Xroad V4050 User manual

V
V4 40 05 50 0O Ow wn ne er r’ ’s s
M
Ma an nu ua al l

Thank you for choosing the XROAD V4050 Navigation system.
This model includes:
94.3” Wide[16:9] TFT Touch Screen LCD with Ultra-bright 480x272 resolution in 16.7 million colors
9400MHz Samsung CPU to ensure powerful performance
9Built-in Bluetooth Hands-Free Calling
9Premium multimedia functions supporting music (MP3), video (AVI), picture (JPEG) and game
9Internal Enhanced GPS receiver (SIRFIII / SIRFstarIII) for a quick start
9Powerful Lithium-Polymer 2100mAH Battery
9Microsoft WinCE Core Version 5.0
92.0 GB SD card preloaded with U.S. and Canada map data
XROAD DISCLAIMS ALL
LIABILITY FOR ANY USE
OF THIS PRODUCT IN A
WAY THAT MAY CAUSE
ACCIDENTS, DAMAGE,
OR THAT MAY VIOLATE
THE LAW
WARNING: DANGER OF ACCIDEN
T
When you use XROAD navigation in your vehicle, it is your
sole responsibility to use the device in a manner that will
not cause accidents, personal injury or property damage,
and not obstruct your view or interfere with operation of
vehicle safety equipment. The user of this product is solely
responsible for observing safe driving practices. DO NOT
operate XROAD V4050 while driving. Park the vehicle first
and operate when necessary.

1. About This Book
This handbook provides a quick guide to the XROAD NAVIGATION system, and the basic functions
of the device are described mainly in respect of hardware. For reasons of product development some
information may not be updated yet, and contents may be changed at any time without prior
notification. No liability shall be assumed for technical or editorial errors or omissions herein; nor for
incidental or consequential damages resulting from the performance or use of this material.
This document contains information protected by copyright and thus may not be reproduced in whole
or in part for any purpose whatsoever. Likewise, it may not be transmitted or reproduced in any form
whatsoever, whether electronically or mechanically - including photocopying and recording.
All brands and trademarks mentioned in this document may be registered by a third party and subject
to current legislation and to the rights of their respective owners, without reservation. The absence of
explicit labeling of registered trademarks does not admit the conclusion that the brand is not subject to
the rights of third parties.
© Copyright 2007, XROAD. All rights reserved.

Page_02
02. For Proper/Best Use
2.1 General
ཿEffective route planning prior to the beginning of each journey is recommended. If you need to setup a
new itinerary while en route, please drive to a safe place or a parking site first. For your own safety, do not
operate the product while driving.
ྀThe product is intended to be used only as a navigation aid, not as a precise measurement of
direction, distance, location or topography. Because calculated routes and voice guidance are for
reference only and may be different from the actual road circumstances, it is the user’s responsibility to
follow traffic signs, road layout and local regulations above all else.
ཱྀWhen you get out of the car, please do not leave your device on the dashboard in direct sunlight,
since an overheated battery can cause malfunction and/or hazard. Use the product within the
recommended operational temperature range (0’C ~ 50’C), and do not expose it to excess heat or cold.
ྂGPS satellite signals cannot pass through solid materials other than glass. So when you are inside a
tunnel or a building or in case of metallic windshield, GPS positioning may not be available. Likewise,
signal reception can be affected by situations such as bad weather or dense overhead cover such as trees.
Similarly, wireless devices may interfere with satellite signals, causing variable signal reception.
ྃLook at the display only when it is absolutely safe to do so. If you have not fully understood the
instructions given by the device, or if you are not sure about what to do next, you may refer briefly
to the map or arrow view of your navigation system.

02. For Proper/Best Use Page_03
2.1 General
ཆA car holder is necessary when using the device in a car, and it is strongly recommended that you
place the device in an appropriate place, avoiding areas for example which obstruct airbag panels and
instruments, or which interfere with the driver’s vision.
ཇTaking good care of your device will ensure trouble-free operation and reduce the risk of damage to
it. Never clean your device with the power on. Use a soft, lint-free cloth moistened with water to wipe the
screen and the exterior of your device. Do not use paper towels to clean the screen. Do not place anything
on top of your device or drop objects on top of it. Do not drop your device or subject it to severe shock. Be
careful not to sit on your device when it is in the back pocket of your trousers, etc. The screen surface is
easily scratched.
཈Keep your device away from excessive moisture and extreme temperatures. Do not subject your
device to sudden and severe temperature changes that could cause condensation inside the unit, with
consequent damage. In the event of moisture condensation, allow your device to dry out completely.
Avoid exposing your device to direct sunlight or strong ultraviolet light for extended periods of time.

