____ 8
PROTECT 30 2. Core Memory Allocation and Interrupt
PROG ADD 30 Priority Groupings ------ ---------- -- - 9
Key-Operated Switch 30 3. READ DIRECT Internal Control Functions ___ 20
DISPLAY 30 4. WRITE DIRECT Internal Control Functions ___ 21
DATA 30
5. Device Status Byte 27
iii

1. SYSTEM DESIGN FEATURES
SIGMA 2, a third-generation computer system, is a totally
integrated combination of high performance hardware and
efficient software. The SIGMA 2 system makes fu II use of
advanced design features first developed for SIGMA?, and
it provides the user with a balanced system that offers ad-
vantages normally found only in large computer systems.
Large Capacity, Low-Cost Input/Output. SIGMA 2 uses
XDS-designed monolithic integrated circuit registers. to pro-
vide four fully automatic, buffered input/output channels
as standard equipment. Up to 16 additional automatic chan-
nels as well as direct input/output capability can be added
at low cost. Maximum channel I/O transfer rate is 400,000
8-bit bytes per second.
Concurrent Foreground/Background Processing. This multi-
programming capabi I ity permits the user to operate one or
more fully-protected, real-time programs in the foreground
while concurrent I y operating a general-purpose program in
the background. Overhead in switching from one task to
another is minimized because both hardware and software
are specificially designed for rapid context switching. A
hardware register permits the software to generate re-
entrant code efficiently. Thus, routines common to several
programs, whether in foreground or background, need to be
stored in memory only once.
Comprehensive, User-Oriented Software. SIGMA 2 pro-
gramming systems increase user productivity by providing
powerful, easy-to-use programming tools. As a result,
user programs are written more quickly at lower cost. The
avai labi Iity of thi s comprehensive software package makes
it possible to exploit the full potential of the hardware.
The package includes two operating systems (Monitors),
a FORTRAN compiler, two assemblers, and a variety of
library and utility programs. To store these extensive soft-
ware systems yet keep core memory costs at a minimum,
XDS has developed its Rapid Access Data (RAD) fi I es. RAD
units offer the large capacity and low cost of ordinary disc
files. In addition, by using one fixed read/write head for
every track of data rather than sharing a movable head
among a large group of tracks, the RAD eliminates the
access delays associated with head movement. The RAD's
fast access time and high data transfer rates produce greater
overall system throughput. Forbasic computer configurations
that do not have a RAD unit, a comprehensive group of
stand-alone programming systems is provided. For use with
larger computer configurations, SIGMA 2 programming
systems are RAD-oriented to capitalize on the inherent
benefits of this high-performance secondary storage.
Powerful, Multilevel Priority Interrupt System. The real-
time oriented SIGMA 2 system provides for quick response
to environmental conditions with up to 132 external inter-
rupt levels. The source of each interrupt signal is auto-
matically identified and responded to according to its pri-
ority. For further system flexibility, each interrupt level
can be individually disarmed (so it stops accepting inputs)
and/or disabled (so response is deferred), all under program
control. Use of the arm/disarm, enable/disable features
makes programmed dynamic reassignment of priorities quick
and convenient, even while a real-time process is occurring.
In establishing a configuration for any system, each group
of 16 interrupt levels can have its group priority assigned
differently, to meet the specific needs of an application.
The way interrupt levels are programmed is not affected by
their priority assignments.
Direct-to-Memory Input/Output
(to external devices, including other processors)
One to Four External Core Memoryt Modules
U
Direct
toCPU
Input/Output
SIGMR 2
Central
Processing
Unit
t
Integra I
Core
Memory
~lnnel
~ ...
Channel
19
Automatic Input/Output Channels (4 standard,
up to 20 total - all operating simultaneously)
Figure 1. SIGMA 2 System Configuration
tIntegral and/or external memories may be combined for
capacities of 4K-64K words.
System Design Features

GENERAL CHARACTERISTICS
In its field, the SIGMA 2 computer is unique in its ability
to function efficiently in general-purpose, real-time, and
multiusage computing environments. The advanced features
and operating characteristics contributing to this capabi Iity
are:
• both word and byte organizotion of memory for maxi-
mum efficiency (words are 16 bits plus pori+y) bytes
are 8 bits.)
• 16 memory sizes available, 4096 to 65,536 words
• ability to connect to SIGMA 5 or SIGMA 7 memory
systems
• an extensive instruction set that facilitates efficient
programming; SIGMA 2 instruction characteristics
include:
•
only one word of storage required for each
instruction
•two levels of indexing and indirect addressing may
be invoked individually or simultaneously
relative addressing (forward and backward)
•
• use of index register 2 as a base address register
• direct reference of up to 1024 addresses; 256
addresses beginning with location zero, 256
addresses beginning with the base address; 256
addresses beginning with the current instruction
location (relative forward), 256 addresses back-
ward from the current instruction (relative
backward)
• eight general-purpose registers to control program
operations; all are available to the program, providing:
• two hardware index registers for preindexing (base
address), post-indexing, or both (double indexing)
• hardware register for subroutine linkages
• double-precision accumulator
• program address register
•
zero register (for a source of zeros)
temporary storage register
•
• rapid context switching, to preserve computer environ-
ment when switching from one program to another, in-
cluding automatic status preservation on interrupt
• both word- and byte-oriented I/O systems, for maxi-
mum flexibil ity
• up to 20 fully automatic I/O channels operating simul-
taneously (4 channels are standard)
• I/O data chaining, for gather-read and scatter-write
operatians
• information transfer rate of approximately one million
words per second for each external memory interface
• direct input/output of a full word without the use of an
I/O channel (optional)
2 General CharacterisHcs
• a real-time priority interrupt system that features:
• 2 to 16 internal interrupt levels and up to 132
external interrupt levels that can be individually
armed, enabled and triggered by program control
• automatic identification, customer-designoted pri-
ority assignments, and extremely fast response time
• memory parity interrupt (optional)
• an optional power fail-safe feature, for automatic
and safe shutdown in the event of a power fai lure,
and unattended startup when power returns
• an optional system protection feature that incl udes
both memory write protection and operation pro-
tection for foreground programs
• up to four real-ti'me clocks (with a choice of reso-
lutions)for independent time bases, available as
an option
a comprehensive array of modular software that expands
in capability and speed as the system grows, with no
reprogramming required
•
• Free-standing software for small systems includes
Symbol and XDS Basic FORTRAN
• XDS Monitor for user convenience and increased
capability in large systems
• Symbol, a basic symbolic assembler
• Extended Symbol for expanded features
• XDS Basic FORTRAN
• XDS FORTRAN IV
General Debug for symbolic program
troubl eshooti ng
• Concordance program for documentation
•
• System Generation program for creating instal-
lation master
• Mathematics Library of standard functions
• Bootstrap Generator for producing self-loading
object programs
The wide range of standard and special-purpose peripheral
equipment, already proven in field operations, includes:
• Rapid-Access Data Files: Capacities for 750,000 to
24,000,000 bytes per control unit; transfer rate of
over 185,000 bytes/second; average access time of
17 milliseconds. Fixed read/write head per track
eliminates positioning time associated with movable-
arm storage devices
• Magnetic Tape Units: 9-track, IBM-compatible
60, 000 or 120, 000 bytes/second transfer rate; 7-track,
IBM-compatible, 15,000/20,000/41,700/60,000
characters/second transfer rates
• Paper Tape Readers and Punches: readers with speeds
of 20 and 300 characters/second, punches with speeds
of 10 and 120 characters/second, plus spoolers

• Keyboard Printers: available with or without a paper
tape reader and paper tape punch
• Card Readers: read cards punched in binary or EBCDIC
card code, 200 to 1500 cpm
• Card Punches: binary or EBCDIC card codes, 300 cpm
• Line Printers: fully buffered, with 132 print positions
and carriage control, 600 or 1000 Ipm
• Graph Plotter: for two-axis plotting of data under
digital control, 300 increments/second
• Display Equipment: oscilloscope display units, light
guns, and character and vector generators
• Data Communications Equipment: a complete line of
character- and message-oriented equipment
REAL-TIME AND MULTIUSAGE FEATURES
Real-time applications are characterized by a need for hard-
ware that provides quick response to an external environment,
sufficient speed to keep up with the real-time process itself,
and input/output flexibility to handle a wide variety of types
of data at varying speeds.
