Installation and Maintenance Instructions
Xpelair SL100 / SL150 Standard
Xpelair SL100P / SL150P Pull Cord
Xpelair SL100T / SL150T Timer
Xpelair SL100HT / SL150HT Humidistat, Timer and Pull Cord
Xpelair SL100PIR / SL150PIR Integral Body Movement Sensor
Toilet / Bathroom 100mm and 150mm AC Slimline Fan Range

AB
C D
SL100 Overall Dimensions
SL150 Overall Dimensions
Setting the fan.
SL100T / SL100PIR / SL150T / SL150PIR Only.
To adjust the over-run period turn the control (T) clockwise to increase and anti-clockwise to decrease –see Figure F.
SL100HT / SL150HT Only –see figures F and G.
The pre-set humidity operation is factory set at approximately 75% Relative Humidity (RH), but can be adjusted between 65%
and 85% RH by control H.
The over -run timer can be adjusted up to 30 minutes by control T – see Figure F.
Turn the controls clockwise to increase RH or time and anti-clockwise to decrease –see Figure F.
The fan can be set so that there is a 2-minute time delayed start to its operation when used with an external on/off switch.
To set the time delay start to ON (fan does not start for 2 minutes) set the jumper switch to position shown in figure F.
To set the time delay start to OFF (fans starts immediately) set the jumper switch to position shown in figure F.
Using the fan.
SL100 / SL150 Only
Operate the fan using the on/off switch. Repeat to switch off.
SL100P / SL150P Only
Operate the fan by pulling and releasing the cord. Repeat to switch off.
SL100T / SL150T Only
Operate the fan using an on/off switch (not supplied). When the switch is turned off, the fan continues to operate for the set
time delay. To adjust the over-run period, turn the control “T” clockwise to increase and anti-clockwise to decrease –see
Figure F.
SL100HT / SL150HT Only –see Figures F and G.
Automatic mode -The fan automatically adjusts to slow changes in natural humidity levels without operating the fan. If the
humidity levels increase at a rate slower than 5% RH in 5 minutes, up to the pre-set humidity level, the fan will not be triggered
by humidity. This is to prevent nuisance triggering of the fan. If humidity levels increase quicker than 5% RH in 5minutes the
fan will operate. When relative humidity drops the fan continues to operate for the adjustable time delay.
Manual mode -Use the integral pull cord switch. When the fan is switched off, it goes into automatic mode. Light flashes when
the fan is operating in manual mode.
External operation -Use the external on/off switch. When the fan is switched off, the fan continues to operate for the
adjustable time delay then goes into automatic mode. The fan can be set so that there is a 2-minute time delayed start to its
operation when used with an external on/off switch.
SL100PIR / SL150PIR Only
The sensor detects movement in the room and activates the fan. When movement is sensed, the fan will run for a pre-set
overrun period and any further movement sensed will re-start the sequence. This ensures that the room is only ventilated
after use.
When the fan is first installed there will be a stabilising period of approximately five minutes. During this time the fan will run
for up to 2 minutes.
All Fans
Re-fit the front cover by hooking in the top corners first, and then swing the cover down to fit the bottom corners. Re-fit the screw.
Re-fit the electrical cover.
Cleaning (recommended once a month).
1. Before cleaning, isolate the fan completely from the mains supply.
2. Remove the front cover by removing the screw from the underside of the cover and pulling off the cover from the bottom
corners first.
3. To clean the front cover, either wipe it with a damp, lint free cloth or wash it with warm soapy water. Thoroughly dry the front
cover and refit.
4. Do not immerse the fan in water or other liquids to clean any other parts of the fan.
5. Do not use strong detergents, solvents or chemical cleaners
6. Allow fan to dry thoroughly before use.
7. Apart from cleaning, no other maintenance is required.

Preparing the hole.
If working above ground floor level, safety precautions must be observed.
WARNING: EYE PROTECTION MUST BE WORN DURING ALL DRILLING AND CHISELLING OPERATIONS.
If installing in a Wall.
1. Check there are no buried pipes or cables in the wall or obstructions on the outside e.g. electricity, gas, water. If in doubt, seek
professional advice.
2. Mark on the wall the centre of the duct hole.
For SL100 range the centre of the hole should be at least 110mm away from the edge of the mounting surface,
For the SL150 range the centre of the hole should be at least 145mm away from the edge of the mounting surface.
3. Use this centre to mark a circle ƒ100mm for SL100 range / ƒ150mm for SL150 range (or to suit the wall duct ƒ115mm for
SL100 range / ƒ165mm for SL150 range).
If core drill equipment is available:
4a. Use as directed by core drill manufacturer.