Page_04
02. For Proper/Best Use
2.2 Safety Precaution
ཿMain System
Never attempt to disassemble, repair or make any modification to your device since this could
cause damage to the device, and even bodily injury or property damage. Do not store or carry flammable
liquids, gases or explosive materials in the same compartment as your device and its parts or
accessories.
ྀBattery
This device contains a non-replaceable Lithium-Polymer internal battery that can burst or explode, releasing
hazardous chemicals. To reduce the danger of fire or burns, never disassemble, crush, puncture, or
dispose of in fire or water. Since there is a high risk of explosion if the battery is replaced by an
incorrect type, replace it only with same type or an equivalent one recommended by the manufacturer.
The battery must be recycled or disposed of properly. Similarly, use a specified battery charger as
approved by the manufacturer.
ཱྀAdapter
Never use the AC adapter in a high-moisture environment, or touch it when your hands/feet are wet.
Also, for cooling purposes, make sure there is adequate ventilation around the adapter when in use, and do
not cover it with paper, vinyl, cloth (including the carrying case) or any other material. The adapter
must be connected to the correct power source, according to the voltage requirements indicated on the
case or packaging of the product. Do not attempt to service the unit if its power lead or body becomes
damaged or exposed to excess moisture.
ྂSD Memory Card
Keep SD or MMC cards in a well-protected case so as to avoid dust and humidity when you are not
using it, and also make sure that no foreign objects can enter the SD slot.

3. Getting It Started Page_05
Your device has an SD slot, for an optional Secure Digital card storing the initial
startup program, digital maps and other data i.e. MP3 files, movie files and
image files. To use the memory card, insert it pointing up into the slot, and the
label facing the front of the device. To remove the card, first make sure that no
application is accessing it, slightly push the top of the card to release it, and then
pull it out of the slot. To take out the card, please turn off the unit. Before
inserting another card, please press on the Power button. When you put SD Card
into SD Slot located at the bottom of the device, please give a deep and hard
push, which works for taking it out of the slot as well.
3.1 Inserting SD Card
WARNING: To avoid personal injury, or accidents, DO NOT install or remove the XROAD
V4050 from the windshield suction mount while driving your vehicle. Also, be careful not
to install the XROAD V4050 in a position to obstruct the view of the driver.
3.2 Mounting & Connecting
2. Slide the rectangular part 3. Insert the jack at the end of
1. First, clean the windshield.
of the suction-cup mount the DC power leading into the
small socket on the side of device
and put the other end into the
cigar lighter socket.
Then, push the center of the
into the corresponding part
suction cup onto the wind-
at the bottom rear of the unit
shield and then press the
fixing lever down

3. Gettin
g
It Started Page_06
3.3. Power Manipulation
Power On Press the Power On/Off button to turn on the device. In case of the first use
of the device that is discharged, connect the power into the unit through the
car cigarette power jack or AC adaptor, then press Power On/Off button.
Power Off Press the Power On/Off button to turn off the device. If the device remains
connected to a 12V power jack, the battery will be charged.
Bluetooth
Button
Press the Bluetooth On/Off button to launch the Bluetooth system
WARNING: the battery is still running and discharging in all modes, except Power Off mode.
* Please allow this delicate gadget to have enough time for its operation (e.g. in pressing buttons,
tapping touch screen, executing each menu, pushing in/out SD card etc.) since running it too hastily
and excessively often leads to mechanical trouble.

5. Hardware Accessories Page_07
5.1 Standard Accessories 5.2 Optional Accessories
Note: the brand, type, spec, and photo of above accessories may vary with actual accessories. Also, accessories packaging items may be changed without prior notice.
ྜྷ
ྙྙྚ
ྜ
ྙAC Adaptor
TMC External Antennaྚ
External GPS Antennaྛ
SD Card Readerྜ
ྚ
ྛྜ
ྛ
ྞ
ྙDVD with manuals & map data Cigarྜ-light adaptor
QuickྚStart Guide ྜྷSD memory card
ྛ
Windshield Suction Moun
t
& Cradle Stylus pen
ྞ

6. A Look at the Home Screen
Page_10
6.1 Overview
ཁFin
g
er Touch: This navi
g
ation instrument can easily be operated with your fin
g
ertip. However, if the
vehicle is moving too much, or if you want to select a point with great accuracy, you will need to use the
stylus pen. The surface of the LCD screen may be damaged if a sharp object is used, or if excessive
pressure is used on the screen.
གSD memory card provided: If the map file is deleted, the navigation function does not perform properly.
གྷMultitasking: This function is used to perform multitasking (for example, navigation plus audio
playback). However, this feature is NOT provided with the V4050 product. Once you pressed M button on
the top left of the navigation, you may switch to main menu, but all other icons will be grayed out and will
not function when you tap on it.
