Xroad MI4300 User manual

Owner’s manual for MI4300

©2008 XROAD All rights reserved. 2
When using XROAD navigation in your vehicle, it is your sole
responsibility to use the device in a manner that will not cause
accidents, personal injury or property damage, or in any manner that
may obstruct your view or interfere with operation of vehicle safety
equipment. The user of this device is sole responsible for observing
safe driving practices.
DO NOT operate XROAD while driving. Park the vehicle first and operate
when necessary.

©2008 XROAD All rights reserved. 3
Exposure to Radio frequency radiation; Antenna shall be
mounted in such a manner to minimize the potential for human contact
during normal operation. The antenna should no be contacted during
operation to avoid the possibility of exceeding the FCC radio frequency
exposure limit. The device and its antenna must not be co-located or
operating in conjunction with any other antenna or transmitter.
There’s a risk of explosion if battery is replaced by an improper
way. Disposal of used battery should follow the instruction.

©2008 XROAD All rights reserved. 4
Please don’t leave the navigation in the car when you don’t
use it for a long time. When it’s overheated by sunlight, the battery
may explode.
XROAD DISCLAIMS ALL LIABILITY FOR ANY USE OF THIS PRODUCT IN A
WAY THAT MAY CAUSE ACCIDENTS, DAMAGE, OR THAT MAY VIOLATE THE LAW.

©2008 XROAD All rights reserved. 5
FCC Information
This device complies with Part 15 of FCC Results. Operation is subject to the following two conditions:
(1) This device may not cause harmful interface, and
(2) This device must accept any interference received, including interference that may cause
undesired operation.

©2008 XROAD All rights reserved. 6
Warning
Changes or modifications not expressly approved by the manufacturer could void the user’s authority
to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for CLASS B digital device, pursuant to Part 15 of FCC Rules. These
limits are designed to provide reasonable protection against harmful interference when the equipment is operated in commercial environment.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try contact the interference by one or more of the following measures:
1.1. Reorient or relocate the receiving antenna.
1.2. Increase the separation between the equipment and receiver.
1.3. Connect the equipment into an outlet on a circuit different from that to which receiver is connected.
1.4. Consult the dealter or experienced radio/TV technician for help.

©2008 XROAD All rights reserved. 7
1. Introduction
This handbook is aimed to provide a quick guide to the XROAD’s basic features and
functions in respect to the unit hardware.
For Instructions on how to use the Navigation Software, please check out the Navigation
Owners Manual which can also be found on this CD.
No liability shall be assumed for technical or editorial errors or omissions herein; nor for
incidental or consequential damages resulting from the performance or use of this material.
This document contains information protected by copyright and may not be reproduced in
whole or in part for any purpose whatsoever. Likewise, it may not be transmitted or
reproduced in any form whatsoever, whether electronically or mechanically - including
photocopying and recording.
All brands and trademarks mentioned in this document may be registered by a third party
and subject to current legislation and to the rights of their respective owners, without
reservation. The absence of explicit labelling of registered trademarks does not admit the
conclusion that the brand is not subject to the rights of third parties.

©2008 XROAD All rights reserved. 8
2. Important Tips and Warnings
2.1 General
a) Effective route planning prior to beginning each journey is highly recommended.
If you need to setup o change your itinerary while on route, please ensure the
vehicle is stopped. For your own safety and for others, please DO NOT
OPERATE THIS UNIT WHILE DRIVING.
b) The Navigation feature is intended to be used only as an aid, not as a precise
measurement of direction, distance, location or topography. Because calculated
routes and voice guidance are for reference only and may be different from the
actual road circumstances, it is the user’s responsibility to follow traffic signs,
speed limits, road layout and local regulations at all times.
c) When you leave your vehicle, please do not leave your unit on the dashboard in
direct sunlight. This may cause the battery to overheat and malfunction. (It also
may get stolen) Use the product within the recommended operational

©2008 XROAD All rights reserved. 9
temperature range (0’C ~ 55’C), and avoid exposing the unit to excessive heat
or cold temperatures.
d) GPS satellite signals cannot pass through solid materials other than glass. So
when you are inside a tunnel or a building, the GPS positioning may not be
available. (Signal will be lost) Signal (GPS) reception can also be affected by
situations such as bad weather or dense overhead cover such as trees and
buildings. Wireless units may also interfere with satellite signals, causing
variable and inaccurate GPS reception.
e) While you are driving, please ensure that you only look at the display when it’s
safe to do so.

©2008 XROAD All rights reserved. 10
2. Important Tips and Warnings
f) The mounting bracket is necessary when using the unit in a car and we strongly
recommended that you mount the unit in an appropriate place so it doesn’t
obstruct your view, airbag panels and instrumentation.
g) By taking good care of your unit, you will ensure trouble-free operation and you
will reduce the risk of damaging the unit. When cleaning the unit, please ensure
that you never clean it with the power on. Use a soft, lint-free cloth moistened
with water when cleaning the screen and the exterior of your unit. Do not use
paper towels or tissues to clean the screen. Do not rest or place anything on top
of your unit. Do not drop your unit.
h) Keep your unit away from excessive moisture and extreme temperatures. Do not
subject your unit to sudden and severe temperature changes that could cause
condensation inside the unit as this will damage the unit. In the event of moisture
condensation, allow your unit to dry out completely. Avoid exposing your
unit to direct sunlight or strong ultraviolet light for extended periods of time.