Multiusage applications, as implemented in SIGMA 2, are
defined as the combining of real-time and background pro-
cessing techniques into one system. The most difficult gen-
eral computing problem is the real-time application with its
requirements for extreme speed and capacity. Because the
SIGMA 2 system has been designed on a real-time base, it
is well qualified for the mixture of applications in a multi-
usage envi ronment. Many of its hardware featu res that
prove valuable for real-time applications are equally useful
in background processing, but in different ways.
The major features that make SIGMA 2 uniquely suitable
for both real-time and multiusage appl ications are described
in the following paragraphs.
Input/Output Facilities. Three distinct SIGMA 2 input/
output systems offer flexibil ity and capacity to meet the
needs of both real-time and general-purpose users: the
byte-oriented, the direct-to-CPU, and the direct-to-
memory I/O systems.
In the byte-oriented I/O system, each automatic I/O chan-
nel has its own high-speed registers and operates indepen-
dently without requiring attention from the program once it
has been started. Data is transferred one byte (8 bits) at
a time. For high-speed peripherals, bytes are assembled
into words in the I/O section and only one memory refer-
ence is made for two bytes. For slow-speed peripherals,
one reference is made for every byte, with a partial write
operation performed by the memory. All I/O channels
may operate concurrently and parity checking is performed
automatically.
The optional direct-to-CPU input/output system uses only
a single instruction to transfer a full 16-bit data word to
and from the A register. The same instruction that trans-
fers data also provides a 16-bit control field for external
control and selection, and accepts status information
returned from the external device to permit rapid sensing of
an external condition. The direct I/O system is generally
used for short bursts of asynchronous data transfers to avoid
tying up an automatic channel. Direct I/O is also useful
when data is to be accepted at medium to high speeds and
each input must be examined immediately when received.
The optional direct-to-memory input/output system provides
an additional memory bus to each of four external memories.
It is used for very high speed I/O transfers to and from
external devices or other processors. Transfers proceed at
full memory speed on a word-oriented basis, with overlap-
ping of multiple I/O and compute occurring automatically
when multiple memory modules are available.
Priority Interrupt System. In a multiusage environment,
many elements are operating asynchronously with respect to
each other. Thus, having a true priority interrupt system,
as the SIGMA 2 does, is especially important. With it the
computer system can respond quickly (and in proper order)
to the many demands made upon it, without the high over-
head cost of complicated programming, lengthy execution
time, and extensive storage allocations. Programs that deal
with interrupt signals from special equipment must sometimes
be checked out before the equipment is actually available.
To simulate special equipment, any external SIGMA 2 inter-
rupt level can be triggered by the CPU itself through execu-
tion of a single instruction.
Context Switching. When responding to a new set of
interrupt-initiated circumstances, a computer system must
preserve the current operating environment while it sets up
the new environment. In SIGMA 2, relevant information
about the current environment is retained as a 32-bit pro-
gram status doubleword (PSD). When an interrupt occurs,
the current PSD is automatically stored at an arbitrary loca-
tion in memory and the interrupt-servicing routine begins,
following the location into which the PSD is stored. At the
end of the interrupt-servicing routine, the PSD is restored
and the interrupt level cleared.
Protection System. Both real-time and background programs
can be run concurrently in a SIGMA 2 system because the
real-time program can be protected against alteration. The
optional protection feature guarantees that protected areas
of memory cannot -be written into by a program residing in
unprotected memory. The protection feature also prevents
the execution of unprotected instructions that could change
the I/O system or the protection system. The protection
pattern can be changed very rapidly.
Real-Time Clocks. In real-time systems, timing informa-
tion must be provided to cause certain operations to occur
at specific instants. Other timing information is also neces-
sary, such as elapsed time after a given event, or the cur-
rent time of day. SIGMA 2 provides up to four real-time
clocks, with varying degrees of resolution, to meet these
needs. These clocks also facilitate handling of separate
time bases and relative time priorities. Three of the clock
counters can be driven from commercial o, c , line frequency
(60 or 50 Hz), from 2- or 8-Hz oscillators, or from an ex-
ternal input; the first (operational) counter is driven by a
SOO-Hz source.