If core drill equipment is not available:
4b. Drill a centre hole right through the wall.
5. Cut the hole. Do not cut right through the wall. (The recommended method is to drill a series of holes, close together, around
the edge of the cutting line and remove the brick between the holes with a chisel).
6. Go outside and cut a hole in the outer wall, repeating the process above.
7. Cut ducting to the correct length if required.
8. Fit the ducting. Ensure that the duct slopes down away from the fan to allow drainage of any incoming rain water to the
outside.
9. Make good the hole Allow the mortar to set before continuing the fan installation.
If installing in a ceiling.
1. Check there are no buried pipes or cables in the ceiling/joists etc. If in doubt, seek professional advice.
2. Cut a hole ƒ100mm for SL100 range or ƒ150mm for SL150 range.
Preparing the fan for installation.
Remove the front cover by removing the screw from the underside of the cover and pulling off the cover from the bottom
corners first.
Remove the electrical cover by removing the 2 screws.
Mount the fan in the hole
If working above ground floor level, safety precautions must be observed.
If installing in a wall or ceiling.
Mark the position of the backplate
1. Hold the backplate so that the word “TOP” marked on it is orientated correctly.
2. Carefully insert the lip into the wall duct/ceiling.
3. Adjust the position of the backplate until it is level.
4. Mark on the wall/ceiling the positions of the fixing holes in the backplate.
5. Remove the back plate from the ducting.
6. Drill screw holes in these positions if necessary, and fit wall plugs if necessary.
Mount the backplate.
1. If installing in a ceiling, appropriate termination ancillaries are required. Follow instructions provided.
2. Remove knockout. Feed the mains cable through the cable entry hole in the back plate to the terminals.
3. Insert the lip of the backplate into the wall duct/ceiling as before.
4. Fasten the backplate to the wall/ceiling using appropriate fasteners. See figure C.
If using screws, do not over tighten.
The fans may also be fixed to the interior of the ceiling using the clamping brackets. Tighten the screws until the fan is firmly
fixed within the hole - see figure D.
Wire the electrical connections.
1. Make sure the mains supply is isolated,
2. Wire the fan as shown in figure E. Check the fan model to diagram, feeding the cable to terminal block.
3. Switch off the mains electrical supply and remove fuses
4. Connect the cable from the isolating switch to the electrical supply wiring.
For fixed wiring circuits the protective fuse for the appliance must not exceed 5A.
E
F
G

Xpelair SL100 / SL100P / SL100T / SL100HT / SL100PIR
Xpelair SL150 / SL150P / SL150T / SL150HT / SL150PIR
Slimline Range of Toilet /Bathroom Fans
Installation and operating instructions.
Please leave this leaflet with the fan for the benefit of the user.
Installing the fan.
These appliances are intended for connection to fixed wiring.
Check that the electrical rating shown on each fan matches the mains supply.
THESE APPLIANCES ARE DOUBLE INSULATED AND DO NOT REQUIRE AN EARTH CONNECTION.
All installations must be supervised by a qualified electrician. Installations and wiring must conform to current IEE Regulations (UK),
local or appropriate regulations (other countries).
This appliance is not intended for use by persons (including children and the infirm) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the
appliance by a person responsible for their safety. Children should be supervised to ensure they do not play with the appliance.
If you have any queries before installing these products or after they have been installed, call the Xpelair Technical Hotline
[phone]. Our engineers are there to help you during normal office hours (UK only) and may be faxed at all other times
on [phone].
Customers outside the UK should contact your local Xpelair distributor.
Description.
All Slimline fans have the following features:
Single speed extraction
Built-in back draught shutter
SL100/SL150 -Operate the fan using an on/off switch (not supplied).
SL100P/SL150P -Operate the fan using an integral pull-cord.
SL100T/SL150T -Built-in timer operates fan for a preset delay of up to 30 minutes.
SL100HT/ SL150HT -Operates when triggered automatically by the humidity sensor, using an external on/off switch or using the
integral pull cord switch (light flashes when the fan is operating in manual mode).
In automatic mode:the built-in timer automatically operates the fan for a pre-set delay time of up to 30
minutes once humidity drops below the pre-set Relative Humidity (RH) value.
In manual mode:when the fan is switched off, it goes into automatic mode. Light flashes when the fan is
operating in manual mode.
External operation: The fan can be set so that there is a 2-minute time delayed start to its operation when
used with an external on/off switch. When switched off using the external on/off switch the fan continues to
run for the preset delay of up to 30 minutes.
SL100PIR/ SL150PIR -An integral body movement sensor operates the fan as long as movement is detected.
