Xiaomi Smart Speaker IR Control User manual

Smart Speaker (IR Control) User Manual

Power Adapter
User Manual
Smart Speaker
Package List
1

2
Plug in the device
Now that we have the soware we need, it’s time to get the hardware itself set up.
Take the power adaptor that came packaged with the device and plug in into the
DC input port, then take the the adapter and plug in into your wall outlet.

3
Download the Google Home app
All of the seings and controls during the setup process are carried out through
the Google Home app, so you’ll need to download it to your phone or tablet. On iOS
and on Android™ devices it is on Google Play.
Google, Android, Google Play, Chromecast built-in and other marks are trademarks of Google LLC.
Google Assistant is not available in certain languages and countries.
App Store is a trademark of Apple Inc.

4
Download the Mi Home app
Download the Mi Home app on Google Play or the App Store. Hold your device
near the speaker, then complete the on-screen setup.
Google, Android, Google Play, Chromecast built-in and other marks are trademarks of Google LLC.
Google Assistant is not available in certain languages and countries.
App Store is a trademark of Apple Inc.

5
Infrared Devices Setup
To open the Mi Home app, check the applicable device categories and product
brand, then follow the on-screen steps to finish the infrared devices setup.
* Infrared (IR) remote control compatible brands and devices may change from time to time based
on the circumstances of our corporate business development. Xiaomi does not guarantee real time
updates of the package and user manual, and actual functions and contents may vary.

6
Talking to your device
The Xiaomi Smart Speaker (IR Control) has Google Assistant. Just say “Ok Google”
to get started, and get more done at home, hands-free.

7
Play some music
Turn up the volume
Next song
Turn on the lights
Set temperature to 22 degrees
Is Daniel's bedroom light on?
Play and control music
Control your home
Good morning
Set a timer for 15 minutes
Set an alarm for 7am tomorrow
Remind me to buy milk tonight
Broadcast it’s dinnertime
Get things done
Tell me a fun fact
What can you do?
Find my phone
Try fun things
Ok Google
To discover more about Google Assistant can do, visit assistant.google.com
*Controlling certain devices and features in your home requires a compatible smart device and/or
Chromecast device. Subscriptions are required to access some content.
What’s the latest news?
What’s the weather this
weekend?
What time is it in London?
What is my agenda today?
Plan your day and get
answers

8
Buon Instruction
Volume up
Volume down
Listening Solid light (white)
Thinking, Alarm and Timer Pulse slowly (white)
Hotword Timeout Blink once (white)
Responding Pulse continuously (white)
Microphone Disabled Solid light (orange)
Indicator light description
Factory reset: Press
and hold both volume
buons together for
about 10 seconds.
Play / Pause: Click
Mi Home setup: Press and
hold for 5 seconds. This
action will reset your device
in the Mi Home app, and you
can set it up as new.
Adjust the digital clock
brightness: Triple-click, then
press volume up/down to
adjust.
Mic on / off: Click. The one-dot indicator
will display solid orange when the
microphone is turned off.

9
WARRANTY NOTICE
1. LIMITED PRODUCT WARRANTY
THIS WARRANTY GIVES YOU SPECIFIC RIGHTS, AND YOU MAY HAVE OTHER
RIGHTS CONVEYED BY LAWS OF YOUR COUNTRY, PROVINCE OR STATE. INDEED,
IN SOME COUNTRIES, PROVINCES OR STATES, CONSUMER LAW MAY IMPOSE A
MINIMUM WARRANTY PERIOD. OTHER THAN AS PERMITTED BY LAW, XIAOMI
DOES NOT EXCLUDE, LIMIT OR SUSPEND OTHER RIGHTS YOU MAY HAVE. FOR A
FULL UNDERSTANDING OF YOUR RIGHTS WE INVITE YOU TO CONSULT THE
LAWS OF YOUR COUNTRY, PROVINCE OR STATE.
This contractual Warranty applies only to the hardware components of Xiaomi Product (hereaer
“Product”) as originally supplied and does not apply to any soware or other equipment that are
owned by Xiaomi or third parties for which an end-user license agreement or separate
warranty/guarantee statements or exclusions are provided or intended to apply.
Xiaomi warrants that the Products are free from defects in materials and workmanship under
normal use and use in accordance with the respective Product user manual, during the Warranty
Period.
The duration and conditions related to the legal warranties are provided by respective local laws.
For more information about the consumer warranty benefits, please refer to Xiaomi's official
website hps://www.mi.com/en/service/warranty/.
Xiaomi warrants to the original purchaser that its Xiaomi Product will be free from defects in
materials and workmanship under normal use in the period mentioned above.
Xiaomi does not guarantee that the operation of the Product will be uninterrupted or error free.
Xiaomi is not liable for damages arising from non-compliance with the instructions related to the
use of the Product.

