Xpelair Ripple Standard 4" User manual

Installation and Maintenance Instructions
067012 - XR100S Xpelair Ripple Standard 4” Fan
067036 - XR100T Xpelair Ripple Timer 4” Fan
Do read the entire instruction leaflet before commencing installation.
Do install each fan with a means for disconnection in all poles in the
fixed wiring.
Do make sure the mains supply is switched off before attempting to
make electrical connections or carry out any maintenance or cleaning.
Please leave this leaflet with the fan for the benefit of the user.
UK customers:
If you have any queries before or after installing this product call the Customer
Helpline [phone]. Our engineers are there to help you during normal
office hours.
Customers outside the UK should contact your local Xpelair distributor.
Xpelair Ripple Fan Range
Xpelair: A brand of the GDC Group Limited, trading as Glen Dimplex
Heating & Ventilation

2
This appliance is intended for connection to fixed wiring.
Check that the electrical rating shown on each fan matches the mains supply.
THE APPLIANCE IS DOUBLE INSULATED AND DOES NOT REQUIRE AN EARTH
CONNECTION.
All installations must be supervised by a qualified electrician. Installations and
wiring must conform to current IEE Regulations (UK), local or appropriate
regulations (other countries).
This appliance can be used by children aged
from 8 years and above and persons with
reduced physical, sensory capabilities or lack
of experience and knowledge if they have been
given supervision or instruction concerning
the use of the appliance in a safe way and
understand the hazards involved. Children
shall not play with the appliance.
Cleaning and maintenance of the appliance
shall not be made by children.
Where to locate the fan.
Locate it as high as possible.
At least 110mm from the edges of the mounting surface to the centre of the
hole.
As far away as possible from and opposite to the main source of air
replacement to ensure airflow across the room (e.g. opposite the internal
doorway).
Near the source of steam or odours.
Not where ambient temperatures are likely to exceed 50°C.
If installed in a kitchen fans must not be mounted immediately above a
cooker hob, or eye level grill.

3
If installing in a room containing a fuel burning device which has a non-
balanced flue, it is the installer's responsibility to ensure that there is
enough replacement air to prevent fumes being drawn down the flue
when the fan is operating up to maximum extract. Refer to Building
Regulations for specific requirements.
Exhaust air must not be discharged into a flue used for exhausting of
fumes from appliances supplied with energy other than electric.
Requirements of all authorities concerned must be observed for exhaust
air discharge and intake flow rates.
Not suitable for use in possible chemical corrosive atmospheres.
ØA
B
C
10/4’’
100,0
37,20
64,50

4

5
A means for disconnection in all poles must be incorporated in
the fixed wiring in accordance with wiring regulations
XR100S
XR100T
For fixed wiring circuits the protective fuse for the appliance must
not exceed 5A

6

7
Warranty
What does an Xpelair Warranty cover?
Xpelair products deliver reliable service for normal, household use in domestic
settings. All Xpelair products are individually tested before leaving the factory.
If you are a consumer and you experience a problem with your Xpelair product,
which is found to be defective due to faulty materials or workmanship within the
Warranty Period, this Xpelair Warranty will cover repair or - at the discretion of
Xpelair –replacement with a functionally equivalent Xpelair product.
The Xpelair Warranty Period is two calendar years from the date of purchase of
your Xpelair product, or the date of delivery of the product, if later. The Xpelair
Warranty is conditional upon you providing the original purchase receipt as proof
of purchase. Please therefore retain your receipt as proof of purchase.
If you do experience a problem with your Xpelair product please call the Helpline
on +44 [0]344 879 3588 or at the address below.
We will need details of your Xpelair product, and a description of the fault which
has occurred. Once we receive your information and proof of purchase we will
contact you to make the necessary arrangements.
Customers outside UK –see international below.
If your Xpelair product is not covered by this Xpelair Warranty there may be a
charge to repair your product. However, we will contact you for agreement to any
charges before any chargeable service is carried out.
What is not covered by an Xpelair Warranty?
The Xpelair Warranty does not cover any of the following:
• Any fault or damage to your Xpelair product due to faulty materials or
workmanship occurring outside the two-year Warranty Period.
• Any fault or damage occurring to any pre-owned Xpelair product or to any other
equipment or property.
• Accidental damage to your Xpelair product or damage to your Xpelair product
from external sources (for example, transit, weather, electrical outages or power
surges).

8
• Fault or damage to your Xpelair product which is:
• Not due to faulty materials or workmanship or which is due to
circumstances outside Xpelair’s control.
• Caused by use of your Xpelair product for anything other than normal
domestic household purposes in the country where it was purchased.
Important
• Caused by any misuse, abuse or negligent use of the Xpelair product, including
but not limited to any failure to use it in accordance with the Operating
Instructions supplied with the product.
• Caused by any failure to assemble, install, clean and maintain your Xpelair
product in accordance with the Operating Instructions supplied with the product
unless this was carried out by Xpelair or its authorised dealers.
• Caused by repairs or alterations to your Xpelair product not carried out by
Xpelair service personnel or its authorised dealer(s).
• Caused by use of any consumables or spare parts for your Xpelair product which
are not Xpelair specified.
Terms and Conditions
• The Xpelair Warranty is valid for Xpelair from the date of purchase of your
Xpelair product from a recognised retailer in the country of purchase and use, or
the date of delivery of the product if later, always provided the original receipt has
been retained and is produced as proof of purchase.
• You must provide to Xpelair or its authorised agents on request the original
receipt as proof of purchase and - if required by Xpelair - proof of delivery. If you
are unable to provide this documentation, you will be required to pay for any
repair work required.
• Any repair work under the Xpelair Warranty will be carried out by Xpelair or its
authorised dealer(s) and any parts that are replaced will become the property of
Xpelair. Any repairs performed under the Xpelair Warranty will not extend the
Warranty Period.

9
• Any replacement of your Xpelair product by Xpelair during the Warranty Period
will start the two-year Warranty Period afresh from the date of delivery of the
replacement Xpelair product to you.
• The Xpelair Warranty does not entitle you to recovery of any indirect or
consequential loss or damage including but not limited to loss or damage to any
other property.
• The Xpelair Warranty is in addition to your statutory rights as a consumer and
your statutory rights are not affected by this Xpelair Warranty.
Contact Xpelair
If you have any questions about what the Xpelair Warranty covers and does not
cover or how to claim under the Xpelair Warranty, please contact us using the
information below.
Contact details
Millbrook House, Grange Drive, Hedge End, Southampton, SO30 2DF
Telephone: [phone]
Email: [e-mail]
http:\\www.xpelair.co.uk
International.
Guarantee: Contact your local distributor or Xpelair direct for details.
Technical Advice and Service: Contact your local Xpelair distributor.
Xpelair: A brand of the GDC Group Limited, trading as Glen Dimplex Heating &
Ventilation
© Glen Dimplex. All rights reserved. Material contained in this publication may
not be reproduced in whole or in part, without prior permission in writing of Glen
Dimplex

10
Important
For electrical products sold within the European Community. At the end of the
electrical products useful life it should not be disposed of with household waste.
Please recycle where facilities exist. Check with a Local Authority or retailer for
recycling advice in your country. Batteries should be disposed of or recycled in
accordance with WEEE Directive 2012/19/EU. Packaging should be recycled where
possible.
Leaflet Number: 08/100030/0 Rev: 1