©2008 XROAD All rights reserved. 11
2. Important Tips and Warnings
2.2 Safety Precaution
Main System
Never attempt to disassemble, repair or make any modification to your unit as you
may damage the unit and could harm yourself. Do not store or carry flammable
liquids, gases or explosive materials in the same compartment as your unit and / or
its parts and accessories.
Backup Battery
This unit contains a non-replaceable Lithium-Polymer internal battery that can burst
or explode and can release hazardous chemicals if damage. To reduce the danger
of fire or burns, never disassemble, crush, puncture, or dispose of the unit in fire or
water. Since there is a high risk of explosion if the battery is replaced by an incorrect
type, the battery must only be replaced by an authorized XROAD service agent.
(Please contact XROAD for further information regarding battery replacement) You
must use the specified battery charger as approved by the manufacturer.

©2008 XROAD All rights reserved. 12
AC Adapter (optional)
Never use the AC adapter in a high-moisture environment, or touch the charger if
you have wet hands or feet. Also, for cooling purposes, please ensure there is
adequate ventilation around the adapter when in use. The AC Adaptor must never
be covered up it with paper, vinyl, cloth (including the carrying case) or any other
material while in use. The adapter must be connected to the correct power source,
according to the voltage requirements indicated on the case or packaging of the
product. Do not attempt to service or repair this adaptor if it becomes damaged or
exposed to excess moisture.
SD Memory Card(optional)
Keep the SD card in a well-protected case and avoid dust and humidity when you
are not using it.

©2008 XROAD All rights reserved. 13
3. Hardware Accessories
3.1 Standard Accessories
Quick start guide
CD containing SW and manuals
Cigar lighter DC power cable
Cradle & Suction mount

©2008 XROAD All rights reserved. 14
4. Getting it Started
4.1 Attaching to the suction mount
Assemble the cradle with the mount and attach the unit to the cradle as the picture
below.
Please do not set up the mount while driving for your safety.

©2008 XROAD All rights reserved. 15
4.2 Power On/Off
Power On: Push the power button
Power Off: Press and hold the power button in 2 seconds.
Reset: Press and hold the power button in 5 seconds.

©2008 XROAD All rights reserved. 16
5. Specification of MI4300
MODEL NAME MI4300
Dimension (main unit) 132.0(mm)x 83.0(mm) x 19.5(mm)
Dimensions
Weight (main unit) 190g
Operational temperature range 0Ȕ~ 55Ȕ
Operatiing conditions
Storage temperature range -10Ȕ~ 70Ȕ
Main CPU CPU Centrality AtlasIII-396Mhz
Operating System OS Microsoft Windows CE 5.0

©2008 XROAD All rights reserved. 17
Memory Flash Memory (including Map
data)
4GB

DRAM 128MB
Display Outline dimension & drive
system
4.3" TFT active matrix system with touch
panel

LCD resolution 480H×272V×RGB (WQVGA)

LCD Color depth 24bit color (16.7M)

Back lighting White LED , 400(min), 500(typ) cd/m2
(without touch panel)
Positioning method High-sensitivity GPS receiver
GPS
Receiving frequency 1575.42MHz (C/A code )

©2008 XROAD All rights reserved. 18
Coldヲ< 60seconds (Average)
Warmヲ<45 seconds (Average)
Acquisition times update rate
(Open Sky)
Hotヲ<15 seconds (Average)
Update rate 1/second, continuous
Accuracy Position : < 10meters, typical
Positioning method GPS, WAAS(US), EGNOS(EU)
Antenna Built-in Patch antenna

Socket for external antenna
TMC Tuner Built-in : SiLabs

©2008 XROAD All rights reserved. 19
Channel selection system PLL frequency synthesizer system
Frequency range 87.5MHz㇊108.0MHz (50KHz step)
Sensitivity (RDS) 25dBuV max
Seek stop level 25dBuV max
Image rejection 35dB min
STD Condition
98.1MHz 64dBuV fmod
57kHz
I/F rejection 80dB min
Changeability range of
brightness
40 to 100%
Auto dimmer chattering
reduction
3 sec
Light Sensor for
backlight control
Dimmer speed 1.5%/10ms

©2008 XROAD All rights reserved. 20
Sensor porting cycle 20msec
SD Card Standard SDHC upto 8GB / MMC2.0
USB I/F USB 2.0 Slave full speed
Headphone 820mVp-p / 32 Ohms Stereo mini jack
Microphone Built-in : -40±1.5 dB
Speaker 1.4W @Max
fo=730Hz±15%
Bluetooth Bluetooth Ver.2.0+EDR
I/O
+4.0/+1.0dBm(Max/Typ) Power Class 2
Rechargeable battery Battery type & capacity Li-polymer, 1150mAh (Typical)

Battery life (navigation mode) Up to 3 hours