Real-Time and Multiusage Features 3

2. SYSTEM ORGANIZATION
INFORMATION FORMAT
The basic element of SIGMA 2 information is a 16-bit word
in which the bit positions are numbered from 0 through 15,
as follows:
A SIGMA 2 word can also be divided into two 8-bit parts
(called bytes) in which the bit positions of each byte are
numbered from 0 through 7, as follows:
Byte 0 Byte 1
12 31.c..5 6701231.567
Two SIGMA 2 words can be combined to form a 32-bit ele-
ment (called a doubleword) in which the bit positions are
numbered from 0 through 31, as follows:
Most significant word Least significant word
o I 2 3 4 5 6 7 B 9 10 11 12 13 \•• 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
A doubleword is always referred to by the address of its
most significant word,
Binary information in SIGMA 2 computers is generally
expressed in hexadecimal notation because four binary dig-
its of information can be expressed by a single hexadecimal
digit. Thus, a byte can be expressed with a string of 2
hexadecimal digits, a word with a string of 4 hexadecimal
digits, and a doubleword with a string of 8 hexadecimal
digits. The following table lists hexadecimal digits and
their binary and decimal equivalents.
Hexadecimal Binary Decimal
0 0000 0
1 0001 1
20010 2
3 001l 3
40100 4
5 0101 5
6 0110 6
7 0111 7
81000 8
9 1001 9
A1010 10
B 1011 11
C1100 12
D 1101 T3
E 1110 14
F 1111 15
In this reference manual, a hexadecimal number isdisplayed
as a string of hexadecimal digits surrounded by single quotes
and preceded by the letter "X". For example, the binary
number 01011010 is expressed in hexadecimal notation as
X'5A'. Hexadecimal numbers are generally used to denote
4 System.Organization
addresses and data values; however, there are many instan-
ces in which decimal numbers are more meaningful or are
customary. Because the SIGMA assembler systems perform
decimalJhexadecimal conversions, addresses and data
values may be expressed as decimal numbers.
In SIGMA 2, fixed-point data consists of a 15-bit integer
and a sign. Positive numbers are represented in true binary
form, with a sign of zero. Negative numbers are repre-
sented in two's complement form, with a sign of one. All
arithmetic operations assume that this format is used. Logi-
cal operations in SIGMA 2, on the other hand, assume that
a logical data word format, consisting of 16 bits without
sign, is used.
CORE MEMORIES
A SIGMA 2 computer can be equipped with either {or both}
oftwo different types of core memory: integral and external.
A magnetic core memory can be provided as an integral port
of the SIGMA 2 central processor configuration. This inte-
gral memory is available only to the SIGMA 2 central pro-
cessor, and it provides a portion of the total SIGMA 2
system memory. In order to implement the maximum mem-
ory capacity {64K words}, external memory is required in
addition to {or in place of} the integral memory.
The external memory provides independent access poths for
ather processors or special (customer designed) devices;
thus, the SIGMA 2 central processor may share common
storage with other SIGMA 2's, SIGMA 5's, SIGMA 7's,
special I/O processors, or other devices. By using two
SIGMA 7 memory modules (of 16K words each) the external
memory system may constitute a 64K SIGMA 2 memory
system. An external memory adaptor allows the SIGMA 2
computer to treat each 32-bit word of the SIGMA 7memory
system as two 16-bit words. Special registers allow the
programmer to establish a correspondence between any
4096-word portion of SIGMA 2 memory addresses and any
2048-word portion of SIGMA 5/7 memory addresses
(32-bit word).
If integral memory is included in the system that also has
external memory, the integral memory utilizes the lower-
numbered memory locations. For example, if a 16K integral
memory and 16K words of external memory are used, the
integral memory contains locations 0 through 16K-l and
the external memory contains locations 16K through 32K-1.
When the SIGMA 2 memory system is 64K words, the mem-
ory is "wrap-around", or "circular", where the next loca-
tion after 64K-l is location O. If a system has less then
64K words, any fetch operation from a nonexistent storage
location causes zeros to be fetched, in which case a
memory parity error also occurs. An attempt to store infor-
mation in a nonexistent storage location essentially results
in a "no operation".
See Appendix C for more information on memory addressing.

CENTRAL PROCESSING UNIT
The various elements in a SIGMA 2 system - memories,
input/output devices, and device controllers - are orga-
nized around a central processing unit (CPU), which i s.the
primary control Iing element for most system functions. Not
only does the CPU execute instructions, but it also controls
all input/output for both the byte-oriented and the direct
I/O systems. Basically, the SIGMA 2 CPU consists of a
register block and an arithmetic and control unit (see Fig-
ure 2).
REGISTER BLOCK
The CPU register block consists of high-speed, integrated-
circuit registers that are capable of communicating with the
arithmetic and control unit simultaneous with the operation
of the core memory. The register block is functionally di-
vided into three parts: general registers, I/o channel reg-
isters, and memory protection system registers. Each register
of the block is 16 bits in length and is identified by an ad-
dress code in the range 0 through 7 for general registers,
8 through 47 for I/O channel registers, and 0 through 15
for protection system registers. Specific configurations of
the READDIRECTand WRITEDIRECTinstructions are used
to transfer information from the accumulator (general reg-
ister 7) to other registers of the register block, and vice
versa (see Chapter 3, "Direct Control Instructions").
General Registers
Eight registers of the register block are used mainly for
storage of program control information. These registers
are addressable by a COpy instruction (for register-to-
register operations) and by certain configurations of the
READ DIRECTand WRITEDIRECTinstructions (for internal
computer control operations). The functions of the general
registers are as follows:
Address Designation Functi on
0 Z Source of zeros for copy
1PProgram address
2L Link address
3 TTemporary storage
4Xl Index 1 (post-index)
5 X2 Index 2 (pre-index or base)
6E Extended accumu
I ator
7 A Accumulator
A reference to the Z register in a COpy instruction pro-
duces a value of zero. The P register contains the address
of the next instruction which would be executed in normal
sequence. The six remaining registers can be used for vari-
ous purposes by a program.
I/O Channel Registers
The next eight registers of the register block are used to
hold control information for the four standard SIGMA 2
I/o channels (two registers are used for each channel).
Additional I/O channel registers can be added, in groups
of eight (up to a maximum of 40 registers, or 20 I/O chan-
nels). The I/O channel registers are loaded with control
information from the accumulator by a specific configuration
of the WRITEDIRECTinstruction. The operation of I/O
channel registers is described in Chapter 4, "I/O Control
Doublewords" .
Protection System Registers
Sixteen optional registers are available for both operation
protection and memory write protection. Each bit in this
16-register group provides protection for a single 256-word
"page" of core memory. (A complete discussion of this
feature is given on page 13.)
ARITHMETIC AND CONTROL UNIT
The arithmetic and control unit contains the necessary regis-
ters and control circuitry to access general registers or core
memory, to modify instruction addresses, to perform arithme-
tic and logical operations, to provide indications of compu-
tational results, and to preserve interrupt status information.
Basically, the arithmetic and control unit consists of arith-
metic and control registers and program status indicators.