10
2. REMEDIES
If a hardware defect is found and a valid claim is received by Xiaomi within the Warranty Period,
Xiaomi will either (1) repair the product at no charge, (2) replace the product, or (3) refund the
Product, excluding potential shipping costs.
3. HOW TO OBTAIN WARRANTY SERVICE
To obtain warranty service, you must deliver the Product, in its original packaging or similar
packaging providing an equal degree of Product protection, to the address specified by Xiaomi.
Except to the extent prohibited by applicable law, Xiaomi may require you to present proofs or
proof of purchase and / or comply with registration requirements before receiving warranty
service.
4. EXCLUSIONS AND LIMITATIONS
Unless otherwise stipulated by Xiaomi, this Limited Warranty applies only to the Product
manufactured by or for Xiaomi and identifiable by the trademarks, trade name or "Xiaomi" or "Mi"
logo.
The Limited Warranty does not apply to any (a) Damage due to acts of nature or God, for example,
lightning strikes, tornadoes, flood, fire, earthquake or other external causes; (b) Negligence; (c)
Commercial use; (d) Alterations or modifications to any part of the Product; (e) Damage caused by
use with non-Xiaomi products; (f) Damage caused by accident, abuse or misuse; (g) Damage
caused by operating the Product outside the permied or intended uses described by Xiaomi or
with improper voltage or power supply; or (h) Damage caused by service (including upgrades and
expansions) performed by anyone who is not a representative of Xiaomi.
It is your responsibility to backup any data, soware, or other materials you may have stored or
preserved on the product. It is likely that the data, soware or other materials in the equipment
will be lost or reformaed during the service process, Xiaomi is not responsible for such damage
or loss.
No Xiaomi reseller, agent, or employee is authorized to make any modification, extension, or
addition to this Limited Warranty. If any term is held to be illegal or unenforceable, the legality or
enforceability of the remaining terms shall not be affected or impaired.
Except as prohibited by laws or otherwise promised by Xiaomi, the aer-sales services shall be
limited to the country or region of the original purchase.

11
Products which were not duly imported and/or were not duly manufactured by
Xiaomi and/or were not duly acquired from Xiaomi or a Xiaomi’s official seller are
not covered by the present warranties. As per applicable law you may benefit from
warranties from the non-official retailer who sold the product. Therefore, Xiaomi
invites you to contact the retailer from whom you purchased the product.
5. IMPLIED WARRANTIES
Except to the extent prohibited by applicable law, all implied warranties (including
warranties of merchantability and fitness for a particular purpose) will have a
limited duration up to a maximum duration of this limited warranty. Some
jurisdictions do not allow limitations on the duration of an implied warranty, so the
above limitation will not be applied in these cases.
6. DAMAGE LIMITATION
Except to the extent prohibited by applicable law, Xiaomi shall not be liable for any
damages caused by accidents, indirect, special or consequential damages,
including but not limited to loss of profits, revenue or data, damages resulting from
any breach of express or implied warranty or condition, or under any other legal
theory, even if Xiaomi has been informed of the possibility of such damages. Some
jurisdictions do not allow the exclusion or limitation of special, indirect, or
consequential damages, so the above limitation or exclusion may not apply to you.
7. CONTACT INFORMATION
For customers, please visit the website: hps://www.mi.com/en/service/warranty/
The contact person for the aer-sale service may be any person in Xiaomi's
authorized service network, Xiaomi's authorized distributors or the final vendor
who sold the products to you. If in doubt please contact the relevant person as
Xiaomi may identify.

12
Input 12V 1A
Wireless IEEE 802.11a/b/g/n/ac (2.4GHz/5GHz) WiFi
Name Xiaomi Smart Speaker (IR Control)
Model L05G
Bluetooth BT 5.0
Technical Specifications
BLE 2402MHz~2480MHz (≤10dBm)
This device is restricted to indoor use only when operating in 5150-5350MHz frequency
range in following countries:
Operating Frequency and Radio Frequency Power
WiFi
BT 2402MHz~2480MHz (≤10dBm)
2412MHz~2472MHz (≤20dBm), 5150MHz~5250MHz (≤23dBm)
5250MHz~5350MHz (≤20dBm), 5470MHz~5725MHz (≤20dBm)

13
Google Assistant
With Xiaomi Smart Speaker (IR Control), you can easily talk to Google and enjoy music at home
just with your voice. You can play your favorite music, control volume and find information about
the song that you are listening to, hands-free. You can also plan your day, set alarms and control
smart devices around your home -- just say “Ok Google” to get started.
With Chromecast built into your speakers, your phone becomes your remote. Simply tap the
Cast buon from apps you already know and love to stream music from your phone, tablet or
laptop to your speakers.
Chromecast built-in™

14
Certifications:
Hereby, Xiaomi Communications Co., Ltd declares that the radio equipment type L05G is in
compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available
at the following internet address:
hp://www.mi.com/global/service/support/declaration.html
All products bearing this symbol are waste electrical and electronic equipment (WEEE as in
directive 2012/19/EU) which should not be mixed with unsorted household waste. Instead, you
should protect human health and the environment by handing over your waste equipment to a
designated collection point for the recycling of waste electrical and electronic equipment,
appointed by the government or local authorities. Correct disposal and recycling will help prevent
potential negative consequences to the environment and human health. Please contact the
installer or local authorities for more information about the location as well as terms and
conditions of such collection points.
Caution:
The product can be used within all European Union countries.
To comply with CE RF exposure requirements, the device must be installed and operated 20cm (8 inches)
or more between the product and all person’s body.
The adapter shall be installed near the equipment and shall be easily accessible.
You can find the product specification label at the base of the device.
Google, Android, Google Play, Chromecast built-in and other marks are trademarks of Google LLC.
Google Assistant is not available in certain languages and countries.

15
Name: Xiaomi Smart Speaker (IR Control)
Model: L05G
Manufacturer: Xiaomi Communications Co., Ltd.
Address: #019, 9th Floor, Building 6, 33 Xi’erqi Middle Road, Haidian District,
Beijing, China
Importer:
Beryko s.r.o.
Pod Vinicemi 931/2, 301 00 Plzeň
www.beryko.cz