Built-in timer automatically operates fan for a preset delay of up to 30 minutes.
What the installer will need.
A means for disconnection in all poles must be incorporated in the fixed wiring in accordance with wiring regulations
(wall or ceiling mounted).
If metal switch boxes are used, earthing regulations must be followed.
Suitably rated 2-core cable –SL100 / SL100P / SL100PIR / SL150 / SL150P / SL150PIR.
Suitably rated 3-core cable –SL100T/ SL100HT / SL150T / SL150HT.
3mm electrician’s screwdriver and No.1 or 2 Pozidrive screwdrivers.
A wall or ceiling on/off switch –SL100T / SL100HT / SL150T / SL150HT.
It is recommended to use a switch with an indicator light.
To prevent a possible hazardous situation from water ingress, an appropriate condensation trap must be fitted as close as
possible to the fan in all situations where any section of the duct work is positioned higher than the fan itself.
FOR SL100 Range: If wall mounting the fan, you will also need:
SLWK10 Wall Kit, or alternatively, an appropriate Wall Grille and ƒ100mm ducting.
A Masonry drill, hammer & chisel (or core drill equipment if available).
Mortar to make good the hole around the ducting.
FOR SL100 Range: If ceiling mounting the fan,
You will need the use of appropriate ancillaries for termination. These items are available from Xpelair:
1. WT10 –Termination ducting kit.
2. FD100 –Flexible Ducting.
3. XCT100 –Condensation Trap.
FOR SL150 Range: If wall mounting the fan, you will also need:
SLWK15 Wall Kit, or alternatively, an appropriate Wall Grille and ƒ150mm ducting.
A Masonry drill, hammer & chisel (or core drill equipment if available).
Mortar to make good the hole around the ducting.
FOR SL150 Range: If ceiling mounting the fan,
You will need the use of appropriate ancillaries for termination. These items are available from Xpelair:
1. WT15 –Termination ducting kit.
2. FD150 –Flexible Ducting.
Where to locate the fan.
Locate it as high as possible.
For the SL100 range At least 110mm from the edges of the mounting surface to the centre of the hole.
For the SL150 range At least 145mm from the edges of the mounting surface to the centre of the hole.
As far away as possible from and opposite to the main source of air replacement to ensure airflow across the room (e.g.
opposite the internal doorway).
Near the source of steam or odours.
Not where ambient temperatures are likely to exceed 50•C.
If installed in a kitchen fans must not be mounted immediately above a cooker hob, or eye level grill.
If installing in a room containing a fuel burning device which has a non-balanced flue, it is the installer's responsibility to
ensure that there is enough replacement air to prevent fumes being drawn down the flue when the fan is operating up to
maximum extract. Refer to Building Regulations for specific requirements.
Exhaust air must not be discharged into a flue used for exhausting of fumes from appliances supplied with energy other
than electric. Requirements of all authorities concerned must be observed for exhaust air discharge and intake flow rates.
When intended for use in possible chemical corrosive atmospheres, consult out Technical Service Department. (For overseas
markets contact your local Xpelair distributor).
SL100PIR / SL150PIR Only –Siting must ensure detection of movement. Care should be taken to avoid obstruction that may
affect detection beams. See figure A.
Installing the isolating switch and cables.
1. Check that the electrical rating shown inside the backplate matches your mains supply.
2. Check there are no buried pipes or cables e.g. electricity, gas, water behind the switch location (in the wall or above the
ceiling). If in doubt, seek professional advice.
3. Isolate the mains supply.
4. Lay in the cable from the isolating switch to the fan location via the on/off switch (if required).
5. Lay in the cable from the isolating switch to the point of connection to the mains supply.
Warning: Do not make any connections to the electrical supply at this stage.
6. Install the isolating switch and on/off switch (if required).
7. Make all connections within the isolating switch and the on/off switch (if required).
Note: on/off switch must be situated so that it cannot be touched by persons making use of the bath or shower.
WARNING: DO NOT MAKE ANY CONNECTIONS TO THE ELECTRICAL SUPPLY AT THIS STAGE.
If in doubt, seek professional advice.
For Australia Only -SL100 / SL100P / SL100PIR
SL150 / SL150P / SL150PIR
Connection to the supply can be made by a flexible 2-core cable complete with 3 pin plug for insertion into an approved 10A GPO or
directly wired through an approved 10A wall mounted surface switch with at least 3mm clearance betweencontacts.
For Australia Only -SL100T / SL100HT / SL150T / SL150HT
These models are permanently connected to the supply and operation is controlled by a remote switch. They should be directly wired to
the supply through an approved 10Awall mounted surface switch with at least 3mm clearance between contacts.