Arithmeti c and Control Registers
Three 16-bit registers (S, H, and D) and an adder are used
to perform arithmetic and logical manipulations and to modi-
fy instruction addresses (see" Effective Address Computation").
Program Status Doubleword
When an interrupt occurs, the current state of the operating
program is saved by the automatic storing of a program status
doubleword (PSD), which is generated automatically from
information in the program status indicators and general reg-
isters. When stored in memory, the PSD has the format
The first word of the PSD contains five status indicators:
protected program (PP), internal interrupt inhibit (II), ex-
ternal interrupt i.!1hibit (EI), overflow (0), and carry (C).
The second word of the PSD is the current contents of the
program address register (general register 1). (Use of the
PSD in interrupt entry and exit is discussed on page 12.)
The protected program indicator bit is a 1 if the current pro-
gram is located in an area of core memory that is protected
by the memory protection option; otherwise, this bit is a O.
The internal and external interrupt inhibits determine whe-
ther a program interruption can occur. If an interrupt in-
hibit is 0, the respective interrupt levels are allowed to
interrupt the program being executed. Conversely, if an
interrupt inhibit is a 1, the respective interrupt levels are
inhibited from interrupting the program. Inhibiting inter-
rupt levels also removes them from the interrupt system pri-
ority chain, allowing a lower-priority interrupt level to
interrupt the program. (Note, however, that the op-
tional override group of internal interrupt levels cannot
be inhibited.)
Central Processing Unit 5

REGISTER BLOCK ARITHMETIC AND CONTROL UNIT
01 Zero
I
S
I
Memory Address
I
Arithmetic
lL Program address
IHI
Control
I
> and control
registers
21 Link address
I
D
I
Memory Data
I
3L
Temporary storage
I
General
I
registers
0
41 Index 1Protected program indicator
5 1 Index 2 (base)
I
D
Internal interrupt inhibit
I D
Program
6
I
Extended accumul ator External interrupt inhib it status
indicators
7
I
Accumulator
I
D
Overflow indicator
0
Carry indicator
8L Channel 0
I
<III
To/from
9L
Channel 0
I
core memory
·
Standard
·I/O channel
I
Channel 3
I
registers
14 To/from
~byte I/o system
15 [ Channel
3
I
I
..
READDIRECT
16
I
Channel 4
I
I
17
I
Channel 4
I
WRITEDIRECT
Optional
·I/O channel
-
·
I
461 Channel
19
I
registers
~
Interrupts
Priority interrupt system
..•
471 Channel 19 1
I
o ~ddresses 0through 4K-l
Protection
1fAddresses 4K through 8K-l
I>
system
·
regi sters
·(optional)
·
ISIAddresses 60K through 64K-11
Figure 2. SIGMA 2 Central Processing Unit
6 Central Processing Unit

The overflow and carry indicators reflect the results of
various operations. The overflow indicator is set to 1 if
overflow occurs during an arithmetic operation. If, after
an arithmetic operation, there is a carry from the most sig-
nificant position (the sign' position) of the adder, the carry
indicator is set to 1. This feature is useful in multiple-
precision operations, where the entire 16 bits are considered
to be the low-order part of an extended operation. Also,
on a subtract operation, the carry indicator will be set to
1 if there is a "borrow" from the sign position of the adder.
In arithmetic operations, the carry and overflow indicators
operate as described above. Some instructions, however,
use these indicators to record status information generated
as a resul t of the operation.
INSTRUCTION FORMAT
Most instructions in SIGMA 2 are of the memory reference
type and have the following format:
In this format, the operorion code (OP) occupies the four
most significant bits, followed by four address-control bits
(R, I, X, and S) and an 8-bit displacement. The R, I, X
and S bits control self-relative/nonrelative/base-relative
addressing, indirect addressing, and indexing.
Two groups of SIGMA 2 instructions have formats some-
what different from the format of the memory reference
type of instructions. The formats of the copy instruction (for
register-to-register operations) and the conditional branch
instructions (which always invoke self-relative addressing)
are described in Chapter 3 (see "Copy Instruction" and
"Conditional Branch Instructions").
EFFECTIVE ADDRESS COMPUTATION
The SIGMA 2 computer forms the effective address of a
memory reference instruction in three basic steps as follows:
Step 1 (determine reference address)
a. If the R bit (bit 4 of the instruction word) and
the S bit (bit 7 of the instruction word) are both
O's, the reference address is equal to the val ue
in the displacement field of the instruction. (This
is referred to as "nonrelative" addressing.)
b. If the R bit is a 0 and the S bit is a 1, the refer-
ence address is equal to the val ue in the dis-
placement field in the instruction plus the 16-bit
value (base address) in index register 2. (This is
referred to as "pre-indexing", or "base-relative"
addressing. )
c. If the R bit is a 1, the reference address is equal
to the 16-bit value in the H register (address of
the instruction) plus the value in the low-order
9 bits of the instruction, interpreted as a 9-bit
two's complement integer (this is referred to as
"self-relative" addressing).
Step 2 (determine direct address)
a. If the I bit (bit 5 of the instruction word) is a 0,
the direct address is equal to the value of the
reference address (as determined in step 1).
b. If the bit is a 1, the reference address is treated
as an indirect address; the direct address is the
16-bit value in the location whose address is
equal to the reference address. In effect, the
indirect address is replaced by the direct address
value.
Step 3 (determine effective address)
a. If the X bit (bit 6 of the instruction word) is a
0, the effective address is equal to the val ue of
the direct address (as determined by step 2).
b. If the X bit is a 1, the effective address is equal
to the value of the direct address plus the 16-bit
value in index register 1. Note that indexing
with Xl is applied after indirect addressing. This
is referred to as "post-indexing".
The effective address for an instruction, therefore, is the
final 16-bit address value developed for that instruction,
starting with the displacement value in the instruction
itself. The core memory location whose address equals the
effective address value is referred to as the "effective
location". Similarly, the contents of the effective location
are referred to as the "effective word".
The process of effective address computation is summarized
in Table 1. The symbols used in Table 1 are defined as
follows:
R Bit 4 of the instruction
Bit 5 of the instruction
XBit 6 of the instruction
S Bit 7 of the instruction
DBits 8 through 15 of the instructian (Displacement)
SD Sign extended displacement value
(D) Contents of location D
(Xl) Contents of index register 1 (general register 4)
(X2) Contents of index register 2 (general register 5)
(H) Contents of the internal H register (the address
of the instruction)
Central Processing Unit 7

Table 1. Effective Address Computation
and Timing
R I X5Effective Address Additional
HaIf-cyc Ies
_.
