Xibu inox exFRAME foam User manual

inox exFRAME foam/disinfect/seatCLEANER

exFRAME foam/disinfect
1 Stück/piece
4 x
4 x
4 x
1 x
Ø 6 mm
(0.238 in)
exFRAME tissuepaper

FOR THE UNITED STATES ONLY
General Safety Information
The following symbols and headings are used throughout this manual to indicate possible hazards to
persons or equipment. The symbols and headings are shown in order of importance. For efficient and safe
operation, be sure to follow the installation and operating instructions provided in this manual. In particu-
lar, all safety symbols and notices must be followed.
Indicates a potentially hazardous situation which, if
not avoided, could result in serious injury or death.
Indicates a potentially hazardous situation which, if
not avoided, could result in minor personal injury.
This safety warning indicates possible hazards to
the product or to other equipment.
Vital information or tips for the installer or operator.
IMPORTANT
General Safety Instructions
When using electrical appliances, basic safety
precautions should always be followed.
CAUTION
For HAGLEITNER senseMANAGEMENT devices only
NOTE This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable pro-
tection against harmful interference in a residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that inter-
ference will not occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
— Reorient or relocate the receiving antenna.
— Increase the separation between the equipment and receiver.
— Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
— Consult the dealer or an experienced radio/TV technician for help
— Americans with Disabilities Act: Title III of the Americans with Disabilities Act (ADA) governs, in
detail, the placement and operation of dispensers. You should ensure that your mounting and
use of dispensers complies with that law as well as the regulations issued under that statute.
The mounting suggestions in this document may or may not fulfill the obligations of the ADA with
respect to your facility.
WARNING
CAUTION
NOTICE

1.
854 mm
(min. 33.6 in)
XIBU senseFOAM
XIBU touchFOAM
XIBU senseDISINFECT
XIBU touchDISINFECT
LUNA cremeSEIFEN
LUNA schaumSEIFEN
LUNA abrasivSEIFEN
LUNA handPROTECT
XIBU exFRAME new
min
70 mm (min. 2.76 in)
min. 35 mm
(min. 1.38 in)
NOTICE
Do not mount
above mirrored
surfaces and
maintain the
minimum
installation
dimensions.
min. 35 mm
(min. 1.38 in)

2.
3.
CAUTION
Before drilling the holes,
make sure there are no
pipes or wires located
behind the wall.

4. optionaloptional powerPACK
!
CAUTION
Always connect the
grounding cable if the
optional powerpack is
used.

5. +/-1°
6.
Level the inox exFRAME
before installing the
dispenser.
IMPORTANT

Art.-Nr. 303012440000
Nov. 2017 / DSSP035-05
9.
CLEAN
fensterTUCH VITAL
Art.-Nr. 4450300400
glasEFFEKT
Art.-Nr. 4450200708
niroGLANZ
Art.-Nr.
4210100708
CARE
7. 8.
