Xeleum Zephyr Gen2 Series User manual

www.xeleum.com Page 1 of 10Xeleum Lighting, LLC. 3430 Quantum Blvd. Boynton Beach, FL 33426 * Phone [phone] * Fax [phone] * www.xeleum.com
Zephyr Gen2 Series
LED Area Light Fixture
Installation Guide
The Zephyr G2 Series of IP67 rated LED luminaires are
designed for pole mounting in outdoor open areas.
Their high energy efficiency and sleek appearance
make them an elegant replacement for traditional
shoebox lighting.
READ AND FOLLOW ALL
SAFETY INSTRUCTIONS
SAVE THIS GUIDE FOR FUTURE
REFERENCE
IMPORTANT ADVISORIES AND SAFEGUARDS
1) Suitable for Installation in wet locations (IP67 rated)
2) Follow all standards specified by the NEC for installation. Consult a local licensed
electrician or electrical contractor if you are unsure.
3) When using electrical equipment, basic safety precautions should always be followed.
Items such as gloves and protective eyewear are recommended.
4) DO NOT lift the fixture by its wires.
5) Always ensure the fixture is secure when mounted, temporarily or permanently, at any
height above ground.
6) These instructions do not purport to cover all details or variations in equipment nor to
provide every possible contingency to meet in connection with installation, operation,
or maintenance.
WARNING!
Risk of Electric Shock. Turn power
off before installation or servicing.
General Product Information
Unpacking
This fixture has been packed carefully with the intent to
prevent damage from occurring during shipment.
Inspect the contents to confirm.
Fixture Specifications
Input 100-277VAC. Max Dimensions (28x16x4.5)in. Max
Weight: 25lbs (Fixture), 29lbs (Packaged). IP67. ETL listed.

Installation Steps
Tenon Mounting
Xeleum Lighting, LLC www.xeleum.com PL-015-WSB-112 Page 2
Step 1
Connect the bracket
to the pole
Mounting Component Options
Step 2
Align the fixture with the
bracket and drop it on
Step 3
Tighten and secure all
screws
Square Pole Mounting
Step 2
Align the fixture with the
bracket mount.
Step 3
Tighten and secure all
screws.
Step 1
Drill holes and utilize the internal
and external brackets to fix the
mount to the pole

Installation Steps
Round Pole Mounting
Xeleum Lighting, LLC www.xeleum.com PL-015-WSB-112 Page 3
Step 1
Drill holes and utilize the internal
and external brackets to fix the
mount to the pole
Step 2
Align the fixture with the
bracket and drop it on
Step 3
Tighten and secure all
screws
Additional Features for Installation
40mm Adapter
An additional adapter can be used on
40mm diameter poles. Having the
adapter is convenient for smaller
poles and can reduce inventory.
Bubble Level
The base comes equipped with a
bubble level that will allow the installer
to easily determine whether the fixture
is tilted or not. If so, loosen screws and
adjust the position accordingly until the
buble is centered between the two
black markers.

Compartment for Easy Wiring
Xeleum Lighting, LLC www.xeleum.com PL-015-WSB-112 Page 4
Open the twist lock on the outside of the mount base to
reveal a compartment for making wiring connections.
Slot Design
The slot design of the mounting
bracket allows for the bracket
to fit different positions of
holes already set on the poles.
Can be adjusted between 48mm(1.89in.)-
142mm(5.59in.) [Hole distance of pole]
Adjustable Slip Fitter
The base has an internal, adjustable slip fitter that saves time by allowing for a standard
mounting process then adjustment later. The compartment is opened with a wide
screwdriver or 5 cent coin. The slip fitter angle is adjusted by a Hex screwdriver and is 180
degree adjustable.

Appendix
Maintenance Notes
Electrical Connections
Zephyr Fixture
Black GND White
Incoming Mains
Live/Hot
Earth/GND
Neutral
Wire
Compartment
Steps
1) For 100-277VAC input, connect
the black wire coming from the
LED fixture to Live/Hot voltage
wire inside the junction box or
cone (depending on mounting
style).
2) For 100-277VAC input, connect
the white wire coming from the
LED fixture to the Neutral wire
inside the junction box.
3) Connect the Green or
Green/Yellow ground wire to the
appropriate green Earth Ground
wire.
•Maintenance of the luminaires should be performed by person(s) familiar with the luminaires
construction and operation and any hazards involved.Regular fixture maintenance programs are
recommended.
•It will occasionally be necessary to clean the outside of the refractor/lens.Frequency of cleaning will
depend on ambient dirt level and minimum light output which is acceptable to user.Refractor/lens
should be washed in asolution of warm water and any mild, non-abrasive household detergent,
rinsed with clean water and wiped dry.
Optional Accessory: Top Lid
Step 1
Make the holes
of the cover that
correspond to
the fixture.
Step 2
Fasten the
screws tightly.
P/N: MC-002-27-xxx
Lid protects against Debris and Wildlife
Driver Maintenance
Step 1
If fixture fails,
contact Xeleum
for replacement
LED driver
Step 2
Lift the latches on
the left and right to
open driver
compartment
Step 3
Replace old driver with new, utilizing same
wiring connections and locations
Xeleum Lighting, LLC www.xeleum.com PL-015-WSB-112 Page 5

Xi-Fi® communication capability comes integrated into the Zephyr G2 fixture, so
applying power to the fixture normally is all that is required to get the system working.
After the fixtures are installed, configuration can be performed using the laptop-based
Xi-Fi® App, which wirelessly communicates directly with the installed fixtures.
The grouping, dimming, and/or motion timeout settings can be set and updated at any
time, in minutes, either by an installer or site manager via the user friendly Xi-Fi®App -
features such as these are typically available only with much more complex and
expensive lighting control systems.
The unique Xi-Fi®control system wirelessly links and controls any Xi-Fi®enabled
Xeleum LED Luminaire for up to 255 zones to be set for any Xi-Fi®enabled units. The
system utilizes a mesh network topology and each unit acts as an individual network
node; these nodes can be spaced up to 150 feet apart and maintain system integrity.
Zephyr fixtures have an integrated microwave doppler effect sensor that detects any
human or motorized motion. That motion event triggers a preset level of brightness not
only on the unit that detects the motion, but all units configured to the same zone.
These zones can be configured through Xeleum's Xi-Fi®App and USB Dongle, which can
be completed much faster via software.
The Xi-Fi®App allows your system to be dynamic post-installation, and allows the
customer to save energy in their own personalized way. Contact a Xeleum
representative or visit www.Xeleum.com/xifi for more details.
Xeleum’s Xi-Fi®Wireless Control System
Xeleum Lighting, LLC www.xeleum.com PL-015-WSB-112 Page 6

Live/Hot
Earth/GND
Neutral
Incoming Wires
[Chassis]
LED’s
V+
V-
Zephyr Wiring Diagram [Default]
Red
Blue
White
White
Black
Red
Black
Green
Black w/White
Purple
Gray

Antenna
Live/Hot
Earth/GND
Neutral
Incoming Wires
[Chassis]
LED’s
V+
V-
[Jumper]
Zephyr Wiring Diagram w/Xi-Fi
White
White
Black
Red
Red
Blue
Black w/White
Purple
Gray
Purple
Gray
Black
Green