0000 D0
0 0 0 1
D+ (X2) 1
0 0 1 0D + (Xl)
1
00 1 1
D + (Xl) + (X2) 2
0 1 0 0 (D) 2
0 1 0 1
(D + (X2)) 3
0
1 1
0(D) + (Xl) 2
0 11 1
(D + (X2)) + (Xl) 3
1 0 0 (H) + SD 0
1
0
1
(H) + SD + (Xl)
1
11
0 «H) + SD) 2
1 1 1 «H) + SD) + (Xl) 2
'---.
INSTRUCTION TIMING
Instruction timing is a function of the half-cycle time of
the computer memory, because all operations are performed
in some multiple of half cycles. A half cycle is one-half
the average time required for the integral memory to per-
form a complete read/restore operation. When operations
use only the integral memory, all half-cycles have approx-
imately the same duration. The half-cycle time may be
extended when references ore made to external memory,
because other processors may interfere with an access to an
external memory. The minimal execution time for a mem-
ory reference instruction is five to eight half-cycles, de-
pending on the instruction involved. This timing is based
on an instruction that is coded either for self-relative or for
nonrelative addressing.
For other cases, see Table 1.
A half-cycle is 460 nanoseconds (±3%) when integral mem-
ory is involved. Each memory access to an external memory
involves an additional amount of time from 40 nano-
seconds to 1 microsecond, depending on such factors as
memory cycle time and cable length involved.
INTERRUPT SYSTEM
The SIGMA 2 priority interrupt system is an improved ver-
sion of the system used successfully inXDS 9300/900 Series
Computers. Up to 148 interrupt levels are normally avail-
able, each with a unique location (see Table 2) assigned
to core memory, each with a unique priority, and each
(except for the override group of interrupt levels) capable
8 Interrupt System
of being selectively armed and/or enabled by the CPU
(see "Interrupt Level States").
Any interrupt level (except for the override group) can be
"triggered" by the CPU; i.e., supplied with a signal at the
same physical point where the signal from the external
source would enter the interrupt level. The triggering of an
interrupt level permits the testing of special systems programs
before the special systems equipment is actually attached to
the computer. It also permits an interrupt-servicing routine
to defer a portion of the processing associated with an inter-
rupt response by processing the urgent part of the interrupt
response, triggering a lower-priority level (for a routine
that handles the less-urgent part), then clearing the high-
priority interrupt level so that other interrupts may be al-
lowed to occur (before the less-urgent part is completed).
INTERNAL INTERRUPT LEVELS
Internal interrupt levels include those that are normally
supplied with a SIGMA 2 system, as well as the optional
counter (real-time clock), power fail-safe, memory parity,
protection violation, and "counter-equals-zero" interrupt
levels. The internal interrupt levels are arranged in three
groups: the counter group, the override group, and the
input/output group.
Counter (real-time clock) Group
These four optional interrupt levels are triggered by pulses
from internal or external clock sources. Counter 1 has
a constant frequency of 500 Hz; counters 2, 3, and 4 can
be individually set to any of four manually switchable
frequencies - the commercial Iine frequency, 2 kHz,
8 kHz, and a user-supplied external signal - that may be
different for each counter. (All counter frequencies are
synchronous except for the Iine frequency and the signal
supplied by the user.) When a clock pulse is received
by one of the counter interrupt levels (and the level is
armed and enabled), the value in the memory location
associated with the level is incremented by 1, and the
level is cleared and armed. If the value in the affected
memory location is zero after being incremented, the
corresponding counter-equals-zero interrupt level in the
input/output group of internal levels (see below) is then
triggered. All other interrupt levels .(including the counter-
equals-zero interrupt levels) are processed by interrupt-
servicing routines and are designated as "normal" interrupt
levels. The counter interrupt levels can be armed, disarmed,
enabled, disabled, or triggered by means of a specific config-
uration (interrupt control mode) of the WRITEDIRECTin-
struction; however, these levels cannot be inhibited. The
priority of the counter interrupt levels is immediately below
the priority of the power off interrupt level, but above the
priority of the memory parity error interrupt level.
Override Group
The interrupt levels in this group are associated with inde-
pendent, optional SIGMA 2 features.

Table 2. Core Memory Allocation and Interrupt Priority Groupings
--
-~-.~---~
Address Priority Level WRITEDIRECT Assignment Avai labi
I ity Group WRITEDIRECT
Dec. Hex. within Group Register Bitt Group Codett
---
---,- ... ---. ,-
0 0 First record loaded
1 1 into memory duri ng
a load operati on
63 3F
64 40
65 41 Unassigned
251 FB
----- -_--- - --
252 Fe 3 0 Counter 4 Optional
253 FD 4 1 Counter 3 (as a set) Counter
254 FE 5
2Counter 2 Optional (no inhibit) X'O'
255 FF 63 Counter 1 (as a set)
256 100 1Power on Optional
--_
----------
257 101 2none Power off (as a set)
258 102 7Memory parity error Optional Override
259 103 8none Protection violation (no inhibit) none
260 104 9Multiply exception Standardttt
261 105 10 none Divide exception
262 106 1 Input/output
-
,~-
-
6Standard
263 107 27Control panel
264 108 38Counter 4
== 0 Optional
265 109 4 9 Counter 3
== 0(as a set) Input/Output
266 lOA
5 10 Counter 2
== 0 Optional
267 lOB 611 Counter 1
== 0(as a set) (inhibited by X'O'
268 10C 712 Integral 1 Optional bit 10 of PSD)
269 10D 813 Integral 2 (as a set)
270 10E 914 Integral 3 Optional
271 10F 10 15 Integral 4 (as a set)
--
-~----
-----_.-
272 110 10
273 111 21External
Group 5 X'5'
287 11F 16 15
288 120 0
------
1
289 121 21Designated by Optional External
·
(inhibited by X'6'
·
customer bit 11 of PSD) Group 6
303 12F 16 15
--
384 180 10
385 181 21External
·
X'C'
Group 12
399 18F 16 15
.
----_ .. - ,_
tWhen the WRITEDIRECTinstruction is used in the interrupt control mode to operate on interrupt levels, the interrupt
levels are selected by specific bit positions of the accumulator. The decimal numbers in this column indicate the bit posi-
tions in the accumulator that correspond to the various interrupt levels.
ttThe hexadecimal numbers in this column indicate the group codes (for use with WRITEDIRECT)of the various interrupt
levels.
tttThe multiply exception and the divide exception interrupt levels are included only in computers that do not have the
multiply/divide option.
Interrupt System 9

The override interrupt levels are always armed (cannot be
disarmed), always enabled (cannot be disabled), cannot be
triggered by a WRITE DIRECT instruction, and cannot be
inhibited.
Power Fail-Safe. The two optional power fail-safe inter-
rupt levels are used to enter routines that save and restore
volati Ie information in the event of a power fai lure. The
power-off interrupt level is triggered whenever the power
supply voltage falls below a safe limit; likewise, the power-
on interrupt level is triggered whenever power returns to
safe limits. The power fail-safe interrupt levels have a
higher-priority than the counter interrupt levels.
Memory Parity Error. The memory parity interrupt option
is used to inform the program (or the computer operator) that
a parity error has occurred upon accessing memory for an
instruction, direct address (in the case of indirect address-
ing), or an operand. If the option is installed and the
PARITY ERROR switches on the control panel are in the
INTERRUPT/NORMAL positions when a parity error occurs,
the memory parity interrupt level is triggered.
Protection Violation. The protection option includes the
protection violation interrupt level. (The protection option
is described on page 13.) If the option is installed and the
PROTECT switch on the processor control panel is in the ON
position when a protection violation is encountered, the
protection violation interrupt level is triggered.
Multiply/Divide Exception. The multiply/divide option
includes the additional logic required for executing the
MULTIPLY and DIVIDE instructions. If the option is not
installed, the multiply exception interrupt level and the
divide exception interrupt levels are provided to allow for
simulation of the unimplemented instructions. In this case,
the appropriate exception interrupt level is triggered, when-
ever an attempt is made to execute a MULTIPLY or DIVIDE
instructi on.
Input/Output Group
This interrupt group includes two standard interrupt levels
and eight optional levels. The I/O and control panel in-
terrupt levels are standard; the four counter-equals-zero
interrupt levels and the four integral interrupt levels are
optional.
All interrupt levels in the input/output group can be in-
hibited by means of the internal interrupt inhibit (bit 10
of the PSD), and can be armed, disarmed, enabled, dis-
abled, and triggered by specific configurations of the
WRITE DIRECT instruction.
I/O Interrupt Level. The I/O interrupt level accepts in-
terrupt signals from the standard I/o system. An I/O rou-
tine must contain an ACKNOWLEDGE I/o INTERRUPT
(AIO) instruction that identifies the source and cause of
an I/O interrupt.
Control Panel Interrupt Level. The control panel interrupt
level is connected to the INTERRUPT switch on the proces-
sor control panel. The control panel interrupt level can
10 Interrupt System
thus be triggered by the computer operator, allowing him to
initiate a specific routine.
Counter-equals-zero Interrupt Levels. The counter-equals-
zero interrupt levels are associated with the four optional
real-time clocks. For each clock option installed, the CPU
automatically increments one of four core memory {counter}
locations as the clock pulses are received. When the value
in a counter location equals zero, the corresponding counter-
equals-zero interrupt level is triggered. Counting continues
after the interrupt level is triggered; unless the counter in-
terrupt level is disarmed or disabled, counting will continue
until zero is reached again. (See "Counter Interrupt Pro-
cessing". )
EXTERNAL INTERRUPT LEVELS
A SIGMA 2 system can contain up to 9 groups of optional
interrupt levels, with up to 4 levels in the first integral
group and up to 16 levels in each of the 8 external groups.
The integral levels are controlled as part of the input/
output group of internal interrupt levels (i. e., inhibited
with the internal interrupt inhibit), and have a lower pri-
ority than the other levels in the input/output group. All
interrupts are controlled separately (i.e., inhibited with the
external interrupt inhibit), and can be arranged in almost
any priority sequence (see "Interrupt Priority Sequenc.e").
INTERRUPT LEVEL STATES
A SIGMA 2 interrupt level is mechanized by means of three
flip-flops. Twoof the flip-fl opsare used to define any offour
mutually exclusive states: disarmed, armed, waiting, and ac-
tive. The third fl lp-Flop is used to enabl e or disable the level.
Thevarious states and the condition causing changes in state
(see Figure 3)are described in the following paragraphs.
Disarmed
When an interrupt level is in the disarmed state, no signal
to that interrupt level is admitted; that is, no record is re-
tained of the signal, nor is any program interrupt caused by
it at any time.
Armed
When an interrupt level is in the armed state, it is capable
of accepting and remembering an interrupt signal. The re-
ceipt of such a signal advances the interrupt level to the
waiting state.
Waiting
When an interrupt level in the armed state receives an inter-
rupt signal, it advances to the waiting state, and remains in
the waiting state until it is allowed to advance to the active
state.
If the level-enable flip-flop is off, the interrupt level can
undergo all state changes except that of moving from the
waiting to the active state. Furthermore, if this flip-flop
is off, the interrupt level is completely removed from the
chain that determines the priority of access to the C PU. Thus,

an interrupt level in the waiting state with its level-enable
in the off condition does not prevent an enabled, uninhibited
interrupt level of lower priority from moving to the active
state.
When an interrupt level is in the waiting state, the follow-
ing conditions must all exist simultaneously before the level
advances to the active state.
1. The level is enabled (i. e., its level enable fl ip-flop is
a I).
2. The group inhibit (if applicable) is off (i. e., the appro-
priate inhibit is a OJ.
3. No higher-priority interrupt level is in the active state
(or is in the enabled, waiting state with its inhibit off).
4. The CPU is in an interruptible phase of operation.
Interrupt
state Flip-flop
configurati on Source of
change signal
Level
enable
Disarmed WRITEDIRECT
ar
exit sequence
Armed
External signal
~------------------ or
WRITEDIRECT
Waiting
I
I
$
Disabled WRITEDIRECT
Enabled
Active
I
I
I
I
I
~
Group inhibit off
No higher-priority level
active (or waiting and
enabled)
Interrupt timing
Figure 3. Interrupt Level Operation
Active
When a normal interrupt level meets all of the conditions
necessary to permit it to move from the waiting state to
the active state, it is permitted to do so by being acknowl-
edged by the computer which then stores the current PSD
at the location specified by the contents of the location
associated with the level. The first instruction of the interrupt-
servicing routine is then taken from the location following
the stored PSD. A new interrupt cannot occur unti I after
the execution of this first instruction.
A normal interrupt level remains in the active state until it
is removed from the active state by a specific configuration
of the WRITEDIRECT(WD) instruction, followed by an LDX
instruction. An interrupt-servicing routine can itself be in-
terrupted (whenever a higher-priority interrupt level meets
all of the conditions for becoming active) and then contin-
ued (after the higher-priority interrupt level is removed from
the active state). However, an interrupt-servicing routine
cannot be interrupted by a lower-priority interrupt level as
long as its interrupt level remains in the active state. Nor-
mally, the interrupt-servicing routine returns its interrupt
level to the armed state and transfers program control back
to the point of interrupt by means of an interrupt routine
exit sequence (see "Interrupt Routine Entry and Exit").
INTERRUPT SYSTEM CONTROL
The SIGMA 2 system has two points of interrupt control. One
point of control isachieved by meansof the interrupt inhibits
in the PSD. Theinterruptinhibitscan be changed byexecut-
ing a WRITEDIRECT(WD) instruction or an interrupt routine
exit sequence. The second point of interrupt control isatthe
individua Iinterrupt level. TheWDinstruction can be used to
individually arm, disarm, enable, disable, or trigger any inter-
rupt level (except for the interrupt levels in the override group).
The WD instruction transmits its 16-biteffective address toall
receiving elements of the SIGMA 2 system (see Chapter 3,
"Direct Control Instructions"). In the case of interrupt sys-
tem control, the following configuration of a WD effective
address is used to control the alteration of the various states
of the individual interrupt levels within the interrupt system:
Bit positions 0-3 must contain the value X'I', to specify the
interrupt control mode. Bit positions 5-7 contain the code
for the operation to be performed with the group of 16 inter-
rupt levels (see Table 2) specified by bit positions 12-15.
Bits 4 and 8-11 must be zeros.
Thi 5 instructi on uses the contents of the accumu Iator (general
register 7) to determine which of the interrupt levels in the
specified group are to be operated upon. For example, if
bit positions 12-15 of the WD effective address contain the
value X'O', bit position 0 of the accumulator corresponds to
the counter 4 interrupt level, bit position 1 corresponds to
the counter 3 interrupt level, and so on through bit posi-
tion 15, which corresponds to the integral 4 interrupt level.
Each interrupt level in the designated group is operated on
according to the function code specified by bits 5 through 7
of the effective address of WD. The defined codes and their
associated functions are as follows:
Code Functi on
001 Disarm all levels corresponding to a 1 in the ac-
cumulator; no other levels are affected.
Interrupt System Control 11

Code Function
010 Arm and enable all levels corresponding to a 1 in
the accumulator; no other levels are affected.
Arm and disable all levels corresponding to CI 1 in
the accumulator; no other levels are affected.
Enable all levels corresponding to a 1 in the ac-
cumulator; no other levels are affected.
Disable all levels corresponding to a 1 in the ac-
cumulator; no other levels are affected.
110 Enable all levels corresponding to a 1 in the ac-
cumulator and disable all other levels.
011
100
101
Trigger 011 levels corresponding to a 1 in the ac-
cumulator. All such levels that are currently
armed advance to the waiting state. Those levels
currently disarmed are not altered, and all levels
corresponding to a 0 in the accumulator are not
affected. The interrupt trigger is applied at the
same input point as that used by the device con-
nected to the interrupt level.
The recommended method for produc ing the appropriate con-
figuration of the WRITEDIRECTeffective address is to indi-
rectly address a memory location that contains the appro-
priate bit configuration for the desired effective address.
111
INTERRUPT PRIORITY SEQUENCE
SIGMA 2 interrupts are arranged in groups so that they may
be connected in a predetermined priority arrangement by
groups of levels. The priority of each level within a group
is fixed, with the first level having the highest-priority and
the last level having the lowest-priority. The user has the
option of ordering a machine with a priority chain starting
with the override group and connecting all remaining groups
in any sequence. This a Ilows the user to establ ish external
interrupts above and below the input/output group of inter-
nal interrupts. Figure 4 illustrates this with a configuration
that a user might establ ish, where (after the override and
counter groups) external interrupt group 5 is given second
highest-priority followed by the input/output group and all
succeeding groups of external interrupts.
INTERRUPT ROUTINE ENTRY AND EXIT
When a normal interrupt level becomes active, the computer
automatically saves the program status doubleword (which
contains the protected program indicator, the interrupt in-
hibits, the carry and overflow indicators, and the program
address). The status information is stored in the location
whose address iscontained in the dedicated interrupt location.
The current value in the program address (P)register isstored
in the location following the status information. The sig-
ni ficance of the stored program address depends upon the
particular interrupt level, as follows:
a. For the protection violation, multiply exception,
and divide exception interrupt levels, the stored
program address is the address of the instruction
12 Interrupt System
Override and counter group (1st priority) Ji
L..------_J
External interrupt group 5 (2nd priority) Ji
L...------_J
Input/output group (3rd priority)
External interrupt group 6 (4th priority) Ji
"____--_j
External interrupt group 7 (5th priority)
Figure 4. Interrupt Priority Chain
that was being executed at the time the interrupt con-
dition occurred, or is the address of a nonexistent or
protected location from which an instruction access was
attempted.
b. For all other normal interrupt levels, the stored program
address is the address of the next instruction in sequence
after the instruction whose execution was just completed
at the time the interrupt condition occurred.
After the program address is stored, the next instruction to
be executed is then taken from the location following the
stored program address. The first instruction of the interrupt-
servicing routine is always executed before another inter-
rupt can occur. Thus the interrupt-servicing routine may
inhibit all other normal interrupt levels so that the routine
itself will not be interrupted while in process.
At the end of an interrupt-servicing routine, an exit sequence
restores the program status that existed when the interrupt
level became active. An exit sequence is a WRITEDIRECT
(WD) instruction with an effective address of X'OOD8' fol-
lowed immediately by a LOAD INDEX (LDX) instruction
with an effective address equal to the address value in the
interrupt location for the routine (no interrupt is allowed to
occur between these two instructions). Execution of LDX in
an interrupt routine exit sequence does not affect the con-
tents of index register 1.
COUNTER INTERRUPT PROCESSING
The counter interrupt levels are not associated with interrupt-
servicing routines as such. Instead, an active counter in-
terrupt level is serviced by accessing the contents of the
memory location assigned to the interrupt level, increment-
ing the value in the memory location by I, and restoring the
new value in the same memory location. The processing of

an active counter interrupt level does not affect the over-
flow indicator or the carry indicator. Thus, the on-going
program is not affected by a counter clock pulse (other than
by the time required for processing) unless the result in the
assigned memory location is all O'safter being incremented;
in that case, the corresponding counter-equals-zero inter-
rupt level is triggered.
CPU INTERRUPT RECOGNITION
If all other conditions are met and an interrupt level iswait-
ing and enobled, the CPU will recognize the interrupt fol-
lowing the completion of any instruction except:
1. WD X'OOD8' (precedes LDX for interrupt routine exit)
2. Between the storing of the PSD and the execution of
the next instruction upon entering a normal interrupt
subroutine.
PROTECTION SYSTEM
The primary purpose of the optional protection feature is to
guarantee the integrity of a master or executive-mode (fore-
ground) program whi Ie another (background) program is con-
currently being executed. The SIGMA 2 protection system
provides both operation protection and memory write pro-
tection by means of 16 words of register storage that are in-
stalled as part of the protection option. Each bit in these
16 words is associated with a specific block of core memory.
A block of core memory is a region of 256 consecutive loca-
tions, whose lowest-numbered address issome integer multi-
ple of 256; thus, bit 0 of protection register 0 is associated
with core memory locations 0 through X' FF', bit 1 of pro-
tection register 0 is associated with core memory locations
X'100' through X'1FF', and bit 15 of protection register
X'F' is associated with core memory locations X'FFOO'
through X'FFFF'. A protection bit of 0 designates an
unprotected memory block and a protection bit of 1 desig-
nates a protected block.
The protection registers .ccn be individually loaded by exe-
cuting a WRITEDIRECTinstruction with an effective address
of X'8r', where r is a hexadecima I digit that designates
which of the protection registers is to be loaded from the
accumulator (A register). Thus, the protection bits for 16
memory pages (4096 words) can be set up by executing a
single instruction.
Operation of the protection system is under control of the
PROTECTswitch and the key-operated lock on the processor
control panel (see Chapter 5). If the protection system is op-
erative, the following rules apply:
1. The privileged instructions (READ DIRECTand WRITE
DIRECT) can be executed on Iy if they are accessed
from protected memory. If a pri vi Ieged instruct ion is
accessed from unprotected memory, the instruction is
not executed; instead, the protection violation inter-
rupt level is triggered.
2. An instruction accessed from unprotected memory can be
immediately followed by an instruction accessed from
protected memory only in response to an interrupt con-
dition. If an instruction is accessed from protected
memory and the immediately preceding instruction was
accessed from unprotected memory, the instruction is
not executed (unless it is in response to an interrupt
condition); instead, the protection violation interrupt
level is triggered. This rule applies to branching from
unprotected memory to protected memory as we II as to
executing an instruction in protected memory as the
next instruction in normal sequence after an instruction
in unprotected memory.
3. A STORE ACCUMULATOR (STA) or an INCREMENT
MEMORY (1M)instruction can be used to a Iter protected
memory on Iy if the instruction is accessed from protected
memory. If an attempt is made to alter protected mem-
ory with an instruction accessed from unprotected mem-
ory, the operation is not performed; instead, the
protection violation interrupt level is triggered.
Protection System 13

3. INSTRUCTION REPERTOIRE
This section contains descri ptions of all SIGMA 2 instructions.
With each description is a diagram showing the format of
the instruction and its operation code (as a hexadecimal
digit in the 4 high-order bit positions of the diagram).
Some of the instruction diagrams are divided by a horizon-
rol line, as in the SHIFT instruction on page 15. In these
cases, the upper portion of the diagram represents the in-
struction format, while the lower portion represents the
format of the instruction's effective address. Bit positions
or fields that are shaded represent portions of the instruc-
tion's effective address that are ignored. However, these
areas should always be coded with O's ta preclude conflict
with features that may be implemented in the future.
Above each diagram are the mnemonic code and name of
the instructions, sometimes followed by a parenthetic note
about optional features or privi leged operation. Under
each diagram is a description of the lnstrucrion, followed
by a list of the registers and indicators that can be affected
by the instruction. The minimal execution time of the in-
struction is given in half-cycles (hc).
The following abbreviations are used in the descriptions:
A Accumulator (general register 7)
E Extended accumulator (general register 6)
X 1 Index 1 (general register 4)
P Program address register (general register 1)
PP Protected program indicator (PSD bit 8)
II Internal interrupt inhibit (PSD bit 10)
EI External interrupt inhibit (PSD bit 11)
o Overflow indicator (PSD bit 14)
C Carry indicator (PSD bit 15)
EL Effective location
EW Effective word, or (EL)
MEMORY REFERENCE INSTRUCTIONS
LDA LOAD ACCUMULATOR
accumulator (general register 7).
Affected: (A) Time:
5 hc
STA STOREACCUMULATOR
STOREACCUMULATOR stores the contents of the accumu-
lator into the effective location.
Affected: (El) Time: 5 hc
14 Instruction Repertoire
LDX LOAD INDEX
Displacement
8 9 10 11 12 13 14 15
LOAD INDEX loads the effective word into index 1 (general
reg ister 4).
Affected: (X 1)
Time: 5 hc
When LOAD INDEX is executed as the next instruction in
sequence after a WRITEDIRECT(WD) instruction with an
effective address of X'OOD8', index register 1 is not af-
fected; instead, LOAD INDEX performs the following op-
erations in order to restore the program environment thot
existed before the computer acknowledged an interrupt
condition:
1. sets the protected program indicator equal to bit 8 of
the effective doubleword
2. sets the internal interrupt inhibit equal to bit 10 of the
effective doubleword
3. sets the external interrupt inhibit equal to bit 11 of the
effective doubleword
4. sets the overflow indicator equal to bit 14 of the effec-
tive doubleword
5. sets the carry indicator equal to bit 15 of the effective
doubleword
6. loads bits 16 through 31 of the effective doubleword
into the program address register (general register 1)
7. clears the highest-priority active interrupt level and re-
turns the interrupt level to the armed state
8. resets the exit condition that was set by the precedi ng
WD instruction (that caused LDXto perform the above
operations)
Bits 0 through 7, 12, and 13 of the effective doubleword are
ignored.
Affected: PP, II, EI, 0, C, (P), highest-
priority active interrupt level Time:
6 hc
ADD ADD
A I RII !xisI Displacement I
o I23"567 a 9 10 11112 13 14 15
ADD adds the effective word to the contents of the accumu-
lator and then loads the result into the accumulator. If the
signs of the two operands are equal but the sign of the re-
sult is different, overflow has occurred, in which case the
overflow indicator is set to 1. If overflow does not occur,
the overflow indicator is reset to O. The carry indicator is
settol ifacarryoccurs from the sign bit position oftheadder;
if such a carry does not occur, the carry indicator is reset
to O.
Affected: (A), 0, C Time: 5 hc
